端口隔离

原创于 2025-05-06 23:19:04 发布 · 272 阅读

1 ·

CC 4.0 BY-SA版权

文章标签：

#运维

sw1配置

[SW1]int g0/0/1
[SW1-GigabitEthernet0/0/1]di th
#
interface GigabitEthernet0/0/1
port link-type access
port default vlan 10
port-isolate enable group 1
#
return
[SW1-GigabitEthernet0/0/1]int g0/0/2
[SW1-GigabitEthernet0/0/2]di th
#
interface GigabitEthernet0/0/2
port link-type access
port default vlan 10
port-isolate enable group 1
#
return
[SW1-GigabitEthernet0/0/2]int g0/0/3
[SW1-GigabitEthernet0/0/3]di th
#
interface GigabitEthernet0/0/3
port link-type access
port default vlan 10
port-isolate enable group 1

sw2配置

[SW2-GigabitEthernet0/0/1]di th
#
interface GigabitEthernet0/0/1
port link-type access
port default vlan 10
#
return
[SW2-GigabitEthernet0/0/2]di th
#
interface GigabitEthernet0/0/1
port link-type access
port default vlan 10
#
return
[SW2-GigabitEthernet0/0/3]di th
#
interface GigabitEthernet0/0/1
port link-type access
port default vlan 10
