Ceph-Quincy-17.2.1版本集群部署

1.环境准备

操作系统：CentOS-8.5.2111-x86_64-dvd1.iso
Ceph版本：Quincy-17.2.1

1.1 关闭防火墙

systemctl stop firewalld.service
systemctl disable firewalld.service

1.2 关闭Selinux

sed -i ‘/^SELINUX=.*/c SELINUX=disabled’ /etc/selinux/config
setenforce 0
reboot

1.3 配置yum源

rename .repo .repo.bak CentOS-Linux-*.repo

cat<<END>/etc/yum.repos.d/ceph.repo
[Ceph]
name=Ceph packages for $basearch
baseurl=https://mirrors.aliyun.com/ceph/rpm-quincy/el8/x86_64/
enabled=1
gpgcheck=0
type=rpm-md

[Ceph-noarch]
name=Ceph noarch packages
baseurl=https://mirrors.aliyun.com/ceph/rpm-quincy/el8/x86_64/
enabled=1
gpgcheck=0
type=rpm-md

[ceph-source]
name=Ceph source packages
baseurl=https://mirrors.aliyun.com/ceph/rpm-quincy/el8/x86_64/
enabled=1
gpgcheck=0
type=rpm-md
END

wget -O /etc/yum.repos.d/CentOS-Base.repo https://mirrors.aliyun.com/repo/Centos-8.repo
sed -i -e ‘/mirrors.cloud.aliyuncs.com/d’ -e ‘/mirrors.aliyuncs.com/d’ /etc/yum.repos.d/CentOS-Base.repo
yum clean all && yum makecache

1.4 时间同步

dnf install chrony -y
systemctl start chronyd.service && systemctl enable chronyd.service
timedatectl set-timezone "Asia/Shanghai"

vi /etc/chrony.conf
#pool 2.centos.pool.ntp.org iburst
server ntp.aliyun.com iburst
server cn.ntp.org.cn iburst

systemctl restart chronyd.service
# 执行时间同步操作
chronyc sources -v

# 查看当前系统时间
date

1.5 cephadm下载

curl --silent --remote-name --location https://github.com/ceph/ceph/raw/quincy/src/cephadm/cephadm
chmod +x cephadm

2.部署

2.1 环境依赖

dnf install python3 podman

更换podman国内源
cat <<END> /etc/containers/registries.conf
[registries.search]
registries = ['0k0953tv.mirror.aliyuncs.com', 'registry.redhat.io', 'docker.io']
[registries.insecure]
registries = []
[registries.block]
registries = []
unqualified-search-registries = ["registry.fedoraproject.org", "registry.access.redhat.com", "registry.centos.org", "docker.io"]
END

2.2 cephadm部署集群

在三个节点上运行
./cephadm add-repo --release quincy
./cephadm install
mkdir -p /etc/ceph

在 ceph-01节点上运行
cephadm bootstrap --mon-ip 192.168.120.71

三个节点都需要安装
cephadm install ceph-common

2.3 扩容节点

# 在 ceph-01节点执行
ssh-copy-id -f -i /etc/ceph/ceph.pub root@ceph-01
ssh-copy-id -f -i /etc/ceph/ceph.pub root@ceph-02
ssh-copy-id -f -i /etc/ceph/ceph.pub root@ceph-03

# 或者，需要在集群三个节点，都执行以下命令，保证集群间所有节点都是免密登录的：
ssh-keygen -t rsa
ssh-copy-id -f -i /root/.ssh/id_rsa.pub root@ceph-01
ssh-copy-id -f -i /root/.ssh/id_rsa.pub root@ceph-02
ssh-copy-id -f -i /root/.ssh/id_rsa.pub root@ceph-03

# 添加节点到集群
ceph orch host add ceph-02 192.168.120.72
ceph orch host add ceph-03 192.168.120.73

# 设置标签 _admin，标签设置完毕，会自动 拷贝 ceph.conf，ceph.client.admin.keyring文件
ceph orch host label add ceph-02 _admin
ceph orch host label add ceph-03 _admin

# 如果没有设置 _admin 标签，需要手动拷贝配置
scp /etc/ceph/ceph.conf root@ceph-02:/etc/ceph/
scp /etc/ceph/ceph.conf root@ceph-03:/etc/ceph/

scp /etc/ceph/ceph.client.admin.keyring root@ceph-02:/etc/ceph/
scp /etc/ceph/ceph.client.admin.keyring root@ceph-03:/etc/ceph/

2.4 添加OSD服务

# 注意：下面的  /dev/sdb 是在节点机器上的一个未使用的磁盘
ceph orch daemon add osd ceph-01:/dev/sdb
ceph orch daemon add osd ceph-02:/dev/sdb
ceph orch daemon add osd ceph-03:/dev/sdb

2.5 创建一个文件系统卷

ceph fs volume create testfs

# 设置一下副本数量
ceph orch apply mds testfs --placement="2 ceph-02 ceph-03"

# 在节点 ceph-01 上添加 mds 服务
ceph orch daemon add mds testfs ceph-01

# 查看mds状态
ceph mds stat

# 查看一下文件系统状态
ceph fs status testfs
