判断在不在有效范围内：
直接上代码
<!DOCTYPE html>
<html>
<head>
	<meta http-equiv="Content-Type" content="text/html; charset=utf-8" />
	<meta name="viewport" content="initial-scale=1.0, user-scalable=no" />
	<style type="text/css">
	body, html{width: 100%;height: 100%;margin:0;font-family:"微软雅黑";}
	#allmap {width: 100%; height:500px; overflow: hidden;}
	#result {width:100%;font-size:12px;}
	dl,dt,dd,ul,li{
		margin:0;
		padding:0;
		list-style:none;
	}
	p{font-size:12px;}
	dt{
		font-size:14px;
		font-family:"微软雅黑";
		font-weight:bold;
		border-bottom:1px dotted #000;
		padding:5px 0 5px 5px;
		margin:5px 0;
	}
	dd{
		padding:5px 0 0 5px;
	}
	li{
		line-height:28px;
	}
	</style>
	<script type="text/javascript" src="http://api.map.baidu.com/api?v=2.0&ak=sSelQoVi2L3KofLo1HOobonW"></script>
	<!--加载鼠标绘制工具-->
    <script type="text/javascript" src="http://api.map.baidu.com/library/DrawingManager/1.4/src/DrawingManager_min.js"></script>

	<link rel="stylesheet" href="http://api.map.baidu.com/library/DrawingManager/1.4/src/DrawingManager_min.css" />
	<!--加载检索信息窗口-->
	<script type="text/javascript" src="http://api.map.baidu.com/library/SearchInfoWindow/1.4/src/SearchInfoWindow_min.js"></script>
	<link rel="stylesheet" href="http://api.map.baidu.com/library/SearchInfoWindow/1.4/src/SearchInfoWindow_min.css" />
	<title>鼠标绘制工具</title>
</head>
<body>
	<div id="allmap" style="overflow:hidden;zoom:1;position:relative;">
		<div id="map" style="height:100%;-webkit-transition: all 0.5s ease-in-out;transition: all 0.5s ease-in-out;"></div>
	</div>
	<div id="result">
        <input type="button" value="获取绘制覆盖物个数" onclick="alert(overlays.length)"/>
        <input type="button" value="获取绘制覆盖物信息" onclick="getLayerInformation()">
        <input type="button" value="绘制多边形" onclick="drawPolygon()">
        <input type="button" value="清除所有覆盖物" onclick="clearAll()"/>
        <label for="">经度：</label> <input type="text" id="ILng" value="120.971601">
        <label for="">纬度：</label> <input type="text" id="ILat" value="31.502151">




        <input type="button" value="判断点是否在多边形内" onclick="IsInPolygon()">
    </div>

</body>
</html>
<script src="http://libs.baidu.com/jquery/2.1.4/jquery.min.js"></script>
<script type="text/javascript" src="GeoUtils.js"></script>
<script type="text/javascript">
	// 百度地图API功能
    var map = new BMap.Map('map');
    var poi = new BMap.Point(120.983962,31.500796);
    map.centerAndZoom(poi, 16);
    map.enableScrollWheelZoom();
    var overlays = [];
	var overlaycomplete = function(e){
        overlays.push(e.overlay);
    };

    var styleOptions = {
        strokeColor:"red",    //边线颜色。
        fillColor:"red",      //填充颜色。当参数为空时，圆形将没有填充效果。
        strokeWeight: 3,       //边线的宽度，以像素为单位。
        strokeOpacity: 0.8,	   //边线透明度，取值范围0 - 1。
        fillOpacity: 0.6,      //填充的透明度，取值范围0 - 1。
        strokeStyle: 'solid' //边线的样式，solid或dashed。
    }
    //实例化鼠标绘制工具
    var drawingManager = new BMapLib.DrawingManager(map, {
        isOpen: false, //是否开启绘制模式
        enableDrawingTool: true, //是否显示工具栏
        drawingToolOptions: {
            anchor: BMAP_ANCHOR_TOP_RIGHT, //位置
            offset: new BMap.Size(5, 5), //偏离值
        },
        circleOptions: styleOptions, //圆的样式
        polylineOptions: styleOptions, //线的样式
        polygonOptions: styleOptions, //多边形的样式
        rectangleOptions: styleOptions //矩形的样式
    });
	 //添加鼠标绘制工具监听事件，用于获取绘制结果
    drawingManager.addEventListener('overlaycomplete', overlaycomplete);
    function clearAll() {

		for(var i = 0; i < overlays.length; i++){
            map.removeOverlay(overlays[i]);
        }
        overlays.length = 0
    }

    function getLayerInformation(){
        console.log(overlays[0].getPath());
    }
    let polygon;




    function drawPolygon(){
        let point = [
            {
                lng:"120.971601",
                lat:"31.502151"
            },
            {
                lng:"120.96923",
                lat:"31.496424"
            },
            {
                lng:"120.976129",
                lat:"31.495685"
            },
            {
                lng:"120.977889",
                lat:"31.499441"
            },
            {
                lng:"120.974871",
                lat:"31.501874"
            },
            {
                lng:"120.971709",
                lat:"31.502151"
            },

        ];
        let polArry = [];
        point.forEach(item => {
            let p = new BMap.Point(item.lng,item.lat);
            polArry.push(p);
        });
        polygon = new BMap.Polygon(polArry,styleOptions);
        map.addOverlay(polygon);
    }

    function IsInPolygon(){
        let lng = $("#ILng").val();
        let lat = $("#ILat").val();
        let point = new BMap.Point(lng,lat);
        let marker = new BMap.Marker(point);
        map.addOverlay(marker);
        if(BMapLib.GeoUtils.isPointInPolygon(point,polygon)){
            console.log("在区域内");
        }else{
            console.log("不再区域内");
        }

    }


    function getLayerInformation(){
        console.log(overlays[0].getPath());
    }

/*

    function getLayerInformation(){

        console.log(overlays[0].getPath());
        let polArry = [];
        let pol = overlays[0].getPath();
        let t = 0.001;
        pol.forEach(item => {
            let point = new BMap.Point(item.lng + t,item.lat + t);
            polArry.push(point);
        });
       let polygon = new BMap.Polygon(polArry,styleOptions);
        map.addOverlay(polygon);
        alert(overlays[0]);
    }
*/


</script>
ak我这边用的是我自己的，你拿去用也行吧
