Overview

View, explore and convert 3D CAD data on desktop, web and mobile

CAD Exchanger SDK The following section enumerates a list of redistributable dynamic libraries for CAD Exchanger SDK. For instance, CadExCore corresponds to CadExCore.dll on Windows, to libCadExCore.so on Linux and libCadExCore.dylib on MacOS.

Note that debug mode libraries (having d suffix, e.g. CadExCored.dll) as well as header files (*.hxx) may not be redistributed.

To ensure that you re-distribute all required dynamic libraries, you can use tools like Depends.exe on Windows, or ldd on Linux specifying the library of your application that is linked with any of the SDK libraries.

Required libraries for C#, Java and Python

The C#, Java and Python CAD Exchanger libraries act as wrappers for the functionality contained in the native libraries. For your application to function correctly you need to use those .NET assemblies, Java JARs and Python modules, classes from which you use in your code, plus all the native libraries required by the utilized components. The transitive dependencies listed in the table below apply only to native libraries, not .NET assemblies, Java JARs and Python modules.

For example, if you use JT import in your application, you'd need:

CadExJTNet.dll and CadExCoreNet.dll assemblies (CadExParaNet.dll is not needed);
CadExJT, CadExPara, CadExCore, geom, tbb and tbmalloc native libraries.

Details

The following table enumerates dynamic library files must be redistributed depending on the required format:

Format or functionality	Required libraries
Common files	CadExCore geom tbb tbbmalloc
3D PDF	CadExX3DPDF CadExView
3D XML	CadExDS3DXML
3DS (Windows only)	CadExA3DS CadExFBX
3MF	CadExX3MF
ACIS	CadExACIS
BRep	CadExBRep
CATIA	CadExCAT
Collada	CadExCollada CadExFBX
Creo	CadExCreo
DXF	CadExDXF CadExFBX CadExACIS
DWG	CadExDWG CadExACIS
FBX	CadExFBX
glTF	CadExGLTF
IFC	CadExIFC
IGES	CadExIGES
INV	CadExINV CadExACIS
JT	CadExJT CadExPara
NX	CadExNX CadExJT CadExPara
OBJ	CadExOBJ
Parasolid	CadExPara
PLY	CadExPLY
PRC	CadExPRC
Revit	CadExRevit
Rhino	CadExRhino
Solid Edge	CadExSLDE CadExPara
SolidWorks	CadExSLD CadExPara
STEP	CadExSTEP
STL	CadExSTL
U3D	CadExU3D
USD	CadExUSD
VRML	CadExVRML
X3D	CadExX3D
Advanced geometry	CadExAdvGeom
Computational meshers	CadExMesh salome nglib
Visualization	CadExView CadExViewD3D (for WPF-based applications) CadExViewOpenGl (for Windows Forms-based applications) CadExViewQtQuick (for QtQuick-based applications) CadExViewWinForms (for Windows Forms-based applications) CadExViewWPF (for WPF-based applications) vis freeimage freetype
Unity	CadExUnity FreeImageNET
UNIGINE	For single precision projects: CadExUnigine CadExUniginePlugin (optional) For double precision projects: CadExUnigineDouble CadExUniginePlugin_double (optional)
C3D plugin	CadExC3DPlugin
