* @file n32g43x_gpio.h
* @author Nations
* @version v1.0.0
*
* @copyright Copyright (c) 2019, Nations Technologies Inc. All rights reserved.
*/
#ifndef __N32G43X_GPIO_H__
#define __N32G43X_GPIO_H__
#ifdef __cplusplus
extern "C" {
#endif
#include "n32g43x.h"
/** @addtogroup N32G43x_StdPeriph_Driver
* @{
*/
/** @addtogroup GPIO
* @{
*/
/** @addtogroup GPIO_Exported_Types
* @{
*/
#define IS_GPIO_ALL_PERIPH(PERIPH) \
(((PERIPH) == GPIOA) || ((PERIPH) == GPIOB) || ((PERIPH) == GPIOC) || ((PERIPH) == GPIOD))
#define GPIO_GET_INDEX(PERIPH) (((PERIPH) == (GPIOA))? 0 :\
((PERIPH) == (GPIOB))? 1 :\
((PERIPH) == (GPIOC))? 2 :3)
#define GPIO_GET_PERIPH(INDEX) (((INDEX)==((uint8_t)0x00))? GPIOA :\
((INDEX)==((uint8_t)0x01))? GPIOB :\
((INDEX)==((uint8_t)0x02))? GPIOC : GPIOD )
/**
* @brief Output Maximum frequency selection
*/
typedef enum
{
GPIO_Slew_Rate_High = 0,
GPIO_Slew_Rate_Low
} GPIO_SpeedType;
#define IS_GPIO_SLEW_RATE(_RATE_) \
(((_RATE_) == GPIO_Slew_Rate_High) || ((_RATE_) == GPIO_Slew_Rate_Low))
/**
* @brief driver strength config
*/
typedef enum
{
GPIO_DC_2mA = 0,
GPIO_DC_4mA = 1,
GPIO_DC_8mA ,
GPIO_DC_12mA
}GPIO_CurrentType;
#define IS_GPIO_CURRENT(CURRENT) \
(((CURRENT) == GPIO_DC_2mA) ||((CURRENT) == GPIO_DC_4mA) \
|| ((CURRENT) == GPIO_DC_8mA)||((CURRENT) == GPIO_DC_12mA))
/**
* @brief Configuration Mode enumeration
*/
/** @brief GPIO_mode_define Mode definition
* @brief GPIO Configuration Mode
* Values convention: 0xW0yz00YZ
* - W : GPIO mode or EXTI Mode
* - y : External IT or Event trigger detection
* - z : IO configuration on External IT or Event
* - Y : Output type (Push Pull or Open Drain)
* - Z : IO Direction mode (Input, Output, Alternate or Analog)
* @{
*/
typedef enum
{
GPIO_Mode_Input = 0x00000000, /*!< Input Floating Mode */
GPIO_Mode_Out_PP = 0x00000001, /*!< Output Push Pull Mode */
GPIO_Mode_Out_OD = 0x00000011, /*!< Output Open Drain Mode */
GPIO_Mode_AF_PP = 0x00000002, /*!< Alternate Function Push Pull Mode */
GPIO_Mode_AF_OD = 0x00000012, /*!< Alternate Function Open Drain Mode */
GPIO_Mode_Analog = 0x00000003, /*!< Analog Mode */
GPIO_Mode_IT_Rising = 0x10110000, /*!< External Interrupt Mode with Rising edge trigger detection */
GPIO_Mode_IT_Falling = 0x10210000, /*!< External Interrupt Mode with Falling edge trigger detection */
GPIO_Mode_IT_Rising_Falling = 0x10310000, /*!< External Interrupt Mode with Rising/Falling edge trigger detection */
GPIO_Mode_EVT_Rising = 0x10120000, /*!< External Event Mode with Rising edge trigger detection */
GPIO_Mode_EVT_Falling = 0x10220000, /*!< External Event Mode with Falling edge trigger detection */
GPIO_Mode_EVT_Rising_Falling = 0x10320000
}GPIO_ModeType;
/**
* @}
*/
#define IS_GPIO_MODE(__MODE__) (((__MODE__) == GPIO_Mode_Input) ||\
((__MODE__) == GPIO_Mode_Out_PP) ||\
((__MODE__) == GPIO_Mode_Out_OD) ||\
((__MODE__) == GPIO_Mode_AF_PP) ||\
((__MODE__) == GPIO_Mode_AF_OD) ||\
((__MODE__) == GPIO_Mode_IT_Rising) ||\
((__MODE__) == GPIO_Mode_IT_Falling) ||\
((__MODE__) == GPIO_Mode_IT_Rising_Falling) ||\
((__MODE__) == GPIO_Mode_EVT_Rising) ||\
((__MODE__) == GPIO_Mode_EVT_Falling) ||\
((__MODE__) == GPIO_Mode_EVT_Rising_Falling) ||\
((__MODE__) == GPIO_Mode_Analog))
/**
* @}
*/
/**
* @}
*/
/** @brief GPIO_pull_define Pull definition
* @brief GPIO Pull-Up or Pull-Down Activation
* @{
*/
typedef enum
{
GPIO_No_Pull = 0x00000000, /*!< No Pull-up or Pull-down activation */
GPIO_Pull_Up = 0x00000001, /*!< Pull-up activation */
GPIO_Pull_Down = 0x00000002 /*!< Pull-down activation */
}GPIO_PuPdType;
/**
* @}
*/
#define IS_GPIO_PULL(__PULL__) (((__PULL__) == GPIO_No_Pull) || ((__PULL__) == GPIO_Pull_Up) || \
((__PULL__) == GPIO_Pull_Down))
/**
* @}
*/
/**
* @brief GPIO Init structure definition
*/
typedef struct
{
uint16_t Pin; /*!< Specifies the GPIO pins to be configured.
This parameter can be any value of @ref GPIO_pins_define */
GPIO_CurrentType GPIO_Current; /*!<Driving current of the select pins>.
This paramter can be a value of @ref GPIO_CurrentType*/
GPIO_SpeedType GPIO_Slew_Rate; /*!< Specifies the speed for the selected pins.
This parameter can be a value of @ref GPIO_SpeedType */
GPIO_PuPdType GPIO_Pull; /*!< Specifies the Pull-up or Pull-Down activation for the selected pins.
This parameter can be a value of @ref GPIO_pull_define */
GPIO_ModeType GPIO_Mode; /*!< Specifies the operating mode for the selected pins.
This parameter can be a value of @ref GPIO_ModeType */
uint32_t GPIO_Alternate; /*!< Peripheral to be connected to the selected pins
This parameter can be a value of @ref GPIOEx_Alternate_function_selection */
} GPIO_InitType;
/**
* @brief Bit_SET and Bit_RESET enumeration
*/
typedef enum
{
Bit_RESET = 0,
Bit_SET
} Bit_OperateType;
#define IS_GPIO_BIT_OPERATE(OPERATE) (((OPERATE) == Bit_RESET) || ((OPERATE) == Bit_SET))
/**
* @}
*/
/** @addtogroup GPIO_Exported_Constants
* @{
*/
/** @addtogroup GPIO_pins_define
* @{
*/
#define GPIO_PIN_0 ((uint16_t)0x0001) /*!< Pin 0 selected */
#define GPIO_PIN_1 ((uint16_t)0x0002) /*!< Pin 1 selected */
#define GPIO_PIN_2 ((uint16_t)0x0004) /*!< Pin 2 selected */
#define GPIO_PIN_3 ((uint16_t)0x0008) /*!< Pin 3 selected */
#define GPIO_PIN_4 ((uint16_t)0x0010) /*!< Pin 4 selected */
#define GPIO_PIN_5 ((uint16_t)0x0020) /*!< Pin 5 selected */
#define GPIO_PIN_6 ((uint16_t)0x0040) /*!< Pin 6 selected */
#define GPIO_PIN_7 ((uint16_t)0x0080) /*!< Pin 7 selected */
#define GPIO_PIN_8 ((uint16_t)0x0100) /*!< Pin 8 selected */
#define GPIO_PIN_9 ((uint16_t)0x0200) /*!< Pin 9 selected */
#define GPIO_PIN_10 ((uint16_t)0x0400) /*!< Pin 10 selected */
#define GPIO_PIN_11 ((uint16_t)0x0800) /*!< Pin 11 selected */
#define GPIO_PIN_12 ((uint16_t)0x1000) /*!< Pin 12 selected */
#define GPIO_PIN_13 ((uint16_t)0x2000) /*!< Pin 13 selected */
#define GPIO_PIN_14 ((uint16_t)0x4000) /*!< Pin 14 selected */
#define GPIO_PIN_15 ((uint16_t)0x8000) /*!< Pin 15 selected */
#define GPIO_PIN_ALL ((uint16_t)0xFFFF) /*!< All pins selected */
#define GPIOA_PIN_AVAILABLE ((uint16_t)0xFFFF)
#define GPIOB_PIN_AVAILABLE ((uint16_t)0xFFFF)
#define GPIOC_PIN_AVAILABLE ((uint16_t)0xFFFF)
#define GPIOD_PIN_AVAILABLE ((uint16_t)0xFFFF)
#define IS_GPIO_PIN(PIN) ((((PIN) & (uint16_t)0x00) == 0x00) && ((PIN) != (uint16_t)0x00))
#define IS_GET_GPIO_PIN(PIN) \
(((PIN) == GPIO_PIN_0) || ((PIN) == GPIO_PIN_1) || ((PIN) == GPIO_PIN_2) || ((PIN) == GPIO_PIN_3) \
|| ((PIN) == GPIO_PIN_4) || ((PIN) == GPIO_PIN_5) || ((PIN) == GPIO_PIN_6) || ((PIN) == GPIO_PIN_7) \
|| ((PIN) == GPIO_PIN_8) || ((PIN) == GPIO_PIN_9) || ((PIN) == GPIO_PIN_10) || ((PIN) == GPIO_PIN_11) \
|| ((PIN) == GPIO_PIN_12) || ((PIN) == GPIO_PIN_13) || ((PIN) == GPIO_PIN_14) || ((PIN) == GPIO_PIN_15))
#define IS_GPIO_PIN_AVAILABLE(__INSTANCE__,__PIN__) \
((((__INSTANCE__) == GPIOA) && (((__PIN__) & (GPIOA_PIN_AVAILABLE)) != 0) && (((__PIN__) | (GPIOA_PIN_AVAILABLE)) == (GPIOA_PIN_AVAILABLE))) || \
(((__INSTANCE__) == GPIOB) && (((__PIN__) & (GPIOB_PIN_AVAILABLE)) != 0) && (((__PIN__) | (GPIOB_PIN_AVAILABLE)) == (GPIOB_PIN_AVAILABLE))) || \
(((__INSTANCE__) == GPIOC) && (((__PIN__) & (GPIOC_PIN_AVAILABLE)) != 0) && (((__PIN__) | (GPIOC_PIN_AVAILABLE)) == (GPIOC_PIN_AVAILABLE))) || \
(((__INSTANCE__) == GPIOD) && (((__PIN__) & (GPIOD_PIN_AVAILABLE)) != 0) && (((__PIN__) | (GPIOD_PIN_AVAILABLE)) == (GPIOD_PIN_AVAILABLE))))
/**
* @}
*/
/** @addtogroup GPIO_Port_Sources
* @{
*/
#define GPIOA_PORT_SOURCE ((uint8_t)0x00)
#define GPIOB_PORT_SOURCE ((uint8_t)0x01)
#define GPIOC_PORT_SOURCE ((uint8_t)0x02)
#define GPIOD_PORT_SOURCE ((uint8_t)0x03)
#define IS_GPIO_REMAP_PORT_SOURCE(PORTSOURCE) \
(((PORTSOURCE) == GPIOA_PORT_SOURCE) || ((PORTSOURCE) == GPIOB_PORT_SOURCE) || ((PORTSOURCE) == GPIOC_PORT_SOURCE) \
|| ((PORTSOURCE) == GPIOD_PORT_SOURCE))
#define IS_GPIO_EVENTOUT_PORT_SOURCE(PORTSOURCE) \
(((PORTSOURCE) == GPIOA_PORT_SOURCE) || ((PORTSOURCE) == GPIOB_PORT_SOURCE) || ((PORTSOURCE) == GPIOC_PORT_SOURCE) \
|| ((PORTSOURCE) == GPIOD_PORT_SOURCE))
#define IS_GPIO_EXTI_PORT_SOURCE(PORTSOURCE) \
(((PORTSOURCE) == GPIOA_PORT_SOURCE) || ((PORTSOURCE) == GPIOB_PORT_SOURCE) || ((PORTSOURCE) == GPIOC_PORT_SOURCE) \
|| ((PORTSOURCE) == GPIOD_PORT_SOURCE))
/**
* @}
*/
/** @addtogroup GPIO_Pin_sources
* @{
*/
#define GPIO_PIN_SOURCE0 ((uint8_t)0x00)
#define GPIO_PIN_SOURCE1 ((uint8_t)0x01)
#define GPIO_PIN_SOURCE2 ((uint8_t)0x02)
#define GPIO_PIN_SOURCE3 ((uint8_t)0x03)
#define GPIO_PIN_SOURCE4 ((uint8_t)0x04)
#define GPIO_PIN_SOURCE5 ((uint8_t)0x05)
#define GPIO_PIN_SOURCE6 ((uint8_t)0x06)
#define GPIO_PIN_SOURCE7 ((uint8_t)0x07)
#define GPIO_PIN_SOURCE8 ((uint8_t)0x08)
#define GPIO_PIN_SOURCE9 ((uint8_t)0x09)
#define GPIO_PIN_SOURCE10 ((uint8_t)0x0A)
#define GPIO_PIN_SOURCE11 ((uint8_t)0x0B)
#define GPIO_PIN_SOURCE12 ((uint8_t)0x0C)
#define GPIO_PIN_SOURCE13 ((uint8_t)0x0D)
#define GPIO_PIN_SOURCE14 ((uint8_t)0x0E)
#define GPIO_PIN_SOURCE15 ((uint8_t)0x0F)
#define IS_GPIO_PIN_SOURCE(PINSOURCE) \
(((PINSOURCE) == GPIO_PIN_SOURCE0) || ((PINSOURCE) == GPIO_PIN_SOURCE1) || ((PINSOURCE) == GPIO_PIN_SOURCE2) \
|| ((PINSOURCE) == GPIO_PIN_SOURCE3) || ((PINSOURCE) == GPIO_PIN_SOURCE4) || ((PINSOURCE) == GPIO_PIN_SOURCE5) \
|| ((PINSOURCE) == GPIO_PIN_SOURCE6) || ((PINSOURCE) == GPIO_PIN_SOURCE7) || ((PINSOURCE) == GPIO_PIN_SOURCE8) \
|| ((PINSOURCE) == GPIO_PIN_SOURCE9) || ((PINSOURCE) == GPIO_PIN_SOURCE10) || ((PINSOURCE) == GPIO_PIN_SOURCE11) \
|| ((PINSOURCE) == GPIO_PIN_SOURCE12) || ((PINSOURCE) == GPIO_PIN_SOURCE13) || ((PINSOURCE) == GPIO_PIN_SOURCE14) \
|| ((PINSOURCE) == GPIO_PIN_SOURCE15))
/**
* @}
*/
/** @defgroup GPIOx_Alternate_function_selection Alternate function selection
* @{
*/
/*
* Alternate function AF0
*/
#define GPIO_AF0_SW_JTAG ((uint8_t)0x00) /* SPI1 Alternate Function mapping */
#define GPIO_AF0_SPI1 ((uint8_t)0x00) /* SPI1 Alternate Function mapping */
#define GPIO_AF0_LPTIM ((uint8_t)0x00) /* LPTIM Alternate Function mapping */
#define GPIO_AF0_SPI2 ((uint8_t)0x00) /* SPI2 Alternate Function mapping */
#define GPIO_AF0_TIM8 ((uint8_t)0x00) /* TIM8 Alternate Function mapping */
#define GPIO_AF0_USART1 ((uint8_t)0x00) /* USART1 Alternate Function mapping */
#define GPIO_AF0_USART3 ((uint8_t)0x00) /* USART3 Alternate Function mapping */
#define GPIO_AF0_LPUART ((uint8_t)0x00) /* LPUART Alternate Function mapping */
#define GPIO_AF0_USART2 ((uint8_t)0x00) /* USART2 Alternate Function mapping */
/**
*
*/
/*
* Alternate function AF1
*/
#define GPIO_AF1_TIM5 ((uint8_t)0x01) /* TIM5 Alternate Function mapping */
#define GPIO_AF1_USART1 ((uint8_t)0x01) /* USART1 Alternate Function mapping */
#define GPIO_AF1_I2C2 ((uint8_t)0x01) /* I2C2 Alternate Function mapping */
#define GPIO_AF1_CAN ((uint8_t)0x01) /* CAN Alternate Function mapping */
#define GPIO_AF1_SPI2 ((uint8_t)0x01) /* SPI2 Alternate Function mapping */
#define GPIO_AF1_TIM9 ((uint8_t)0x01) /* TIM9 Alternate Function mapping */
#define GPIO_AF1_SPI1 ((uint8_t)0x01) /* SPI1 Alternate Function mapping */
#define GPIO_AF1_I2C1 ((uint8_t)0x01) /* I2C1 Alternate Function mapping */
#define GPIO_AF1 ((uint8_t)0x01) /* test Alternate Function mapping */
/**
*
*/
/*
* Alternate function AF2
*/
#define GPIO_AF2_TIM2 ((uint8_t)0x02) /* TIM2 Alternate Function mapping */
#define GPIO_AF2_TIM3 ((uint8_t)0x02) /* TIM3 Alternate Function mapping */
#define GPIO_AF2_TIM1 ((uint8_t)0x02) /* TIM1 Alternate Function mapping */
#define GPIO_AF2_LPTIM ((uint8_t)0x02) /* LPTIM Alternate Function mapping */
#define GPIO_AF2_TIM4 ((uint8_t)0x02) /* TIM4 Alternate Function mapping */
#define GPIO_AF2_LPUART ((uint8_t)0x02) /* LPUART Alternate Function mapping */
/**
*
*/
/*
* Alternate function AF3
*/
#define GPIO_AF3_EVENTOUT ((uint8_t)0x03) /* EVENTOUT Alternate Function mapping */
/**
*
*/
/*
* Alternate function AF4
*/
#define GPIO_AF4_USART2 ((uint8_t)0x04) /* USART2 Alternate Function mapping */
#define GPIO_AF4_LPUART ((uint8_t)0x04) /* LPUART Alternate Function mapping */
#define GPIO_AF4_USART1 ((uint8_t)0x04) /* USART1 Alternate Function mapping */
#define GPIO_AF4_TIM3 ((uint8_t)0x04) /* TIM3 Alternate Function mapping*/
#define GPIO_AF4_SPI1 ((uint8_t)0x04) /* SPI1 Alternate Function mapping */
#define GPIO_AF4_I2C1 ((uint8_t)0x04) /* I2C1 Alternate Function mapping */
#define GPIO_AF4_USART3 ((uint8_t)0x04) /* USART3 Alternate Function mapping */
/**
*
*/
/*
* Alternate function AF5
*/
#define GPIO_AF5_TIM2 ((uint8_t)0x05) /* TIM2 Alternate Function mapping */
#define GPIO_AF5_TIM1 ((uint8_t)0x05) /* TIM1 Alternate Function mapping */
#define GPIO_AF5_SPI1 ((uint8_t)0x05) /* SPI1 Alternate Function mapping */
#define GPIO_AF5_SPI2 ((uint8_t)0x05) /* SPI2 Alternate Function mapping */
#define GPIO_AF5_I2C2 ((uint8_t)0x05) /* I2C2 Alternate Function mapping */
#define GPIO_AF5_LPTIM ((uint8_t)0x05) /* LPTIM Alternate Function mapping */
#define GPIO_AF5_CAN ((uint8_t)0x05) /* CAN Alternate Function mapping */
#define GPIO_AF5_USART3 ((uint8_t)0x05) /* USART3 Alternate Function mapping */
/**
*
*/
/*
* Alternate function AF6
*/
#define GPIO_AF6_USART2 ((uint8_t)0x06) /* USART2 Alternate Function mapping */
#define GPIO_AF6_LPUART ((uint8_t)0x06) /* LPUART Alternate Function mapping */
#define GPIO_AF6_TIM5 ((uint8_t)0x06) /* TIM5 Alternate Function mapping */
#define GPIO_AF6_TIM8 ((uint8_t)0x06) /* TIM8 Alternate Function mapping */
#define GPIO_AF6_I2C2 ((uint8_t)0x06) /* I2C2 Alternate Function mapping */
#define GPIO_AF6_UART4 ((uint8_t)0x06) /* UART4 Alternate Function mapping */
#define GPIO_AF6_UART5 ((uint8_t)0x06) /* UART5 Alternate Function mapping */
#define GPIO_AF6_SPI1 ((uint8_t)0x06) /* SPI1 Alternate Function mapping */
/**
*
*/
/*
* Alternate function AF7
*/
#define GPIO_AF7_COMP1 ((uint8_t)0x07) /* COMP1 Alternate Function mapping */
#define GPIO_AF7_COMP2 ((uint8_t)0x07) /* COMP2 Alternate Function mapping */
#define GPIO_AF7_I2C1 ((uint8_t)0x07) /* I2C1 Alternate Function mapping */
#define GPIO_AF7_TIM8 ((uint8_t)0x07) /* TIM8 Alternate Function mapping */
#define GPIO_AF7_TIM5 ((uint8_t)0x07) /* TIM5 Alternate Function mapping */
#define GPIO_AF7_LPUART ((uint8_t)0x07) /* LPUART Alternate Function mapping */
#define GPIO_AF7_UART5 ((uint8_t)0x07) /* UART5 Alternate Function mapping */
#define GPIO_AF7_TIM1 ((uint8_t)0x07) /* TIM1 Alternate Function mapping */
#define GPIO_AF7_USART3 ((uint8_t)0x07) /* USART3 Alternate Function mapping */
/**
*
*/
/*
* Alternate function AF8
*/
#define GPIO_AF8_COMP1 ((uint8_t)0x08) /* COMP1 Alternate Function mapping */
#define GPIO_AF8_COMP2 ((uint8_t)0x08) /* COMP2 Alternate Function mapping */
#define GPIO_AF8_LPTIM ((uint8_t)0x08) /* LPTIM Alternate Function mapping */
#define GPIO_AF8_MCO ((uint8_t)0x08) /* MCO Alternate Function mapping */
/**
*
*/
/*
* Alternate function AF9
*/
#define GPIO_AF9_RTC ((uint8_t)0x09) /* RTC Alternate Function mapping */
#define GPIO_AF9_COMP1 ((uint8_t)0x09) /* COMP1 Alternate Function mapping */
#define GPIO_AF9_TSC ((uint8_t)0x09) /* COMP1 Alternate Function mapping */
/**
*
*/
/*
* Alternate function AF15
*/
#define GPIO_AF15 ((uint8_t)0x0F) /* NON Alternate Function mapping */
#define GPIO_NO_AF (GPIO_AF15)
/**
* @}
*/
/**
* IS_GPIO_AF macro definition
*/
#define IS_GPIO_AF(__AF__) (((__AF__) == GPIO_AF0_SPI1) || ((__AF__) == GPIO_AF1_TIM5) || \
((__AF__) == GPIO_AF0_LPTIM) || ((__AF__) == GPIO_AF1_USART1) || \
((__AF__) == GPIO_AF0_SPI2) || ((__AF__) == GPIO_AF1_I2C2) || \
((__AF__) == GPIO_AF0_TIM8) || ((__AF__) == GPIO_AF1_CAN) || \
((__AF__) == GPIO_AF0_USART1) || ((__AF__) == GPIO_AF1_SPI2) || \
((__AF__) == GPIO_AF0_USART3) || ((__AF__) == GPIO_AF1_TIM9) || \
((__AF__) == GPIO_AF0_LPUART) || ((__AF__) == GPIO_AF1_SPI1) || \
((__AF__) == GPIO_AF0_USART2) || ((__AF__) == GPIO_AF1_I2C1) || \
((__AF__) == GPIO_AF3_EVENTOUT) || ((__AF__) == GPIO_AF2_TIM2) || \
((__AF__) == GPIO_AF5_TIM2) || ((__AF__) == GPIO_AF2_TIM3) || \
((__AF__) == GPIO_AF5_TIM1) || ((__AF__) == GPIO_AF2_TIM1) || \
((__AF__) == GPIO_AF5_SPI1) || ((__AF__) == GPIO_AF2_LPTIM) || \
((__AF__) == GPIO_AF5_SPI2) || ((__AF__) == GPIO_AF2_TIM4) || \
((__AF__) == GPIO_AF5_I2C2) || ((__AF__) == GPIO_AF2_LPUART) || \
((__AF__) == GPIO_AF5_LPTIM) || ((__AF__) == GPIO_AF4_USART2) || \
((__AF__) == GPIO_AF5_CAN) || ((__AF__) == GPIO_AF4_LPUART) || \
((__AF__) == GPIO_AF5_USART3) || ((__AF__) == GPIO_AF4_USART1) || \
((__AF__) == GPIO_AF6_USART2) || ((__AF__) == GPIO_AF4_TIM3) || \
((__AF__) == GPIO_AF6_LPUART) || ((__AF__) == GPIO_AF4_SPI1) || \
((__AF__) == GPIO_AF6_TIM5) || ((__AF__) == GPIO_AF4_I2C1) || \
((__AF__) == GPIO_AF6_TIM8) || ((__AF__) == GPIO_AF4_USART3) || \
((__AF__) == GPIO_AF6_I2C2) || ((__AF__) == GPIO_AF7_COMP1) || \
((__AF__) == GPIO_AF6_UART4) || ((__AF__) == GPIO_AF7_COMP2) || \
((__AF__) == GPIO_AF6_UART5) || ((__AF__) == GPIO_AF7_I2C1) || \
((__AF__) == GPIO_AF6_SPI1) || ((__AF__) == GPIO_AF7_TIM8) || \
((__AF__) == GPIO_AF8_COMP1) || ((__AF__) == GPIO_AF7_TIM5) || \
((__AF__) == GPIO_AF8_COMP2) || ((__AF__) == GPIO_AF7_LPUART) || \
((__AF__) == GPIO_AF8_LPTIM) || ((__AF__) == GPIO_AF7_UART5) || \
((__AF__) == GPIO_AF9_RTC) || ((__AF__) == GPIO_AF7_TIM1) || \
((__AF__) == GPIO_AF9_COMP1) || ((__AF__) == GPIO_AF7_USART3) || \
((__AF__) == GPIO_AF15) || ((__AF__) == GPIO_NO_AF))
/**
* @}
*/
/** @defgroup GPIO Alternate function remaping
* @{
*/
#define AFIO_SPI1_NSS (11U)
#define AFIO_SPI2_NSS (10U)
#define IS_AFIO_SPIX(_PARAMETER_) \
(((_PARAMETER_) == AFIO_SPI1_NSS) ||((_PARAMETER_) == AFIO_SPI2_NSS))
typedef enum
{
AFIO_SPI_NSS_High_IMPEDANCE = 0U,
AFIO_SPI_NSS_High_LEVEL = 1U
}AFIO_SPI_NSSType;
#define IS_AFIO_SPI_NSS(_PARAMETER_) \
(((_PARAMETER_) == AFIO_SPI_NSS_High_IMPEDANCE) ||((_PARAMETER_) == AFIO_SPI_NSS_High_LEVEL))
typedef enum
{
AFIO_ADC_ETRI= 9U,
AFIO_ADC_ETRR = 8U
}AFIO_ADC_ETRType;
typedef enum
{
AFIO_ADC_TRIG_EXTI_0 = 0x0U,
AFIO_ADC_TRIG_EXTI_1 = 0x01U,
AFIO_ADC_TRIG_EXTI_2,
AFIO_ADC_TRIG_EXTI_3,
AFIO_ADC_TRIG_EXTI_4,
AFIO_ADC_TRIG_EXTI_5,
AFIO_ADC_TRIG_EXTI_6,
AFIO_ADC_TRIG_EXTI_7,
AFIO_ADC_TRIG_EXTI_8,
AFIO_ADC_TRIG_EXTI_9,
AFIO_ADC_TRIG_EXTI_10,
AFIO_ADC_TRIG_EXTI_11,
AFIO_ADC_TRIG_EXTI_12,
AFIO_ADC_TRIG_EXTI_13,
AFIO_ADC_TRIG_EXTI_14,
AFIO_ADC_TRIG_EXTI_15,
AFIO_ADC_TRIG_TIM8_CH3,
AFIO_ADC_TRIG_TIM8_CH4
}AFIO_ADC_Trig_RemapType;
#define IS_AFIO_ADC_ETR(_PARAMETER_) \
(((_PARAMETER_) == AFIO_ADC_ETRI) ||((_PARAMETER_) == AFIO_ADC_ETRR))
#define IS_AFIO_ADC_ETRI(_PARAMETER_) \
(((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_0) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_1)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_2) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_3)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_4) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_5)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_6) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_7)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_8) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_9)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_10) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_11)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_12) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_13)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_14) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_15)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_TIM8_CH4))
#define IS_AFIO_ADC_ETRR(_PARAMETER_) \
(((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_0) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_1)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_2) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_3)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_4) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_5)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_6) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_7)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_8) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_9)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_10) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_11)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_12) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_13) ||\
((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_14) ||((_PARAMETER_) == AFIO_ADC_TRIG_EXTI_15)|| \
((_PARAMETER_) == AFIO_ADC_TRIG_TIM8_CH3))
/**
* @}
*/
/** @addtogroup GPIO_Exported_Macros
* @{
*/
/**
* @}
*/
/** @addtogroup GPIO_Exported_Functions
* @{
*/
void GPIO_DeInit(GPIO_Module* GPIOx);
void GPIO_AFIOInitDefault(void);
void GPIO_InitPeripheral(GPIO_Module* GPIOx, GPIO_InitType* GPIO_InitStruct);
void GPIO_InitStruct(GPIO_InitType* GPIO_InitStruct);
uint8_t GPIO_ReadInputDataBit(GPIO_Module* GPIOx, uint16_t Pin);
uint16_t GPIO_ReadInputData(GPIO_Module* GPIOx);
uint8_t GPIO_ReadOutputDataBit(GPIO_Module* GPIOx, uint16_t Pin);
uint16_t GPIO_ReadOutputData(GPIO_Module* GPIOx);
void GPIO_SetBits(GPIO_Module* GPIOx, uint16_t Pin);
void GPIO_ResetBits(GPIO_Module* GPIOx, uint16_t Pin);
void GPIO_WriteBit(GPIO_Module* GPIOx, uint16_t Pin, Bit_OperateType BitCmd);
void GPIO_Write(GPIO_Module* GPIOx, uint16_t PortVal);
void GPIO_ConfigPinLock(GPIO_Module* GPIOx, uint16_t Pin);
void GPIO_ConfigEventOutput(uint8_t PortSource, uint8_t PinSource);
void GPIO_CtrlEventOutput(FunctionalState Cmd);
void GPIO_ConfigPinRemap(uint8_t PortSource, uint8_t PinSource, uint32_t AlternateFunction);
void GPIO_ConfigEXTILine(uint8_t PortSource, uint8_t PinSource);
void AFIO_ConfigSPINSSMode(uint32_t AFIO_SPIx_NSS,AFIO_SPI_NSSType SpiNssType);
void AFIO_ConfigADCExternalTrigRemap(AFIO_ADC_ETRType ADCETRType,AFIO_ADC_Trig_RemapType ADCTrigRemap);
#ifdef __cplusplus
}
#endif
#endif /* __N32G43X_GPIO_H__ */
/**
* @}
*/
/**
* @}
*/
/**
* @}
*/
注释
最新发布
由于提供的博客内容、目录等信息为空，无法提炼关键信息形成摘要。
扫一扫
4万+
被折叠的 条评论
为什么被折叠?
到【灌水乐园】发言
