Android 高仿 IOS 滚轮选择控件


https://github.com/lvfaqiang/Android-PickerView-master

最近根据项目需要,整理了一个相对比较全面的 WheelView 使用控件,借用之前看到的一句话来说,就是站在巨人肩膀上,进行了一些小调整。
这里先贴上效果图

这里写图片描述

一般常用的时间选择格式,,单项选择,以及城市联动,这里基本都可以满足了。

这里把 单项选择,和 日期时间选择 给提出到 Util 类中,代码如下:

public class Util {

    /**
     * 时间选择回调
     */
    public interface TimerPickerCallBack {
        void onTimeSelect(String date);
    }

    /**
     * 弹出时间选择
     *
     * @param context
     * @param type     TimerPickerView 中定义的 选择时间类型
     * @param format   时间格式化
     * @param callBack 时间选择回调
     */
    public static void alertTimerPicker(Context context, TimePickerView.Type type, final String format, final TimerPickerCallBack callBack) {
        TimePickerView pvTime = new TimePickerView(context, type);
        //控制时间范围
        //        Calendar calendar = Calendar.getInstance();
        //        pvTime.setRange(calendar.get(Calendar.YEAR) - 20, calendar.get(Calendar.YEAR));
        pvTime.setTime(new Date());
        pvTime.setCyclic(false);
        pvTime.setCancelable(true);
        //时间选择后回调
        pvTime.setOnTimeSelectListener(new TimePickerView.OnTimeSelectListener() {

            @Override
            public void onTimeSelect(Date date) {
//                        tvTime.setText(getTime(date));
                SimpleDateFormat sdf = new SimpleDateFormat(format);
                callBack.onTimeSelect(sdf.format(date));
            }
        });
        pvTime.setTextSize(16);
        //弹出时间选择器
        pvTime.show();
    }


    /**
     * 底部滚轮点击事件回调
     */
    public interface OnWheelViewClick {
        void onClick(View view, int postion);
    }

    /**
     * 弹出底部滚轮选择
     *
     * @param context
     * @param list
     * @param click
     */
    public static void alertBottomWheelOption(Context context, ArrayList<?> list, final OnWheelViewClick click) {

        final PopupWindow popupWindow = new PopupWindow();

        View view = LayoutInflater.from(context).inflate(R.layout.layout_bottom_wheel_option, null);
        TextView tv_confirm = (TextView) view.findViewById(R.id.btnSubmit);
        final WheelView wv_option = (WheelView) view.findViewById(R.id.wv_option);
        wv_option.setAdapter(new ArrayWheelAdapter(list));
        wv_option.setCyclic(false);
        wv_option.setTextSize(16);
        tv_confirm.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                popupWindow.dismiss();
                click.onClick(view, wv_option.getCurrentItem());
            }
        });

        view.findViewById(R.id.btnCancel).setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                // TODO: 2016/8/11 0011 取消
                popupWindow.dismiss();
            }
        });
        view.setOnTouchListener(new View.OnTouchListener() {
            @Override
            public boolean onTouch(View view, MotionEvent motionEvent) {
                int top = view.findViewById(R.id.ll_container).getTop();
                if (motionEvent.getAction() == MotionEvent.ACTION_UP) {
                    int y = (int) motionEvent.getY();
                    if (y < top) {
                        popupWindow.dismiss();
                    }
                }
                return true;
            }
        });
        popupWindow.setContentView(view);
        popupWindow.setOutsideTouchable(true);
        popupWindow.setFocusable(true);
        popupWindow.setBackgroundDrawable(new BitmapDrawable());
        popupWindow.setWidth(ViewGroup.LayoutParams.MATCH_PARENT);
        popupWindow.setHeight(ViewGroup.LayoutParams.MATCH_PARENT);
        popupWindow.showAtLocation(((ViewGroup) ((Activity) context).findViewById(android.R.id.content)).getChildAt(0), Gravity.CENTER, 0, 0);
    }
}


  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 19
  • 20
  • 21
  • 22
  • 23
  • 24
  • 25
  • 26
  • 27
  • 28
  • 29
  • 30
  • 31
  • 32
  • 33
  • 34
  • 35
  • 36
  • 37
  • 38
  • 39
  • 40
  • 41
  • 42
  • 43
  • 44
  • 45
  • 46
  • 47
  • 48
  • 49
  • 50
  • 51
  • 52
  • 53
  • 54
  • 55
  • 56
  • 57
  • 58
  • 59
  • 60
  • 61
  • 62
  • 63
  • 64
  • 65
  • 66
  • 67
  • 68
  • 69
  • 70
  • 71
  • 72
  • 73
  • 74
  • 75
  • 76
  • 77
  • 78
  • 79
  • 80
  • 81
  • 82
  • 83
  • 84
  • 85
  • 86
  • 87
  • 88
  • 89
  • 90
  • 91
  • 92
  • 93
  • 94
  • 95
  • 96
  • 97
  • 98
  • 99
  • 100
  • 101
  • 102
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 19
  • 20
  • 21
  • 22
  • 23
  • 24
  • 25
  • 26
  • 27
  • 28
  • 29
  • 30
  • 31
  • 32
  • 33
  • 34
  • 35
  • 36
  • 37
  • 38
  • 39
  • 40
  • 41
  • 42
  • 43
  • 44
  • 45
  • 46
  • 47
  • 48
  • 49
  • 50
  • 51
  • 52
  • 53
  • 54
  • 55
  • 56
  • 57
  • 58
  • 59
  • 60
  • 61
  • 62
  • 63
  • 64
  • 65
  • 66
  • 67
  • 68
  • 69
  • 70
  • 71
  • 72
  • 73
  • 74
  • 75
  • 76
  • 77
  • 78
  • 79
  • 80
  • 81
  • 82
  • 83
  • 84
  • 85
  • 86
  • 87
  • 88
  • 89
  • 90
  • 91
  • 92
  • 93
  • 94
  • 95
  • 96
  • 97
  • 98
  • 99
  • 100
  • 101
  • 102
  • 单项选择

    这里是模拟传入 ArrayList 形式的 String 类型 :

// 单项选择
        for (int i = 0; i <= 10; i++) {
            mList.add("模拟数据" + i);
        }

        tv_single_option.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View v) {
                Util.alertBottomWheelOption(MainActivity.this, mList, new Util.OnWheelViewClick() {
                    @Override
                    public void onClick(View view, int postion) {
                        Toast.makeText(MainActivity.this, mList.get(postion), Toast.LENGTH_SHORT).show();
                    }
                });
            }
        });


  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16

补充:我们实际项目中用法可能是传入一个实体对象,那么我们到 WheelView 中找到设置显示内容的方法:

/**
     * 根据传进来的对象反射出getPickerViewText()方法,来获取需要显示的值
     * @param item
     * @return
     */
    private String getContentText(Object item) {
        String contentText = item.toString();
        try {
            Class<?> clz = item.getClass();
            Method m = clz.getMethod(GETPICKERVIEWTEXT);
            contentText = m.invoke(item, new Object[0]).toString();
        } catch (NoSuchMethodException e) {
        } catch (InvocationTargetException e) {
        } catch (IllegalAccessException e) {
        } catch (Exception e){
        }
        return contentText;
    }


  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18

根据以上代码,可以看到如果是一个实体对象,那么就是通过对象内部定义的一个方法名为 GETPICKERVIEWTEXT(静态常量=”getPickerViewText”)的返回值来作为显示内容,

所以在创建对象的时候,要注意在对象内部添加一个 getPickerViewText()方法,代码如下:

public class TypeBean {

    private int id;
    private String name;

    public TypeBean(int id, String name) {
        this.id = id;
        this.name = name;
    }

    public int getId() {
        return id;
    }

    public void setId(int id) {
        this.id = id;
    }

    public String getName() {
        return name;
    }

    public void setName(String name) {
        this.name = name;
    }

    //这个用来显示在PickerView上面的字符串,PickerView会通过反射获取getPickerViewText方法显示出来。
    public String getPickerViewText() {
        //这里还可以判断文字超长截断再提供显示
        return name;
    }
}



  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 19
  • 20
  • 21
  • 22
  • 23
  • 24
  • 25
  • 26
  • 27
  • 28
  • 29
  • 30
  • 31
  • 32
  • 33
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 19
  • 20
  • 21
  • 22
  • 23
  • 24
  • 25
  • 26
  • 27
  • 28
  • 29
  • 30
  • 31
  • 32
  • 33
  • 日期选择
    这里是传入 选择日期类型,和 回调时间格式 就能直接得到想要的结果,
@Override
    public void onClick(View v) {
        String format = "";
        TimePickerView.Type type = null;
        switch (v.getId()) {
            case R.id.btn_ymdhm:
                type = TimePickerView.Type.ALL;
                format = "yyyy-MM-dd HH:mm";
                break;
            case R.id.btn_ymdh:
                type = TimePickerView.Type.YEAR_MONTH_DAY_HOUR;
                format = "yyyy-MM-dd HH";
                break;
            case R.id.btn_ymd:
                type = TimePickerView.Type.YEAR_MONTH_DAY;
                format = "yyyy-MM-dd";
                break;
            case R.id.btn_mdhm:
                type = TimePickerView.Type.MONTH_DAY_HOUR_MIN;
                format = "MM-dd HH:mm";
                break;
            case R.id.btn_hm:
                type = TimePickerView.Type.HOURS_MINS;
                format = "HH:mm";
                break;
            case R.id.btn_ym:
                type = TimePickerView.Type.YEAR_MONTH;
                format = "yyyy-MM";
                break;
        }
        Util.alertTimerPicker(this, type, format, new Util.TimerPickerCallBack() {
            @Override
            public void onTimeSelect(String date) {
                Toast.makeText(TestActivity.this, date, Toast.LENGTH_SHORT).show();
            }
        });

    }


  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 19
  • 20
  • 21
  • 22
  • 23
  • 24
  • 25
  • 26
  • 27
  • 28
  • 29
  • 30
  • 31
  • 32
  • 33
  • 34
  • 35
  • 36
  • 37
  • 38
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 19
  • 20
  • 21
  • 22
  • 23
  • 24
  • 25
  • 26
  • 27
  • 28
  • 29
  • 30
  • 31
  • 32
  • 33
  • 34
  • 35
  • 36
  • 37
  • 38
  • 条件选择
private ArrayList<ProvinceBean> options1Items = new ArrayList<ProvinceBean>();
private ArrayList<ArrayList<String>> options2Items = new ArrayList<ArrayList<String>>();
private ArrayList<ArrayList<ArrayList<String>>> options3Items = new ArrayList<ArrayList<ArrayList<String>>>();

OptionsPickerView pvOptions;

private void showOptions(){
        //选项选择器
        pvOptions = new OptionsPickerView(this);
        // 初始化三个列表数据
        DataModel.initData(options1Items, options2Items, options3Items);

        //三级联动效果
        pvOptions.setPicker(options1Items, options2Items, options3Items, true);
        //设置选择的三级单位
//        pwOptions.setLabels("省", "市", "区");
        pvOptions.setTitle("选择城市");
        pvOptions.setCyclic(false, false, false);
        //设置默认选中的三级项目
        //监听确定选择按钮
        pvOptions.setSelectOptions(1, 1, 1);
        pvOptions.setTextSize(18);
        pvOptions.setOnoptionsSelectListener(new OptionsPickerView.OnOptionsSelectListener() {

            @Override
            public void onOptionsSelect(int options1, int option2, int options3) {
                //返回的分别是三个级别的选中位置
                String tx = options1Items.get(options1).getPickerViewText()
                        + options2Items.get(options1).get(option2)
                        + options3Items.get(options1).get(option2).get(options3);
                tvOptions.setText(tx);
                vMasker.setVisibility(View.GONE);
            }
        });
        //点击弹出选项选择器
        tvOptions.setOnClickListener(new View.OnClickListener() {

            @Override
            public void onClick(View v) {
                pvOptions.show();
            }
        });
    }


  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 19
  • 20
  • 21
  • 22
  • 23
  • 24
  • 25
  • 26
  • 27
  • 28
  • 29
  • 30
  • 31
  • 32
  • 33
  • 34
  • 35
  • 36
  • 37
  • 38
  • 39
  • 40
  • 41
  • 42
  • 43
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 19
  • 20
  • 21
  • 22
  • 23
  • 24
  • 25
  • 26
  • 27
  • 28
  • 29
  • 30
  • 31
  • 32
  • 33
  • 34
  • 35
  • 36
  • 37
  • 38
  • 39
  • 40
  • 41
  • 42
  • 43

基本使用就这些了,也没什么技术含量,只是作为常用工具整理,也希望能给大家带来方便。

感谢一下提供该组件源码的大神。

Demo地址
