首先声明下面的技术方案并非我的原创,也是通过百度搜索并验证是可行的,并把具体实现方式公布出来,希望可以帮到有同样需求的小伙伴门,共同进步~~
需求:为IOS自已开发的应用的所有画面添加防截屏、防录制的功能
解决依据是根据UITextField只要设置了setSecureTextEntry为true后,在进行录屏或者截屏的时候都会被系统隐去。
由于我们的app中即有非故事板画面又有故事板画面,所以只能一个画面一个画面的添加; 也可以创建一个非故事板类型的超类,来负责自动替换根UIView。
解决方案:
1、如果是非故事板类型的ViewController,在viewDidLoad方法开始处将self.view替换为防截屏的UIView,参见下面的示例代码:
- (void)viewDidLoad {
[super viewDidLoad];
// 防截屏
UITextField *bgTextField = [[UITextField alloc] init];
[bgTextField setSecureTextEntry:true];
UIView *bgView = bgTextField.subviews.firstObject;
[bgView setUserInteractionEnabled:true];
self.view = bgView;
// 其它初始化代码
}
2、如果是故事板类型的ViwController的,需要将故事板中将UIView改为SecurityScreenShortView(通过继承UIView后,在初始化方法中初始化防截屏安全区)即可,过程如下所示:
1)、打开故事板设计画面;
2)、选中相应ViewController的根UIView;
3)、在最右侧设计器中将Class中的UIView改为SecurityScreenShortView后保存即可
SecurityScreenShortView.h
//
// SecurityScreenShortView.h
//
// Created by 杜燕军 on 2022/8/1.
//
#import <UIKit/UIKit.h>
NS_ASSUME_NONNULL_BEGIN
API_AVAILABLE(ios(13.2))
@interface SecurityScreenShortView : UIView
@property (nonatomic, strong) UITextField *textField;
@property (nonatomic, strong) UIView *safeZone;
+ (UIView *)creactWithFrame:(CGRect)frame;
@end
NS_ASSUME_NONNULL_END
SecurityScreenShortView.m
//
// SecurityScreenShortView.m
//
// Created by 杜燕军 on 2022/8/1.
//
#import "SecurityScreenShortView.h"
@implementation SecurityScreenShortView
+ (UIView *)creactWithFrame:(CGRect)frame {
return [[SecurityScreenShortView alloc] initWithFrame:frame];
}
- (instancetype)initWithCoder:(NSCoder *)coder {
self = [super initWithCoder:coder];
if (self) {
[self addSafeZoneView];
}
return self;
}
- (instancetype)initWithFrame:(CGRect)frame {
self = [super initWithFrame:frame];
if (self) {
[self addSafeZoneView];
}
return self;
}
- (void)addSafeZoneView {
[self addSubview:self.safeZone];
UILayoutPriority lowPriority = UILayoutPriorityDefaultLow - 1;
UILayoutPriority heightPriority = UILayoutPriorityDefaultHigh - 1;
self.safeZone.translatesAutoresizingMaskIntoConstraints = NO;
[self.safeZone setContentHuggingPriority:lowPriority forAxis:UILayoutConstraintAxisVertical];
[self.safeZone setContentHuggingPriority:lowPriority forAxis:UILayoutConstraintAxisHorizontal];
[self.safeZone setContentCompressionResistancePriority:heightPriority forAxis:UILayoutConstraintAxisVertical];
[self.safeZone setContentCompressionResistancePriority:heightPriority forAxis:UILayoutConstraintAxisHorizontal];
[self addConstraints:@[
[NSLayoutConstraint constraintWithItem:self.safeZone attribute:NSLayoutAttributeTop relatedBy:NSLayoutRelationEqual toItem:self attribute:NSLayoutAttributeTop multiplier:1 constant:0],
[NSLayoutConstraint constraintWithItem:self.safeZone attribute:NSLayoutAttributeBottom relatedBy:NSLayoutRelationEqual toItem:self attribute:NSLayoutAttributeBottom multiplier:1 constant:0],
[NSLayoutConstraint constraintWithItem:self.safeZone attribute:NSLayoutAttributeLeading relatedBy:NSLayoutRelationEqual toItem:self attribute:NSLayoutAttributeLeading multiplier:1 constant:0],
[NSLayoutConstraint constraintWithItem:self.safeZone attribute:NSLayoutAttributeTrailing relatedBy:NSLayoutRelationEqual toItem:self attribute:NSLayoutAttributeTrailing multiplier:1 constant:0],
]];
}
- (void)addSubview:(UIView *)view {
if (self.safeZone == view) {
[super addSubview:view];
}else{
[self.safeZone addSubview:view];
}
}
- (void)insertSubview:(UIView *)view atIndex:(NSInteger)index {
if (self.safeZone == view) {
[super insertSubview:view atIndex:index];
}else{
[self.safeZone insertSubview:view atIndex:index];
}
}
- (void)insertSubview:(UIView *)view aboveSubview:(UIView *)siblingSubview {
if (self.safeZone == view) {
[super insertSubview:view aboveSubview:siblingSubview];
}else{
[self.safeZone insertSubview:view aboveSubview:siblingSubview];
}
}
- (void)insertSubview:(UIView *)view belowSubview:(UIView *)siblingSubview {
if (self.safeZone == view) {
[super insertSubview:view belowSubview:siblingSubview];
}else{
[self.safeZone insertSubview:view belowSubview:siblingSubview];
}
}
- (UITextField *)textField{
if(!_textField){
_textField = [[UITextField alloc]init];
_textField.secureTextEntry = YES;
_textField.enabled = NO;
}
return _textField;
}
- (UIView *)safeZone{
if(!_safeZone){
// 获取配置参数“是否开启防截屏”,默认值是0(未开启防截屏功能)此处不需要可以删除
int noScreenShortEnable = [[ParamManager manager] getIntParam:@“noScreen” :0];
if (noScreenShortEnable == 1) {
// 防截屏
_safeZone = self.textField.subviews.firstObject ?: [[UIView alloc] init];
_safeZone.userInteractionEnabled = YES;
for (UIView *v in _safeZone.subviews) {
[v removeFromSuperview];
}
} else {
// 非防截屏
_safeZone = [[UIView alloc] init];
}
}
return _safeZone;
}
@end
故事板设置参照图
引用的方案链接:
2、由于github故障的原因,所以故事板的链接找不到了;
