CNN构建

import numpy as np
import h5py
import matplotlib.pyplot as plt

np.random.seed(1)


def zero_pad(X, pad):
    """
    给样本集X的所有样本进行零填补
    :param X: （m,n_H,n_W,n_C），样本数量、图片的高、宽、深度
    :param pad: padding个数
    :return: X_pad: 填补后的结果（m, n-H+2*pad,n_W+2*pad,n_C）
    """
    X_pad = np.pad(X, ((0, 0), (pad, pad), (pad, pad), (0, 0)), 'constant', constant_values=0)
    return X_pad


def conv_single_step(a_slice_prev, W, b):
    """
    单步卷积（这个函数只执行一步卷积）
    :param a_slice_prev:输入矩阵的一小块数据，这里输入矩阵也就是上一层的输出矩阵，维度（f,f,n_C_prev）
    :param W: 权重参数，指过滤器，维度是（f,f,n_C_prev）, 因为是对a_slice_prev的卷积，故维度也是一样的
    :param b: 每个过滤器都有1个b，维度是（1，1，1）
    :return: Z- 卷积一步后得到的一个数值，作为输出矩阵中的一个元素
    """
    s = np.multiply(a_slice_prev, W) + b
    Z = np.sum(s)
    return Z


def conv_forward(A_prev, W, b, hparameters):
    """
    卷积网络前向传播
    :param A_prev: 本层输入矩阵，也是上一层的输出矩阵 （m, n_H_prev, n_W_prev, n_C_prev）
    :param W: 权重，即过滤器参数 （f, f, n_C_prev, n_C），n_C代表过滤器个数
    :param b: 阈值 （1,1,1,n_C），一个过滤器一个阈值
    :param hparameters: 超参数步长s和padding数p
    :return: Z 卷积结果 （m,n_H,n_W,n_C）
    cache 缓存，用于反向传播使用
    """
    (m, n_H_prev, n_W_prev, n_C_prev) = A_prev.shape
    (f, f, n_C_prev, n_C) = W.shape
    stride = hparameters['stride']
    pad = hparameters['pad']
    n_H = int((n_H_prev + 2 * pad - f) / stride) + 1
    n_W = int((n_W_prev + 2 * pad - f) / stride) + 1

    Z = np.zeros((m, n_H, n_W, n_C))
    A_prev_pad = zero_pad(A_prev, pad)
    for i in range(m):  # 遍历每一个样本
        a_prev_pad = A_prev_pad[i]  # 取出一个样本对应的输入矩阵， 32 * 32 * 3
        for h in range(n_H):  # 遍历输出矩阵的高 0->28
            for w in range(n_W):  # 遍历输出矩阵的宽 0-> 28
                for c in range(n_C):  # 遍历每一个过滤器 0->2
                    # 计算输入矩阵本次应该卷积的区域索引，然后通过这些所有取出将被卷积的小块数据。
                    vert_start = h * stride  # 0,2,4...28
                    vert_end = vert_start + f  # 0+f,2+f,4+f...28
                    horiz_start = w * stride  # 0,2,4...64
                    horiz_end = horiz_start + f  # 0+f,2+f,4+f...64+f
                    a_slice_prev = a_prev_pad[vert_start:vert_end, horiz_start: horiz_end,
                                   :]  # [0:2, 2:4, 4:6...26:28、 0:2,0:2,0:2、...] ->[0:2, 2:4, 4:6...26:28、 2:4,2:4,2:4、...]  即先向下滑，再向右滑。
                    # 卷积
                    # W[..., c]：这里使用 W[..., c] 表示取出卷积核 W 中所有通道对应的第 c 个滤波器（卷积核）。
                    # ... 是 NumPy 的切片语法，表示取所有前面的维度，因此 W[..., c] 提取出第 c 个卷积核（它的形状是 (f, f, n_C_prev)）。
                    Z[i, h, w, c] = conv_single_step(a_slice_prev, W[..., c], b[..., c])
    assert (Z.shape == (m, n_H, n_W, n_C))
    cache = (A_prev, W, b, hparameters)
    return Z, cache


def pool_forward(A_prev, hparameters, mode="max"):
    """池化
    参数
    :param A_prev: 输入矩阵，也是上一层的输出矩阵 （m,n_H_prev,n_W_prev,n_C_prev）
    :param hparameters:  窗口大小f和步长s
    :param mode: max、average
    :return: A-池化层的输出矩阵，维度是（m,n_H,n_W,n_C）
    cache-缓存一些数据
    """
    (m, n_H_prev, n_W_prev, n_C_prev) = A_prev.shape
    f = hparameters["f"]  # 窗口大小
    stride = hparameters["stride"]  # 步长
    n_H = int((n_H_prev - f) / stride) + 1
    n_W = int((n_W_prev - f) / stride) + 1
    n_C = n_C_prev  # 在原卷积层操作，通道数不变
    A = np.zeros((m, n_H, n_W, n_C))
    for i in range(m):
        a_prev = A_prev[i]
        for h in range(n_H):
            for w in range(n_W):
                for c in range(n_C):
                    vert_start = h * stride
                    vert_end = vert_start + f
                    horiz_start = w * stride
                    horiz_end = horiz_start + f
                    # 取出将被池化的子矩阵窗口
                    a_prev_slice = a_prev[vert_start:vert_end, horiz_start: horiz_end, c]
                    if mode == "max":
                        A[i, h, w, c] = np.max(a_prev_slice)
                    elif mode == "average":
                        A[i, h, w, c] = np.mean(a_prev_slice)
                    else:
                        assert (1 == 1), "Not support mode"
    cache = (A_prev, hparameters)
    assert (A.shape == (m, n_H, n_W, n_C))
    return A, cache


def conv_backward(dZ, cache):
    """
    :param dZ: 后一层相关的dZ，维度是 (m, n_H,n_W,n_C)
    :param cache:  缓存数据
    :return:
    dA_prev -- 本卷积层输入矩阵的dA，维度（m, n_H_prev, n_W_prev, n_C_prev）
    dW -- 本卷积层的dW, 维度是(f, f, n_C_prev, n_C)
    db -- 本卷积层的db，维度（1, 1, 1, n_C）
    """
    (A_prev, W, b, hparameters) = cache
    (m, n_H_prev, n_W_prev, n_C_prev) = A_prev.shape
    (f, f, n_C_prev, n_C) = W.shape
    stride = hparameters["stride"]
    pad = hparameters["pad"]
    (m, n_H, n_W, n_C) = dZ.shape

    dA_prev = np.zeros((m, n_H_prev, n_W_prev, n_C_prev))
    dW = np.zeros((f, f, n_C_prev, n_C))
    db = np.zeros((1, 1, 1, n_C))

    A_prev_pad = zero_pad(A_prev, pad)
    dA_prev_pad = zero_pad(dA_prev, pad)

    for i in range(m):  # 遍历每一个样本
        a_prev_pad = A_prev_pad[i]
        da_prev_pad = dA_prev_pad[i]
        for h in range(n_H):  # 遍历输出矩阵的高
            for w in range(n_W):  # 遍历输出矩阵的宽
                for c in range(n_C):  # 遍历输出矩阵的深度
                    # 计算输入矩阵中的子矩阵索引
                    vert_start = h
                    vert_end = vert_start + f
                    horiz_start = w
                    horiz_end = horiz_start + f
                    # 取出当前进行卷积的子矩阵
                    a_slice = a_prev_pad[vert_start:vert_end, horiz_start:horiz_end, :]  # 同一份特征图，不同的卷积核有不同的w,b
                    da_prev_pad[vert_start:vert_end, horiz_start:horiz_end, :] += W[:, :, :, c] * dZ[i, h, w, c]
                    dW[:, :, :, c] += a_slice * dZ[i, h, w, c]
                    db[:, :, :, c] += dZ[i, h, w, c]
        dA_prev[i, :, :, :] = da_prev_pad[pad:-pad, pad:-pad, :]
    assert (dA_prev.shape == (m, n_H_prev, n_W_prev, n_C_prev))
    return dA_prev, dW, db


def create_mask_from_window(x):
    # x是一个矩阵，np.max(x)会得到最大元素
    # mask是一个与x维度相同的矩阵，里面其他元素为0，只有x最大值的位置处为1
    mask = x == np.max(x)
    return mask


def distribute_value(dz, shape):
    """
    参数
    :param dz: 一个 数值
    :param shape: 输出矩阵的维度
    :return: a, a的维度就是shape，里面的值是dz平分而来的
    """
    (n_H, n_W) = shape
    average = dz / (n_H * n_W)
    a = np.ones(shape) * average
    return a


def pool_backward(dA, cache, mode="max"):
    """
    参数
    :param dA: 本池化层的输出矩阵对应的偏导数
    :param cache: 前向传播缓存的值
    :param mode:最大池化还是平均池化， max 或 average
    :return: dA_prev 本池化的输入矩阵对应的偏导数
    """
    (A_prev, hparameters) = cache
    stride = hparameters["stride"]
    f = hparameters["f"]
    m, n_H_prev, n_W_prev, n_C_prev = A_prev.shape
    m, n_H, n_W, n_C = dA.shape
    dA_prev = np.zeros(A_prev.shape)
    for i in range(m):
        a_prev = A_prev[i]
        for h in range(n_H):
            for w in range(n_W):
                for c in range(n_C):
                    vert_start = h
                    vert_end = vert_start + f
                    horiz_start = w
                    horiz_end = horiz_start + f
                    if mode == "max":
                        a_prev_slice = a_prev[vert_start:vert_end, horiz_start:horiz_end, c]  # 第c个卷积核的结果
                        mask = create_mask_from_window(a_prev_slice)
                        dA_prev[i, vert_start:vert_end, horiz_start:horiz_end, c] += np.multiply(mask, dA[i, h, w, c])
                    elif mode == "average":
                        da = dA[i, h, w, c]
                        shape = (f, f)
                        dA_prev[i, vert_start:vert_end, horiz_start:horiz_end, c] += distribute_value(da, shape)
    assert (dA_prev.shape == A_prev.shape)
    return dA_prev


def test1():
    np.random.seed(1)
    x = np.random.randn(4, 3, 3, 2)
    x_pad = zero_pad(x, 2)
    print("x.shape:", x.shape)
    print("x_pad.shape:", x_pad.shape)
    print("x[1,1]=", x[1, 1])
    print("x_pad[1,1]=", x_pad[1, 1])
    fig, axarr = plt.subplots(1, 2)
    axarr[0].set_title('x')
    print(x)
    print("-=-----")
    print(x[0, :, :, 0])
    axarr[0].imshow(x[0, :, :, 0])
    axarr[1].set_title('x_pad')
    # x_pad[0, 1:3, 2:4,:] = 128 #测试滑动
    # x_pad[0, 2:5, 2:4,:] = 128 #测试滑动
    print("xxxx", x_pad)
    axarr[1].imshow(x_pad[0, :, :, 0])
    plt.show()


def test2():
    a_slice_prev = np.random.randn(4, 4, 3)
    W = np.random.randn(4, 4, 3)
    b = np.random.randn(1, 1, 1)
    Z = conv_single_step(a_slice_prev, W, b)
    print("Z=", Z)


def test3():
    np.random.seed(1)
    A_prev = np.random.randn(10, 4, 4, 3)
    W = np.random.randn(2, 2, 3, 8)
    b = np.random.randn(1, 1, 1, 8)
    hparameters = {"pad": 2, "stride": 1}
    Z, cache_conv = conv_forward(A_prev, W, b, hparameters)
    print("Z's mean =", np.mean(Z))
    print("cache_conv[0][1][2][3]=", cache_conv[0][1][2][3])
    return Z, cache_conv


def test4():
    np.random.seed(1)
    A_prev = np.random.randn(2, 4, 4, 3)
    hparameters = {"stride": 1, "f": 4}
    A, cache = pool_forward(A_prev, hparameters)
    print("mode=max")
    print("A=", A)
    print()
    A, cache = pool_forward(A_prev, hparameters, mode="average")
    print("mode=average")
    print("A=", A)


def test5():
    np.random.seed(1)
    Z, cache_conv = test3()
    dA, dW, db = conv_backward(Z, cache_conv)
    print("dA_mean =", np.mean(dA))
    print("dW_mean =", np.mean(dW))
    print("db_mean =", np.mean(db))


def test6():
    np.random.seed(1)
    x = np.random.randn(2, 3)
    mask = create_mask_from_window(x)
    print("x=", x)
    print("mask=", mask)


def test7():
    a = distribute_value(2, (2, 2))
    print("distributed value = ", a)


def test8():
    np.random.seed(1)
    A_prev = np.random.randn(5, 5, 3, 2)
    hparameters = {"stride": 1, "f": 2}
    A, cache = pool_forward(A_prev, hparameters)
    dA = np.random.randn(5, 4, 2, 2)
    dA_prev = pool_backward(dA, cache, mode="max")
    print("mode=max")
    print("mean of dA = ", np.mean(dA))
    print("dA_prev[1,1]=", dA_prev[1, 1])
    print()
    dA_prev=pool_backward(dA,cache,mode="average")
    print("mode=average")
    print('mean of dA = ', np.mean(dA))
    print('dA_prev[1,1] = ', dA_prev[1, 1])


if __name__ == "__main__":
    # test1()
    # test2()
    # test3()
    # test4()
    # test5()
    # test6()
    # test7()
    test8()
