MT7681 sdk最新消息

         最新消息消息确定，mt7681芯片已经在大陆供货，使用比较另类的andes 加mtk自家工具链的开发软件，没有像之前rt5350.mt7620之类的linux系统，芯片封装是40管脚的qfn.体积很小，但是焊接特别费劲，花了我半个小时焊接好的，mt7681只要外接一个普通8个管脚的spi flash当作程序存储器就能实现wifi，是目前世界上最小的wife方案，mt7681价格批量被定在2.5刀左右，自带电源管理内置dcdc，尽量减少用户外部原件，目前已经开始做板子了。 mt7681sdk相关的开发板，资料请见

http://shop63460958.taobao.com

Feature Support and Notes:
1: Add Tx packet length paramter (-l) for ATE command
2: Add Rx cnt Duration Paramter (-t) for ATE command
3: Add bandwidth select Paramter "-b" for ATE command
4: Fix ATE Tx Result is not correct as the TxPwr Per rate set wrong data
5: Fix RxCalibration  AvgRSSI0 is not exactly.
6. Summary Boardcast+multicast+nottomeUnicast frame in Rx calibration
7: Merge Calibration mode and Recovery Mode into Recovery.bin


8: Delect AT cmd refer to TCP
9: Rename uart rx to air compile option.
10:Do flash_merge.sh 3  as compile Recvoery Mode FW
11:Enable soft PWM by default
12:Query GPIO in APK can get GPIO0~4 status, no matter some of them are in PWM modee
13:Add Recovery Mode duration paratimer for customerization
14:Enable Uart symbol for customer usage


15:Support 802.11n  Bandwidth 40M  for Rx Path (Default use BW_40 in Smnt state, and BW_20 in other states).
16:release sample code and control Macro to  calcurate PMK by 7681 software, it will spend 6sec
17:release ws_got_ip(),  ws_got_ip_fail() to customer.
18:Release AES Decrypt/Encrypt API to customer.
19:Enable Reboot AT cmd in flag_sta.mk
20:Enable Power Calibratioin to improve Rx sensitivity
21:Separate main(), wifi_task, RxHandle  to *_pub.c, and release more .h file to customer.
22:Add paramter PRINT_FLAG  to determin if enable Printf_High()/DBGPRINT_HIGH()
23:add input paramter bSpecificAP, to inidicate if use Specific SSID for scanning


24:Flash Write API improvement
25:Add 3 APIs to enable GPIO interrput.
26:Add IoT_gpio_read( ) to Read gpio status:  (*pPolarity 0=output mode, 1=input mode),  (*pVal  0=low,  1=High)
27:use IoT_gpio_read() to instead of IoT_gpio_input() in uart2wifi handle


28:Fix FW Upgrade fail from uart, because FW upgrade size is not correct
29:Fix some AP may feedback DHCP OFFER/ACK in a long time--Set BOOTP flag as 0x0
30:Fix smnt/scan process abnormal by stop smnt, scan timer when do wifi_state_chg()
31:Fix uiP input fail while UDP client connect->disconnect-->connect (remote port change)
32:Fix Not send Auth frame if disable CFG_SUPPORT_MTK_SMNT.
33:Fix GPIO0,1 swap issue
34:Fix Rx/Tx Dequeue fail--Move wifi_rx_proc outside from ATEPeriodicExec()
35:Fix AP mode can not Tx/Rx


Known issue:
