UICollectionView (仿系统相册,按日期分区 item瀑布流)

原创 2015年11月19日 18:04:34


#import "PhotoManageCell.h"
#import "footView.h"

@interface ViewController : UIViewController<UICollectionViewDataSource,UICollectionViewDelegate,PhotoManageCellEditDelegate,PhotoManageCellSelectedDelegate>

@property(nonatomic,retain) footView *footer_View;

@end

static NSString *CellIdentifier = @"Cell";
@interface ViewController (){
    NSMutableArray *listAry;
    UICollectionView *collection_View;
    UIButton *deleteBtn;
    NSMutableArray *imgIdAry;
}

@end

@implementation ViewController

- (void)viewDidLoad {
    [super viewDidLoad];
    [self modelListAry];
    [self buildCollectionView];
    // Do any additional setup after loading the view, typically from a nib.
}

-(void)modelListAry
{
    NSArray *ary1 = [NSArray arrayWithObjects:@"5",@"4",@"3",@"2",@"1", nil];
    NSArray *ary2 = [NSArray arrayWithObjects:@"4",@"3",@"2",@"1", nil];
    NSArray *ary3 = [NSArray arrayWithObjects:@"3",@"2",@"1", nil];
    NSArray *ary4 = [NSArray arrayWithObjects:@"2",@"1", nil];
    NSArray *ary5 = [NSArray arrayWithObjects:@"1", nil];

    NSDictionary *dic1 = [NSDictionary dictionaryWithObjectsAndKeys:ary1,@"value",@"2015820",@"index",nil];
    NSDictionary *dic2 = [NSDictionary dictionaryWithObjectsAndKeys:ary5,@"value",@"2015810",@"index",nil];
    NSDictionary *dic3 = [NSDictionary dictionaryWithObjectsAndKeys:ary4,@"value",@"2015828",@"index",nil];
    NSDictionary *dic4 = [NSDictionary dictionaryWithObjectsAndKeys:ary3,@"value",@"2015824",@"index",nil];
    NSDictionary *dic5 = [NSDictionary dictionaryWithObjectsAndKeys:ary2,@"value",@"2015805",@"index",nil];
    listAry = [NSMutableArray arrayWithObjects:dic1,dic2,dic3,dic4,dic5, nil];

    //数组排序
    NSArray *sortDescriptors = [NSArray arrayWithObject:[NSSortDescriptor sortDescriptorWithKey:@"index" ascending:YES]];
    [listAry sortUsingDescriptors:sortDescriptors];
}

-(void)buildCollectionView
{

    if (!collection_View)
    {
        __weak ViewController *photoManageVC = self;
        collection_View = [self createCollectionView];
        collection_View.backgroundColor = [UIColor lightGrayColor];
        [self.view addSubview:collection_View];
        collection_View.autoresizingMask = UIViewAutoresizingFlexibleWidth|UIViewAutoresizingFlexibleHeight;
    }
    else
    {
        [collection_View reloadData];
    }
}


-(UICollectionView *)createCollectionView
{

    UICollectionViewFlowLayout *layout = [[UICollectionViewFlowLayout alloc] init];
    float cellWidth=(self.view.bounds.size.width-30)/3;
    float cellHeight=100;
    //计算每页多少个,设置为2页的个数
    [layout setItemSize:CGSizeMake(cellWidth, cellHeight)];
    //设置其布局方向 垂直显示
    [layout setScrollDirection:UICollectionViewScrollDirectionVertical];
    layout.sectionInset = UIEdgeInsetsMake(10,10,10,10);
    layout.minimumLineSpacing = 5;
    layout.minimumInteritemSpacing = 5;

    UICollectionView *collectionView=[[UICollectionView alloc] initWithFrame:CGRectMake(0,64,CGRectGetWidth(self.view.frame),self.view.frame.size.height-64) collectionViewLayout:layout];
    collectionView.dataSource=self;
    collectionView.delegate=self;
    collectionView.backgroundColor = [UIColor clearColor];
    collectionView.alwaysBounceVertical = YES;
    [collectionView registerClass:[PhotoManageCell class] forCellWithReuseIdentifier:CellIdentifier];

    layout.headerReferenceSize = CGSizeMake(self.view.frame.size.width-20, 40.0f);
    [collectionView registerClass:[footView class] forSupplementaryViewOfKind:UICollectionElementKindSectionHeader withReuseIdentifier:@"foot"];

    return collectionView;
}


- (NSInteger)collectionView:(UICollectionView *)collectionView numberOfItemsInSection:(NSInteger)section
{
    return [[[listAry objectAtIndex:section] objectForKey:@"value"] count];
}

//定义展示的Section的个数
-(NSInteger)numberOfSectionsInCollectionView:(UICollectionView *)collectionView
{
    return [listAry count];
}
//每个UICollectionView展示的内容
-(UICollectionViewCell *)collectionView:(UICollectionView *)collectionView cellForItemAtIndexPath:(NSIndexPath *)indexPath
{

    PhotoManageCell *cell= [collectionView dequeueReusableCellWithReuseIdentifier:CellIdentifier forIndexPath:indexPath];
    cell.editDelegate = self;
    cell.selectedDelegate = self;
    if (cell==nil) {
        cell = [[PhotoManageCell alloc]init];
    }
    NSArray *ary = [[listAry objectAtIndex:indexPath.section] objectForKey:@"value"];
    [cell setInfoData:ary index:indexPath.item];

    return cell;
}

-(void)collectionView:(UICollectionView *)collectionView didSelectItemAtIndexPath:(NSIndexPath *)indexPath
{

    NSDictionary *indexDic = [listAry objectAtIndex:indexPath.item];

    //选取图片
//    if ([self.selectedImgDelegate respondsToSelector:@selector(didSelectedImgBack:imageURl:imageId:)])
//    {
//        NSURL *smallImgUrl = [NSURL URLWithString:[indexDic objectForKey:@"imgSrc"]];
//        NSString *imageId = [indexDic objectForKey:@"imgId"];
//        [self.selectedImgDelegate didSelectedImgBack:self imageURl:smallImgUrl imageId:imageId];
//        return;
//    }
//
//    //进入预览大图
//    NSURL *bigImgUrl = [NSURL URLWithString:[indexDic objectForKey:@"imgSrc"]];
//    BigImageViewController *bigImgVC = [[BigImageViewController alloc]init];
//    bigImgVC.imageUrl = bigImgUrl;
//
//    [self presentViewController:bigImgVC animated:YES completion:^{}];

}


-(UICollectionReusableView *)collectionView:(UICollectionView *)collectionView viewForSupplementaryElementOfKind:(NSString *)kind atIndexPath:(NSIndexPath *)indexPath
{


    if (kind == UICollectionElementKindSectionHeader) {
        self.footer_View = [collectionView dequeueReusableSupplementaryViewOfKind:kind withReuseIdentifier:@"foot" forIndexPath:indexPath];
        [self.footer_View setInfoData:[listAry objectAtIndex:indexPath.section]  index:indexPath.item];

        return self.footer_View;

    }
    return 0;
}


@protocol PhotoManageCellEditDelegate <NSObject>
@optional
-(void)editCellBegin:(NSUInteger)object;

@end

@protocol PhotoManageCellSelectedDelegate <NSObject>
@optional
-(void)selectedCell:(UIButton*)button index:(NSUInteger)index;

@end

@interface PhotoManageCell : UICollectionViewCell<UIGestureRecognizerDelegate>{
    UILongPressGestureRecognizer *longPress;
}

@property(nonatomic,retain)UIImageView *productImg;
@property(nonatomic,retain)UIButton *selBtn;
@property(nonatomic,assign) id<PhotoManageCellEditDelegate> editDelegate;
@property(nonatomic,assign) id<PhotoManageCellSelectedDelegate> selectedDelegate;

-(void)setInfoData:(id)data index:(NSUInteger)index;

@end

#define k_LongTapTime 0.6f
#define btn_tag 40000
#import "PhotoManageCell.h"
#import "UIImageView+WebCache.h"
@implementation PhotoManageCell


-(instancetype)initWithFrame:(CGRect)frame
{
    if (self==[super initWithFrame:frame]){

        self.backgroundColor = [UIColor clearColor];
        longPress = [[UILongPressGestureRecognizer alloc]initWithTarget:self action:@selector(beginEdit:)];
        longPress.minimumPressDuration = k_LongTapTime;
        longPress.delegate = self;
        [self addGestureRecognizer:longPress];

        self.productImg = [[UIImageView alloc]init];
        self.productImg.backgroundColor = [UIColor redColor];
        [self addSubview:self.productImg];

        self.selBtn = [[UIButton alloc]init];
        [self.selBtn setBackgroundImage:[UIImage imageNamed:@""] forState:UIControlStateNormal];
        [self.selBtn setBackgroundImage:[UIImage imageNamed:@"selectBtn"] forState:UIControlStateSelected];
        [self.selBtn addTarget:self action:@selector(selectedItem:) forControlEvents:UIControlEventTouchUpInside];
        [self addSubview:self.selBtn];


    }
    return self;
}

-(void)selectedItem:(UIButton*)button
{
    button.selected = !button.selected;
    if (self.selectedDelegate)
    {
        [self.selectedDelegate selectedCell:button index:button.tag-btn_tag];
    }
}

-(void)beginEdit:(UILongPressGestureRecognizer*)longPressGes
{
    if (longPressGes.state == UIGestureRecognizerStateBegan)
    {
        NSLog(@"开始编辑可选");
        if (self.editDelegate)
        {
            [self.editDelegate editCellBegin:longPress.view.tag];
        }
    }
    if (longPressGes.state == UIGestureRecognizerStateEnded)
    {
        NSLog(@"结束");
    }
}

/*
 "imgId":"", //图片ID
	"imgSmall":"",  //小图,
	"imgBig":"",   //大图
	"imgSrc":""	//原图
 */
-(void)setInfoData:(id)data index:(NSUInteger)index
{
//    [self.productImg sd_setImageWithURL:[data objectForKey:@"imgSmall"]  placeholderImage:[UIImage imageNamed:@"productimg"] options:SDWebImageRetryFailed|SDWebImageLowPriority];

//    self.selBtn.selected = [[data objectForKey:@"isSelected"] boolValue];
    [self.selBtn setTitle:[data objectAtIndex:index] forState:UIControlStateNormal];
    [self.selBtn setTitleColor:[UIColor blackColor] forState:UIControlStateNormal];
//    self.selBtn.userInteractionEnabled = [[data objectForKey:@"isEnable"] boolValue];
    self.selBtn.tag = btn_tag+index;
    self.tag = index;
}



-(void)layoutSubviews
{
    [super layoutSubviews];

    float cell_width = CGRectGetWidth(self.frame);
    float cell_height = CGRectGetHeight(self.frame);

    self.productImg.frame = CGRectMake(0, 0, cell_width, cell_height);
    self.selBtn.frame = CGRectMake(0, 0, cell_width, cell_height);


}

@interface footView : UICollectionReusableView{

}

@property(nonatomic,assign) BOOL hasMoreData;
@property(nonatomic,retain) UILabel *lbl;

-(void)setInfoData:(id)data index:(NSUInteger)index;

@end

#import "footView.h"
@implementation footView

-(instancetype)initWithFrame:(CGRect)frame
{
    if (self=[super initWithFrame:frame])
    {
        self.backgroundColor = [UIColor blueColor];
        self.lbl = [[UILabel alloc]init];
        self.lbl.textColor = [UIColor blackColor];

        [self addSubview:self.lbl];
    }
    return self;
}

-(void)setInfoData:(id)data index:(NSUInteger)index;
{
    self.lbl.text = [data objectForKey:@"index"];
    self.lbl.tag = index;
}

-(void)setHasMoreData:(BOOL)hasMoreData
{


}


-(void)layoutSubviews
{
    [super layoutSubviews];
    self.lbl.frame = CGRectMake(0, 0, CGRectGetWidth(self.frame), CGRectGetHeight(self.frame));
}

@end






版权声明:本文为博主原创文章,未经博主允许不得转载。
