需求：flink分批读clickhouse数据，处理后再存clickhouse。当然也可以按需读存其他地方。

流式数据批量插入。

1.maven依赖

<dependency>
    <groupId>com.clickhouse</groupId>
    <artifactId>clickhouse-jdbc</artifactId>
    <version>0.3.2-patch5</version>
</dependency>
<dependency>
    <groupId>org.apache.flink</groupId>
    <artifactId>flink-java</artifactId>
    <version>1.14.6</version>
</dependency>
<dependency>
    <groupId>org.apache.flink</groupId>
    <artifactId>flink-streaming-java_2.11</artifactId>
    <version>1.14.6</version>
</dependency>
<dependency>
    <groupId>org.apache.flink</groupId>
    <artifactId>flink-clients_2.11</artifactId>
    <version>1.14.6</version>
</dependency>
<dependency>
    <groupId>org.apache.flink</groupId>
    <artifactId>flink-runtime-web_2.11</artifactId>
    <version>1.14.6</version>
</dependency>
<dependency>
    <groupId>org.apache.flink</groupId>
    <artifactId>flink-table-api-java-bridge_2.11</artifactId>
    <version>1.14.6</version>
</dependency>
<dependency>
    <groupId>org.apache.flink</groupId>
    <artifactId>flink-table-planner_2.11</artifactId>
    <version>1.14.6</version>
</dependency>

2.main

import com.alibaba.fastjson.JSONObject;
import com.sumec.flink.entity.RuleDto;
import com.sumec.flink.entity.UserProductTagDto;
import com.sumec.flink.entity.UserRule;
import org.apache.commons.lang3.StringUtils;
import org.apache.flink.api.common.RuntimeExecutionMode;
import org.apache.flink.api.common.functions.FlatMapFunction;
import org.apache.flink.api.common.restartstrategy.RestartStrategies;
import org.apache.flink.api.common.time.Time;
import org.apache.flink.shaded.guava30.com.google.common.collect.Lists;
import org.apache.flink.streaming.api.datastream.DataStream;
import org.apache.flink.streaming.api.datastream.SingleOutputStreamOperator;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.util.Collector;

import java.text.SimpleDateFormat;
import java.util.Date;
import java.util.List;
import java.util.Map;
import java.util.Optional;
import java.util.concurrent.TimeUnit;

public class FlinkClickhouseDemo {

    public static void main(String[] args) {
        // 创建Flink执行环境
        StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setRuntimeMode(RuntimeExecutionMode.AUTOMATIC);
        env.setRestartStrategy(RestartStrategies.fixedDelayRestart(3, Time.of(10, TimeUnit.SECONDS)));

        // 数据源，读clickhouse，并行度按需设置
        DataStream<Map<String, String>> users = env.addSource(new ClickhouseSource()).setParallelism(1);

        // transformation: map keyBy timeWindow apply
        // 此处简单过滤和转换，按需设置并行度
        SingleOutputStreamOperator<List<UserProductTagDto>> singleDto = users.filter(new FilterFunction<Map<String, String>>() {
            @Override
            public boolean filter(Map<String, String> map) throws Exception {
                return filterData(map, ruleDto);
            }
        }).setParallelism(150).map(new MapFunction<Map<String, String>, List<UserProductTagDto>>() {
            @Override
            public List<UserProductTagDto> map(Map<String, String> stringStringMap) throws Exception {
                return parse(stringStringMap, ruleDto.getAnalysisNo());
            }
        }).setParallelism(150);

        // sink，写clickhouse或其他地方，按需设置并行度
        userProductList.addSink(new ClickHouseSink()).setParallelism(32);

        // execute
        try {
            env.execute();
        } catch (Exception e) {
            System.out.println(e.getMessage());
        }
    }

    // transform
    private static List<UserProductTagDto> parse(Map<String, String> map) throws Exception {
        // 按需处理
    }

    public static boolean filterData(Map<String, String> map, RuleDto ruleDto) {

    }
}

3.自定义source

存量数据：按天分批取数据处理

增量数据：每隔一段时间拉取一次数据

import com.clickhouse.client.internal.google.common.collect.Maps;
import lombok.extern.slf4j.Slf4j;
import org.apache.flink.configuration.Configuration;
import org.apache.flink.streaming.api.functions.source.RichParallelSourceFunction;
import ru.yandex.clickhouse.ClickHouseConnection;
import ru.yandex.clickhouse.ClickHouseDataSource;
import ru.yandex.clickhouse.ClickHouseStatement;
import ru.yandex.clickhouse.settings.ClickHouseProperties;
import ru.yandex.clickhouse.settings.ClickHouseQueryParam;

import java.sql.ResultSet;
import java.sql.ResultSetMetaData;
import java.time.LocalDate;
import java.time.format.DateTimeFormatter;
import java.util.HashMap;
import java.util.Map;
import java.util.UUID;
import java.util.concurrent.atomic.AtomicInteger;

@Slf4j
public class ClickhouseSource extends RichParallelSourceFunction<Map<String, String>> {

    private boolean flag = true;
    private ClickHouseConnection conn = null;
    private ClickHouseStatement stmt = null;
    private ResultSet rs = null;
    private Map<ClickHouseQueryParam, String> additionalDBParams = new HashMap<>();

    // open只执行一次,适合开启资源
    @Override
    public void open(Configuration parameters) throws Exception {
        String url = "jdbc:clickhouse://xxxxx:8123";

        ClickHouseProperties properties = new ClickHouseProperties();
        properties.setSessionId(UUID.randomUUID().toString());
//        properties.setUser("default");
//        properties.setPassword("");
        properties.setDatabase("xxx");

        ClickHouseDataSource dataSource = new ClickHouseDataSource(url, properties);
        // ClickHouseProperties
        additionalDBParams.put(ClickHouseQueryParam.SESSION_ID, UUID.randomUUID().toString());
        conn = dataSource.getConnection();
        stmt = conn.createStatement();
    }

    @Override
    public void run(SourceContext<Map<String, String>> ctx) throws Exception {

        String sql = "select * from xxx where event_time between '%s 00:00:00' and '%s 23:59:59' limit %s,%s";
        String start = "2024-01-01";
        String end = "2024-01-01";
        int limitStart = 0;
        int limit = 50000;
        while (flag) {
            String newsql = String.format(sql, start, end, limitStart, limit);

            rs = stmt.executeQuery(newsql, additionalDBParams);
            int c = 0;
            while (rs.next()) {
                c++;
                Map<String, String> hm = Maps.newHashMap();
                ResultSetMetaData rsmd = rs.getMetaData();
                int count = rsmd.getColumnCount();// 获取列的数量
                for (int i = 1; i <= count; i++) {
                    String key = rsmd.getColumnLabel(i);
                    String value = rs.getString(i);
                    hm.put(key, value);
                }
                ctx.collect(hm);
            }

            limitStart += c;

            if (c < limit) {
                // 查完了，换时间
                limitStart = 0;
                LocalDate localDate = LocalDate.parse(start, DateTimeFormatter.ofPattern("yyyy-MM-dd")).plusDays(1);
                start = localDate.toString();
                end = localDate.toString();

                if (localDate.isAfter(LocalDate.now())) {
                    break;
                }
            }
        }
    }

    // 接收到cancel命令时取消数据生成
    @Override
    public void cancel() {
        flag = false;
    }

    @Override
    public void close() throws Exception {
        if (conn != null)
            conn.close();
        if (stmt != null)
            stmt.close();
        if (rs != null)
            rs.close();
    }
}

4.自定义sink

注意：

1.流式处理要求实时性，可即时插入，数据量大时会有性能问题，可以转存kafka

2.对于历史数据处理任务，流式数据做批量插入，可缓存后批量插入，最后一批数据未达到batchSize时会丢失，需要在close方法中再做一次处理。

import com.sumec.flink.entity.UserProductTagDto;
import lombok.extern.slf4j.Slf4j;
import org.apache.commons.collections4.CollectionUtils;
import org.apache.flink.configuration.Configuration;
import org.apache.flink.streaming.api.functions.sink.RichSinkFunction;
import ru.yandex.clickhouse.ClickHouseConnection;
import ru.yandex.clickhouse.ClickHouseDataSource;
import ru.yandex.clickhouse.ClickHouseStatement;
import ru.yandex.clickhouse.settings.ClickHouseProperties;
import ru.yandex.clickhouse.settings.ClickHouseQueryParam;

import java.sql.PreparedStatement;
import java.sql.ResultSet;
import java.util.HashMap;
import java.util.List;
import java.util.Map;
import java.util.Optional;
import java.util.UUID;

@Slf4j
public class ClickHouseSink extends RichSinkFunction<List<UserProductTagDto>> {
    private ClickHouseConnection conn = null;
    private PreparedStatement stmt = null;
    private ResultSet rs = null;
    private Map<ClickHouseQueryParam, String> additionalDBParams = new HashMap<>();
    private final int batchSize = 10000;
    private String sql = "insert into";

    // open只执行一次,适合开启资源
    @Override
    public void open(Configuration parameters) throws Exception {
        String url = "jdbc:clickhouse://xxxxxx:8123";

        ClickHouseProperties properties = new ClickHouseProperties();
        properties.setSessionId(UUID.randomUUID().toString());
//        properties.setUser("default");
//        properties.setPassword("");
        properties.setDatabase("xxxx");

        ClickHouseDataSource dataSource = new ClickHouseDataSource(url, properties);
        // ClickHouseProperties
        additionalDBParams.put(ClickHouseQueryParam.SESSION_ID, UUID.randomUUID().toString());
        conn = dataSource.getConnection();
        stmt = conn.createStatement(sql);
    }

    @Override
    public void invoke(List<UserProductTagDto> value, Context context) throws Exception {
        if (CollectionUtils.isEmpty(value)) {
            return;
        }

        for (UserProductTagDto dto : value) {
            preparedStatement.setString(1, dto.getUserNo());
            preparedStatement.setString(2, dto.getAnalysisNo());
            preparedStatement.setString(3, dto.getProductTagNo());
            preparedStatement.setInt(4, dto.getActionType());
            preparedStatement.setString(5, dto.getEventTime());
            preparedStatement.setString(6, DateFormatUtils.format(new Date(), "yyyy-MM-dd HH:mm:ss"));
            preparedStatement.addBatch();
            count++;
        }

        // 流式数据缓存后，批量插入clickhouse，能大大提高性能
        if (count >= batchSize) {
            preparedStatement.executeBatch();
            count = 0;
        }

        // 按需，也可以即时处理
//      preparedStatement.executeBatch();
    }

    @Override
    public void close() throws Exception {
        if (count != 0) {
            // 缓存批量插入，注意插入最后一批数据，防止未达到batchSize丢失
            preparedStatement.executeBatch();
        }
        if (conn != null)
            conn.close();
        if (stmt != null)
            stmt.close();
        if (rs != null)
            rs.close();
    }
}
