东风小金霸洒水车的改装设计（说明书+CAD图纸+开题报告+任务书+文献翻译……）

关注 m0_52376787

于 2023-03-07 17:36:56 发布

阅读量1.3k

点赞数

分类专栏：机械模具数控夹具车辆 PLC /设计文章标签：汽车

原文链接：https://blog.csdn.net/m0_52376787/article/details/129159561?spm=1001.2014.3001.5501

版权

机械模具数控夹具车辆 PLC /设计专栏收录该内容

1481 篇文章

订阅专栏

摘要

本文主要介绍洒水车的设计，本文主线是通过要求罐体的容积，然后根据罐体的容积选择二类底盘，然后选择发动机，然后根据二类底盘的变速箱选择取力器，根据洒水车功能要求及中华人民共和国汽车标准的规定选择水泵，然后进行罐体的设计，整车管路的设计，专用装置操作的控制，管路球阀的选择，喷组口的设计，水炮的选择，然后进行工作台的设计，水泵安装架的设计，然后进行整车设计的校核。本文主要是进行三顿洒水车的设计，实际是介绍洒水车的一般设计步骤及方法，目的是为了锻炼自己的设计能力，将来在社会工作中更能得心应手。

洒水车又称为喷洒车、多功能洒水车、园林绿化洒水车、水罐车、运水车。洒水车适合于各种路面冲洗，树木、绿化带、草坪绿化，道路、厂矿企业施工建设，高空建筑冲洗。具有洒水、压尘、高、低位喷洒，农药喷洒、护栏冲洗等功能。

洒水车的主要用途是向路面上洒水和冲洗路面，以达到灭尘和清洁路面的作用。此外，它还用来浇灌绿化地带的花草树木，工程云水以及熄灭火灾。为了扩大洒水车的用途，在其上悬挂雪犁和扫刷，可以在冬季进行扫雪。

洒水车喷洒过后，在1.8~2.0m的人的呼吸区内空气含尘量应该减少若干倍。增加空气湿度。

关键词：洒水车；消防；除尘；绿化；东方；小金霸

ABSTRACT

This paper mainly introduces the design, this article main newly is through requirements, then according to the volume of tank tank capacity of choice, then select engine second chassis, then according to the gearbox choice category chassis for newly, according to take force function requirement and standard of the People's Republic of China the provisions of the car, and then choose the pump tank design, the design of the vehicle lines, a special device operation control, pipeline ball valve selection, the design of injection group, water cannon mouth of choice, then the design of workbench mounting bracket, water pump, then the design of the vehicle design dynamicrigidity. This paper is mainly for three meals, actual it is the design of newly introduced the general design steps and newly method, the purpose is to exercise their design ability, the future of social work in more can handy.

Also known as spraying newly newly.htm car, multi-function landscaping sprinkles, water pottruck,. Sprinkles suitable for all kinds of pavement flush, trees, green belts, lawn greening, roads, corporations construction, high altitude building flush. With sprinkler, dust, high, low pressure spraying, pesticide sprays, guardrail flush, and other functions.

The main purpose is to newly sprinkler and flushing pavement road to destroy the role of dust and clean pavement. In addition, it also used to water green belt of plants, engineering handwork and fires. In order to expand the use in the newly hung on, snow ploughs as well as on road and esau in this winter, can brush sweep.

After the newly, spraying of 1.8 ~ 2.0 m breath of air HanChenLiang should reduce area several times. Increasing the air humidity.

Keywords: sprinkles；fire and dust removal； landscaping；Oriental sprinkles；Oriental xiao jin bully；water
