容器名	盛放组件
web容器	web相关组件（controller,springmvc,web等组件）
root容器	业务和持久层相关组件（service,aop,tx,dataSource,mybatis,mapper等）

为了方便编写，我们可以三层架构每层对应一个配置类，分别指定两个容器加载

配置名	对应内容	对应容器
WebJavaConfig	controller,springmvc相关	web容器
ServiceJavaConfig	service,aop,tx相关	root容器
MapperJavaConfig	mapper,datasource,mybatis相关	root容器

Ioc如何初始化？

对于web项目，可以选择web.xml和配置类方式进行ioc配置，相较于xml配置，配置类更简介方便

public class SpringIoCInit extends AbstractAnnotationConfigDispatcherServletInitializer {

    //rootioc容器的配置类
    @Override
    protected Class<?>[] getRootConfigClasses() {
        return new Class[]{DataSourceJavaConfig.class, MapperJavaConfigNew.class,ServiceJavaConfig.class};
    }

    //webioc容器的配置类指定
    @Override
    protected Class<?>[] getServletConfigClasses() {
        return new Class[]{WebMvcJavaConfig.class};
    }

    //dispatcherServlet的拦截路径
    @Override
    protected String[] getServletMappings() {
        return new String[]{"/"};
    }
}

二、简单实现整合SSM

（一）service层实现

1.数据库准备

CREATE TABLE schedule (
  id INT NOT NULL AUTO_INCREMENT,
  title VARCHAR(255) NOT NULL,
  completed BOOLEAN NOT NULL,
  PRIMARY KEY (id)
);

INSERT INTO schedule (title, completed)
VALUES
    ('学习java', true),
    ('学习Python', false),
    ('学习C++', true),
    ('学习JavaScript', false),
    ('学习HTML5', true),
    ('学习CSS3', false),
    ('学习Vue.js', true),
    ('学习React', false),
    ('学习Angular', true),
    ('学习Node.js', false),
    ('学习Express', true),
    ('学习Koa', false),
    ('学习MongoDB', true),
    ('学习MySQL', false),
    ('学习Redis', true),
    ('学习Git', false),
    ('学习Docker', true),
    ('学习Kubernetes', false),
    ('学习AWS', true),
    ('学习Azure', false);

2.pojo包下准备实体类

@Data
public class Schedule implements Serializable {

    private Integer id;
    @NotBlank
    private String title;
    @NotNull
    private Boolean completed;

    private static final long serialVersionUID = 1L;
}

3.until包下准备R类，用于接收返回状态码&状态&具体数据

@Data
public class R {

    private int code = 200; //200成功状态码

    private boolean flag = true; //返回状态

    private Object data;  //返回具体数据

    public  static R ok(Object data){
        R r = new R();
        r.data = data;
        return r;
    }

    public static R  fail(Object data){
        R r = new R();
        r.code = 500; //错误码
        r.flag = false; //错误状态
        r.data = data;
        return r;
    }
}

4.service包下创建ScheduleService

@Service
public interface ScheduleService {

    R page(int pageSize, int currentPage);

    R remove(Integer id);

    R save(Schedule schedule);

    R update(Schedule schedule);
}

5.config包下配置service

/**
 * description: 业务层配置类： service , aop , tx
 * @author UserName
 *
 * 1.service
 * 2.开启aop注解的支持 aspect : @Before @After @AfterReturning @AfterThrowing @Around  @Aspect @Order
 * 3.tx声明式事务管理： 1.对应的事务管理器实现 [TransactionManager DataSource。。 Hibernate。。 Jpa。。]
 *                   2.开启事务注解支持  @Transactional
 */
@Configuration
@EnableAspectJAutoProxy
@EnableTransactionManagement
@ComponentScan("com.example.service") //advice
public class ServiceJavaConfig {

    @Bean
    public TransactionManager transactionManager(DataSource dataSource){
        DataSourceTransactionManager dataSourceTransactionManager = new DataSourceTransactionManager();
        dataSourceTransactionManager.setDataSource(dataSource);
        System.out.println("dataSource = " + dataSource.toString());
        return dataSourceTransactionManager;
    }
}

6.mapper包下创建ScheduleMapper类

public interface ScheduleMapper{
    List<Schedule> queryList();

    int deleteById(Integer id);

    int insert(Schedule schedule);

    int update(Schedule schedule);
}

（二）mapper配置实现

1.准备dataSource

1.1 resource文件夹下创建jdbc.properties

jdbc.user=root
jdbc.password=123456
jdbc.url=jdbc:mysql://localhost:3306/studb
jdbc.driver=com.mysql.cj.jdbc.Driver

1.2 config包下实现DataSourceJavaConfig配置

@Configuration
@PropertySource("classpath:jdbc.properties")
public class DataSourceJavaConfig {

    @Value("${jdbc.user}")
    private String user;

    @Value("${jdbc.password}")
    private String password;

    @Value("${jdbc.url}")
    private String url;

    @Value("${jdbc.driver}")
    private String driver;

    @Bean
    public DataSource dataSource(){
        DruidDataSource dataSource = new DruidDataSource();
        dataSource.setUsername(user);
        dataSource.setPassword(password);
        dataSource.setUrl(url);
        dataSource.setDriverClassName(driver);
        return dataSource;
    }
}

2.mapper包下创建ScheduleMapper类

public interface ScheduleMapper{
    List<Schedule> queryList();

    int deleteById(Integer id);

    int insert(Schedule schedule);

    int update(Schedule schedule);
}

3. resource文件夹下创建com/example/mapper包存放ScheduleMapper.xml文件

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE mapper
        PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
        "https://mybatis.org/dtd/mybatis-3-mapper.dtd">
<!-- 全限定符 -->
<mapper namespace="com.example.mapper.ScheduleMapper">
    <select id="queryList" resultType="schedule">
        select * from schedule
    </select>

    <!--    int deleteById(Integer id);-->
    <delete id="deleteById">
        delete from schedule where id = #{id}
    </delete>

    <insert id="insert" >
        insert into schedule (title,completed) value (#{title},#{completed});
    </insert>

    <update id="update" >
        update schedule set title = #{title} ,completed = #{completed}
        where id = #{id}
    </update>
</mapper>

4.使用配置类代替xml配置，config包下创建MapperJavaConfig配置mybatis

@Configuration
public class MapperJavaConfigNew {

    @Bean
    public SqlSessionFactoryBean sqlSessionFactory(DataSource dataSource){

        SqlSessionFactoryBean sqlSessionFactoryBean = new SqlSessionFactoryBean();

        //指定配置文件等信息
        //指定数据库连接池对象
        sqlSessionFactoryBean.setDataSource(dataSource);

        //指定mybatis配置文件的功能，使用代码的形式
        org.apache.ibatis.session.Configuration configuration
                = new org.apache.ibatis.session.Configuration();
        // <setting name="mapUnderscoreToCamelCase" value="true"/>
        configuration.setMapUnderscoreToCamelCase(true);
        configuration.setLogImpl(Slf4jImpl.class);
        configuration.setAutoMappingBehavior(AutoMappingBehavior.FULL);

        //org.apache.ibatis.session.Configuration // 存储setting的配置文件
        sqlSessionFactoryBean.setConfiguration(configuration);

        //别名设置
        sqlSessionFactoryBean.setTypeAliasesPackage("com.example.pojo");

        //分页插件
        PageInterceptor pageInterceptor = new PageInterceptor();
        Properties properties = new Properties();
        properties.setProperty("helperDialect","mysql");
        pageInterceptor.setProperties(properties);
        sqlSessionFactoryBean.addPlugins(pageInterceptor);

        return sqlSessionFactoryBean;
    }

    //mapper代理对象加入到ioc
    @Bean
    public MapperScannerConfigurer mapperScannerConfigurer(){
        // Mapper代理兑现的factoryBean -> 指定一个包 -> mapper接口 -》sqlSessionFactory -> sqlSession -> getMapper -> mapper代理对象 -》 ioc
        MapperScannerConfigurer mapperScannerConfigurer = new MapperScannerConfigurer();
        mapperScannerConfigurer.setBasePackage("com.example.mapper"); //mapper接口和mapperxml所在的共同包
        return  mapperScannerConfigurer;
    }

}

（三） controller层实现

1.untils包下准备PageBean数据结构用于实现分页功能

@Data
@NoArgsConstructor
@AllArgsConstructor
public class PageBean<T> {
    private int currentPage;   // 当前页码
    private int pageSize;      // 每页显示的数据量
    private long total;    // 总数据条数
    private List<T> data;      // 当前页的数据集合
}

2.service/impl包下创建ScheduleServiceImpl实现ScheduleService的增/删/改/分页查询功能

/**
* @author UserName
* @description 针对表【schedule】的数据库操作Service实现
* @createDate 2024-04-10 22:49:02
*/
@Service
public class ScheduleServiceImpl implements ScheduleService{

    private ScheduleMapper scheduleMapper;

    @Autowired(required = false)
    public ScheduleServiceImpl(ScheduleMapper scheduleMapper) {
        this.scheduleMapper = scheduleMapper;
    }

    @Override
    public R page(int pageSize, int currentPage) {
        //分页
        PageHelper.startPage(currentPage,pageSize); // sql limit x,y;
        //查询
        List<Schedule> scheduleList = scheduleMapper.queryList();
        //把查询到的List放入PageInfo进行分页数据装配
        PageInfo<Schedule> info = new PageInfo<>(scheduleList);

        //再装配入我们设定好的PageBean结构中
        PageBean<Schedule> pageBean = new PageBean<>(currentPage,pageSize,info.getTotal(),info.getList());

        return R.ok(pageBean);
    }

    @Override
    public R remove(Integer id) {

        int rows = scheduleMapper.deleteById(id);

        if (rows > 0){
            return R.ok(null);
        }

        return R.fail(null);
    }

    @Override
    public R save(Schedule schedule) {

        int rows = scheduleMapper.insert(schedule);

        if (rows > 0){
            return R.ok(null);
        }
        return R.fail(null);
    }

    @Override
    public R update(Schedule schedule) {
        //判断id不能为null
        if (schedule.getId() == null) {
            return R.fail("核心参数为null，无法修改！");
        }

        int rows = scheduleMapper.update(schedule);

        if (rows > 0){
            return R.ok(null);
        }

        return R.fail(null);
    }

}

3.controller包下ScheduleController实现响应结果

@CrossOrigin //解决跨域问题，允许其他源访问我们的controller 浏览器大哥就不拦截了!
@RestController
@RequestMapping(value = "schedule")
@Slf4j
public class ScheduleController {
    private ScheduleService  scheduleService;

    @Autowired
    public ScheduleController(ScheduleService scheduleService) {
        this.scheduleService = scheduleService;
    }

    //接收参数
    //响应结果 springmvc
    @GetMapping("{pageSize}/{currentPage}")
    public R page(@PathVariable int pageSize,
                  @PathVariable int currentPage){

        R r = scheduleService.page(pageSize,currentPage);
        //sl4fj
        log.info("查询的数据为：{}",r);
        return r;
    }


    @DeleteMapping("{id}")
    public R remove(@PathVariable Integer id){
        return scheduleService.remove(id);
    }

    @PostMapping
    public R save(@Validated @RequestBody Schedule schedule, BindingResult result){
        if (result.hasErrors()){
            return R.fail("参数为null,不能保存！");
        }
        return scheduleService.save(schedule);
    }

    @PutMapping
    public R update(@Validated @RequestBody Schedule schedule, BindingResult result){
        if (result.hasErrors()){
            return R.fail("参数为null,不能修改！");
        }
        return scheduleService.update(schedule);
    }
}

4.config包下实现WebMvcJavaConfig

@EnableWebMvc
@Configuration
@ComponentScan("com.example.controller")
public class WebMvcJavaConfig implements WebMvcConfigurer {
//通过重写这个方法，启用默认Servlet处理器，使得对静态资源的请求能够被容器处理。
    @Override
    public void configureDefaultServletHandling(DefaultServletHandlerConfigurer configurer) {
        configurer.enable();
    }
//配置视图解析器，将逻辑视图名称解析为具体的视图。
    @Override
    public void configureViewResolvers(ViewResolverRegistry registry) {
        registry.jsp("/WEB-INF/views/","jsp");
    }
//添加拦截器，通过这个方法可以配置自定义的拦截器，对请求进行预处理或后处理。
    @Override
    public void addInterceptors(InterceptorRegistry registry) {
       // registry.addInterceptor(new xx()).addPathPatterns().excludePathPatterns()
    }
}

（四）配置IOC

@EnableWebMvc
@Configuration
@ComponentScan("com.example.controller")
public class WebMvcJavaConfig implements WebMvcConfigurer {
//通过重写这个方法，启用默认Servlet处理器，使得对静态资源的请求能够被容器处理。
    @Override
    public void configureDefaultServletHandling(DefaultServletHandlerConfigurer configurer) {
        configurer.enable();
    }
//配置视图解析器，将逻辑视图名称解析为具体的视图。
    @Override
    public void configureViewResolvers(ViewResolverRegistry registry) {
        registry.jsp("/WEB-INF/views/","jsp");
    }
//添加拦截器，通过这个方法可以配置自定义的拦截器，对请求进行预处理或后处理。
    @Override
    public void addInterceptors(InterceptorRegistry registry) {
       // registry.addInterceptor(new xx()).addPathPatterns().excludePathPatterns()
    }
}
