在线录屏是指在互联网上进行屏幕录制的过程。它允许用户通过网络连接，将自己的屏幕活动记录下来，并可以在需要时进行播放、共享或存档。在线录屏常用于教育、培训、演示、游戏等场景，可以帮助用户展示操作步骤、解决问题、分享经验等。通常，在线录屏工具提供了丰富的功能，例如选择录制区域、添加音频注释、调整录制质量等，以满足用户的不同需求。
复制代码 隐藏代码
// 检查浏览器是否支持 MediaDevices 接口
if (navigator.mediaDevices) {
// 获取媒体设备的用户授权
navigator.mediaDevices.getUserMedia({ audio: true, video: true })
.then(function(stream) {
// 获取到媒体流后的处理逻辑
// 在这里可以对获取到的音视频流进行操作
// 例如：显示视频流、播放音频流等
})
.catch(function(error) {
// 处理获取媒体设备失败的情况
console.log('获取媒体设备失败: ' + error.message);
});
} else {
console.log('您的浏览器不支持 MediaDevices 接口');
}
上述示例代码首先检查浏览器是否支持 MediaDevices 接口。如果支持，它会调用 getUserMedia 方法来请求用户授权访问媒体设备（包括音频和视频）。如果用户授权成功，将返回一个媒体流对象，可以在 .then 方法中对该流进行处理。如果用户拒绝授权或发生其他错误，将在 .catch 方法中处理错误情况。
通过这样的调用方式，您可以使用 MediaDevices 接口来获取媒体设备的流，并对其进行进一步的操作和处理。
浏览器兼容性：
可以说是大部分不支持，毕竟是新的Web API接口，详细可以去MDN中查看MediaDevices - Web API 接口参考 | MDN (mozilla.org)
录屏可以对整个屏幕，某个软件甚至某个进程单独录取。
相关实现代码：
潦草布局一下，毕竟只是个玩具，不需要多华丽。
复制代码 隐藏代码
<div class="RecordScreen">
<div class="Operate">
<div class="Content">
<div class="flex Start" @click="onStart" v-if="!setState">
<el-icon size="50px" color=" var(--el-color-primary)">
<VideoCameraFilled/>
</el-icon>
<el-button type="primary">{{ currentLang.start }}</el-button>
</div>
<div class="flex Pause" @click="onPause" v-if="setState === 'recording'">
<el-icon size="50px" color=" var(--el-color-primary)">
<VideoPause/>
</el-icon>
<el-button type="info">{{ currentLang.stop }}</el-button>
</div>
<div class="flex Resume" @click="onResume" v-if="setState === 'paused'">
<el-icon size="50px" color=" var(--el-color-primary)">
<VideoPlay/>
</el-icon>
<el-button type="info">{{ currentLang.continue }}</el-button>
</div>
<div class="flex Stop" @click="onStop" v-if="setState">
<el-icon size="50px" color=" var(--el-color-primary)">
<SwitchButton/>
</el-icon>
<el-button type="danger">{{ currentLang.end }}</el-button>
</div>
</div>
<el-divider v-if="VideoURL"/>
<div class="Operate__Download">
<div v-if="!VideoURL"
style="width: 100vw;height: 100vh;position: absolute;top: 0;left: 0;z-index: 99999;background-color: var(--el-bg-color);">
</div>
<el-input v-model="DownloadName" placeholder="please input">
<template #append>.mp4</template>
</el-input>
<el-button type="primary" :icon="Download" @click="onDownload">{{ currentLang.saveVideo }}</el-button>
</div>
</div>
<div class="RecordScreen__state">
<div v-if="setState" class="REC">
<div></div>
<div>REC</div>
</div>
<el-icon v-if="!VideoURL" size="40vh" color="var(--el-color-primary)">
<Monitor/>
</el-icon>
<div v-if="setState" class="Timing">
<div>{{ Hour }}:{{ Minute }}:{{ Seconds }}</div>
<div>{{ setState === 'paused' ? currentLang.pauseScreenRecording : currentLang.recordingScreen }}</div>
</div>
<video v-if="VideoURL" :src="VideoURL" controls></video>
</div>
</div>
简单定义几个变量
复制代码 隐藏代码
const VideoURL = ref('')
const DownloadName = ref('')
const setState = ref('')
let mediaRecorder = null
let mediaThen = null
开始录屏
复制代码 隐藏代码
const onStart = () => {
VideoURL.value = ''
mediaThen = null
navigator.mediaDevices.getDisplayMedia({video: true, audio: true})
.then(mediaStream => {
mediaThen = mediaStream
mediaRecorder = new MediaRecorder(mediaStream);
Timing()
console.log(mediaRecorder)
const chunks = [];
mediaRecorder.ondataavailable = event => {
if (event.data.size > 0) {
chunks.push(event.data);
}
};
mediaRecorder.onstop = () => {
const blob = new Blob(chunks, {type: 'video/mp4'});
const recordedVideoURL = URL.createObjectURL(blob);
VideoURL.value = recordedVideoURL
setState.value = '' //inactive
};
mediaRecorder.start();
setState.value = mediaRecorder.state //recording
})
.catch(error => {
// if (error == 'DOMException: Permission denied') return false
// ElMessageBox({
// title: '当前浏览器或设备不支持录屏',
// confirmButtonText: '确定',
// message: h('p', null, [
// h('span', null, error),
// ]),
// })
});
}
暂停录屏
复制代码 隐藏代码
const onPause = () => {
clearTimeout(timer)
mediaRecorder.pause()
setState.value = mediaRecorder.state //paused
}
恢复录屏
复制代码 隐藏代码
const onResume = () => {
Timing()
mediaRecorder.resume()
setState.value = mediaRecorder.state //recording
}
结束录屏
复制代码 隐藏代码
const onStop = () => {
mediaRecorder.stop()
mediaThen.getTracks().forEach(track => track.stop())
setState.value = '' //inactive
}
最后把样式补上
复制代码 隐藏代码
<style scoped lang="scss">
home.php?mod=space&uid=556296 Flex {
display: flex;
align-items: center;
justify-content: center;
}
@mixin side {
padding: 10px;
gap: 10px;
}
@mixin font($size: 0.9rem, $Color: red, $spacing: 0.2rem) {
font-size: $size;
line-height: $size;
color: $Color;
letter-spacing: $spacing;
}
.RecordScreen {
@font-face {
font-family: digital-display;
src: url(data:font/woff2;base64,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)
}
home.php?mod=space&uid=697773 Flex;
justify-content: space-around;
height: 100vh;
overflow: hidden;
box-shadow: var(--el-box-shadow);
position: relative;
flex-direction: column-reverse;
.flex {
@include Flex;
flex-direction: column;
}
.Operate {
.Content {
@include Flex;
.Start {
@include side;
}
.Pause {
@include side;
}
.Resume {
@include side;
}
.Stop {
@include side;
}
}
&__Download {
@include Flex;
gap: 10px;
position: relative;
overflow: hidden;
}
}
&__state {
position: relative;
border-radius: 1rem;
@include Flex;
justify-content: space-around;
width: 57vmax;
height: 70vh;
border: 1px dashed var(--el-color-primary);
background: #022125 url($bg) center no-repeat;
overflow: hidden;
.REC {
@include Flex;
gap: 0.5rem;
position: absolute;
top: 0.9rem;
left: 0.9rem;
:first-child {
width: 1rem;
height: 1rem;
border-radius: 50rem;
background-color: red;
}
:last-child {
@include font()
}
}
.Timing {
display: flex;
align-items: flex-start;
gap: 1rem;
flex-direction: column;
:first-child {
@include font(2rem, #1fb5c9, 0.3rem);
font-weight: 600;
font-family: digital-display;
}
:last-child {
@include font(1.8rem, #1fb5c9, 0.3rem);
font-weight: 600;
}
}
video {
width: 100%;
height: 100%;
vertical-align: middle;
}
}
}
</style>
