三辊卷板机主机设计【说明书（论文）+CAD图纸+开题报告+任务书+外文翻译】

关注 m0_52376787

于 2023-03-08 12:51:11 发布

阅读量907

点赞数

分类专栏：机械模具数控夹具车辆 PLC /设计文章标签：制造文档资料设计模式科技

原文链接：https://blog.csdn.net/m0_52376787/article/details/129159561?spm=1001.2014.3001.5501

版权

机械模具数控夹具车辆 PLC /设计专栏收录该内容

1449 篇文章

订阅专栏

本文详细介绍了对称式三辊卷板机的设计过程，包括机架类型选择、扭矩计算、电动机选取、下辊受力校核、上辊液压传动设计以及卷板机的翻倒机构。特别强调了Solidworks和AutoCAD在三维图形设计中的应用，以实现设计的可视化。该卷板机适用于天然气管道的卷制和其他领域，具有结构简单、操作方便等优点。

摘要生成于 C知道，由 DeepSeek-R1 满血版支持，前往体验 >

摘要

本设计是关于对称式三辊卷板机的。主要有对卷板机机架类型的设计选择，辊子需要扭矩的计算，电动机的选择，下辊的受力校核，上辊的液压传动设计以及卷板机翻倒机构的液压装置，从而保证了上辊能够在下压过程中提供使板材发生弯曲变形的力，设计中还有关于对当前机械行业应用流行的设计软件solidworks、autocad的学习应用，以便将自己的设计转成三维图形，从而能够直观的了解到本设计。

对称式三辊卷板机主要是应用于天然气管道的卷制，它也能够应用于其他场合，在造船、航空、化工能领域也应用广泛。它具有明显的优点：结构简单、占用空间小、质量小、操作方便，稳定性也很好。它主要就是能够使金属板材受到大于其屈服极限的力而发生弯曲变形成圆筒状，圆锥状的零件。

关键词：卷板机，上辊，液压缸，机架，电动机

Design 12×2000 bending machine mainframe

ABSTRACT

This design is symmetrical with about to the three-roll bending machine. There are mainly on the type of rack design options, calculate the roll torque is required, the choice of the motor, checking the force rolls, hydraulic design and hydraulic device .Bending roller downward movement to ensure the enough pressure on the roller can be provided ,so the bending of the sheet material force generation, as well as during the design of the current machinery industry applications popular design software solidworks and pccad learning application, in order to turn our designs into three-dimensional graphics, allowing us understand of the design intuitively.

Symmetric three roller coiling machine is mainly used in rolling natural gas pipelines, it can also be applied to other situations, in shipbuilding, aviation, and chemical energy fields are also widely used. It has obvious advantages: simple structure, small footprint, low weight, easy operation, stability is also very good. It is possible to make the metal sheet is mainly being greater than the yield limit of the bending force deformed into a cylindrical shape, a conical part.

KEY WORDS: Bending Machine, Cylinder,Hydraulic cylinder, Chassis, Electric motor
