1. PasswordBox 控件基础介绍

1.1 什么是 PasswordBox？

PasswordBox（密码框）是 WPF 中专门用于接收密码输入的控件，它与普通的 TextBox 最大的区别在于会隐藏用户输入的内容，以确保密码安全。

1.2 PasswordBox 的核心特点

内容隐藏：输入的文字显示为圆点或星号
安全性：不直接暴露密码内容
专用性：专门为密码输入场景设计
限制性：密码字段不是依赖属性，不能直接数据绑定

1.3 PasswordBox 与 TextBox 的对比

特性	TextBox	PasswordBox
显示内容	明文显示	隐藏显示（●或*）
数据绑定	支持直接绑定	需要特殊处理
适用场景	普通文本输入	密码等敏感信息输入
安全性	较低	较高

2. PasswordBox 基本使用与布局

2.1 基础 PasswordBox 创建

🔹 最简单的密码框

<PasswordBox />

🔹 带提示文本的密码框

<PasswordBox PasswordChar="*" />

2.2 样式和布局设置

🔹 基本样式配置

<StackPanel Margin="20" Width="300">
    <!-- 基础密码框样式 -->
    <PasswordBox Width="200"
                 Height="35"
                 HorizontalAlignment="Left"
                 Margin="0,5"
                 PasswordChar="●"/>
</StackPanel>

🔹 完整登录表单布局

<Grid Margin="20">
    <Grid.RowDefinitions>
        <RowDefinition Height="Auto"/>
        <RowDefinition Height="Auto"/>
        <RowDefinition Height="Auto"/>
    </Grid.RowDefinitions>
    <Grid.ColumnDefinitions>
        <ColumnDefinition Width="Auto"/>
        <ColumnDefinition Width="*"/>
    </Grid.ColumnDefinitions>

    <!-- 用户名标签 -->
    <TextBlock Grid.Row="0" Grid.Column="0"
               Text="用户名:"
               VerticalAlignment="Center"
               Margin="0,0,10,10"/>

    <!-- 用户名输入框 -->
    <TextBox Grid.Row="0" Grid.Column="1"
             Height="35"
             VerticalAlignment="Center"
             Margin="0,0,0,10"/>

    <!-- 密码标签 -->
    <TextBlock Grid.Row="1" Grid.Column="0"
               Text="密码:"
               VerticalAlignment="Center"
               Margin="0,0,10,10"/>

    <!-- 密码输入框 -->
    <PasswordBox Grid.Row="1" Grid.Column="1"
                 Name="LoginPasswordBox"
                 Height="35"
                 VerticalAlignment="Center"
                 PasswordChar="•"
                 Margin="0,0,0,10"/>

    <!-- 登录按钮 -->
    <Button Grid.Row="2" Grid.Column="1"
            Content="登录"
            Width="80"
            Height="30"
            HorizontalAlignment="Right"
            Click="LoginButton_Click"/>
</Grid>

🔹 美化样式设计

<StackPanel Margin="20" Width="250">
    <!-- 现代风格的密码框 -->
    <PasswordBox Name="StyledPasswordBox"
                 Height="40"
                 PasswordChar="●"
                 VerticalAlignment="Center"
                 FontSize="14"
                 Padding="10,8">
        <PasswordBox.Style>
            <Style TargetType="PasswordBox">
                <Setter Property="BorderBrush" Value="#DDD"/>
                <Setter Property="BorderThickness" Value="1"/>
                <Setter Property="Background" Value="White"/>
                <Setter Property="Foreground" Value="#333"/>
            </Style>
        </PasswordBox.Style>
    </PasswordBox>
</StackPanel>

3. PasswordBox 核心属性详解

3.1 PasswordChar 属性

🔹 设置密码显示字符

<StackPanel Margin="20">
    <TextBlock Text="不同密码显示字符:" FontWeight="Bold" Margin="0,0,0,10"/>

    <!-- 星号显示 -->
    <PasswordBox PasswordChar="*"
                 Height="35"
                 Margin="0,5"
                 ToolTip="星号显示"/>

    <!-- 圆点显示 -->
    <PasswordBox PasswordChar="●"
                 Height="35"
                 Margin="0,5"
                 ToolTip="圆点显示"/>

    <!-- 自定义字符显示 -->
    <PasswordBox PasswordChar="★"
                 Height="35"
                 Margin="0,5"
                 ToolTip="星形显示"/>

    <!-- 无字符显示（显示空白） -->
    <PasswordBox PasswordChar=" "
                 Height="35"
                 Margin="0,5"
                 ToolTip="无显示字符"/>
</StackPanel>

3.2 MaxLength 属性

🔹 限制密码最大长度

<StackPanel Margin="20" Width="300">
    <TextBlock Text="密码长度限制示例:" FontWeight="Bold" Margin="0,0,0,10"/>

    <!-- 限制6位密码（常用） -->
    <PasswordBox Name="SixDigitPassword"
                 MaxLength="6"
                 Height="35"
                 PasswordChar="●"
                 Margin="0,5"
                 ToolTip="最多6位字符"/>

    <!-- 限制8位密码 -->
    <PasswordBox Name="EightDigitPassword"
                 MaxLength="8"
                 Height="35"
                 PasswordChar="●"
                 Margin="0,5"
                 ToolTip="最多8位字符"/>

    <!-- 限制16位密码 -->
    <PasswordBox Name="LongPassword"
                 MaxLength="16"
                 Height="35"
                 PasswordChar="●"
                 Margin="0,5"
                 ToolTip="最多16位字符"/>

    <!-- 实时显示输入长度 -->
    <TextBlock Name="PasswordLengthDisplay"
               Text="已输入: 0/8 位"
               HorizontalAlignment="Right"
               Foreground="Gray"
               Margin="0,5,0,0"/>
</StackPanel>

// 后台代码：实时监控密码长度
private void EightDigitPassword_PasswordChanged(object sender, RoutedEventArgs e)
{
    int currentLength = EightDigitPassword.Password.Length;
    PasswordLengthDisplay.Text = $"已输入: {currentLength}/8 位";

    // 根据长度改变颜色提示
    if (currentLength >= 8)
    {
        PasswordLengthDisplay.Foreground = Brushes.Red;
    }
    else if (currentLength >= 6)
    {
        PasswordLengthDisplay.Foreground = Brushes.Orange;
    }
    else
    {
        PasswordLengthDisplay.Foreground = Brushes.Gray;
    }
}

3.3 Password 属性

🔹 获取和设置密码值

// 获取密码值（在后台代码中）
string password = passwordBox.Password;

// 设置密码值（通常用于重置或测试）
passwordBox.Password = "defaultPassword";

4. PasswordBox 的数据绑定问题与解决方案

4.1 为什么不能直接数据绑定？

🔹 问题根源

PasswordBox.Password 属性不是依赖属性，这意味着：

不能使用 {Binding} 直接绑定
不能自动更新数据源
需要手动处理数据同步

🔹 错误示例

<!-- 这样是行不通的！ -->
<PasswordBox Password="{Binding UserPassword}" />

4.2 解决方案一：使用 PasswordChanged 事件

🔹 基本事件处理

<PasswordBox Name="EventPasswordBox"
             PasswordChanged="EventPasswordBox_PasswordChanged"
             Height="35"
             Margin="10"/>

// 后台代码处理密码变化
private void EventPasswordBox_PasswordChanged(object sender, RoutedEventArgs e)
{
    string password = EventPasswordBox.Password;

    // 更新ViewModel或执行其他逻辑
    if (viewModel != null)
    {
        viewModel.Password = password;
    }

    // 可以添加其他逻辑，如密码强度检查
    CheckPasswordStrength(password);
}

private void CheckPasswordStrength(string password)
{
    // 简单的密码强度检查逻辑
    if (password.Length == 0)
    {
        strengthDisplay.Text = "请输入密码";
        strengthDisplay.Foreground = Brushes.Gray;
    }
    else if (password.Length < 6)
    {
        strengthDisplay.Text = "密码太短";
        strengthDisplay.Foreground = Brushes.Red;
    }
    else if (password.Length < 8)
    {
        strengthDisplay.Text = "密码强度一般";
        strengthDisplay.Foreground = Brushes.Orange;
    }
    else
    {
        strengthDisplay.Text = "密码强度足够";
        strengthDisplay.Foreground = Brushes.Green;
    }
}

4.3 解决方案二：使用附加属性实现绑定

🔹 创建附加属性辅助类

public static class PasswordBoxHelper
{
    public static readonly DependencyProperty PasswordProperty =
        DependencyProperty.RegisterAttached(
            "Password",
            typeof(string),
            typeof(PasswordBoxHelper),
            new FrameworkPropertyMetadata(string.Empty, OnPasswordPropertyChanged));

    public static readonly DependencyProperty AttachProperty =
        DependencyProperty.RegisterAttached(
            "Attach",
            typeof(bool),
            typeof(PasswordBoxHelper),
            new PropertyMetadata(false, Attach));

    private static readonly DependencyProperty IsUpdatingProperty =
        DependencyProperty.RegisterAttached(
            "IsUpdating",
            typeof(bool),
            typeof(PasswordBoxHelper));

    public static void SetAttach(DependencyObject dp, bool value)
    {
        dp.SetValue(AttachProperty, value);
    }

    public static bool GetAttach(DependencyObject dp)
    {
        return (bool)dp.GetValue(AttachProperty);
    }

    public static string GetPassword(DependencyObject dp)
    {
        return (string)dp.GetValue(PasswordProperty);
    }

    public static void SetPassword(DependencyObject dp, string value)
    {
        dp.SetValue(PasswordProperty, value);
    }

    private static bool GetIsUpdating(DependencyObject dp)
    {
        return (bool)dp.GetValue(IsUpdatingProperty);
    }

    private static void SetIsUpdating(DependencyObject dp, bool value)
    {
        dp.SetValue(IsUpdatingProperty, value);
    }

    private static void OnPasswordPropertyChanged(DependencyObject sender, DependencyPropertyChangedEventArgs e)
    {
        PasswordBox passwordBox = sender as PasswordBox;
        passwordBox.PasswordChanged -= PasswordChanged;

        if (!GetIsUpdating(passwordBox))
        {
            passwordBox.Password = (string)e.NewValue;
        }

        passwordBox.PasswordChanged += PasswordChanged;
    }

    private static void Attach(DependencyObject sender, DependencyPropertyChangedEventArgs e)
    {
        PasswordBox passwordBox = sender as PasswordBox;

        if (passwordBox == null)
            return;

        if ((bool)e.OldValue)
        {
            passwordBox.PasswordChanged -= PasswordChanged;
        }

        if ((bool)e.NewValue)
        {
            passwordBox.PasswordChanged += PasswordChanged;
        }
    }

    private static void PasswordChanged(object sender, RoutedEventArgs e)
    {
        PasswordBox passwordBox = sender as PasswordBox;
        SetIsUpdating(passwordBox, true);
        SetPassword(passwordBox, passwordBox.Password);
        SetIsUpdating(passwordBox, false);
    }
}

🔹 在 XAML 中使用附加属性绑定

<PasswordBox Name="BindablePasswordBox"
             Height="35"
             Margin="10"
             local:PasswordBoxHelper.Attach="True"
             local:PasswordBoxHelper.Password="{Binding UserPassword, Mode=TwoWay, UpdateSourceTrigger=PropertyChanged}"/>

4.4 解决方案三：使用行为（Behavior）

🔹 需要安装 Microsoft.Xaml.Behaviors.Wpf

<PasswordBox Height="35" Margin="10">
    <i:Interaction.Behaviors>
        <local:PasswordBoxBindingBehavior Password="{Binding UserPassword, Mode=TwoWay}"/>
    </i:Interaction.Behaviors>
</PasswordBox>

public class PasswordBoxBindingBehavior : Behavior<PasswordBox>
{
    public static readonly DependencyProperty PasswordProperty =
        DependencyProperty.Register(
            "Password",
            typeof(string),
            typeof(PasswordBoxBindingBehavior),
            new FrameworkPropertyMetadata(string.Empty, FrameworkPropertyMetadataOptions.BindsTwoWayByDefault, OnPasswordPropertyChanged));

    public string Password
    {
        get { return (string)GetValue(PasswordProperty); }
        set { SetValue(PasswordProperty, value); }
    }

    protected override void OnAttached()
    {
        base.OnAttached();
        AssociatedObject.PasswordChanged += PasswordBox_PasswordChanged;
    }

    protected override void OnDetaching()
    {
        base.OnDetaching();
        AssociatedObject.PasswordChanged -= PasswordBox_PasswordChanged;
    }

    private void PasswordBox_PasswordChanged(object sender, RoutedEventArgs e)
    {
        Password = AssociatedObject.Password;
    }

    private static void OnPasswordPropertyChanged(DependencyObject d, DependencyPropertyChangedEventArgs e)
    {
        var behavior = d as PasswordBoxBindingBehavior;
        if (behavior != null && behavior.AssociatedObject != null)
        {
            if (!behavior.AssociatedObject.Password.Equals(e.NewValue))
            {
                behavior.AssociatedObject.Password = e.NewValue as string;
            }
        }
    }
}

5. 完整登录系统实现

5.1 完整的登录界面

<Window x:Class="WpfApp.LoginWindow"
        xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
        Title="用户登录"
        Height="400"
        Width="350"
        WindowStartupLocation="CenterScreen"
        ResizeMode="NoResize">

    <Grid Background="#F5F5F5">
        <Border Background="White"
                Margin="30"
                CornerRadius="10"
                BorderBrush="#E0E0E0"
                BorderThickness="1"
                Padding="30">

            <StackPanel>
                <!-- 标题 -->
                <TextBlock Text="用户登录"
                           FontSize="24"
                           FontWeight="Bold"
                           HorizontalAlignment="Center"
                           Margin="0,0,0,30"
                           Foreground="#333"/>

                <!-- 用户名输入 -->
                <TextBlock Text="用户名"
                           FontWeight="SemiBold"
                           Margin="0,0,0,5"
                           Foreground="#666"/>
                <TextBox Name="UsernameTextBox"
                         Height="40"
                         Padding="10"
                         FontSize="14"
                         BorderBrush="#DDD"
                         BorderThickness="1"
                         Background="#FAFAFA"/>

                <!-- 密码输入 -->
                <TextBlock Text="密码"
                           FontWeight="SemiBold"
                           Margin="0,15,0,5"
                           Foreground="#666"/>
                <PasswordBox Name="LoginPasswordBox"
                             Height="40"
                             PasswordChar="●"
                             Padding="10"
                             FontSize="14"
                             BorderBrush="#DDD"
                             BorderThickness="1"
                             Background="#FAFAFA"
                             PasswordChanged="LoginPasswordBox_PasswordChanged"/>

                <!-- 密码强度提示 -->
                <TextBlock Name="PasswordStrengthText"
                           FontSize="11"
                           Margin="0,5,0,0"
                           HorizontalAlignment="Right"/>

                <!-- 记住密码选项 -->
                <CheckBox Name="RememberPasswordCheckBox"
                          Content="记住密码"
                          Margin="0,20,0,10"
                          Foreground="#666"/>

                <!-- 登录按钮 -->
                <Button Content="登录"
                        Height="45"
                        Background="#2196F3"
                        Foreground="White"
                        FontSize="16"
                        FontWeight="SemiBold"
                        BorderThickness="0"
                        Cursor="Hand"
                        Click="LoginButton_Click"
                        Margin="0,10,0,0"/>

                <!-- 注册链接 -->
                <TextBlock Text="没有账号？立即注册"
                           HorizontalAlignment="Center"
                           Margin="0,20,0,0"
                           Foreground="#2196F3"
                           Cursor="Hand"
                           TextDecorations="Underline"
                           MouseLeftButtonDown="RegisterText_MouseLeftButtonDown"/>
            </StackPanel>
        </Border>
    </Grid>
</Window>

5.2 后台逻辑实现

public partial class LoginWindow : Window
{
    public LoginWindow()
    {
        InitializeComponent();

        // 设置焦点到用户名输入框
        UsernameTextBox.Focus();
    }

    private void LoginPasswordBox_PasswordChanged(object sender, RoutedEventArgs e)
    {
        UpdatePasswordStrength(LoginPasswordBox.Password);
    }

    private void UpdatePasswordStrength(string password)
    {
        if (string.IsNullOrEmpty(password))
        {
            PasswordStrengthText.Text = "";
            return;
        }

        // 简单的密码强度评估
        int strength = 0;

        // 长度检查
        if (password.Length >= 8) strength++;
        if (password.Length >= 12) strength++;

        // 复杂度检查
        if (password.Any(char.IsUpper)) strength++;
        if (password.Any(char.IsLower)) strength++;
        if (password.Any(char.IsDigit)) strength++;
        if (password.Any(ch => !char.IsLetterOrDigit(ch))) strength++;

        // 更新显示
        switch (strength)
        {
            case 0:
            case 1:
                PasswordStrengthText.Text = "密码强度: 弱";
                PasswordStrengthText.Foreground = Brushes.Red;
                break;
            case 2:
            case 3:
                PasswordStrengthText.Text = "密码强度: 中";
                PasswordStrengthText.Foreground = Brushes.Orange;
                break;
            case 4:
            case 5:
                PasswordStrengthText.Text = "密码强度: 强";
                PasswordStrengthText.Foreground = Brushes.Green;
                break;
            default:
                PasswordStrengthText.Text = "密码强度: 很强";
                PasswordStrengthText.Foreground = Brushes.DarkGreen;
                break;
        }
    }

    private void LoginButton_Click(object sender, RoutedEventArgs e)
    {
        string username = UsernameTextBox.Text;
        string password = LoginPasswordBox.Password;

        // 输入验证
        if (string.IsNullOrWhiteSpace(username))
        {
            MessageBox.Show("请输入用户名", "提示", MessageBoxButton.OK, MessageBoxImage.Warning);
            UsernameTextBox.Focus();
            return;
        }

        if (string.IsNullOrEmpty(password))
        {
            MessageBox.Show("请输入密码", "提示", MessageBoxButton.OK, MessageBoxImage.Warning);
            LoginPasswordBox.Focus();
            return;
        }

        // 模拟登录验证
        bool loginSuccess = AuthenticateUser(username, password);

        if (loginSuccess)
        {
            // 登录成功处理
            MessageBox.Show("登录成功！", "成功", MessageBoxButton.OK, MessageBoxImage.Information);

            // 如果选择了记住密码，保存相关信息
            if (RememberPasswordCheckBox.IsChecked == true)
            {
                SaveLoginInfo(username);
            }

            // 打开主窗口
            MainWindow mainWindow = new MainWindow();
            mainWindow.Show();
            this.Close();
        }
        else
        {
            // 登录失败处理
            MessageBox.Show("用户名或密码错误", "登录失败", MessageBoxButton.OK, MessageBoxImage.Error);
            LoginPasswordBox.Password = ""; // 清空密码框
            LoginPasswordBox.Focus();
        }
    }

    private bool AuthenticateUser(string username, string password)
    {
        // 这里应该是实际的用户验证逻辑
        // 例如：数据库查询、API调用等

        // 模拟验证 - 实际项目中需要替换为真实逻辑
        return username == "admin" && password == "123456";
    }

    private void SaveLoginInfo(string username)
    {
        // 保存登录信息的逻辑
        // 注意：实际项目中密码不应该明文保存
        Properties.Settings.Default.LastUsername = username;
        Properties.Settings.Default.RememberPassword = true;
        Properties.Settings.Default.Save();
    }

    private void RegisterText_MouseLeftButtonDown(object sender, MouseButtonEventArgs e)
    {
        // 打开注册窗口
        RegisterWindow registerWindow = new RegisterWindow();
        registerWindow.ShowDialog();
    }
}

6. 安全最佳实践

6.1 密码安全处理

🔹 不要在代码中硬编码密码

// 错误做法
string hardcodedPassword = "myPassword123";

// 正确做法 - 从安全配置中获取
string passwordFromConfig = ConfigurationManager.AppSettings["EncryptedPassword"];

🔹 使用安全字符串

using System.Security;

private SecureString GetSecurePassword(PasswordBox passwordBox)
{
    return passwordBox.SecurePassword;
}

private void ProcessSecurePassword(PasswordBox passwordBox)
{
    SecureString securePassword = passwordBox.SecurePassword;

    // 使用安全字符串进行处理
    IntPtr unmanagedString = IntPtr.Zero;
    try
    {
        unmanagedString = Marshal.SecureStringToGlobalAllocUnicode(securePassword);
        string password = Marshal.PtrToStringUni(unmanagedString);

        // 处理密码...
    }
    finally
    {
        Marshal.ZeroFreeGlobalAllocUnicode(unmanagedString);
    }
}

6.2 输入验证

🔹 客户端验证

private bool ValidatePasswordInput(string password)
{
    if (string.IsNullOrEmpty(password))
    {
        ShowValidationError("密码不能为空");
        return false;
    }

    if (password.Length < 6)
    {
        ShowValidationError("密码长度至少6位");
        return false;
    }

    if (password.Length > 20)
    {
        ShowValidationError("密码长度不能超过20位");
        return false;
    }

    // 更多验证规则...
    return true;
}

private void ShowValidationError(string message)
{
    // 显示验证错误信息
    ValidationTextBlock.Text = message;
    ValidationTextBlock.Foreground = Brushes.Red;
    ValidationTextBlock.Visibility = Visibility.Visible;
}

7. 高级功能扩展

7.1 显示/隐藏密码功能

<Grid Width="300" Height="40" Margin="10">
    <Grid.ColumnDefinitions>
        <ColumnDefinition Width="*"/>
        <ColumnDefinition Width="Auto"/>
    </Grid.ColumnDefinitions>

    <PasswordBox Name="TogglePasswordBox"
                 Grid.Column="0"
                 PasswordChar="●"
                 Padding="10,8"/>

    <Button Grid.Column="1"
            Content="👁️"
            Width="40"
            Background="Transparent"
            BorderThickness="0"
            Click="TogglePasswordVisibility_Click"
            ToolTip="显示/隐藏密码"/>
</Grid>

private void TogglePasswordVisibility_Click(object sender, RoutedEventArgs e)
{
    // 切换密码显示/隐藏的逻辑
    // 注意：实际实现需要更复杂的处理
}

7.2 密码生成器

<StackPanel Margin="20" Width="300">
    <PasswordBox Name="GeneratedPasswordBox"
                 Height="35"
                 PasswordChar="●"
                 Margin="0,0,0,10"/>

    <Button Content="生成随机密码"
            Click="GenerateRandomPassword_Click"
            Height="30"/>
</StackPanel>

private void GenerateRandomPassword_Click(object sender, RoutedEventArgs e)
{
    string randomPassword = GenerateSecurePassword(12);
    GeneratedPasswordBox.Password = randomPassword;
}

private string GenerateSecurePassword(int length)
{
    const string validChars = "abcdefghijklmnopqrstuvwxyzABCDEFGHIJKLMNOPQRSTUVWXYZ1234567890!@#$%^&*";
    StringBuilder result = new StringBuilder();
    Random random = new Random();

    for (int i = 0; i < length; i++)
    {
        result.Append(validChars[random.Next(validChars.Length)]);
    }

    return result.ToString();
}
