SAPUI5整合Echarts

SAPUI5整合Echarts

1、在index.html中引入echarts.js

<script src="https://cdn.staticfile.org/echarts/4.3.0/echarts.min.js"></script>

2、编写ECharts.view.xml

<mvc:View
    controllerName="sap.ui.taking.controller.ECharts"
    xmlns="sap.m"
    xmlns:mvc="sap.ui.core.mvc">
    <VBox justifyContent="Center" alignContent="Center" fitContainer="true" alignItems="Center">
        <Button press="onECharts" text="出现图表"/>
    </VBox>
</mvc:View>

3、编写ECharts.controller.js

sap.ui.define([
    'sap/ui/core/mvc/Controller',
    'sap/ui/model/json/JSONModel'
], function(Controller,JSONModel) {


    'use strict';
    return Controller.extend("sap.ui.taking.controller.ECharts"
