中文注释版:
# vim: expandtab:ts=4:sw=4
from __future__ import absolute_import
from datetime import datetime
import numpy as np
from . import kalman_filter
from . import linear_assignment
from . import iou_matching
from .track import Track
class Tracker:
def __init__( # 构造函数,用于初始化 Tracker 类
self,
metric, # 传入的距离度量对象,用于测量与跟踪之间的关联
max_iou_distance=0.7, # 最大IoU(交并比)距离,用于关联检测框和跟踪对象
max_age=30, # 最大年龄,跟踪在丢失多少次后才被删除
n_init=3, # 初始化帧数,新跟踪对象在成为确认跟踪前需要经过的帧数
override_track_class=None, # 用于覆盖默认的跟踪类
today=None, # 当前日期,用于跟踪对象的命名
gating_only_position=False, # 在门限过程中是否仅使用位置信息进行比较
):
"""多目标跟踪器-参数说明
----------
metric : nn_matching.NearestNeighborDistanceMetric
用于测量与跟踪关联的距离度量指标。
max_age : int
在跟踪被删除前允许错过的最大帧数。
n_init : int
在确认跟踪之前需要连续检测的帧数。如果在前 `n_init` 帧内发生错过,则跟踪状态将被设置为 `Deleted`。
today: Optional[datetime.date]
提供今天的日期,用于跟踪的命名
属性
----------
metric : nn_matching.NearestNeighborDistanceMetric
用于测量到跟踪关联的距离度量指标。
max_age : int
在跟踪被删除前允许错过的最大帧数。
n_init : int
跟踪在初始化阶段保持的帧数。
kf : kalman_filter.KalmanFilter
一个卡尔曼滤波器,用于在图像空间内过滤目标轨迹。
tracks : List[Track]
当前时间步中活跃的跟踪列表。
gating_only_position : Optional[bool]
在门限过程中使用,比较 KF 预测状态和测量状态。如果为 True,则在门限过程中只考虑状态分布的 x, y 位置。默认为 False,将考虑 x,y, 宽高比和高度。
"""
# 初始化函数体
self.today = today # 设置当前日期
self.metric = metric # 设置传入的距离度量对象
self.max_iou_distance = max_iou_distance # 设置最大IoU距离
self.max_age = max_age # 设置最大年龄
self.n_init = n_init # 设置初始化帧数
self.gating_only_position = gating_only_position # 设置是否仅在门限过程中使用位置信息
# 初始化卡尔曼滤波器,用于预测跟踪对象的状态
self.kf = kalman_filter.KalmanFilter()
# 初始化活跃跟踪列表
self.tracks = []
# 初始化待删除跟踪ID列表
self.del_tracks_ids = []
# 初始化下一个可用的跟踪ID
self._next_id = 1
# 如果提供了覆盖跟踪类,则使用提供的类,否则使用默认的 Track 类
if override_track_class:
self.track_class = override_track_class
else:
self.track_class = Track
def predict(self):
"""
推进跟踪状态分布一个时间步长向前。
这个函数应在每个时间步调用一次,在 `update` 函数之前。
"""
for track in self.tracks:
track.predict(self.kf)
# 对每个跟踪对象调用其 predict 方法,使用卡尔曼滤波器预测下一状态
def update(self, detections, today=None):
"""
执行测量更新和跟踪管理。
参数
----------
detections : List[deep_sort.detection.Detection]
当前时间步的检测列表。
today: Optional[datetime.date]
提供今天的日期,用于跟踪的命名
"""
if self.today:
if today is None:
today = datetime.now().date()
# 如果提供了今天的日期,则使用该日期,否则获取当前日期
# 检查是否为新的一天,如果是,则刷新跟踪索引
if today != self.today:
self.today = today
self._next_id = 1
# 运行匹配级联
matches, unmatched_tracks, unmatched_detections = self._match(detections)
# 更新跟踪集合
for track_idx, detection_idx in matches:
self.tracks[track_idx].update(self.kf, detections[detection_idx])
# 对匹配的跟踪更新其状态
for track_idx in unmatched_tracks:
self.tracks[track_idx].mark_missed()
# 标记未匹配的跟踪为错过
for detection_idx in unmatched_detections:
self._initiate_track(detections[detection_idx])
# 为未匹配的检测初始化新跟踪
# 准备更新跟踪列表和删除跟踪ID列表
new_tracks = []
self.del_tracks_ids = []
for t in self.tracks:
if not t.is_deleted():
new_tracks.append(t)
else:
self.del_tracks_ids.append(t.track_id)
# 清除已删除的跟踪,更新跟踪列表
self.tracks = new_tracks
# 更新距离度量
active_targets = [t.track_id for t in self.tracks if t.is_confirmed()]
# 准备特征和目标列表用于更新距离度量
features, targets = [], []
for track in self.tracks:
if not track.is_confirmed():
continue
features += track.features
targets += [track.track_id for _ in track.features]
# 更新跟踪的特征列表,只保留最后一个特征
track.features = [track.features[-1]]
self.metric.partial_fit(
np.asarray(features), np.asarray(targets), active_targets
)
# 使用特征和目标列表部分拟合距离度量,更新其内部状态
def _match(self, detections):
"""
执行匹配算法,将检测结果与现有跟踪进行关联。
参数
----------
detections : List[deep_sort.detection.Detection]
当前时间步的检测列表。
返回
------
matches : List[Tuple[int, int]]
匹配的跟踪索引和检测索引的元组列表。
unmatched_tracks : List[int]
未匹配的跟踪索引列表。
unmatched_detections : List[int]
未匹配的检测索引列表。
"""
def gated_metric(tracks, dets, track_indices, detection_indices):
"""
计算门限化的匹配成本矩阵。
参数
----------
tracks : List[Track]
跟踪列表。
dets : List[Detection]
检测列表。
track_indices : List[int]
跟踪的索引列表。
detection_indices : List[int]
检测的索引列表。
返回
------
cost_matrix : numpy.ndarray
计算得到的门限化匹配成本矩阵。
"""
features = np.array([dets[i].feature for i in detection_indices])
targets = np.array([tracks[i].track_id for i in track_indices])
# 计算特征和目标之间的距离成本矩阵
cost_matrix = self.metric.distance(features, targets)
# 使用卡尔曼滤波器预测和检测对象的空间位置,生成门限化的成本矩阵
cost_matrix = linear_assignment.gate_cost_matrix(
self.kf, cost_matrix, tracks, dets, track_indices, detection_indices,
only_position=self.gating_only_position
)
return cost_matrix
# 将跟踪集合分为已确认和未确认的跟踪。
confirmed_tracks = [i for i, t in enumerate(self.tracks) if t.is_confirmed()]
unconfirmed_tracks = [
i for i, t in enumerate(self.tracks) if not t.is_confirmed()
]
# 使用外观特征关联已确认的跟踪。
(
matches_a,
unmatched_tracks_a,
unmatched_detections,
) = linear_assignment.matching_cascade(
gated_metric,
self.metric.matching_threshold,
self.max_age,
self.tracks,
detections,
confirmed_tracks,
)
# 使用IOU关联剩余的跟踪和未确认的跟踪。
iou_track_candidates = unconfirmed_tracks + [
k for k in unmatched_tracks_a if self.tracks[k].time_since_update == 1
]
unmatched_tracks_a = [
k for k in unmatched_tracks_a if self.tracks[k].time_since_update != 1
]
(
matches_b,
unmatched_tracks_b,
unmatched_detections,
) = linear_assignment.min_cost_matching(
iou_matching.iou_cost,
self.max_iou_distance,
self.tracks,
detections,
iou_track_candidates,
unmatched_detections,
)
matches = matches_a + matches_b
# 合并两个匹配列表
unmatched_tracks = list(set(unmatched_tracks_a + unmatched_tracks_b))
# 合并两个未匹配跟踪的列表
return matches, unmatched_tracks, unmatched_detections
# 返回匹配结果和未匹配的跟踪及检测列表
def _initiate_track(self, detection):
"""
初始化一个新的跟踪对象。
参数
----------
detection : deep_sort.detection.Detection
当前帧中的一个检测对象。
返回
------
无
"""
# 使用卡尔曼滤波器初始化新跟踪的状态和协方差
mean, covariance = self.kf.initiate(detection.to_xyah())
# 如果提供了今天的日期,则在跟踪ID中包含日期信息
if self.today:
track_id = "{}_{}".format(self.today, self._next_id)
else:
# 否则,只使用跟踪ID计数器
track_id = "{}".format(self._next_id)
# 创建并添加新的跟踪对象到跟踪列表中
self.tracks.append(
self.track_class(
mean, # 初始状态的均值向量
covariance, # 初始状态的协方差矩阵
track_id, # 新跟踪的唯一ID
self.n_init, # 初始化帧数
self.max_age, # 最大年龄
# 以下参数是跟踪对象的属性
feature=detection.feature, # 检测对象的特征
original_ltwh=detection.get_ltwh(), # 检测对象的原始边界框
det_class=detection.class_name, # 检测对象的类别名称
det_conf=detection.confidence, # 检测对象的置信度
instance_mask=detection.instance_mask, # 检测对象的实例掩码
others=detection.others, # 检测对象的其他信息
)
)
# 递增跟踪ID计数器
self._next_id += 1
def delete_all_tracks(self):
"""
删除所有跟踪对象。
返回
------
无
"""
# 清空跟踪列表
self.tracks = []
# 重置跟踪ID计数器
self._next_id = 1
