手把手教你如何将图片“嵌入”网页中

原创 2017年01月03日 23:36:49

网页必不可少的组成元素是什么?我想所有人都知道是文字和图片。

那么如何向网页中添加图片?会HTMLCSS的同学肯定知道,利用<img>标签插入图片,为src属性指定图片的相对路径,然后将图片放置到那个路径上去就可以了,例如下面的这个简单的HTML代码:

<!DOCTYPEhtml PUBLIC "-//W3C//DTD HTML 4.01//EN" "http://www.w3.org/TR/html4/strict.dtd">

<html>

   <head>

       <meta http-equiv="Content-Type" content="text/html;charset=utf-8">

        <title> HTML内嵌图片教程</title>

   </head>

   <body>

       <img src="sea.png" width="800px"height="510px" alt="sea" />

   </body>

</html>

再加上一张好看的图片(sea.png):

手把手教你如何将图片“嵌入”网页中 - 远行的风 - 风的驿站

话不多说,下面我们来介绍如何将图片“嵌入”到HTML代码中,这样我们就不需要拷贝图片到指定路径下了,显示整张图片就只需要一个页面文件就可以了。

我们简单说下原理,我们知道,所有东西归根结底都是数据,图片也不例外,图片文件实际是由图片文件头,信息头(有的格式没有),图片数据,图片结束标识(有的格式没有)这些部分组成,在浏览器解析文件的时候,先到src指定的路径下将图片文件读取出来,然后按照图片头定义的文件压缩格式,对图片数据进行读取显示。所以我们可以直接将图片的内容进行编码然后存入HTML文件中即可。

HTML中支持base64编码的数据直接嵌入到网页中,这里提供一个网址,可以在线将文件内容转换为base64编码的数据,点击“choosefile”,然后点击“convertthe source data”,即可生成文件的base64编码数据。网址如下:

http://www.motobit.com/util/base64-decoder-encoder.asp



当然我们也可以手动编写一个小工具进行转码,C语言实现的base64编码方法如下:

char*base64_encode(char* in_str)

{

   int i=0;

   charbase64_table[]="ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789+/";

   int curr_out=0;

   if(in_len>0)

   {

       while(i<in_len)

       {

           char a=in_str[i];

           char b=i+1>=in_len?0:in_str[i+1];

           char c=i+2>=in_len?0:in_str[i+2];

           if(i+2<in_len)          /*0*/

           {

               out_str[curr_out++]=base64_table[(a>>2)&(0x3f)];        //the first

               out_str[curr_out++]=base64_table[((a&0x03)<<4)+(b>>4)];   //the first and the second

               out_str[curr_out++]=base64_table[((b&0x0f)<<2)+(c>>6)];   //the second and the third

               out_str[curr_out++]=base64_table[c&0x3f];          //the third

           }

           else if(i+1<in_len)      /*2*/

           {

               out_str[curr_out++]=base64_table[(a>>2)&(0x3f)];   //thefirst

               out_str[curr_out++]=base64_table[((a&0x03)<<4)+(b>>4)]; //the first and the second

               out_str[curr_out++]=base64_table[(b&0x0f)<<2];    //the last low 4 bits of the second

               out_str[curr_out++]='=';   //fill with the '='

           }

           else                         /*1*/

           {

               out_str[curr_out++]=base64_table[(a>>2)&(0x3f)];  //the first

               out_str[curr_out++]=base64_table[(a&(0x03))<<4];  //the rest ofof the first

               out_str[curr_out++]='=';    //fill with  '=' in the lasttwo bits

               out_str[curr_out++]='=';

           }

           i+=3;

       }

       out_str[curr_out]='\0';

   }

   return out_str;

};

调用时将文件内容读入char*,然后作为函数参数传入,函数的返回值即为编码后的结果。

这里我们将限于篇幅,将图像缩小为30像素×18像素后,得到的编码如下(仍然很多):

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



然后,我们修改之前的HTML页面中的img标签如下:


然后保存,测试一下结果,发现图片已经嵌入到页面中了:

手把手教你如何将图片“嵌入”网页中 - 远行的风 - 风的驿站

以上就是嵌入图片的方法,我们看到,其实就是将图片的数据嵌入到了页面中,使用这种方法会显著增加HTML文件的大小,如果不是非常小的图片或者十分有必要这么做的情况下,我们尽量不要使用这种方式。


123application/vnd.lotus-1-2-3

3gpvideo/3gpp

aabapplication/x-authoware-bin

aamapplication/x-authoware-map

aasapplication/x-authoware-seg

aiapplication/postscript

aifaudio/x-aiff

aifcaudio/x-aiff

aiffaudio/x-aiff

alsaudio/X-Alpha5

amcapplication/x-mpeg

aniapplication/octet-stream

asctext/plain

asdapplication/astound

asfvideo/x-ms-asf

asnapplication/astound

aspapplication/x-asap

asxvideo/x-ms-asf

auaudio/basic

avbapplication/octet-stream

avivideo/x-msvideo

awbaudio/amr-wb

bcpioapplication/x-bcpio

binapplication/octet-stream

bldapplication/bld

bld2application/bld2

bmpapplication/x-MS-bmp

bpkapplication/octet-stream

bz2application/x-bzip2

calimage/x-cals

ccnapplication/x-cnc

ccoapplication/x-cocoa

cdfapplication/x-netcdf

cgimagnus-internal/cgi

chatapplication/x-chat

classapplication/octet-stream

clpapplication/x-msclip

cmxapplication/x-cmx

coapplication/x-cult3d-object

codimage/cis-cod

cpioapplication/x-cpio

cptapplication/mac-compactpro

crdapplication/x-mscardfile

cshapplication/x-csh

csmchemical/x-csml

csmlchemical/x-csml

css text/css

curapplication/octet-stream

dcmx-lml/x-evm

dcrapplication/x-director

dcximage/x-dcx

dhtmltext/html

dirapplication/x-director

dllapplication/octet-stream

dmgapplication/octet-stream

dmsapplication/octet-stream

docapplication/msword

dotapplication/x-dot

dviapplication/x-dvi

dwfdrawing/x-dwf

dwgapplication/x-autocad

dxfapplication/x-autocad

dxrapplication/x-director

ebkapplication/x-expandedbook

embchemical/x-embl-dl-nucleotide

emblchemical/x-embl-dl-nucleotide

epsapplication/postscript

eriimage/x-eri

esaudio/echospeech

eslaudio/echospeech

etcapplication/x-earthtime

etxtext/x-setext

evmx-lml/x-evm

evyapplication/x-envoy

exeapplication/octet-stream

fh4image/x-freehand

fh5image/x-freehand

fhcimage/x-freehand

fifimage/fif

fmapplication/x-maker

fpximage/x-fpx

fvivideo/isivideo

gauchemical/x-gaussian-input

gcaapplication/x-gca-compressed

gdbx-lml/x-gdb

gifimage/gif

gpsapplication/x-gps

gtarapplication/x-gtar

gzapplication/x-gzip

hdfapplication/x-hdf

hdmtext/x-hdml

hdmltext/x-hdml

hlpapplication/winhlp

hqxapplication/mac-binhex40

htmtext/html

htmltext/html

htstext/html

icex-conference/x-cooltalk

icoapplication/octet-stream

iefimage/ief

ifmimage/gif

ifsimage/ifs

imyaudio/melody

insapplication/x-NET-Install

ipsapplication/x-ipscript

ipxapplication/x-ipix

itaudio/x-mod

itzaudio/x-mod

ivri-world/i-vrml

j2kimage/j2k

jadtext/vnd.sun.j2me.app-descriptor

jamapplication/x-jam

jarapplication/java-archive

jnlpapplication/x-java-jnlp-file

jpeimage/jpeg

jpegimage/jpeg

jpgimage/jpeg

jpzimage/jpeg

jsapplication/x-javascript

jwcapplication/jwc

kjxapplication/x-kjx

lakx-lml/x-lak

latexapplication/x-latex

lccapplication/fastman

lclapplication/x-digitalloca

lcrapplication/x-digitalloca

lghapplication/lgh

lhaapplication/octet-stream

lmlx-lml/x-lml

lmlpackx-lml/x-lmlpack

lsfvideo/x-ms-asf

lsxvideo/x-ms-asf

lzhapplication/x-lzh

m13application/x-msmediaview

m14application/x-msmediaview

m15audio/x-mod

m3uaudio/x-mpegurl

m3urlaudio/x-mpegurl

ma1audio/ma1

ma2audio/ma2

ma3audio/ma3

ma5audio/ma5

manapplication/x-troff-man

mapmagnus-internal/imagemap

mbdapplication/mbedlet

mctapplication/x-mascot

mdbapplication/x-msaccess

mdzaudio/x-mod

meapplication/x-troff-me

meltext/x-vmel

miapplication/x-mif

midaudio/midi

midiaudio/midi

mifapplication/x-mif

milimage/x-cals

mioaudio/x-mio

mmfapplication/x-skt-lbs

mngvideo/x-mng

mnyapplication/x-msmoney

mocapplication/x-mocha

mochaapplication/x-mocha

modaudio/x-mod

mofapplication/x-yumekara

molchemical/x-mdl-molfile

mopchemical/x-mopac-input

movvideo/quicktime

movievideo/x-sgi-movie

mp2audio/x-mpeg

mp3audio/x-mpeg

mp4video/mp4

mpcapplication/vnd.mpohun.certificate

mpevideo/mpeg

mpegvideo/mpeg

mpgvideo/mpeg

mpg4video/mp4

mpgaaudio/mpeg

mpnapplication/vnd.mophun.application

mppapplication/vnd.ms-project

mpsapplication/x-mapserver

mrltext/x-mrml

mrmapplication/x-mrm

msapplication/x-troff-ms

mtsapplication/metastream

mtxapplication/metastream

mtzapplication/metastream

mzvapplication/metastream

narapplication/zip

nbmpimage/nbmp

ncapplication/x-netcdf

ndbx-lml/x-ndb

ndwnapplication/ndwn

nifapplication/x-nif

nmzapplication/x-scream

nokia-op-logoimage/vnd.nok-oplogo-color

npxapplication/x-netfpx

nsndaudio/nsnd

nvaapplication/x-neva1

odaapplication/oda

oomapplication/x-AtlasMate-Plugin

pacaudio/x-pac

paeaudio/x-epac

panapplication/x-pan

pbmimage/x-portable-bitmap

pcximage/x-pcx

pdaimage/x-pda

pdbchemical/x-pdb

pdfapplication/pdf

pfrapplication/font-tdpfr

pgmimage/x-portable-graymap

pictimage/x-pict

pmapplication/x-perl

pmdapplication/x-pmd

pngimage/png

pnmimage/x-portable-anymap

pnzimage/png

potapplication/vnd.ms-powerpoint

ppmimage/x-portable-pixmap

ppsapplication/vnd.ms-powerpoint

pptapplication/vnd.ms-powerpoint

pqfapplication/x-cprplayer

pqiapplication/cprplayer

prcapplication/x-prc

proxyapplication/x-ns-proxy-autoconfig

psapplication/postscript

ptlkapplication/listenup

pubapplication/x-mspublisher

pvxvideo/x-pv-pvx

qcpaudio/vnd.qcelp

qtvideo/quicktime

qtiimage/x-quicktime

qtifimage/x-quicktime

r3ttext/vnd.rn-realtext3d

raaudio/x-pn-realaudio

ramaudio/x-pn-realaudio

rarapplication/x-rar-compressed

rasimage/x-cmu-raster

rdfapplication/rdf+xml

rfimage/vnd.rn-realflash

rgbimage/x-rgb

rlfapplication/x-richlink

rmaudio/x-pn-realaudio

rmfaudio/x-rmf

rmmaudio/x-pn-realaudio

rmvbaudio/x-pn-realaudio

rnxapplication/vnd.rn-realplayer

roffapplication/x-troff

rpimage/vnd.rn-realpix

rpmaudio/x-pn-realaudio-plugin

rttext/vnd.rn-realtext

rtex-lml/x-gps

rtfapplication/rtf

rtgapplication/metastream

rtxtext/richtext

rvvideo/vnd.rn-realvideo

rwcapplication/x-rogerwilco

s3maudio/x-mod

s3zaudio/x-mod

scaapplication/x-supercard

scdapplication/x-msschedule

sdfapplication/e-score

seaapplication/x-stuffit

sgmtext/x-sgml

sgmltext/x-sgml

shapplication/x-sh

sharapplication/x-shar

shtmlmagnus-internal/parsed-html

shwapplication/presentations

si6image/si6

si7image/vnd.stiwap.sis

si9image/vnd.lgtwap.sis

sisapplication/vnd.symbian.install

sitapplication/x-stuffit

skdapplication/x-Koan

skmapplication/x-Koan

skpapplication/x-Koan

sktapplication/x-Koan

slcapplication/x-salsa

smdaudio/x-smd

smiapplication/smil

smilapplication/smil

smpapplication/studiom

smzaudio/x-smd

sndaudio/basic

spctext/x-speech

splapplication/futuresplash

sprapplication/x-sprite

spriteapplication/x-sprite

sptapplication/x-spt

srcapplication/x-wais-source

stkapplication/hyperstudio

stmaudio/x-mod

sv4cpioapplication/x-sv4cpio

sv4crcapplication/x-sv4crc

svfimage/vnd

svgimage/svg-xml

svhimage/svh

svrx-world/x-svr

swfapplication/x-shockwave-flash

swflapplication/x-shockwave-flash

tapplication/x-troff

tadapplication/octet-stream

talktext/x-speech

tarapplication/x-tar

tazapplication/x-tar

tbpapplication/x-timbuktu

tbtapplication/x-timbuktu

tclapplication/x-tcl

texapplication/x-tex

texiapplication/x-texinfo

texinfoapplication/x-texinfo

tgzapplication/x-tar

thmapplication/vnd.eri.thm

tifimage/tiff

tiffimage/tiff

tkiapplication/x-tkined

tkinedapplication/x-tkined

tocapplication/toc

toyimage/toy

trapplication/x-troff

trkx-lml/x-gps

trmapplication/x-msterminal

tsiaudio/tsplayer

tspapplication/dsptype

tsvtext/tab-separated-values

tsvtext/tab-separated-values

ttfapplication/octet-stream

ttzapplication/t-time

txttext/plain

ultaudio/x-mod

ustarapplication/x-ustar

uuapplication/x-uuencode

uueapplication/x-uuencode

vcdapplication/x-cdlink

vcftext/x-vcard

vdovideo/vdo

vibaudio/vib

vivvideo/vivo

vivovideo/vivo

vmdapplication/vocaltec-media-desc

vmfapplication/vocaltec-media-file

vmiapplication/x-dreamcast-vms-info

vmsapplication/x-dreamcast-vms

voxaudio/voxware

vqeaudio/x-twinvq-plugin

vqfaudio/x-twinvq

vqlaudio/x-twinvq

vrex-world/x-vream

vrmlx-world/x-vrml

vrtx-world/x-vrt

vrwx-world/x-vream

vtsworkbook/formulaone

wavaudio/x-wav

waxaudio/x-ms-wax

wbmpimage/vnd.wap.wbmp

webapplication/vnd.xara

wiimage/wavelet

wisapplication/x-InstallShield

wmvideo/x-ms-wm

wmaaudio/x-ms-wma

wmdapplication/x-ms-wmd

wmfapplication/x-msmetafile

wmltext/vnd.wap.wml

wmlcapplication/vnd.wap.wmlc

wmlstext/vnd.wap.wmlscript

wmlscapplication/vnd.wap.wmlscriptc

wmlscripttext/vnd.wap.wmlscript

wmvaudio/x-ms-wmv

wmxvideo/x-ms-wmx

wmzapplication/x-ms-wmz

wpngimage/x-up-wpng

wptx-lml/x-gps

wriapplication/x-mswrite

wrlx-world/x-vrml

wrzx-world/x-vrml

wstext/vnd.wap.wmlscript

wscapplication/vnd.wap.wmlscriptc

wvvideo/wavelet

wvxvideo/x-ms-wvx

wxlapplication/x-wxl

x-gzipapplication/x-gzip

xarapplication/vnd.xara

xbmimage/x-xbitmap

xdmapplication/x-xdma

xdmaapplication/x-xdma

xdwapplication/vnd.fujixerox.docuworks

xhtapplication/xhtml+xml

xhtmapplication/xhtml+xml

xhtmlapplication/xhtml+xml

xlaapplication/vnd.ms-excel

xlcapplication/vnd.ms-excel

xllapplication/x-excel

xlmapplication/vnd.ms-excel

xlsapplication/vnd.ms-excel

xltapplication/vnd.ms-excel

xlwapplication/vnd.ms-excel

xmaudio/x-mod

xml text/xml

xmzaudio/x-mod

xpiapplication/x-xpinstall

xpmimage/x-xpixmap

xsittext/xml

xsl text/xml

xul text/xul

xwdimage/x-xwindowdump

xyzchemical/x-pdb

yz1application/x-yz1

zapplication/x-compress

zacapplication/x-zaurus-zac

zipapplication/zip

版权声明:本文为博主原创文章,未经博主允许不得转载。

Linux下的raw Socket(原始套接字)编程

前言 本文所述代码托管在https://github.com/Wuchenwcf/MyCode/blob/master/C%2B%2B/Linux/rawSocketTest.cpp 简介 最近项目需...

java编程华容道智力游戏

华容道java代码: import java.awt.*; import java.awt.event.*; public class MoveExample {  public stati...

如何将本地图片嵌入网页?

因为经常会用Mardown写作,图片一般是用本地图片,但是导出html的时候,图片路径还是连接到本地的图片,如果把这个网页文件放到其他地方,就找不到图片了,所以最后显示不出来。后来得知可以把图片以ba...
  • onlyshi
  • onlyshi
  • 2017年10月31日 20:52
  • 105

【MFC】手把手教你如何将获取的字符串转换为数组

简单步骤 开发环境 VC++6.0 工程创建操作 界面设计 功能实现代码 void CBlogDlg::Oninout() { // TODO: Add you...

手把手教你如何将一个拥有巨大市场潜力的超前产品给做死

Wattage是一个硬件创造平台产品,让就算不懂电子和生产的人也可以在该平台上可视化的进行硬件产品设计创新,然后该平台会将用户设计好的虚拟硬件产品转换成可以真正进行生产的硬件模型,然后通过激光和3D打...

手把手教你如何将tomcat设置成开机自启动后台服务

Apache Tomcat开机后台启动 | 浏览:9960 | 更新:2012-04-22 08:07 1 2 3 4 5 6 ...

手把手教你:Ubuntu14+apache2+django1.7+python2.7下网页/网站部署

本人亲自尝试了网上众多的部署网页/网站方法,绝大多数都未能试验成功,这次的项目光部署这块遇到了很多问题,大概耗费了我一个星期。 本着:王道论坛中的赠人玫瑰,手留余香的精神。我把自己一路所走的历程发布出...

安卓手把手教你结合阿里云OSS存储实现视频(音频,图片)的上传与下载

首先,明白阿里云OSS是个什么鬼 阿里云对象存储(Object Storage Service,简称OSS),是阿里云对外提供的海量,安全,低成本,高可靠的云存储服务。用户可以通过调用API...

手把手教你快速拿到iOS应用中所有图片资源

最近闲来无事, 突然想到一个有趣的技能,我们看别人高仿一些项目,奇怪图片资源和其他资源文件是怎么拿到的,今天,我就一步一步教大家拿到一个iOS应用里面的所有资源.说到这里,就会提到一个常识: Ima...
  • Levilly
  • Levilly
  • 2016年08月04日 16:21
  • 756
内容举报
返回顶部
收藏助手
不良信息举报
您举报文章:手把手教你如何将图片“嵌入”网页中
举报原因:
原因补充:

(最多只允许输入30个字)
