1.目标效果

首先明白一点我们要做出的东西需要呈现一个怎样的形式，其中位于行业前排的无疑是SQLFlow：

当第一次看到此图我就决定血缘追踪就应该是这个样子，能够清晰的解析出每个字段和表之间的血缘关系。以此我们设定输出的基准，我们要做的项目目标就是如此。

2.代码实现

1.功能函数识别

该功能也是必须要实现的功能，我们需要明白这个SQL主要是干什么事情的。如果是插入INSERT或者是CREATE就有血缘分析的必要，如果是SELECT的话那么做简单的SQL解析即可。有了研究sqlparse源码的成果我们调用相应的函数即可：

sql="select * from table1;insert into table select a,b,c from table2"

if __name__ == '__main__':
    table_names=[]
    #sql=get_sqlstr('read_sql.txt')
    stmt_tuple=analysis_statements(sql)
    for each_stmt in stmt_tuple:
        type_name=get_main_functionsql(each_stmt)
        print(type_name)

输出：

那么对于SELECT我们就SQL涉及到的表追溯即可：

对于CREATE和INSERT的做血缘即可：

2.SQL标准格式

对于传入的SQL我们首先要让这条语句符合标准的SQL语句格式，这样对于传输格式保持一致，兼容很有作用。一般我们都是通过文本来读入。故需要读取文本做处理：

原始文本：

处理后：

if __name__ == '__main__':
    sql=get_sqlstr('read_sql.txt')
    print(sql)

3.解析AST树

得到的SQL无论是ANTRL还是SQLPARSE都是解析为一棵树的形式进行递归回溯。最终都要解析生产的SQL树：

sql="select * from table1;insert into table3 select a,b,c from table2"

if __name__ == '__main__':
    #sql=get_sqlstr('read_sql.txt')
    stmt_tuple=analysis_statements(sql)
    for each_stmt in stmt_tuple:
        table_names=[]
        type_name=get_main_functionsql(each_stmt)
        get_ASTTree(each_stmt)

4.最终效果：

SQL：

select
b.product_name "产品",
count(a.order_id) "订单量",
b.selling_price_max "销售价",
b.gross_profit_rate_max/100 "毛利率",
case when b.business_type =1 then '自营消化' when b.business_type =2 then '服务商消化'  end "消化模式"
from(select 'CRM签单' label,date(d.update_ymd) close_ymd,c.product_name,c.product_id,
    a.order_id,cast(a.recipient_amount as double) amt,d.cost
    from mysql4.dataview_fenxiao.fx_order a
    left join mysql4.dataview_fenxiao.fx_order_task b on a.order_id = b.order_id
    left join mysql7.dataview_trade.ddc_product_info c on cast(c.product_id as varchar) = a.product_ids and c.snapshot_version = 'SELLING'
    inner join (select t1.par_order_id,max(t1.update_ymd) update_ymd,
                sum(case when t4.product2_type = 1 and t5.shop_id is not null then t5.price else t1.order_hosted_price end) cost
               from hive.bdc_dwd.dw_mk_order t1
               left join hive.bdc_dwd.dw_mk_order_status t2 on t1.order_id = t2.order_id and t2.acct_day = substring(cast(DATE_ADD('day',-1,CURRENT_DATE) as varchar),9,2)
               left join mysql7.dataview_trade.mk_order_merchant t3 on t1.order_id = t3.order_id
               left join mysql7.dataview_trade.ddc_product_info t4 on t4.product_id = t3.MERCHANT_ID and t4.snapshot_version = 'SELLING'
               left join mysql4.dataview_scrm.sc_tprc_product_info t5 on t5.product_id = t4.product_id and t5.shop_id = t1.seller_id
               where t1.acct_day = substring(cast(DATE_ADD('day',-1,CURRENT_DATE) as varchar),9,2)
               and t2.valid_state in (100,200) ------有效订单
               and t1.order_mode = 10    --------产品消耗订单
               and t2.complete_state = 1  -----订单已经完成
               group by t1.par_order_id
    ) d on d.par_order_id  = b.task_order_id
    where c.product_type = 0 and date(from_unixtime(a.last_recipient_time)) > date('2016-01-01') and a.payee_type <> 1 -----------已收款
    UNION ALL
    select '企业管家消耗' label,date(c.update_ymd) close_ymd,b.product_name,b.product_id,
    a.task_id,(case when a.yb_price = 0 and b.product2_type = 1 then b.selling_price_min else a.yb_price end) amt,
    (case when a.yb_price = 0 and b.product2_type = 2 then 0 when b.product2_type = 1 and e.shop_id is not null then e.price else c.order_hosted_price end) cost
    from mysql8.dataview_tprc.tprc_task a
    left join mysql7.dataview_trade.ddc_product_info b on a.product_id = b.product_id and b.snapshot_version = 'SELLING'
    inner join hive.bdc_dwd.dw_mk_order c on a.order_id = c.order_id and c.acct_day = substring(cast(DATE_ADD('day',-1,CURRENT_DATE) as varchar),9,2)
    left join hive.bdc_dwd.dw_mk_order_status d on d.order_id = c.order_id and d.acct_day = substring(cast(DATE_ADD('day',-1,CURRENT_DATE) as varchar),9,2)
    left join mysql4.dataview_scrm.sc_tprc_product_info e on e.product_id = b.product_id and e.shop_id = c.seller_id
    where  d.valid_state in (100,200) and d.complete_state = 1  and c.order_mode = 10
    union ALL
    select '交易管理系统' label,date(t6.close_ymd) close_ymd,t4.product_name,t4.product_id,
    t1.order_id,(t1.order_hosted_price-t1.order_refund_price) amt,
    (case when t1.order_mode <> 11 then t7.user_amount when t1.order_mode = 11 and t4.product2_type = 1 and t5.shop_id is not null then t5.price else t8.cost end) cost
    from hive.bdc_dwd.dw_mk_order t1
    left join hive.bdc_dwd.dw_mk_order_business t2 on t1.order_id = t2.order_id and t2.acct_day=substring(cast(DATE_ADD('day',-1,CURRENT_DATE) as varchar),9,2)
    left join mysql7.dataview_trade.mk_order_merchant t3 on t1.order_id = t3.order_id
    left join mysql7.dataview_trade.ddc_product_info t4 on t4.product_id = t3.MERCHANT_ID and t4.snapshot_version = 'SELLING'
    left join mysql4.dataview_scrm.sc_tprc_product_info t5 on t5.product_id = t4.product_id and t5.shop_id = t1.seller_id
    left join hive.bdc_dwd.dw_fact_task_ss_daily t6 on t6.task_id = t2.task_id and t6.acct_time=date_format(date_add('day',-1,current_date),'%Y-%m-%d')
    left join (select a.task_id,sum(a.user_amount) user_amount
               from hive.bdc_dwd.dw_fn_deal_asyn_order a
               where a.is_new=1 and a.service='Trade_Payment' and a.state=1 and a.acct_day=substring(cast(DATE_ADD('day',-1,CURRENT_DATE) as varchar),9,2)
               group by a.task_id)t7 on t7.task_id = t2.task_id
    left join (select t1.par_order_id,sum(t1.order_hosted_price - t1.order_refund_price) cost
               from hive.bdc_dwd.dw_mk_order t1
               where t1.acct_day = substring(cast(DATE_ADD('day',-1,CURRENT_DATE) as varchar),9,2) and t1.order_type = 1 and t1.order_stype = 4 and t1.order_mode = 12
               group by t1.par_order_id) t8 on t1.order_id = t8.par_order_id
    where t1.acct_day = substring(cast(DATE_ADD('day',-1,CURRENT_DATE) as varchar),9,2)
    and t1.order_type = 1 and t1.order_stype in (4,5) and t1.order_mode <> 12 and t4.product_id is not null and t1.order_hosted_price > 0 and t6.is_deal = 1 and t6.close_ymd >= '2018-12-31'
)a
left join mysql7.dataview_trade.ddc_product_info b on a.product_id = b.product_id and b.snapshot_version = 'SELLING'
where b.product2_type = 1 -------标品
and close_ymd between DATE_ADD('day',-7,CURRENT_DATE)  and DATE_ADD('day',-1,CURRENT_DATE)
GROUP BY b.product_name,
b.selling_price_max,
b.gross_profit_rate_max/100,
b.actrul_supply_num,
case when b.business_type =1 then '自营消化' when b.business_type =2 then '服务商消化'  end
order by count(a.order_id) desc
limit 10

if __name__ == '__main__':
    table_names=[]
    sql=get_sqlstr('read_sql.txt')
