fortios 虚拟机
FortiGate is successful Next Generation Firewall which provides a lot of features for to day needs. The Forti family have products from WAN optimizer to APT sandbox. In this tutorial we will look how to setup FortiGate or FortiOS for the first time. We assume we have all ready downloaded and imported into VMware or similar virtualization platform.
FortiGate是成功的下一代防火墙,它提供了许多满足日常需求的功能。 Forti系列拥有从WAN优化器到APT沙箱的产品。 在本教程中,我们将首次了解如何设置FortiGate或FortiOS。 我们假设已经准备好全部下载并导入到VMware或类似的虚拟化平台中。
从控制台或CLI登录 (Login From Console or CLI)
First we need to login from cli. Because Forti do not have nay IP address specified and in order to access. So the default user name is admin
and default password is empty. We can just put enter to login cli.
首先,我们需要从cli登录。 因为Forti没有指定IP地址和要访问的IP地址。 因此,默认用户名为admin
,默认密码为空。 我们只需要输入enter即可登录cli。
![Login From Console or CLI](https://i-blog.csdnimg.cn/blog_migrate/762ab3dfafc3ccdb0d2d9adc83312c84.png)
进入接口配置模式(Enter Interface Configuration Mode)
In order to set IP address we should enter configuration mode. We can enter interface configuration mode with the following command.
为了设置IP地址,我们应该进入配置模式。 我们可以使用以下命令进入接口配置模式。
$ config system interface
![Enter Interface Configuration Mode](https://i-blog.csdnimg.cn/blog_migrate/5432038dcda7ac5ed6494b2bb0d771b8.png)
