本文介绍了在生产环境中，IRIS集群的镜像状态对于故障转移的重要性。虽然IRIS内部API提供了相关接口，但缺乏方便的外部集成方式。文章展示了如何在IRIS上开发一个REST接口，用于暴露镜像状态数据，以供外部系统进行企业级监控集成。接口实现涉及切换到%SYS命名空间调用API，并强调了接口安全性和权限管理的重要性。

摘要生成于 C知道，由 DeepSeek-R1 满血版支持，前往体验 >

在生产环境中IRIS通常以故障转移集群的形态被部署，而集群中各故障转移成员的镜像状态将决定该集群在故障发生时是否能够顺利切换保障业务不中断。因此，成员状态通常也是运维团队需要巡检或监控的目标。

尽管IRIS内部API提供了丰富的集群配置、成员状态等一系列接口，但除Portal上的镜像监视器外，并没有特定的接口便于外部系统访问(如进行企业级监控集成时)，也没有整合好的监控接口可用，但在IRIS上开发一个REST接口暴露镜像状态数据并不困难，如下所示：

Include%syMirror
Class Monitor.MirrorMonitoring Extends %CSP.REST
{

/// Default the Content-Type for this application.
Parameter CONTENTTYPE = "application/json";
/// By default convert the input stream to Unicode
Parameter CONVERTINPUTSTREAM = 1;
/// The default response charset is utf-8
Parameter CHARSET = "utf-8";
ClassMethod GetMirrorStatus() As %Status
{
        set tSC = $$$OK
        //保存起始命名空间
        Set nsName = ##Class(%SYSTEM.SYS).NameSpace()
        set mirrorName=$lg(##class(%SYSTEM.Mirror).GetMirrorNames(),1)
        if "" = mirrorName {
            Quit tSC
        }
        #Dim mirrorStatus as %DynamicObject = {}
        //进入%SYS命名空间，通过系统API获取镜像状态
        zn "%SYS"
        //获取仲裁状态
        Set mir = ##class(Config.Mirrors).Open(mirrorName)
        #Dim arbiterStatus as %DynamicObject = {}
        Set arbiteraddr = $P(mir.ArbiterNode,"^",1)
        Set arbiterStatus.ArbiterNode = arbiteraddr
        Set vip = $P(mir.VirtualAddress,"^",1)
        Set arbiterStatus.VirtualAddress = vip

        Set modeString = ""
        Set mode = $SYSTEM.Mirror.FailoverRule()
        If mode = $$$ArbiterControlledMirrorFailover {
            Set modeString = "Arbiter Controlled"
        } ElseIf mode = $$$AgentControlledMirrorFailover {
            Set modeString = "Agent Controlled"
        } Else {
            Set modeString = "User Controlled"
        }
        Set arbiterStatus.FailoverMode = modeString

        Set stateString = ""
        Set state = $SYSTEM.Mirror.ArbiterState()
        Set thisConnected = $SELECT($ZB(+state,+$$$ArbiterConnected,1)'=0:1,1:0)
        Set otherConnected = $SELECT($ZB(+state,+$$$ArbiterPeerConnected,1)'=0:1,1:0)
        If 'thisConnected {
            Set stateString = "This member is not connected to the arbiter"
        } ElseIf 'otherConnected {
            Set stateString = "Only this member is connected to the arbiter"
        } Else {
            Set stateString = "Both failover members are connected to the arbiter"
        }
        Set arbiterStatus.ConnectionStatus = stateString

        set mirrorStatus.ArbiterStatus = arbiterStatus


        //获取镜像成员状态
        #Dim memberArray as %DynamicArray = []
        Set result = ##class(%ResultSet).%New("SYS.Mirror:MemberStatusList")
        Set tSC = result.Execute(mirrorName)
        while result.Next() {
            #Dim memberStatus as %DynamicObject = {}
            Set colCount = result.GetColumnCount()
            for i = 1:1:colCount
            {
                set name = result.GetColumnName(i)
                set value = result.GetData(i)
                d memberStatus.%Set(name,value)
            }
            d memberArray.%Push(memberStatus)
        }
        set mirrorStatus.MemberStatus = memberArray

        //获取镜像数据库状态
        #Dim dbArray as %DynamicArray = []
        Set bdr = ##class(%ResultSet).%New("SYS.Mirror:MirroredDatabaseList")
        Set tSC = bdr.Execute()
        while bdr.Next() {
            #Dim dbStatus as %DynamicObject = {}
            Set colCount = bdr.GetColumnCount()
            for i = 1:1:colCount
            {
                set name = bdr.GetColumnName(i)
                set value = bdr.GetData(i)
                d dbStatus.%Set(name,value)
            }
            d dbArray.%Push(dbStatus)
        }
        set mirrorStatus.DatabaseStatus = dbArray

        //返回被执行时的命名空间
        zn nsName
        d mirrorStatus.%ToJSON()
        Quit tSC
}

XData UrlMap [ XMLNamespace = "http://www.intersystems.com/urlmap" ]
{
<Routes>
<Route Url="/getMirrorStatus" Method="GET" Call="GetMirrorStatus"/>
</Routes>
}

}
