Android4.0（Phone）拨号启动过程分析（三）与Framework层通信

        由于Android几乎所有的代码都是公开的，如果要对Framework层分析就必需先拿到Framework层的代码，我在前面已经搭建好了ubuntu14.04的环境，下载好了Android4.0的源码，其中也包括了Framework层和Package的代码，导出到宿主机Windows XP中用Source Insight 3.5工具来查看源码，Package中的代码可以导入到Eclipse下查看，我是把frameworks\base整个目录都导入到Source Insight 3.5工程中，可以选择我们需要的目录导入，如frameworks\base\media\tests\contents\media_api目录下有很多音、视频文件，可以只导入frameworks\base\core、frameworks\base\telephony、frameworks\base\services、frameworks\base\include等目录。需要代码的可以到这下载：http://pan.baidu.com/s/1i3KczeX在PhoneApp初始化时，有以下代码

@Override
public void onCreate() {
	//...........
	if (phone == null) {
		// 初始化phone frameworks层
			PhoneFactory.makeDefaultPhones(this);

			// 获取默认的phone对象
			phone = PhoneFactory.getDefaultPhone();

			mCM = CallManager.getInstance();
			mCM.registerPhone(phone);
		//.............
	}
	//...............
}

在应用层的PhoneApp中调用PhoneFactory的静态方法makeDefaultPhones创建一个默认的Phone对象，而framework中采用的是代理模式和工厂模式实现，在makedefaultPhone中

 //***** Class Methods

    public static void makeDefaultPhones(Context context) {
        makeDefaultPhone(context);
    }

    /**
     * FIXME replace this with some other way of making these
     * instances
     */
    public static void makeDefaultPhone(Context context) {
        synchronized(Phone.class) {
            if (!sMadeDefaults) {
                sLooper = Looper.myLooper();
                sContext = context;

                if (sLooper == null) {
                    throw new RuntimeException(
                        "PhoneFactory.makeDefaultPhone must be called from Looper thread");
                }

                int retryCount = 0;
                for(;;) {
                    boolean hasException = false;
                    retryCount ++;

                    try {
                        // use UNIX domain socket to
                        // prevent subsequent initialization
                        new LocalServerSocket("com.android.internal.telephony");
                    } catch (java.io.IOException ex) {
                        hasException = true;
                    }

                    if ( !hasException ) {
                        break;
                    } else if (retryCount > SOCKET_OPEN_MAX_RETRY) {
                        throw new RuntimeException("PhoneFactory probably already running");
                    } else {
                        try {
                            Thread.sleep(SOCKET_OPEN_RETRY_MILLIS);
                        } catch (InterruptedException er) {
                        }
                    }
                }

                sPhoneNotifier = new DefaultPhoneNotifier();

                // Get preferred network mode
                int preferredNetworkMode = RILConstants.PREFERRED_NETWORK_MODE;
                if (BaseCommands.getLteOnCdmaModeStatic() == Phone.LTE_ON_CDMA_TRUE) {
                    preferredNetworkMode = Phone.NT_MODE_GLOBAL;
                }
                int networkMode = Settings.Secure.getInt(context.getContentResolver(),
                        Settings.Secure.PREFERRED_NETWORK_MODE, preferredNetworkMode);
                Log.i(LOG_TAG, "Network Mode set to " + Integer.toString(networkMode));

                // Get cdmaSubscription
                // TODO: Change when the ril will provides a way to know at runtime
                //       the configuration, bug 4202572. And the ril issues the
                //       RIL_UNSOL_CDMA_SUBSCRIPTION_SOURCE_CHANGED, bug 4295439.
                int cdmaSubscription;
                int lteOnCdma = BaseCommands.getLteOnCdmaModeStatic();
                switch (lteOnCdma) {
                    case Phone.LTE_ON_CDMA_FALSE:
                        cdmaSubscription = RILConstants.SUBSCRIPTION_FROM_NV;
                        Log.i(LOG_TAG, "lteOnCdma is 0 use SUBSCRIPTION_FROM_NV");
                        break;
                    case Phone.LTE_ON_CDMA_TRUE:
                        cdmaSubscription = RILConstants.SUBSCRIPTION_FROM_RUIM;
                        Log.i(LOG_TAG, "lteOnCdma is 1 use SUBSCRIPTION_FROM_RUIM");
                        break;
                    case Phone.LTE_ON_CDMA_UNKNOWN:
                    default:
                        //Get cdmaSubscription mode from Settings.System
                        cdmaSubscription = Settings.Secure.getInt(context.getContentResolver(),
                                Settings.Secure.PREFERRED_CDMA_SUBSCRIPTION,
                                preferredCdmaSubscription);
