6.S081 Lab10: mmap

mmap

1. 注册系统调用：

   // user.h
   void *mmap(void *addr, uint64 length, int prot, int flags, int fd, uint64 offset);
   int munmap(void* addr, uint64 length);

   // syscall.h
   #define SYS_mmap   22
   #define SYS_munmap 23

   // syscall.c
   extern uint64 sys_mmap(void);
   extern uint64 sys_munmap(void);

   [SYS_mmap]    sys_mmap,
   [SYS_munmap]  sys_munmap,


   # usys.pl
   entry("mmap");
   entry("munmap");


   $U/_mmaptest\


2. 定义结构体VMA，宏NVMA，增加struct proc字段：

   // param.h
   #define NVMA         16

   // proc.h
   struct VMA {
       uint64 addr;
       uint64 length;
       int prot;
       int flags;
       struct file *file;
   };

   struct proc {
       struct spinlock lock;

       // p->lock must be held when using these:
       enum procstate state;        // Process state
       struct proc *parent;         // Parent process
       void *chan;                  // If non-zero, sleeping on chan
       int killed;                  // If non-zero, have been killed
       int xstate;                  // Exit status to be returned to parent's wait
       int pid;                     // Process ID

       // these are private to the process, so p->lock need not be held.
       uint64 kstack;               // Virtual address of kernel stack
       uint64 sz;                   // Size of process memory (bytes)
       pagetable_t pagetable;       // User page table
       struct trapframe *trapframe; // data page for trampoline.S
       struct context context;      // swtch() here to run process
       struct file *ofile[NOFILE];  // Open files
       struct inode *cwd;           // Current directory
       char name[16];               // Process name (debugging)
       struct VMA vmas[NVMA];
   };


3. 定义函数sys_mmap：

   uint64 sys_mmap(void) {
       uint64 addr, length, offset;
       int prot, flags, fd;
       struct file *file;
       struct proc *p = myproc();

       if(argaddr(0, &addr) || argaddr(1, &length) || argint(2, &prot)
       || argint(3, &flags) || argfd(4, &fd, &file) || argaddr(5, &offset))
           return -1;

       if(!file->writable)
           if(flags==MAP_SHARED && (prot&PROT_WRITE))
               return -1;

       for(int i = 0; i<NVMA; ++i) {
           if(!p->vmas[i].length) {
               p->vmas[i].addr = p->sz;
               p->vmas[i].length = length;
               p->vmas[i].prot  = prot;
               p->vmas[i].flags = flags;
               p->vmas[i].file = filedup(file);
               p->sz += length;

               return p->vmas[i].addr;
           }
       }

       panic("no free VMA");
   }


4. 修改函数uvmunmap、uvmcopy：

   /* if((*pte & PTE_V) == 0)
     panic("uvmunmap: not mapped"); */

   if((*pte & PTE_V) == 0)
     continue;


5. 修改函数usertrap：

   if(r_scause() == 8){
       // system call

       if(p->killed)
           exit(-1);

       // sepc points to the ecall instruction,
       // but we want to return to the next instruction.
       p->trapframe->epc += 4;

       // an interrupt will change sstatus &c registers,
       // so don't enable until done with those registers.
       intr_on();

       syscall();
   } else if((which_dev = devintr()) != 0){
       // ok
   } else if(r_scause()==13 || r_scause()==15) {
       uint64 va = r_stval();
       struct VMA *vma = 0;

       for(int i = 0; i<NVMA; ++i) {
           if(p->vmas[i].addr <= va
           && va < p->vmas[i].addr+p->vmas[i].length) {
               vma = &(p->vmas[i]);
               break;
           }
       }

       if(!vma)
           p->killed = 1;
       else {
           uint64 offset = va - vma->addr;
           uint64 pa = (uint64)kalloc();

           if(!pa)
               p->killed = 1;
           else {
               int flags = PTE_U;

               memset((void*)pa, 0, PGSIZE);

               ilock(vma->file->ip);
               readi(vma->file->ip, 0, pa, offset, PGSIZE);
               iunlock(vma->file->ip);

               if(vma->prot&PROT_READ)
                   flags |= PTE_R;
               if(vma->prot&PROT_WRITE)
                   flags |= PTE_W;
               if(vma->prot&PROT_EXEC)
                   flags |= PTE_X;

               if(mappages(p->pagetable, va, PGSIZE, pa, flags)) {
                   kfree((void*)pa);
                   p->killed = 1;
               }
           }
       }
   } else {
       printf("usertrap(): unexpected scause %p pid=%d\n", r_scause(), p->pid);
       printf("            sepc=%p stval=%p\n", r_sepc(), r_stval());
       p->killed = 1;
   }


6. 定义函数sys_munmap：

   uint64 sys_munmap(void) {
   struct proc *p = myproc();
   uint64 addr, length;

   if(argaddr(0, &addr) || argaddr(1, &length))
       return -1;

   for(int i = 0; i<NVMA; ++i) {
       if(p->vmas[i].addr == addr) {
           p->vmas[i].addr += length;
           p->vmas[i].length -= length;
           if(p->vmas[i].flags == MAP_SHARED)
               filewrite(p->vmas[i].file, addr, length);
           uvmunmap(p->pagetable, addr, length/PGSIZE, 1);
           if(!p->vmas[i].length)
               fileclose(p->vmas[i].file);
           return 0;
       }
   }

   return -1;
   }


7. 增加fork、exit字段：

   // fork
   for(int i = 0; i<NVMA; ++i) {
       if(p->vmas[i].length) {
           memmove(&np->vmas[i], &p->vmas[i], sizeof(p->vmas[i]));
           filedup(p->vmas[i].file);
       }
   }

   // exit
   for(int i = 0; i<NVMA; ++i) {
       if(p->vmas[i].length) {
           if(p->vmas[i].flags == MAP_SHARED)
               filewrite(p->vmas[i].file, p->vmas[i].addr, p->vmas[i].length);
           uvmunmap(p->pagetable, p->vmas[i].addr, p->vmas[i].length/PGSIZE, 1);
           p->vmas[i].length = 0;
       }
   }


8. 根据编译器提示增加头文件

   // proc.c
   #include "fcntl.h"

   // trap.c
   #include "sleeplock.h"
   #include "fs.h"
   #include "file.h"
   #include "fcntl.h"


总结

总结下来就是不要想着一步到位，先把最重要的部分写出来，写完一个小模块就可以去跑测试，参数合法性可以在跑测试时慢慢添加。
