Android之PopupWindow-底部弹出,以及中间弹出有变暗效果

This class represents a popup window that can be used to display an arbitrary view.

The popup window is a floating container that appears on top of the current activity.官网原文

大概意思:这个类代表一个弹出窗口,可以用来显示任意的视图.弹出的窗口是当前活动的一个浮动容器.

在这里写出我们项目中常用的两种弹窗方式,底部弹窗以及中间弹窗,并且可以设置PopupWindow以外部分有变暗的效果.只要大家理解了一种,其它的都可以很快的写出来的.

先来张效果图:




底部弹出PopupWindow(点击PopupWindow以外部分,PopupWindow 会消失)

这里需要注意的是:当我们点击返回键或点击PopupWindow以外的地方时,需要PopupWindow消失时,下面的两个方法是很重要的.
popupWindow.setFocusable(true); //设置PopupWindow的焦点
popupWindow.setBackgroundDrawable(new ColorDrawable(0x00000000)); //为PopupWindow设置背景,这里为了不影响效果,我也设置了透明背景.具体解释看代码中,我写了很详细的注释.

?

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40

/** * 底部弹出PopupWindow * * 点击PopupWindow以外部分或点击返回键时,PopupWindow 会 消失 * @param view  parent view */ public void showBottomPopupWindow(View view) {          //自定义PopupWindow的布局          View contentView = LayoutInflater.from( this ).inflate(R.layout.popupwindow_layout, null );          //初始化PopupWindow,并为其设置布局文件          final PopupWindow popupWindow = new PopupWindow(contentView);          //确定按钮点击事件          contentView.findViewById(R.id.tv_confirm).setOnClickListener( new View.OnClickListener() {              @Override              public void onClick(View v) {                  Toast.makeText(PopupWindowTest. this , "点击了确定" , Toast.LENGTH_SHORT).show();                  popupWindow.dismiss();              }          });          //取消按钮点击事件          contentView.findViewById(R.id.tv_cancel).setOnClickListener( new View.OnClickListener() {              @Override              public void onClick(View v) {                  popupWindow.dismiss();              }          });          //设置PopupWindow的宽和高,必须设置,否则不显示内容(也可用PopupWindow的构造方法设置宽高)          popupWindow.setWidth(LinearLayout.LayoutParams.MATCH_PARENT);          popupWindow.setHeight(LinearLayout.LayoutParams.WRAP_CONTENT);          //当需要点击返回键,或者点击空白时,需要设置下面两句代码.          //如果有背景，则会在contentView外面包一层PopupViewContainer之后作为mPopupView，如果没有背景，则直接用contentView作为mPopupView。          //而这个PopupViewContainer是一个内部私有类，它继承了FrameLayout，在其中重写了Key和Touch事件的分发处理          popupWindow.setFocusable( true );          popupWindow.setBackgroundDrawable( new ColorDrawable( 0x00000000 ));   //为PopupWindow设置透明背景.          popupWindow.setOutsideTouchable( false );          //设置PopupWindow进入和退出动画          popupWindow.setAnimationStyle(R.style.anim_popup_bottombar);          //设置PopupWindow显示的位置          popupWindow.showAtLocation(view, Gravity.BOTTOM, 0 , 0 );      }

底部弹出PopupWindow(点击PopupWindow以外部分,PopupWindow 不会消失 )

这里设置的是,点击PopupWindow以外部分,不让PopupWindow消失,只有点击返回键,或用户主动取消时,PopupWindow才会消失.已满足有时我们变态的需求….直接上代码.

?

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48

/** * 底部弹出PopupWindow * * 点击PopupWindow以外部分或点击返回键时,PopupWindow 不会 消失 * @param view  parent view */      public void showBottomPopupWindow2(View view) {          //自定义PopupWindow的布局          View contentView = LayoutInflater.from( this ).inflate(R.layout.popupwindow_layout, null );          contentView.setFocusable( true );          contentView.setFocusableInTouchMode( true );          //初始化PopupWindow对象,并为其设置宽高以及布局文件          final PopupWindow popupWindow = new PopupWindow(contentView, LinearLayout.LayoutParams.MATCH_PARENT, LinearLayout.LayoutParams.WRAP_CONTENT);          popupWindow.setFocusable( true );          popupWindow.setOutsideTouchable( false );            contentView.setOnKeyListener( new View.OnKeyListener() {              @Override              public boolean onKey(View v, int keyCode, KeyEvent event) {                  if (keyCode == KeyEvent.KEYCODE_BACK) {                      popupWindow.dismiss();                        return true ;                  }                  return false ;              }          });          //确定按钮点击事件          contentView.findViewById(R.id.tv_confirm).setOnClickListener( new View.OnClickListener() {              @Override              public void onClick(View v) {                  Toast.makeText(PopupWindowTest. this , "点击了确定" , Toast.LENGTH_SHORT).show();                  popupWindow.dismiss();              }          });          //取消按钮点击事件          contentView.findViewById(R.id.tv_cancel).setOnClickListener( new View.OnClickListener() {              @Override              public void onClick(View v) {                  popupWindow.dismiss();              }          });            //设置PopupWindow进入和退出动画          popupWindow.setAnimationStyle(R.style.anim_popup_bottombar);          //设置PopupWindow显示在底部          popupWindow.showAtLocation(view, Gravity.BOTTOM, 0 , 0 );      }

中间弹出PopupWindow,有一种变暗的效果

其实设置变暗效果也挺简单的,我们知道,微信上就有这种效果.下面给出代码:(需要注意的是:需要监听PopupWindow的状态,当PopupWindow消失时,恢复设置的背景颜色)

?

1 2 3 4

// 设置PopupWindow以外部分的背景颜色  有一种变暗的效果 final WindowManager.LayoutParams wlBackground = getWindow().getAttributes(); wlBackground.alpha = 0 .5f;      // 0.0 完全不透明,1.0完全透明 getWindow().setAttributes(wlBackground);

完整代码:

?

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59

/** * 中间弹出PopupWindow * *  设置PopupWindow以外部分有一中变暗的效果 * @param view  parent view */ public void showCenterPopupWindow(View view) {          View contentView = LayoutInflater.from( this ).inflate(R.layout.popupwindow_layout, null );          final PopupWindow popupWindow = new PopupWindow(contentView, LinearLayout.LayoutParams.WRAP_CONTENT, LinearLayout.LayoutParams.WRAP_CONTENT);          TextView tvTitle = (TextView)contentView.findViewById(R.id.tv_title);          TextView tvConfirm = (TextView)contentView.findViewById(R.id.tv_confirm);          TextView tvCancel = (TextView)contentView.findViewById(R.id.tv_cancel);          tvTitle.setText( "标为已读" );          tvConfirm.setText( "置顶公众号" );          tvCancel.setText( "取消关注" );            tvTitle.setOnClickListener( new View.OnClickListener() {              @Override              public void onClick(View v) {                  Toast.makeText(PopupWindowTest. this , "标为已读" , Toast.LENGTH_SHORT).show();                  popupWindow.dismiss();              }          });            tvConfirm.setOnClickListener( new View.OnClickListener() {              @Override              public void onClick(View v) {                  Toast.makeText(PopupWindowTest. this , "置顶公众号" , Toast.LENGTH_SHORT).show();                  popupWindow.dismiss();              }          });            tvCancel.setOnClickListener( new View.OnClickListener() {              @Override              public void onClick(View v) {                  Toast.makeText(PopupWindowTest. this , "取消关注" , Toast.LENGTH_SHORT).show();                  popupWindow.dismiss();              }          });          popupWindow.setFocusable( true );          popupWindow.setBackgroundDrawable( new ColorDrawable( 0x00000000 ));          // 设置PopupWindow以外部分的背景颜色  有一种变暗的效果          final WindowManager.LayoutParams wlBackground = getWindow().getAttributes();          wlBackground.alpha = 0 .5f;      // 0.0 完全不透明,1.0完全透明          getWindow().setAttributes(wlBackground);          // 当PopupWindow消失时,恢复其为原来的颜色          popupWindow.setOnDismissListener( new PopupWindow.OnDismissListener() {              @Override              public void onDismiss() {                  wlBackground.alpha = 1 .0f;                  getWindow().setAttributes(wlBackground);              }          });          //设置PopupWindow进入和退出动画          popupWindow.setAnimationStyle(R.style.anim_popup_centerbar);          // 设置PopupWindow显示在中间          popupWindow.showAtLocation(view,Gravity.CENTER, 0 , 0 );        }

下面给出源码,大家直接查看PopupWindowTest.java文件,动画源码在res/anim下 https://github.com/ListenerGao/MyTest/blob/master/app/src/main/java/com/listenergao/mytest/activity/PopupWindowTest.java
