主要依照springSecurity用户名密码登录的认证流程来重写短信认证流程，不清楚springSecurity的认证流程的先建议熟悉一下springSecurity认证流程，这样对短信认证登录就比较好理解。

这里有个认证流程讲解可以参考参考https://blog.csdn.net/yuanlaijike/article/details/84703690

后端:

ruoyi-admin模块

一、增加生成验证码类

位置：GenerateSms.java

a.预览图：

b.详细代码：

package com.ruoyi.web.controller.system;

import com.ruoyi.common.constant.Constants;
import com.ruoyi.common.core.domain.AjaxResult;
import com.ruoyi.common.core.domain.model.LoginBody;
import com.ruoyi.common.core.redis.RedisCache;
import com.ruoyi.common.utils.uuid.IdUtils;
import io.swagger.annotations.Api;
import io.swagger.annotations.ApiImplicitParam;
import io.swagger.annotations.ApiOperation;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Controller;
import org.springframework.web.bind.annotation.PostMapping;
import org.springframework.web.bind.annotation.RequestBody;
import org.springframework.web.bind.annotation.RequestParam;
import org.springframework.web.bind.annotation.ResponseBody;

import java.util.HashMap;
import java.util.Map;
import java.util.concurrent.TimeUnit;

@Api("生成验证码接口")
@Controller
public class GenerateSms {
    @Autowired
    private RedisCache redisCache;

    private Logger logger = LoggerFactory.getLogger(getClass());


    @ApiOperation("生成验证码")
    @ApiImplicitParam(name = "mobile",value = "手机号码",required = true,dataType = "String",paramType = "query")
    @PostMapping("/sms/code")
    @ResponseBody
    public AjaxResult sms(@RequestBody LoginBody loginBody) {

        String mobile=loginBody.getMobile();
        // 保存验证码信息
        String uuid = IdUtils.simpleUUID();
        String verifyKey = Constants.SMS_CAPTCHA_CODE_KEY + uuid;

        int code = (int) Math.ceil(Math.random() * 9000 + 1000);
        Map<String, Object> map = new HashMap<>(16);
        map.put("mobile", mobile);
        map.put("code", code);

        redisCache.setCacheObject(verifyKey, map, Constants.SMS_EXPIRATION, TimeUnit.MINUTES);
//        session.setAttribute("smsCode", map);

        logger.info(" 为 {} 设置短信验证码：{}", mobile, code);
        AjaxResult ajax = AjaxResult.success();
        ajax.put("uuid", uuid);
        return ajax;
    }

}

二、添加手机号登录映射

位置：SysLoginController.java

a.预览图：

详细代码：

    /**
     * 手机号登录方法
     *
     * @param
     * @return 结果
     */
    @ApiOperation("手机号登录")
    @ApiImplicitParam(name = "loginBody", value = "登录信息", dataType = "LoginBody")
    @PostMapping("/sms/login")
    public AjaxResult smsLogin(@RequestBody LoginBody loginBody)
    {
        String mobile=loginBody.getMobile();
        String smsCode=loginBody.getSmsCode();
        String uuid=loginBody.getUuid();
        AjaxResult ajax = loginService.smsLogin(mobile, smsCode,
                uuid);
        return ajax;
    }

ruoyi-common模块

一、增加手机号及短信验证码字段

位置：LoginBody.java

a.预览图：

b.详细代码：

    /**
     * 手机号
     */
    private String mobile;

    /**
     * 手机验证码
     */
    private String smsCode;



    public String getMobile() {
        return mobile;
    }

    public void setMobile(String mobile) {
        this.mobile = mobile;
    }

    public String getSmsCode() {
        return smsCode;
    }

    public void setSmsCode(String smsCode) {
        this.smsCode = smsCode;
    }

二、添加相关常量

位置：Constants.java

a.预览图：

b.详细代码：

    /**
     * 短信验证码 redis key
     */
    public static final String SMS_CAPTCHA_CODE_KEY = "sms_captcha_codes:";


    /**
     * 短信验证码有效期（分钟）
     */
    public static final Integer SMS_EXPIRATION = 1;

ruoyi-framework模块

一、添加手机号登录验证方法

位置：SysLoginService.java

a.预览图：

b.详细代码：

    /**
     * 手机号登录验证
     *
     * @param mobile 手机号
     * @param code 验证码
     * @param uuid 唯一标识
     * @return 结果
     */

    public AjaxResult smsLogin(String mobile, String code, String uuid)
    {

        // 用户验证
        Authentication authentication = null;
        try
        {
            checkSmsCode(mobile,code,uuid);

            // 该方法会去调用UserDetailsServiceImpl.loadUserByUsername
            authentication = authenticationManager
                    .authenticate(new SmsCodeAuthenticationToken(mobile));
        }
        catch (Exception e)
        {

                AsyncManager.me().execute(AsyncFactory.recordLogininfor(mobile, Constants.LOGIN_FAIL, e.getMessage()));
                throw new CustomException(e.getMessage());

        }
        AsyncManager.me().execute(AsyncFactory.recordLogininfor(mobile, Constants.LOGIN_SUCCESS, MessageUtils.message("user.login.success")));
        LoginUser loginUser = (LoginUser) authentication.getPrincipal();
        AjaxResult ajax = AjaxResult.success();

        // 生成token
        String token = tokenService.createToken(loginUser);
        ajax.put(Constants.TOKEN, token);
        return  ajax;
    }

    /**
     * 检查手机号登录
     * @param
     */
    private void checkSmsCode(String mobile,String inputCode, String uuid) {

        String verifyKey = Constants.SMS_CAPTCHA_CODE_KEY + uuid;

        Map<String, Object> smsCode =  redisCache.getCacheObject(verifyKey);
//        redisCache.deleteObject(verifyKey);
        if(StringUtils.isEmpty(inputCode)){
            throw new BadCredentialsException("验证码不能为空");
        }

        if(smsCode == null) {
            throw new BadCredentialsException("验证码失效");
        }

        String applyMobile = (String) smsCode.get("mobile");
        int code = (int) smsCode.get("code");

        if(!applyMobile.equals(mobile)) {
            throw new BadCredentialsException("手机号码不一致");
        }
        if(code != Integer.parseInt(inputCode)) {
            throw new BadCredentialsException("验证码错误");
        }
    }

二、增加短信配置及相关文件

前提条件：

在com.ruoyi.framework下创建smsConfig包，结构如下：

com.ruoyi.framework.smsConfig

1.CustomAuthenticationFailureHandler.java

a.预览图：

b.详细代码：

package com.ruoyi.framework.smsConfig;

import com.fasterxml.jackson.databind.ObjectMapper;
import com.ruoyi.common.core.domain.AjaxResult;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.http.HttpStatus;
import org.springframework.security.authentication.BadCredentialsException;
import org.springframework.security.core.AuthenticationException;
import org.springframework.security.web.authentication.AuthenticationFailureHandler;
import org.springframework.stereotype.Component;

import javax.servlet.ServletException;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import java.io.IOException;

@Component
public class CustomAuthenticationFailureHandler implements AuthenticationFailureHandler {
    @Autowired
    private ObjectMapper objectMapper;

    private Logger logger = LoggerFactory.getLogger(getClass());

    @Override
    public void onAuthenticationFailure(HttpServletRequest request, HttpServletResponse response, AuthenticationException exception) throws IOException, ServletException {
        logger.info("登陆失败");

        response.setStatus(HttpStatus.INTERNAL_SERVER_ERROR.value());
        response.setContentType("application/json;charset=UTF-8");
        AjaxResult ajax = AjaxResult.error(exception.getMessage());

        if (exception instanceof BadCredentialsException)
        {
            response.getWriter().write(objectMapper.writeValueAsString(ajax));
        }
//        response.getWriter().write(objectMapper.writeValueAsString(exception.getMessage()));
    }
}

2.CustomAuthenticationSuccessHandler.java

a.预览图：

b.详细代码：

package com.ruoyi.framework.smsConfig;

import com.fasterxml.jackson.databind.ObjectMapper;
import com.ruoyi.common.constant.Constants;
import com.ruoyi.common.core.domain.AjaxResult;
import com.ruoyi.common.core.domain.model.LoginUser;
import com.ruoyi.framework.web.service.TokenService;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.security.core.Authentication;
import org.springframework.security.web.authentication.AuthenticationSuccessHandler;
import org.springframework.stereotype.Component;

import javax.servlet.ServletException;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import java.io.IOException;

@Component
public class CustomAuthenticationSuccessHandler implements AuthenticationSuccessHandler {
    @Autowired
    private ObjectMapper objectMapper;
    @Autowired
    TokenService tokenService;

    private Logger logger = LoggerFactory.getLogger(getClass());

    @Override
    public void onAuthenticationSuccess(HttpServletRequest request, HttpServletResponse response, Authentication authentication) throws IOException, ServletException {
        logger.info("登录成功");

        AjaxResult ajax = AjaxResult.success();
        LoginUser loginUser = (LoginUser) authentication.getPrincipal();
        String token = tokenService.createToken(loginUser);
        ajax.put(Constants.TOKEN, token);

        response.setContentType("application/json;charset=UTF-8");
//        response.getWriter().write(objectMapper.writeValueAsString(tokenService.createToken(loginUser)));
        response.getWriter().write(objectMapper.writeValueAsString(ajax));
    }
}

3.SmsCodeAuthenticationFilter.java

a.预览图：

b.详细代码：

package com.ruoyi.framework.smsConfig;

import org.springframework.security.authentication.AuthenticationServiceException;
import org.springframework.security.core.Authentication;
import org.springframework.security.core.AuthenticationException;
import org.springframework.security.web.authentication.AbstractAuthenticationProcessingFilter;
import org.springframework.security.web.util.matcher.AntPathRequestMatcher;
import org.springframework.util.Assert;

import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;

/**
 * 短信登录的鉴权过滤器，模仿 UsernamePasswordAuthenticationFilter 实现
 */
public class SmsCodeAuthenticationFilter extends AbstractAuthenticationProcessingFilter {
    /**
     * 手机号码的字段name
     */
    public static final String SPRING_SECURITY_FORM_MOBILE_KEY = "mobile";

    private String mobileParameter = SPRING_SECURITY_FORM_MOBILE_KEY;
    /**
     * 是否仅 POST 方式
     */
    private boolean postOnly = true;

    public SmsCodeAuthenticationFilter() {
        // 短信登录的请求 post 方式的 /sms/login
        super(new AntPathRequestMatcher("/sms/login", "POST"));
    }

    @Override
    public Authentication attemptAuthentication(HttpServletRequest request, HttpServletResponse response) throws AuthenticationException {
        if (postOnly && !request.getMethod().equals("POST")) {
            throw new AuthenticationServiceException(
                    "Authentication method not supported: " + request.getMethod());
        }

        String mobile = obtainMobile(request);

        if (mobile == null) {
            mobile = "";
        }

        mobile = mobile.trim();

        SmsCodeAuthenticationToken authRequest = new SmsCodeAuthenticationToken(mobile);

        // Allow subclasses to set the "details" property
        setDetails(request, authRequest);

        return this.getAuthenticationManager().authenticate(authRequest);
    }

    protected String obtainMobile(HttpServletRequest request) {
        return request.getParameter(mobileParameter);
    }

    protected void setDetails(HttpServletRequest request, SmsCodeAuthenticationToken authRequest) {
        authRequest.setDetails(authenticationDetailsSource.buildDetails(request));
    }

    public String getMobileParameter() {
        return mobileParameter;
    }

    public void setMobileParameter(String mobileParameter) {
        Assert.hasText(mobileParameter, "Mobile parameter must not be empty or null");
        this.mobileParameter = mobileParameter;
    }

    public void setPostOnly(boolean postOnly) {
        this.postOnly = postOnly;
    }
}

4.SmsCodeAuthenticationProvider.java

a.预览图：

b.详细代码：

package com.ruoyi.framework.smsConfig;

import com.ruoyi.common.constant.Constants;
import com.ruoyi.common.core.redis.RedisCache;
import org.springframework.security.authentication.AuthenticationProvider;
import org.springframework.security.authentication.BadCredentialsException;
import org.springframework.security.core.Authentication;
import org.springframework.security.core.AuthenticationException;
import org.springframework.security.core.userdetails.UserDetails;
import org.springframework.security.core.userdetails.UserDetailsService;
import org.springframework.web.context.request.RequestContextHolder;
import org.springframework.web.context.request.ServletRequestAttributes;

import javax.servlet.http.HttpServletRequest;
import java.util.Map;

/**
 * 短信登陆鉴权 Provider，要求实现 AuthenticationProvider 接口
 *
 */

public class SmsCodeAuthenticationProvider implements AuthenticationProvider {

    private UserDetailsService userDetailsService;



    @Override
    public Authentication authenticate(Authentication authentication) throws AuthenticationException {
        SmsCodeAuthenticationToken authenticationToken = (SmsCodeAuthenticationToken) authentication;

        String mobile = (String) authenticationToken.getPrincipal();

//        checkSmsCode(mobile);

        UserDetails userDetails = userDetailsService.loadUserByUsername(mobile);

        // 此时鉴权成功后，应当重新 new 一个拥有鉴权的 authenticationResult 返回
        SmsCodeAuthenticationToken authenticationResult = new SmsCodeAuthenticationToken(userDetails, userDetails.getAuthorities());

        authenticationResult.setDetails(authenticationToken.getDetails());

        return authenticationResult;
    }

    private void checkSmsCode(String mobile) {
        RedisCache redisCache = (RedisCache) SpringContextUtil.getBean("redisCache");

        HttpServletRequest request = ((ServletRequestAttributes) RequestContextHolder.getRequestAttributes()).getRequest();
        String inputCode = request.getParameter("smsCode");
        String uuid = request.getParameter("uuid");

        String verifyKey = Constants.SMS_CAPTCHA_CODE_KEY + uuid;

        Map<String, Object> smsCode =   redisCache.getCacheObject(verifyKey);
//        redisCache.deleteObject(verifyKey);

         if(smsCode == null) {
            throw new BadCredentialsException("验证码失效");
        }

        String applyMobile = (String) smsCode.get("mobile");
        int code = (int) smsCode.get("code");

        if(!applyMobile.equals(mobile)) {
            throw new BadCredentialsException("手机号码不一致");
        }
        if(code != Integer.parseInt(inputCode)) {
            throw new BadCredentialsException("验证码错误");
        }
    }

    @Override
    public boolean supports(Class<?> authentication) {
        // 判断 authentication 是不是 SmsCodeAuthenticationToken 的子类或子接口
        return SmsCodeAuthenticationToken.class.isAssignableFrom(authentication);
    }

    public UserDetailsService getUserDetailsService() {
        return userDetailsService;
    }

    public void setUserDetailsService(UserDetailsService userDetailsService) {
        this.userDetailsService = userDetailsService;
    }
}

5.SmsCodeAuthenticationSecurityConfig.java

a.预览图：

b.详细代码：

package com.ruoyi.framework.smsConfig;

import com.ruoyi.framework.web.service.SmsUserDetailsServiceImpl;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.security.config.annotation.SecurityConfigurerAdapter;
import org.springframework.security.config.annotation.web.builders.HttpSecurity;
import org.springframework.security.web.DefaultSecurityFilterChain;
import org.springframework.stereotype.Component;

@Component
public class SmsCodeAuthenticationSecurityConfig extends SecurityConfigurerAdapter<DefaultSecurityFilterChain, HttpSecurity> {
    @Autowired
    private SmsUserDetailsServiceImpl userDetailsService;
    @Autowired
    private CustomAuthenticationSuccessHandler customAuthenticationSuccessHandler;
    @Autowired
    private CustomAuthenticationFailureHandler customAuthenticationFailureHandler;

    @Override
    public void configure(HttpSecurity http) throws Exception {
      /*  SmsCodeAuthenticationFilter smsCodeAuthenticationFilter = new SmsCodeAuthenticationFilter();
        smsCodeAuthenticationFilter.setAuthenticationManager(http.getSharedObject(AuthenticationManager.class));
        smsCodeAuthenticationFilter.setAuthenticationSuccessHandler(customAuthenticationSuccessHandler);
        smsCodeAuthenticationFilter.setAuthenticationFailureHandler(customAuthenticationFailureHandler);
*/
        SmsCodeAuthenticationProvider smsCodeAuthenticationProvider = new  SmsCodeAuthenticationProvider();
        smsCodeAuthenticationProvider.setUserDetailsService(userDetailsService);

        http.authenticationProvider(smsCodeAuthenticationProvider);
     /*   http.authenticationProvider(smsCodeAuthenticationProvider)
                .addFilterAfter(smsCodeAuthenticationFilter, UsernamePasswordAuthenticationFilter.class);*/
    }
}

6.SmsCodeAuthenticationToken.java

a.预览图：

b.详细代码：

package com.ruoyi.framework.smsConfig;

import org.springframework.security.authentication.AbstractAuthenticationToken;
import org.springframework.security.core.GrantedAuthority;
import org.springframework.security.core.SpringSecurityCoreVersion;

import java.util.Collection;

/**
 * 短信登录 AuthenticationToken，模仿 UsernamePasswordAuthenticationToken 实现
 */
public class SmsCodeAuthenticationToken extends AbstractAuthenticationToken {

    private static final long serialVersionUID = SpringSecurityCoreVersion.SERIAL_VERSION_UID;

    /**
     * 在 UsernamePasswordAuthenticationToken 中该字段代表登录的用户名，
     * 在这里就代表登录的手机号码
     */
    private final Object principal;

    /**
     * 构建一个没有鉴权的 SmsCodeAuthenticationToken
     */
    public SmsCodeAuthenticationToken(Object principal) {
        super(null);
        this.principal = principal;
        setAuthenticated(false);
    }

    /**
     * 构建拥有鉴权的 SmsCodeAuthenticationToken
     */
    public SmsCodeAuthenticationToken(Object principal, Collection<? extends GrantedAuthority> authorities) {
        super(authorities);
        this.principal = principal;
        // must use super, as we override
        super.setAuthenticated(true);
    }

    @Override
    public Object getCredentials() {
        return null;
    }

    @Override
    public Object getPrincipal() {
        return this.principal;
    }

    @Override
    public void setAuthenticated(boolean isAuthenticated) throws IllegalArgumentException {
        if (isAuthenticated) {
            throw new IllegalArgumentException(
                    "Cannot set this token to trusted - use constructor which takes a GrantedAuthority list instead");
        }

        super.setAuthenticated(false);
    }

    @Override
    public void eraseCredentials() {
        super.eraseCredentials();
    }
}

7.SpringContextUtil.java

a.预览图：

b.详细代码：

package com.ruoyi.framework.smsConfig;

import org.springframework.beans.BeansException;
import org.springframework.context.ApplicationContext;
import org.springframework.context.ApplicationContextAware;
import org.springframework.stereotype.Component;

@Component
public class SpringContextUtil implements ApplicationContextAware {
    //     Spring应用上下文环境
    private static ApplicationContext applicationContext;

    /**
     * 实现ApplicationContextAware接口的回调方法，设置上下文环境
     *
     * @param applicationContext
     */
    @Override
    public void setApplicationContext(ApplicationContext applicationContext) {
        SpringContextUtil.applicationContext = applicationContext;
    }

    /**
     * @return ApplicationContext
     */
    public static ApplicationContext getApplicationContext() {
        return applicationContext;
    }

    /**
     * 获取对象
     * 这里重写了bean方法，起主要作用
     * @param name
     * @return Object 一个以所给名字注册的bean的实例
     * @throws BeansException
     */
    public static Object getBean(String name) throws BeansException {
        return applicationContext.getBean(name);
    }
    public static <T> T getBean(Class<T> requiredType) {

        return applicationContext.getBean(requiredType);
    }

}

三、service包增加短信登录实现类

位置：SmsUserDetailsServiceImpl.java

a.预览图：

b.详细代码：

package com.ruoyi.framework.web.service;

import com.ruoyi.common.core.domain.entity.SysUser;
import com.ruoyi.common.core.domain.model.LoginUser;
import com.ruoyi.common.enums.UserStatus;
import com.ruoyi.common.exception.BaseException;
import com.ruoyi.common.utils.StringUtils;
import com.ruoyi.system.service.ISysUserService;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.security.core.userdetails.UserDetails;
import org.springframework.security.core.userdetails.UserDetailsService;
import org.springframework.security.core.userdetails.UsernameNotFoundException;
import org.springframework.stereotype.Service;

/**
 * 用户验证处理
 *
 * @author ruoyi
 */
@Service
public class SmsUserDetailsServiceImpl implements UserDetailsService
{
    private static final Logger log = LoggerFactory.getLogger(UserDetailsServiceImpl.class);

    @Autowired
    private ISysUserService userService;

    @Autowired
    private SysPermissionService permissionService;

    @Override
    public UserDetails loadUserByUsername(String phone) throws UsernameNotFoundException
    {
        SysUser user = userService.selectUserByPhone(phone);
        if (StringUtils.isNull(user))
        {
            log.info("登录手机号：{} 不存在.", phone);
            throw new UsernameNotFoundException("登录手机号：" + phone + " 不存在");
        }
        else if (UserStatus.DELETED.getCode().equals(user.getDelFlag()))
        {
            log.info("登录用户：{} 已被删除.", phone);
            throw new BaseException("对不起，您的账号：" + phone + " 已被删除");
        }
        else if (UserStatus.DISABLE.getCode().equals(user.getStatus()))
        {
            log.info("登录用户：{} 已被停用.", phone);
            throw new BaseException("对不起，您的账号：" + phone + " 已停用");
        }

        return createLoginUser(user);
    }

    public UserDetails createLoginUser(SysUser user)
    {
        return new LoginUser(user, permissionService.getMenuPermission(user));
    }
}

四、service包下类增加@Primary注解

位置：UserDetailsServiceImpl.java

a.预览图：

b.详细代码：

package com.ruoyi.framework.web.service;

import com.ruoyi.common.core.domain.entity.SysUser;
import com.ruoyi.common.core.domain.model.LoginUser;
import com.ruoyi.common.enums.UserStatus;
import com.ruoyi.common.exception.BaseException;
import com.ruoyi.common.utils.StringUtils;
import com.ruoyi.system.service.ISysUserService;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.security.core.userdetails.UserDetails;
import org.springframework.security.core.userdetails.UserDetailsService;
import org.springframework.security.core.userdetails.UsernameNotFoundException;
import org.springframework.stereotype.Service;

/**
 * 用户验证处理
 *
 * @author ruoyi
 */
@Service
public class SmsUserDetailsServiceImpl implements UserDetailsService
{
    private static final Logger log = LoggerFactory.getLogger(UserDetailsServiceImpl.class);

    @Autowired
    private ISysUserService userService;

    @Autowired
    private SysPermissionService permissionService;

    @Override
    public UserDetails loadUserByUsername(String phone) throws UsernameNotFoundException
    {
        SysUser user = userService.selectUserByPhone(phone);
        if (StringUtils.isNull(user))
        {
            log.info("登录手机号：{} 不存在.", phone);
            throw new UsernameNotFoundException("登录手机号：" + phone + " 不存在");
        }
        else if (UserStatus.DELETED.getCode().equals(user.getDelFlag()))
        {
            log.info("登录用户：{} 已被删除.", phone);
            throw new BaseException("对不起，您的账号：" + phone + " 已被删除");
        }
        else if (UserStatus.DISABLE.getCode().equals(user.getStatus()))
        {
            log.info("登录用户：{} 已被停用.", phone);
            throw new BaseException("对不起，您的账号：" + phone + " 已停用");
        }

        return createLoginUser(user);
    }

    public UserDetails createLoginUser(SysUser user)
    {
        return new LoginUser(user, permissionService.getMenuPermission(user));
    }
}

五、添加注入配置及放行映射

位置：SecurityConfig.java

a.预览图：

b.详细代码：

package com.ruoyi.framework.config;

import com.ruoyi.framework.smsConfig.SmsCodeAuthenticationSecurityConfig;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.context.annotation.Bean;
import org.springframework.http.HttpMethod;
import org.springframework.security.authentication.AuthenticationManager;
import org.springframework.security.config.annotation.authentication.builders.AuthenticationManagerBuilder;
import org.springframework.security.config.annotation.method.configuration.EnableGlobalMethodSecurity;
import org.springframework.security.config.annotation.web.builders.HttpSecurity;
import org.springframework.security.config.annotation.web.configuration.WebSecurityConfigurerAdapter;
import org.springframework.security.config.http.SessionCreationPolicy;
import org.springframework.security.core.userdetails.UserDetailsService;
import org.springframework.security.crypto.bcrypt.BCryptPasswordEncoder;
import org.springframework.security.web.authentication.UsernamePasswordAuthenticationFilter;
import org.springframework.security.web.authentication.logout.LogoutFilter;
import org.springframework.web.filter.CorsFilter;
import com.ruoyi.framework.security.filter.JwtAuthenticationTokenFilter;
import com.ruoyi.framework.security.handle.AuthenticationEntryPointImpl;
import com.ruoyi.framework.security.handle.LogoutSuccessHandlerImpl;

/**
 * spring security配置
 *
 * @author ruoyi
 */
@EnableGlobalMethodSecurity(prePostEnabled = true, securedEnabled = true)
public class SecurityConfig extends WebSecurityConfigurerAdapter
{
    /**
     * 自定义用户认证逻辑
     */
    @Autowired
    private UserDetailsService userDetailsService;

    /**
     * 认证失败处理类
     */
    @Autowired
    private AuthenticationEntryPointImpl unauthorizedHandler;

    /**
     * 退出处理类
     */
    @Autowired
    private LogoutSuccessHandlerImpl logoutSuccessHandler;

    /**
     * token认证过滤器
     */
    @Autowired
    private JwtAuthenticationTokenFilter authenticationTokenFilter;

    /**
     * 跨域过滤器
     */
    @Autowired
    private CorsFilter corsFilter;

    @Autowired
    private SmsCodeAuthenticationSecurityConfig smsCodeAuthenticationSecurityConfig;

    /**
     * 解决 无法直接注入 AuthenticationManager
     *
     * @return
     * @throws Exception
     */
    @Bean
    @Override
    public AuthenticationManager authenticationManagerBean() throws Exception
    {
        return super.authenticationManagerBean();
    }

    /**
     * anyRequest          |   匹配所有请求路径
     * access              |   SpringEl表达式结果为true时可以访问
     * anonymous           |   匿名可以访问
     * denyAll             |   用户不能访问
     * fullyAuthenticated  |   用户完全认证可以访问（非remember-me下自动登录）
     * hasAnyAuthority     |   如果有参数，参数表示权限，则其中任何一个权限可以访问
     * hasAnyRole          |   如果有参数，参数表示角色，则其中任何一个角色可以访问
     * hasAuthority        |   如果有参数，参数表示权限，则其权限可以访问
     * hasIpAddress        |   如果有参数，参数表示IP地址，如果用户IP和参数匹配，则可以访问
     * hasRole             |   如果有参数，参数表示角色，则其角色可以访问
     * permitAll           |   用户可以任意访问
     * rememberMe          |   允许通过remember-me登录的用户访问
     * authenticated       |   用户登录后可访问
     */
    @Override
    protected void configure(HttpSecurity httpSecurity) throws Exception
    {
        httpSecurity
                .apply(smsCodeAuthenticationSecurityConfig).and()
                // CSRF禁用，因为不使用session
                .csrf().disable()
                // 认证失败处理类
                .exceptionHandling().authenticationEntryPoint(unauthorizedHandler).and()
                // 基于token，所以不需要session
                .sessionManagement().sessionCreationPolicy(SessionCreationPolicy.STATELESS).and()
                // 过滤请求
                .authorizeRequests()
                // 对于登录login 验证码captchaImage 允许匿名访问
                // 对于登录login 验证码captchaImage 允许匿名访问
                .antMatchers("/sms/**").permitAll()
                .antMatchers("/login", "/captchaImage").anonymous()
                .antMatchers(
                        HttpMethod.GET,
                        "/*.html",
                        "/**/*.html",
                        "/**/*.css",
                        "/**/*.js"
                ).permitAll()
                .antMatchers("/profile/**").anonymous()
                .antMatchers("/common/download**").anonymous()
                .antMatchers("/common/download/resource**").anonymous()
                .antMatchers("/swagger-ui.html").anonymous()
                .antMatchers("/swagger-resources/**").anonymous()
                .antMatchers("/webjars/**").anonymous()
                .antMatchers("/*/api-docs").anonymous()
                .antMatchers("/druid/**").anonymous()
                // 除上面外的所有请求全部需要鉴权认证
                .anyRequest().authenticated()
                .and()
                .headers().frameOptions().disable();
        httpSecurity.logout().logoutUrl("/logout").logoutSuccessHandler(logoutSuccessHandler);
        // 添加JWT filter
        httpSecurity.addFilterBefore(authenticationTokenFilter, UsernamePasswordAuthenticationFilter.class);
        // 添加CORS filter
        httpSecurity.addFilterBefore(corsFilter, JwtAuthenticationTokenFilter.class);
        httpSecurity.addFilterBefore(corsFilter, LogoutFilter.class);
    }


    /**
     * 强散列哈希加密实现
     */
    @Bean
    public BCryptPasswordEncoder bCryptPasswordEncoder()
    {
        return new BCryptPasswordEncoder();
    }

    /**
     * 身份认证接口
     */
    @Override
    protected void configure(AuthenticationManagerBuilder auth) throws Exception
    {
        auth.userDetailsService(userDetailsService).passwordEncoder(bCryptPasswordEncoder());
    }
}

ruoyi-system模块

一、添加手机号查询用户接口

位置：ISysUserService.java

a.预览图：

b.详细代码：

    /**
     * 通过手机号码查询用户
     *
     * @param phone 手机号
     * @return 用户对象信息
     */
    public SysUser selectUserByPhone(String phone);

二、添加手机号查询用户接口实现

位置：SysUserServiceImpl.java

a.预览图：

b.详细代码：

    /**
     * 通过手机号码查询用户
     *
     * @param phone 手机号
     * @return 用户对象信息
     */
    @Override
    public SysUser selectUserByPhone(String phone) {
        return userMapper.selectUserByPhone(phone);
    }

三、添加手机号查询用户mapper

位置：SysUserMapper.java

1a.预览图：

1b.详细代码：

    /**
     * 通过手机号码查询用户
     *
     * @param phone 手机号
     * @return 用户对象信息
     */
    public SysUser selectUserByPhone(String phone);

位置：SysUserMapper.xml

2a.预览图：

2b.详细代码：

	<select id="selectUserByPhone" parameterType="String" resultMap="SysUserResult">
		<include refid="selectUserVo"/>
		where u.phonenumber = #{phone}
	</select>

前端：

说明：

仅讲解核心部分代码，具体相关的页面随用户喜好

ruoyi-ui模块

增加短信登录和发送短信验证码方法

位置：login.js

a.预览图：

b.详细代码：

// 短信登录方法
export function smsLogin(mobile,smsCode,uuid) {
  const data = {
    mobile,
    smsCode,
    uuid
  }
  return request({
    url: '/sms/login',
    method: 'post',
    data: data
  })
}


// 发送短信验证码
export function getSmsCode(mobile) {

  const data = {
    mobile
  }

  return request({
    url: '/sms/code',
    method: 'post',
    data:data
  })
}

增加短信登录方法

位置：user.js

a.预览图：

b.详细代码：

    // 短信登录
    SmsLogin({ commit }, userInfo) {
      const mobile = userInfo.mobile.trim()
      const smsCode = userInfo.smsCode
      const uuid = userInfo.uuid
      return new Promise((resolve, reject) => {
        smsLogin( mobile, smsCode, uuid).then(res => {
          setToken(res.token)
          commit('SET_TOKEN', res.token)
          resolve()
        }).catch(error => {
          reject(error)
        })
      })
    }

增加发送短信验证码和短信登录逻辑

位置：login.vue

预览图：

无

b.详细代码：

<template>
  <div class="login">
    <el-form ref="loginForm" :model="loginForm" :rules="loginRules" class="login-form">
      <h3 class="title">若依后台管理系统</h3>
      <el-form-item prop="username" v-if="!isSmsLogin">
        <el-input v-model="loginForm.username" type="text" auto-complete="off" placeholder="账号">
          <svg-icon slot="prefix" icon-class="user" class="el-input__icon input-icon" />
        </el-input>
      </el-form-item>
      <el-form-item prop="password" v-if="!isSmsLogin">
        <el-input
          v-model="loginForm.password"
          type="password"
          auto-complete="off"
          placeholder="密码"
          @keyup.enter.native="handleLogin"
        >
          <svg-icon slot="prefix" icon-class="password" class="el-input__icon input-icon" />
        </el-input>
      </el-form-item>
      <el-form-item prop="code" v-if="!isSmsLogin">
        <el-input
          v-model="loginForm.code"
          auto-complete="off"
          placeholder="验证码"
          style="width: 63%"
          @keyup.enter.native="handleLogin"
        >
          <svg-icon slot="prefix" icon-class="validCode" class="el-input__icon input-icon" />
        </el-input>
        <div class="login-code">
          <img :src="codeUrl" @click="getCode" class="login-code-img"/>
        </div>
      </el-form-item>

      <el-form-item prop="mobile" v-if="isSmsLogin">
        <el-input v-model="loginForm.mobile" type="text" auto-complete="off" placeholder="手机号">
          <svg-icon slot="prefix" icon-class="user" class="el-input__icon input-icon" />
        </el-input>
      </el-form-item>
      <el-form-item prop="smsCode" v-if="isSmsLogin">
        <el-input
          v-model="loginForm.smsCode"
          auto-complete="off"
          placeholder="验证码"
          style="width: 63%"
          @keyup.enter.native="handleLogin"
        >
          <svg-icon slot="prefix" icon-class="validCode" class="el-input__icon input-icon" />
        </el-input>
        <div class="login-code">
          <el-button round @click.native.prevent="getSmsCode">{{computeTime>0 ? `(${computeTime}s)已发送` : '获取验证码'}}</el-button>
        </div>
      </el-form-item>

      <el-row>
        <el-checkbox v-model="loginForm.rememberMe" style="margin:0px 0px 25px 0px;">记住密码</el-checkbox>
        <div class="sms-login">
          <el-button
            size="mini"
            type="text"
            @click.native.prevent="loginMethod"
          >
            <span v-if="isSmsLogin">账号密码登录</span>
            <span v-else>短信登录</span>
          </el-button>
        </div>
      </el-row>

      <el-form-item style="width:100%;">
        <el-button
          :loading="loading"
          size="medium"
          type="primary"
          style="width:100%;"
          @click.native.prevent="handleLogin"
        >
          <span v-if="!loading">登 录</span>
          <span v-else>登 录 中...</span>
        </el-button>
      </el-form-item>
    </el-form>
    <!--  底部  -->
    <div class="el-login-footer">
      <span>Copyright © 2018-2020 ruoyi.vip All Rights Reserved.</span>
    </div>
  </div>
</template>

<script>
import { getCodeImg , getSmsCode , smsLogin } from "@/api/login";
import Cookies from "js-cookie";
import { encrypt, decrypt } from '@/utils/jsencrypt'

export default {
  name: "Login",
  data() {
    return {
      codeUrl: "",
      cookiePassword: "",
      computeTime: 0,
      loginForm: {
        username: "",
        password: "",
        rememberMe: false,
        code: "",
        uuid: "",
        mobile: "",
        smsCode: ""
      },
      loginRules: {
        username: [
          { required: true, trigger: "blur", message: "用户名不能为空" }
        ],
        mobile: [
          { required: true, trigger: "blur", message: "手机号不能为空" }
        ],
        password: [
          { required: true, trigger: "blur", message: "密码不能为空" }
        ],
        code: [{ required: true, trigger: "change", message: "验证码不能为空" }],
        // smsCode: [{ required: true, trigger: "blur", message: "验证码不能为空" }]
      },
      loading: false,
      isSmsLogin: false,
      redirect: undefined
    };
  },
  watch: {
    $route: {
      handler: function(route) {
        this.redirect = route.query && route.query.redirect;
      },
      immediate: true
    }
  },
  created() {
    this.getCode();
    this.getCookie();
  },
  methods: {
    loginMethod(){
      this.isSmsLogin = !this.isSmsLogin;
    },
    getSmsCode(){
      if (!this.computeTime) {
       this.$refs.loginForm.validate(valid => {
         if (valid) {
            getSmsCode(this.loginForm.mobile).then(res =>{
              if(res.code === 200){
                this.$message({
                        message: '验证码已发送',
                        type: 'success'
                      });
              this.loginForm.uuid = res.uuid;
              this.computeTime = 60;
              this.timer = setInterval(() => {
              	this.computeTime--;
              	if (this.computeTime <= 0) {
              		clearInterval(this.timer)
              	}
              }, 1000);
              }

            })
         }
      })
     }
    },
    getCode() {
      getCodeImg().then(res => {
        this.loginForm.uuid = res.uuid;
      });
    },
    getCookie() {
      const username = Cookies.get("username");
      const password = Cookies.get("password");
      const rememberMe = Cookies.get('rememberMe')
      this.loginForm = {
        username: username === undefined ? this.loginForm.username : username,
        password: password === undefined ? this.loginForm.password : decrypt(password),
        rememberMe: rememberMe === undefined ? false : Boolean(rememberMe)
      };
    },
    handleLogin() {
      this.$refs.loginForm.validate(valid => {
        if (valid) {
          if(this.isSmsLogin){
            this.loading = true;
            if (this.loginForm.rememberMe) {
              Cookies.set("mobile", this.loginForm.mobile, { expires: 30 });
              Cookies.set('rememberMe', this.loginForm.rememberMe, { expires: 30 });
            } else {
              Cookies.remove("mobile");
              Cookies.remove('rememberMe');
            }

            this.$store.dispatch("SmsLogin", this.codeLoginForm).then(() => {
              this.$router.push({ path: this.redirect || "/" }).catch(()=>{});
            }).catch(() => {
              this.loading = false;
            });
          }else{
            this.loading = true;
            if (this.loginForm.rememberMe) {
              Cookies.set("username", this.loginForm.username, { expires: 30 });
              Cookies.set("password", encrypt(this.loginForm.password), { expires: 30 });
              Cookies.set('rememberMe', this.loginForm.rememberMe, { expires: 30 });
            } else {
              Cookies.remove("username");
              Cookies.remove("password");
              Cookies.remove('rememberMe');
            }
            this.$store.dispatch("Login", this.loginForm).then(() => {
              this.$router.push({ path: this.redirect || "/" }).catch(()=>{});
            }).catch(() => {
              this.loading = false;
              this.getCode();
            });
          }
        }
      });
    }
  }
};
</script>

<style rel="stylesheet/scss" lang="scss">
.login {
  display: flex;
  justify-content: center;
  align-items: center;
  height: 100%;
  background-image: url("../assets/images/login-background.jpg");
  background-size: cover;
}
.title {
  margin: 0px auto 30px auto;
  text-align: center;
  color: #707070;
}

.login-form {
  border-radius: 6px;
  background: #ffffff;
  width: 400px;
  padding: 25px 25px 5px 25px;
  .el-input {
    height: 38px;
    input {
      height: 38px;
    }
  }
  .input-icon {
    height: 39px;
    width: 14px;
    margin-left: 2px;
  }
}
.login-tip {
  font-size: 13px;
  text-align: center;
  color: #bfbfbf;
}
.login-code {
  width: 33%;
  height: 38px;
  float: right;
  img {
    cursor: pointer;
    vertical-align: middle;
  }
}

.sms-login {
  width: 25%;
  height: 30px;
  float: right;


}
.el-login-footer {
  height: 40px;
  line-height: 40px;
  position: fixed;
  bottom: 0;
  width: 100%;
  text-align: center;
  color: #fff;
  font-family: Arial;
  font-size: 12px;
  letter-spacing: 1px;
}
.login-code-img {
  height: 38px;
}
</style>
