策略迭代的关键部分是策略评估,首先评估状态的价值,然后根据状态的动作值进行相应的策略改进,并进行下一轮评估和改进。直到策略稳定,策略改进可以通过求解静态最优化问题来实现,通过状态动作值来选择动作,通常比策略评估容易。
基于状态值的策略迭代算法包括以下三个阶段
1:初始化策略函数和状态值函数
2:策略评估:在当前策略下 使用贝尔曼方程更新状态值函数 直到收敛
3:策略改进:基于贪心策略得到更优策略,直到策略收敛不再变化
算法步骤如下
汽车租赁问题描述:杰克经营两家异地的汽车租赁场,每天都有客户来租车,如果每个租赁场有可供外租的汽车,每租出一辆汽车,杰克获得10美元,为了保证每个租赁场有足够的汽车可租,每天晚上杰克会在两个租赁场之间移动车辆,每辆车的移车费用为2美元,假设每个租赁场的租车和还车的数量是一个泊松随机量。给定三个假设
1:任何一个租赁场车辆总数不超过20辆
2:当天还回的车辆第二天才能出租
3:两个租车场之间每天最多可移车数量为5辆
下面利用策略迭代方法 计算两个租赁场点之间的最优移车策略
经过五轮的策略评估和改进后 得到最优策略和最优价值
最优策略如下
最优价值如下
部分代码如下
# 代10-例4.6-汽车租赁问题
import matplotlib
matplotlib.use('TkAgg')
import matplotlib.pyplot as plt
import numpy as np
import seaborn as sns
from scipy.stats import poisson
# %matplotlib inline
plt.rcParams['font.sans-serif']=['SimHei'] #显示中文标签
plt.rcParams['axes.unicode_minus']=False
matplotlib.use('TkAgg')
# 每个租赁场的最大车辆数
MAX_CARS = 20
# 每晚挪车的最大数
MAX_MOVE_OF_CARS = 5
#第一个租赁场租车的𝜆值
RENTAL_REQUEST_FIRST_LOC = 4
#第而个租赁场租车的𝜆值
RENTAL_REQUEST_SECOND_LOC = 3
#第一个租赁场还车的𝜆值
RETURNS_FIRST_LOC = 2
#第而个租赁场还车的𝜆值
RETURNS_SECOND_LOC = 3
DISCOUNT = 0.9
# 租出一辆车奖励值
RENTAL_CREDIT = 10
# 挪车费用
MOVE_CAR_COST = 2
# 所有可能的动作
actions = np.arange(-MAX_MOVE_OF_CARS, MAX_MOVE_OF_CARS + 1)
# An up bound for poisson distribution
# If n is greater than this value, then the probability of getting n is truncated to 0
POISSON_UPPER_BOUND = 11
# Probability for poisson distribution
# @lam: lambda should be less than 10 for this function
poisson_cache = dict()
def poisson_probability(n, lam):
global poisson_cache
key = n * 10 + lam
if key not in poisson_cache:
poisson_cache[key] = poisson.pmf(n, lam)
return poisson_cache[key]
def expected_return(state, action, state_value, constant_returned_cars):
"""
@state: [# of cars in first location, # of cars in second location]
@action: positive if moving cars from first location to second location,
negative if moving cars from second location to first location
@stateValue: state value matrix
@constant_returned_cars: if set True, model is simplified such that
the # of cars returned in daytime becomes constant
rather than a random value from poisson distribution, which will reduce calculation time
and leave the optimal policy/value state matrix almost the same
"""
# initailize total return
returns = 0.0
# cost for moving cars
returns -= MOVE_CAR_COST * abs(action)
# moving cars
NUM_OF_CARS_FIRST_LOC = min(state[0] - action, MAX_CARS)
NUM_OF_CARS_SECOND_LOC = min(state[1] + action, MAX_CARS)
# go through all possible rental requests
for rental_request_first_loc in range(POISSON_UPPER_BOUND):
for rental_request_second_loc in range(POISSON_UPPER_BOUND):
# probability for current combination of rental requests
prob = poisson_probability(rental_request_first_loc, RENTAL_REQUEST_FIRST_LOC) * \
poisson_probability(rental_request_second_loc, RENTAL_REQUEST_SECOND_LOC)
num_of_cars_first_loc = NUM_OF_CARS_FIRST_LOC
num_of_cars_second_loc = NUM_OF_CARS_SECOND_LOC
# valid rental requests should be less than actual # of cars
valid_rental_first_loc = min(num_of_cars_first_loc, rental_request_first_loc)
valid_rental_second_loc = min(num_of_cars_second_loc, rental_request_second_loc)
# get credits for renting
reward = (valid_rental_first_loc + valid_rental_second_loc) * RENTAL_CREDIT
num_of_cars_first_loc -= valid_rental_first_loc
num_of_cars_second_loc -= valid_rental_second_loc
if constant_returned_cars:
# get returned cars, those cars can be used for renting tomorrow
returned_cars_first_loc = RETURNS_FIRST_LOC
returned_cars_second_loc = RETURNS_SECOND_LOC
num_of_cars_first_loc = min(num_of_cars_first_loc + returned_cars_first_loc, MAX_CARS)
num_of_cars_second_loc = min(num_of_cars_second_loc + returned_cars_second_loc, MAX_CARS)
returns += prob * (reward + DISCOUNT * state_value[num_of_cars_first_loc, num_of_cars_second_loc])
else:
for returned_cars_first_loc in range(POISSON_UPPER_BOUND):
for returned_cars_second_loc in range(POISSON_UPPER_BOUND):
prob_return = poisson_probability(
returned_cars_first_loc, RETURNS_FIRST_LOC) * poisson_probability(returned_cars_second_loc, RETURNS_SECOND_LOC)
num_of_cars_first_loc_ = min(num_of_cars_first_loc + returned_cars_first_loc, MAX_CARS)
num_of_cars_second_loc_ = min(num_of_cars_second_loc + returned_cars_second_loc, MAX_CARS)
prob_ = prob_return * prob
returns += prob_ * (reward + DISCOUNT *
state_value[num_of_cars_first_loc_, num_of_cars_second_loc_])
return returns
def figure_4_2(constant_returned_cars=True):
value = np.zeros((MAX_CARS + 1, MAX_CARS + 1))
policy = np.zeros(value.shape, dtype=np.int)
iterations = 0
_, axes = plt.subplots(2, 3, figsize=(40, 20))
plt.subplots_adjust(wspace=0.1, hspace=0.2)
axes = axes.flatten()
while True:
fig = sns.heatmap(np.flipud(policy), cmap="YlGnBu", vmax=5, vmin=-5,ax=axes[iterations],center=0)
fig.set_ylabel('# B ',fontsize=30)
fig.set_yticks(list(reversed(range(MAX_CARS + 1))))
fig.set_xlabel('# A', fontsize=30)
fig.set_title('policy {}'.format(iterations), fontsize=30)
# policy evaluation (in-place)
while True:
old_value = value.copy()
or (-j <= action <= 0):
# if(-i <= action <= 0) or (0 <= action <= j):
action_returns.append(expected_return([i, j], action, value, constant_returned_cars))
else:
action_returns.append(-np.inf)
new_action = actions[np.argmax(action_returns)]
policy[i, j] = new_action
if policy_stable and old_action != new_action:
policy_stable = False
print('policy stable {}'.format(policy_stable))
if policy_stable:
fig = sns.heatmap(np.flipud(value), cmap="YlGnBu", ax=axes[-1])
fig.set_ylabel('# 第一地点的车辆数', fontsize=30)
fig.set_yticks(list(reversed(range(MAX_CARS + 1))))
fig.set_xlabel('# 第二地点的车辆数', fontsize=30)
fig.set_title('optimal value', fontsize=30)
break
iterations += 1
#保存路径
#plt.savefig('images/figure_4_2.png')
plt.show()
#plt.close()
if __name__ == '__main__':
figure_4_2()
