Android中使用ViewPager实现图片的切换

主要包含三步，配置布局文件，设置MainActivity类，配置适配器类

.xml文件：



<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical" >

    <TextView
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:gravity="center"
        android:text="请选择图片"
        android:textColor="#ff0000"
        android:textSize="20sp" />

    <FrameLayout
        android:layout_width="match_parent"
        android:layout_height="match_parent" >

        <android.support.v4.view.ViewPager
            android:id="@+id/viewPager"
            android:layout_width="match_parent"
            android:layout_height="wrap_content" />

        <LinearLayout
            android:id="@+id/viewGroup"
            android:layout_width="fill_parent"
            android:layout_height="wrap_content"
            android:layout_alignParentBottom="true"
            android:layout_marginBottom="30dp"
            android:gravity="center_horizontal"
            android:orientation="horizontal" >
        </LinearLayout>
    </FrameLayout>

</LinearLayout>

MainActivity类：

package com.example.android_005_viewpager;

import java.util.ArrayList;
import java.util.List;

import android.app.Activity;
import android.os.Bundle;
import android.support.v4.view.ViewPager;
import android.support.v4.view.ViewPager.OnPageChangeListener;
import android.view.Menu;
import android.view.MenuItem;
import android.view.ViewGroup;
import android.view.ViewGroup.LayoutParams;
import android.view.Window;
import android.widget.ImageView;

public class MainActivity extends Activity {

	// 装图片id的数组
	private int[] bitmaps = {R.drawable.yanshi, R.drawable.yanshi, R.drawable.yanshi,
			R.drawable.yanshi, R.drawable.yanshi,
		 R.drawable.ic_launcher,
			R.drawable.ie_arrow_normal };
	private ViewPager viewpager;
	private List<ImageView> list;// 装ImageView的集合
	private ImageView imageView;
	private ImageView[] tips;// 装点点的集合
	private ViewGroup viewGroup;

	@Override
	protected void onCreate(Bundle savedInstanceState) {
		super.onCreate(savedInstanceState);
		requestWindowFeature(Window.FEATURE_NO_TITLE);
		setContentView(R.layout.activity_main);

		viewpager = (ViewPager) findViewById(R.id.viewPager);
		viewGroup = (ViewGroup) findViewById(R.id.viewGroup);

		// 将imageView图片资源存在集合中
		list = new ArrayList<ImageView>();
		for (int i = 0; i < bitmaps.length; i++) {
			imageView = new ImageView(MainActivity.this);
			imageView.setBackgroundResource(bitmaps[i]);
			// 为imageView设置tag，将id传入，方便页面跳转时，发送图片的资源id
			imageView.setTag(bitmaps[i]);
			list.add(imageView);
		}

		// 将点点装入到结集合中
		tips = new ImageView[bitmaps.length];
		for (int i = 0; i < bitmaps.length; i++) {
			imageView = new ImageView(MainActivity.this);
			imageView.setLayoutParams(new LayoutParams(100, 100));
			tips[i] = imageView;
			if (i == 0) {
				tips[i].setBackgroundResource(R.drawable.heart);
			} else {
				tips[i].setBackgroundResource(R.drawable.ie_arrow_normal);
			}
			viewGroup.addView(imageView);
		}

		// 设置适配器
		viewpager.setAdapter(new MyAdapter(list, this));
		viewpager.setOnPageChangeListener(new OnPageChangeListener()
		{

			public void onPageSelected(int arg0) {
				setImageBackground(arg0 % bitmaps.length);
			}

			public void onPageScrolled(int arg0, float arg1, int arg2) {

			}
			public void onPageScrollStateChanged(int arg0) {

			}
		});

		// 第一次初始化界面时，显示的界面
		// 设置ViewPager的默认项, 设置为长度的100倍，这样子开始就能往左滑动
		viewpager.setCurrentItem((bitmaps.length) * 100);
	}

	/**
	 * 设置选中的tip的背景 ，选中哪个图片，哪个图片的点点就变成白的
	 */
	private void setImageBackground(int selectItems)
	{
		for (int i = 0; i < tips.length; i++)
		{
			if (i == selectItems)
			{
				tips[i].setBackgroundResource(bitmaps[i]);
			} else
			{
				tips[i].setBackgroundResource(bitmaps[i]&R.drawable.heart);
			}
		}
	}
}

MyAdapter类：

package com.example.android_005_viewpager;

import java.util.List;

import android.content.Context;
import android.support.v4.view.PagerAdapter;
import android.view.View;
import android.view.ViewGroup;
import android.widget.ImageView;


public class MyAdapter extends PagerAdapter {
 private List<ImageView> list;
 private Context context;

 public MyAdapter (  List<ImageView> list, Context context) {
  super();
  this.list = list;
  this.context = context;
 }
 //该方法将返回所包含的item总个数。为了实现一种循环滚动的效果，返回了基本整形的最大值
 @Override
 public int getCount() {
  return Integer.MAX_VALUE;
 }
//判断出去的view是否等于进来的view，如果为true直接复用
 @Override
 public boolean isViewFromObject(View arg0, Object arg1) {
  return arg0==arg1;
 }

 //销毁预加载以外的view对象，会把需要销毁的对象的索引位置传进来，就是position，y
 //因为imageView只要6条数据，而position会取到很大的值，所以使用取余数的方法来获取每一条数据项
 @Override
 public void destroyItem(ViewGroup container, int position, Object object) {
  container.removeView(list.get(position%list.size()));
 }
 //装入图片
 @Override
 public Object instantiateItem(ViewGroup container, final int position) {
  final ImageView imageView = list.get(position % list.size());
  container.addView(list.get(position%list.size()),0);
  return list.get(position%list.size());
 }
}

运行结果如下，拨动图片能够实现一起移动：

图片的移动

以上就是ViewPager实现图片切换的步骤
