IOS 自定义滑动Tab(顶部) 带滑动的条条

// 代码写得也比较粗糙， 希望能有帮助吧

// 看下文件的目录

// 开始代码啦 ********************

//

//  WWCSwitchTabViewController.h

//  TestCAOrUIViewAnimationApp7-30

//

//  Created by Whitney.c on 15/8/7.

//  Copyright (c) 2015年 ZhongShan Sun union Medical Technology Co. Ltd. All rights reserved.

//

#import <UIKit/UIKit.h>

#import "WWCSwitchTabView.h"

#import "WWCFavoriteTabView.h"

#import "WWCBestLoveTabView.h"

#import "WWHistoryTabView.h"

#define tabViewHeight 40

@interface WWCSwitchTabViewController :UIViewController <SwitchTabTestDelegate>

{



    WWCSwitchTabView *switchTabView;





    NSArray *data;





    WWCFavoriteTabView *favoriteView;

    WWCBestLoveTabView *bestLoveView;

    WWHistoryTabView *historyView;



    NSArray *arrVies;

}

@end

//

//  WWCSwitchTabViewController.m

//  TestCAOrUIViewAnimationApp7-30

//

//  Created by Whitney.c on 15/8/7.

//  Copyright (c) 2015年 ZhongShan Sun union Medical Technology Co. Ltd. All rights reserved.

//

#import "WWCSwitchTabViewController.h"

#import "GeneralMarro.h"

@interface WWCSwitchTabViewController ()

@end

@implementation WWCSwitchTabViewController

- (void)viewDidLoad {

    [super viewDidLoad];

    // Do any additional setup after loading the view.



    self.view.backgroundColor = [UIColor whiteColor];



    self.title =@"SwitchTest";



    [self loadSelfLayoutSubviews];



}

-(void)loadSelfLayoutSubviews

{



    data = [[NSArray alloc] initWithObjects:@"收藏",@"最爱",@"历史",nil];



    switchTabView = [[WWCSwitchTabView alloc] initWithFrame:CGRectMake(0,0, ScreenWidth, tabViewHeight)];

    switchTabView.switchTabDelegate = self;



    [self.view addSubview:switchTabView];





    [self initSwitchView];

}

-(void)initSwitchView

{

    CGFloat height = CGRectGetHeight(self.view.frame) - 64 ;

    CGFloat width = CGRectGetWidth(self.view.frame);





    CGRect allFrame = CGRectMake(0, tabViewHeight, width, height);



    favoriteView  =[[WWCFavoriteTabView alloc] initWithFrame:allFrame];

    favoriteView.backgroundColor = [UIColor redColor] ;//Color(46, 48, 59, 1);



    bestLoveView = [[WWCBestLoveTabView alloc] initWithFrame:allFrame];

    bestLoveView.backgroundColor =  [UIColor purpleColor];//Color(46, 48, 99, 1);



    historyView = [[WWHistoryTabView alloc] initWithFrame:allFrame];

    historyView.backgroundColor = [UIColor magentaColor];//Color(46, 66, 99, 1);



    arrVies = [[NSArray alloc] initWithObjects:favoriteView,bestLoveView,historyView,nil];







    [self.view addSubview:favoriteView];

    [self.view addSubview:historyView];

    [self.view addSubview:bestLoveView];





    // 默认显示收藏/0

    [self showCurrentView:[arrVies objectAtIndex:0]];





}

// 显示指定的View

-(void)showCurrentView:(UIView *)view

{



    for (int i =0; i < arrVies.count; i ++ ) {

        UIView *view  = [arrViesobjectAtIndex:i];

        view.hidden =YES;

    }



    view.hidden =NO;





}

#pragma mark - SwitchTabDelegate

-(NSInteger)numberOfSwitchTabView

{

    returndata.count;

}

-(NSString *)titleOfSwithcTabViewatIndex:(NSInteger)indexRow

{



    return [dataobjectAtIndex:indexRow];

}

-(void)didSelectedSwitchTabView:(WWCSwitchTabView *)switchView atIndex:(NSInteger)indexRow

{



    [selfshowCurrentView:[arrViesobjectAtIndex:indexRow]];

}

-(UIColor *)colorForBackground:(NSInteger)indexRow// 返回指定位置的背景颜色

{

    return  [UIColorbrownColor];

}

-(UIColor *)colorForTitle:(NSInteger)indexRow// 返回指定标题字体颜色

{

    return  [UIColorwhiteColor];

}

-(UIColor *)colorForTitle_selected:(NSInteger)indexRow// 返回选中指定标题字体颜色

{

    return [UIColor blueColor];

}

-(UIFont *)fontForSwitchTitle

{

    return [UIFont systemFontOfSize:14];

}

-(UIColor *)footLineColor

{

    return [UIColor blueColor];

}

- (void)didReceiveMemoryWarning {

    [super didReceiveMemoryWarning];

    // Dispose of any resources that can be recreated.

}

/*

#pragma mark - Navigation

// In a storyboard-based application, you will often want to do a little preparation before navigation

- (void)prepareForSegue:(UIStoryboardSegue *)segue sender:(id)sender {

    // Get the new view controller using [segue destinationViewController].

    // Pass the selected object to the new view controller.

}

*/

@end

// 自定义的TabView ************

//

//  WWCSwitchTabView.h

//  TestCAOrUIViewAnimationApp7-30

//

//  Created by Whitney.c on 15/8/7.

//  Copyright (c) 2015年 ZhongShan Sun union Medical Technology Co. Ltd. All rights reserved.

//

#import <UIKit/UIKit.h>

@class WWCSwitchTabView;

@protocol SwitchTabTestDelegate <NSObject>

@required //要求

-(NSInteger)numberOfSwitchTabView;// 返回的个数

-(NSString *)titleOfSwithcTabViewatIndex:(NSInteger)indexRow;//返回指定位置的标题

// 点击(滑动)事件

-(void)didSelectedSwitchTabView:(WWCSwitchTabView *)switchView atIndex:(NSInteger)indexRow;

@optional //可选

-(UIColor *)colorForBackground:(NSInteger)indexRow;// 返回指定位置的背景颜色

-(UIColor *)colorForTitle:(NSInteger)indexRow;// 返回指定标题字体颜色

-(UIColor *)colorForTitle_selected:(NSInteger)indexRow;// 返回选中指定标题字体颜色

-(UIFont *)fontForSwitchTitle;

-(UIColor *)footLineColor;

@end

@interface WWCSwitchTabView :UIView

{



    UIView *footLineView;

    CGFloat tab_width ;

}

@property (assign)NSInteger switchTabCount;

@property (copy,nonatomic) NSString *switchTabTitle;

@property (assign)CGFloat tab_width;

@property (strong,nonatomic) UIColor *bgColor;

@property (strong,nonatomic) UIColor *titleColor;

@property (assign)UIColor *titleSelectedColor;

@property (assign)UIColor *footLineColor;

@property (strong,nonatomic) id<SwitchTabTestDelegate> switchTabDelegate;

@end

//

//  WWCSwitchTabView.m

//  TestCAOrUIViewAnimationApp7-30

//

//  Created by Whitney.c on 15/8/7.

//  Copyright (c) 2015年 ZhongShan Sun union Medical Technology Co. Ltd. All rights reserved.

//

#import "WWCSwitchTabView.h"

@implementation WWCSwitchTabView

-(id)initWithFrame:(CGRect)frame

{



    self = [superinitWithFrame:frame];

    if (self) {

        [selfloadSelfLayoutViews];

    }

    returnself;

}

-(void)loadSelfLayoutViews

{



    NSLog(@".... loadSelfLayoutViews ...");

}

-(void)layoutSubviews

{



    CGFloat width =self.frame.size.width;

    CGFloat height =CGRectGetHeight(self.frame);

    NSLog(@"width %f" , width);



    self.backgroundColor = [UIColorgrayColor];





    if (self.switchTabDelegate) {



       self.switchTabCount = [self.switchTabDelegatenumberOfSwitchTabView];



        tab_width = width/self.switchTabCount;



        // 初始化切换的tab按钮

        CGFloat y =0;

        for (int i=0; i <self.switchTabCount; i++) {

            CGFloat x = i*tab_width;



            UIButton *switchButton = [UIButtonbuttonWithType:UIButtonTypeCustom];

            switchButton.frame =CGRectMake(x, y, tab_width, height);

            switchButton.tag = i +100 ;

            self.switchTabTitle = [self.switchTabDelegatetitleOfSwithcTabViewatIndex:i];

            // 标题

            [switchButton setTitle:self.switchTabTitleforState:UIControlStateNormal];

            // 背景

            [switchButton setBackgroundColor:[self.switchTabDelegatecolorForBackground:i]];

            // 字体颜色

            [switchButton setTitleColor:[self.switchTabDelegatecolorForTitle:i] forState:UIControlStateNormal];

            // 选择字体颜色

            [switchButton setTitleColor:[self.switchTabDelegatecolorForTitle_selected:i] forState:UIControlStateHighlighted];

            // 按钮点击事件

            [switchButton addTarget:selfaction:@selector(switcAction:)forControlEvents:UIControlEventTouchUpInside];

            // 设置字体

            [switchButton.titleLabelsetFont:[self.switchTabDelegatefontForSwitchTitle]];



            [selfaddSubview:switchButton];



        }



        // 初始化底部Line



        CGFloat l_x =5;

        CGFloat l_y = height -2;

        CGFloat l_w =tab_width- 10;

        CGFloat l_h =2;



        footLineView = [[UIViewalloc] initWithFrame:CGRectMake(l_x, l_y, l_w, l_h)];

        footLineView.backgroundColor = [self.switchTabDelegatefootLineColor];

        [selfaddSubview:footLineView];

    }



}

-(void)switcAction:(UIButton *)sender

{

    UIButton *button = (UIButton *)sender;



    if (self.switchTabDelegate ) {



        [UIViewanimateWithDuration:0.5animations:^{



            CGRect frame =footLineView.frame;

            frame.origin.x =5 +((button.tag-100) *tab_width);

            footLineView.frame = frame;



        }completion:^(BOOL isFinished){



        }];



        [self.switchTabDelegatedidSelectedSwitchTabView:selfatIndex:button.tag-100];

    }



}

/*

// Only override drawRect: if you perform custom drawing.

// An empty implementation adversely affects performance during animation.

- (void)drawRect:(CGRect)rect {

    // Drawing code

}

*/

@end

// ************************ 切换的3个视图

//

//  WWCFavoriteTabView.h

//  TestCAOrUIViewAnimationApp7-30

//

//  Created by Whitney.c on 15/8/7.

//  Copyright (c) 2015年 ZhongShan Sun union Medical Technology Co. Ltd. All rights reserved.

//

#import <UIKit/UIKit.h>

@interface WWCFavoriteTabView :UIView

@end

//

//  WWCFavoriteTabView.m

//  TestCAOrUIViewAnimationApp7-30

//

//  Created by Whitney.c on 15/8/7.

//  Copyright (c) 2015年 ZhongShan Sun union Medical Technology Co. Ltd. All rights reserved.

//

#import "WWCFavoriteTabView.h"

@implementation WWCFavoriteTabView

/*

// Only override drawRect: if you perform custom drawing.

// An empty implementation adversely affects performance during animation.

- (void)drawRect:(CGRect)rect {

    // Drawing code

}

*/

@end

// 另外2个跟FavoriteView 一样的， 里面可以自定义自己所需要的内容

代码结束
