zskiplistNode* zslGetElementByRank(zskiplist *zsl, unsigned long rank) {
zskiplistNode *x;
unsigned long traversed = 0;
int i;
// 获取跳表的表头
x = zsl->header;
// 从最大层数开始逐一遍历
for (i = zsl->level-1; i >= 0; i–) {
while (x->level[i].forward && (traversed + x->level[i].span) <= rank)
{
traversed += x->level[i].span;
x = x->level[i].forward;
}
if (traversed == rank) {
return x;
}
}
return NULL;
}
这种设计使得查找效率提升了，但也会有一定的负面影响，那就是为了维持相邻两层上的结点数的比例为2:1，一旦新增结点或删除结点就需要调整数据结构，从而带来额外的开销。为了避免这种问题，跳表在创建结点时，采用的是另外一种设计方法——随机生成每个结点的层数。此时，相邻的两层链表上的结点数不需要严格的是2:1的关系，降低了插入操作的复杂度。
看一下插入操作的代码，如下所示，
/* Insert a new node in the skiplist. Assumes the element does not already
-
exist (up to the caller to enforce that). The skiplist takes ownership
-
of the passed SDS string ‘ele’. */
zskiplistNode *zslInsert(zskiplist *zsl, double score, sds ele) {
zskiplistNode *update[ZSKIPLIST_MAXLEVEL], *x;
unsigned int rank[ZSKIPLIST_MAXLEVEL];
int i, level;serverAssert(!isnan(score));
x = zsl->header;
for (i = zsl->level-1; i >= 0; i–) {
/* store rank that is crossed to reach the insert position /
rank[i] = i == (zsl->level-1) ? 0 : rank[i+1];
while (x->level[i].forward &&
(x->level[i].forward->score < score ||
(x->level[i].forward->score == score &&
sdscmp(x->level[i].forward->ele,ele) < 0)))
{
rank[i] += x->level[i].span;
x = x->level[i].forward;
}
update[i] = x;
}
/ we assume the element is not already inside, since we allow duplicated-
scores, reinserting the same element should never happen since the
-
caller of zslInsert() should test in the hash table if the element is
-
already inside or not. */
level = zslRandomLevel();
if (level > zsl->level) {
for (i = zsl->level; i < level; i++) {
rank[i] = 0;
update[i] = zsl->header;
update[i]->level[i].span = zsl->length;
}
zsl->level = level;
}
x = zslCreateNode(level,score,ele);
for (i = 0; i < level; i++) {
x->level[i].forward = update[i]->level[i].forward;
update[i]->level[i].forward = x;/* update span covered by update[i] as x is inserted here */
x->level[i].span = update[i]->level[i].span - (rank[0] - rank[i]);
update[i]->level[i].span = (rank[0] - rank[i]) + 1;
}
/* increment span for untouched levels */
for (i = level; i < zsl->level; i++) {
update[i]->level[i].span++;
}x->backward = (update[0] == zsl->header) ? NULL : update[0];
if (x->level[0].forward)
x->level[0].forward->backward = x;
else
zsl->tail = x;
zsl->length++;
return x;
} -
zslRandomLevel函数决定了跳表结点层数。层数初始化为1，然后生成随机数小于ZSKPLIST\_P（随机数概率阈值）则增加1层，最大层数ZSKIPLIST\_MAXLEVEL为64。代码如下，
#define ZSKIPLIST_MAXLEVEL 64 /* Should be enough for 2^64 elements /
#define ZSKIPLIST_P 0.25 / Skiplist P = 1/4 /
/ Returns a random level for the new skiplist node we are going to create.
- The return value of this function is between 1 and ZSKIPLIST_MAXLEVEL
- (both inclusive), with a powerlaw-alike distribution where higher
- levels are less likely to be returned. */
int zslRandomLevel(void) {
// 初始化层数
int level = 1;
while ((random()&0xFFFF) < (ZSKIPLIST_P * 0xFFFF))
level += 1;
return (level<ZSKIPLIST_MAXLEVEL) ? level : ZSKIPLIST_MAXLEVEL;
}
### 哈希表和跳表组合
哈希表的数据结构就不多说了，那么这两种索引结构如何组合使用的？
在创建一个zset时，代码会先调用dictCreate函数创建哈希表，再调用zslCreate函数创建跳表。如下所示，
zs = zmalloc(sizeof(*zs));
zs->dict = dictCreate(&zsetDictType,NULL);
zs->zsl = zslCreate();
在Sorted Set插入数据时会调用zsetAdd函数，下面看一下该函数，
/* Add a new element or update the score of an existing element in a sorted
-
set, regardless of its encoding.
-
The set of flags change the command behavior. They are passed with an integer
-
pointer since the function will clear the flags and populate them with
-
other flags to indicate different conditions.
-
The input flags are the following:
-
ZADD_INCR: Increment the current element score by ‘score’ instead of updating
-
the current element score. If the element does not exist, we -
assume 0 as previous score. -
ZADD_NX: Perform the operation only if the element does not exist.
-
ZADD_XX: Perform the operation only if the element already exist.
-
When ZADD_INCR is used, the new score of the element is stored in
-
‘*newscore’ if ‘newscore’ is not NULL.
-
The returned flags are the following:
-
ZADD_NAN: The resulting score is not a number.
-
ZADD_ADDED: The element was added (not present before the call).
-
ZADD_UPDATED: The element score was updated.
-
ZADD_NOP: No operation was performed because of NX or XX.
-
Return value:
-
The function returns 1 on success, and sets the appropriate flags
-
ADDED or UPDATED to signal what happened during the operation (note that
-
none could be set if we re-added an element using the same score it used
-
to have, or in the case a zero increment is used).
-
The function returns 0 on erorr, currently only when the increment
-
produces a NAN condition, or when the ‘score’ value is NAN since the
-
start.
-
The commad as a side effect of adding a new element may convert the sorted
-
set internal encoding from ziplist to hashtable+skiplist.
-
Memory managemnet of ‘ele’:
-
The function does not take ownership of the ‘ele’ SDS string, but copies
-
it if needed. */
int zsetAdd(robj *zobj, double score, sds ele, int *flags, double newscore) {
/ Turn options into simple to check vars. */
int incr = (*flags & ZADD_INCR) != 0;
int nx = (*flags & ZADD_NX) != 0;
int xx = (*flags & ZADD_XX) != 0;
flags = 0; / We’ll return our response flags. */
double curscore;/* NaN as input is an error regardless of all the other parameters. */
if (isnan(score)) {
*flags = ZADD_NAN;
return 0;
}/* Update the sorted set according to its encoding. */
// 如果采用ziplist编码方式，zsetAdd函数的处理逻辑
if (zobj->encoding == OBJ_ENCODING_ZIPLIST) {
unsigned char *eptr;if ((eptr = zzlFind(zobj->ptr,ele,&curscore)) != NULL) { /* NX? Return, same element already exists. */ if (nx) { *flags |= ZADD_NOP; return 1; } /* Prepare the score for the increment if needed. */ if (incr) { score += curscore; if (isnan(score)) { *flags |= ZADD_NAN; return 0; } if (newscore) *newscore = score; } /* Remove and re-insert when score changed. */ if (score != curscore) { zobj->ptr = zzlDelete(zobj->ptr,eptr); zobj->ptr = zzlInsert(zobj->ptr,ele,score); *flags |= ZADD_UPDATED; } return 1; } else if (!xx) { /* Optimize: check if the element is too large or the list * becomes too long *before* executing zzlInsert. */ zobj->ptr = zzlInsert(zobj->ptr,ele,score); if (zzlLength(zobj->ptr) > server.zset_max_ziplist_entries || sdslen(ele) > server.zset_max_ziplist_value) zsetConvert(zobj,OBJ_ENCODING_SKIPLIST); if (newscore) *newscore = score; *flags |= ZADD_ADDED; return 1; } else { *flags |= ZADD_NOP; return 1; }// 如果采用zipList的编码方式，zsetAdd函数的处理逻辑
} else if (zobj->encoding == OBJ_ENCODING_SKIPLIST) {
zset *zs = zobj->ptr;
zskiplistNode *znode;
dictEntry de;
// 从哈希表中查询新增元素
de = dictFind(zs->dict,ele);
// 如果查到新增元素
if (de != NULL) {
/ NX? Return, same element already exists. */
if (nx) {
*flags |= ZADD_NOP;
return 1;
}
// 从哈希表中查询元素的权重
curscore = (double)dictGetVal(de);/* Prepare the score for the increment if needed. */ // 如果要更新权重值 if (incr) { score += curscore; if (isnan(score)) { *flags |= ZADD_NAN; return 0; } if (newscore) *newscore = score; } /* Remove and re-insert when score changes. */ // 如果权重发生了变化 if (score != curscore) { // 更新跳表结点 znode = zslUpdateScore(zs->zsl,curscore,ele,score); /* Note that we did not removed the original element from * the hash table representing the sorted set, so we just * update the score. */ // 让哈希表元素值指向跳表结点的权重 dictGetVal(de) = &znode->score; /* Update score ptr. */ *flags |= ZADD_UPDATED; } return 1; } else if (!xx) { ele = sdsdup(ele); znode = zslInsert(zs->zsl,score,ele); serverAssert(dictAdd(zs->dict,ele,&znode->score) == DICT_OK); *flags |= ZADD_ADDED; if (newscore) *newscore = score; return 1; } else { *flags |= ZADD_NOP; return 1; }} else {
serverPanic(“Unknown sorted set encoding”);
}
return 0; /* Never reached. */
}
zsetAdd函数会先判断zset时采用ziplist的编码方式还是skiplist的编码方式。如果是skiplist的编码方式，它会先调用哈希表的dictFind函数，查找要插入的元素是否存在。如果插入的元素不存在，则直接调用zslInsert和dictAdd插入新元素；如果插入的元素存在，则zsetAdd会判断是否需要增加元素的权重值。如果权重值发生了变化，zsetAdd函数会调用zslUpdateScore函数，更新跳表中的元素权重值。紧接着，zsetAdd函数会把哈希表中该元素指向跳表结点中的权重值，这样一来，哈希表中元素的权重值就可以保持最新值。
## 总结
Sorted Set数据类型的底层实现同时采用了哈希表和跳表两种结构设计，提高了检索效率。哈希表能够快速的查找单个元素及其权重值，而跳表能快速快速检索到某一个结点是否在跳表的数据结构中。
那么编码方式是如何进行选择的呢？针对不同长度的数据，使用不同大小的元数据信息（prevlen和encoding），这样可以有效的节省内存开销。当有序集合元素数量小于128且所有元素长度小于64byte，zset采用的是ziplist编码方式。
可以看一下ziplist.c源码中的zipStoreEntryEncoding函数，
/* Write the encoidng header of the entry in ‘p’. If p is NULL it just returns
-
the amount of bytes required to encode such a length. Arguments:
-
‘encoding’ is the encoding we are using for the entry. It could be
-
ZIP_INT_* or ZIP_STR_* or between ZIP_INT_IMM_MIN and ZIP_INT_IMM_MAX
-
for single-byte small immediate integers.
-
‘rawlen’ is only used for ZIP_STR_* encodings and is the length of the
-
srting that this entry represents.
-
The function returns the number of bytes used by the encoding/length
-
header stored in ‘p’. */
unsigned int zipStoreEntryEncoding(unsigned char *p, unsigned char encoding, unsigned int rawlen) {
unsigned char len = 1, buf[5];if (ZIP_IS_STR(encoding)) {
/* Although encoding is given it may not be set for strings,
* so we determine it here using the raw length. */
if (rawlen <= 0x3f) {
if (!p) return len;
buf[0] = ZIP_STR_06B | rawlen;
} else if (rawlen <= 0x3fff) {
len += 1;
if (!p) return len;
buf[0] = ZIP_STR_14B | ((rawlen >> 8) & 0x3f);
buf[1] = rawlen & 0xff;
