CICS Application Programming Fundamentals 第8-7章

8. The Sign-on Process - 7. Registered Users File

****** ********************************* Top of Data **********************************
000001            05  Registered-User-Id      pic x(08).
000002            05  Registered-Password     pic x(08).
000003            05  Registered-User-Type    pic x(03).
000004                88  Standard-User       value 'STD'.
000005                88  Manager-User        value 'MGR'.
000006                88  Admin-User          value 'ADM'.
000007            05  Registered-Status       pic x(01).
000008                88  ACTIVE              value 'A'.
000009                88  DELETED             value 'D'.
000010       * YYYYMMDDhhmmss
000011            05  Last-Effective-Date-Time pic x(14).
000012            05  filler                  pic x(66).
****** ******************************** Bottom of Data ********************************

****** ********************************************************************* Top of Dat
000001 //JC$CRTQS JOB ,'CREATE QSAM ',CLASS=C,MSGCLASS=S,MSGLEVEL=(1,1),       JOB00059
000002 //             REGION=4096K,TIME=1440,COND=((4,LT)),NOTIFY=&SYSUID
000003 //*
000004 //*!!! PLS DOUBLE CHECK AND REMARK THIS LINE TO SUBMIT
000005 //*
000006 //* DELETE OLD
000007 //DELETE   EXEC PGM=IEFBR14
000008 //DELFILE  DD DSN=PRDHKB.MM.MD.EREGUSR,
000009 //            DISP=(MOD,DELETE,DELETE),
000010 //            UNIT=SYSDA,
000011 //            VOL=SER=UAPP02
000012 //* REPO DUMMY DATA
000013 //DEFINE   EXEC PGM=SORT
000014 //SYSOUT   DD  SYSOUT=*
000015 //SORTIN   DD  *
000016 TESTUSR1PASS1   STDA20230625120000
000017 TESTUSR2PASS2   MGRA20230625121500
000018 TESTUSR3PASS3   ADMA20230625123000
000019 /*
000020 //SORTOUT  DD  DSN=PRDHKB.MM.MD.EREGUSR,
000021 //             DISP=(NEW,CATLG,DELETE),
000022 //             UNIT=SYSDA,
000023 //             VOL=SER=UAPP02,
000024 //             SPACE=(CYL,(5,2),RLSE),
000025 //             DCB=(RECFM=FB,LRECL=100,BLKSIZE=0)
000026 //SYSIN    DD  *
000027   OPTION COPY
000028   OUTREC FIELDS=(1,80,100:C' ')
000029 /*
****** ******************************************************************** Bottom of D

****** ********************************************************************* Top of Dat
000001 //JC$CRTKS JOB ,'CREATE KSDS ',CLASS=C,MSGCLASS=S,MSGLEVEL=(1,1),       JOB00060
000002 //             REGION=4096K,TIME=1440,COND=((4,LT)),NOTIFY=&SYSUID
000003 //*
000004 // !!! PLS DOUBLE CHECK AND REMARK THIS LINE TO SUBMIT
000005 //*
000006 //* DEFINE KSDS
000007 //TDINTRA  EXEC PGM=IDCAMS
000008 //SEEDDATA DD DISP=SHR,DSN=PRDHKB.MM.MD.EREGUSR
000009 //SYSPRINT DD SYSOUT=*
000010 //SYSIN    DD *
000011   DELETE PRDHKO.MM.MD.EREGUSR CLUSTER ERASE PURGE
000012   SET MAXCC = 0
000013
000014   DEFINE CLUSTER(NAME(PRDHKO.MM.MD.EREGUSR)    -
000015                  INDEXED                       -
000016                  CYL(10 10)                    -
000017                  RECORDSIZE(100 100)           -
000018                  KEYS(8 0)                     -
000019                  FREESPACE(0 20)               -
000020                  SHAREOPTIONS(2 3)             -
000021                  LOG(NONE)                     -
000022                  VOLUME(UAPP02)                -
000023                  CISZ(4096))                   -
000024          DATA (NAME(PRDHKO.MM.MD.EREGUSR.DATA)) -
000025          INDEX (NAME(PRDHKO.MM.MD.EREGUSR.INDEX))
000026
000027   IF LASTCC = 0 THEN -
000028       REPRO INFILE(SEEDDATA) OUTDATASET(PRDHKO.MM.MD.EREGUSR)
000029       IF LASTCC = 0 THEN -
000030           LISTCAT ENTRIES(PRDHKO.MM.MD.EREGUSR) ALL
000031           IF LASTCC = 0 THEN -
000032               PRINT INDATASET(PRDHKO.MM.MD.EREGUSR)
000033 /*
000034 //*
****** ******************************************************************** Bottom of D

  DEF FILE(EREGUSR) G(PS)
  INS FILE(EREGUSR) G(PS)

  VI FILE(EREGUSR) G(PS)
  OBJECT CHARACTERISTICS                                    CICS RELEASE = 0650
   CEDA  View File( EREGUSR  )
    File           : EREGUSR
    Group          : PS
    DEScription    :
   VSAM PARAMETERS
    DSNAme         : PRDHKO.MM.MD.EREGUSR
...
   OPERATIONS
    Add            : Yes                No | Yes
    BRowse         : Yes                No | Yes
    DELete         : Yes                No | Yes
    READ           : Yes                Yes | No
    UPDATE         : Yes                No | Yes
 + AUTO JOURNALLING

                                                      SYSID=CICS APPLID=CICS

 PF 1 HELP 2 COM 3 END             6 CRSR 7 SBH 8 SFH 9 MSG 10 SB 11 SF 12 CNCL
