x-y数控工作台机电系统设计【设计说明书（论文）+8张CAD图纸】

关注 m0_52376787

于 2023-03-17 08:46:18 发布

阅读量2.8k

点赞数 4

分类专栏：机械模具数控夹具车辆 PLC /设计文章标签：制造自动化文档资料科技

原文链接：https://blog.csdn.net/m0_52376787/article/details/129159561?spm=1001.2014.3001.5501

版权

机械模具数控夹具车辆 PLC /设计专栏收录该内容

1451 篇文章

订阅专栏

摘要

X-Y数控工作台是是指能分别沿着X 向和Y向移动的工作台，是许多机电一体化设备的基本部件，如数控车床的纵—横向进刀机构、数控铣床和数控钻床的X-Y工作台、激光加工设备的工作台、电子元件表面贴装设备等。模块化的X-Y数控工作台，通常由导轨座、移动滑块、工作、滚珠丝杠螺母副，以及伺服电动机等部件构成。其中伺服电动机做执行元件用来驱动滚珠丝杠，滚珠丝杠螺母带动滑块和工作平台在导轨上运动，完成工作台在X、Y方向的直线移动。导轨副、滚珠丝杠螺母副和伺服电动机等均以标准化，由专门厂家生产，设计时只需根据工作载荷选取即可。控制系统根据需要，可以选取用标准的工作控制计算机，也可以设计专用的微机控制系统。

关键词 X-Y数控工作台；伺服电动机；数控车床

Abstract

CNC XY table are mean to each along X and Y to move to the table, electromechanical integration equipment, many basic components, such as vertical CNC lathe - lateral feed body,CNC milling and CNC drilling machine XY work Taiwan, laser processing equipment, workstations, electronic components surface mount equipment. Modular CNC XY table, usually by rail seat, move the slider, work, ball screw pair, and the servo motor and other component parts. One servo motor to drive the ball screw actuator to do, the ball screw drive and work platform slide rail movement, complete table in the X, Y direction of the straight line movement. Guideways, ball screw pair and servo motors etc., shall be standardized by the specialized manufacturers, design can be selected only according to work load. Control system as needed, you can select a computer using a standard job control, you can design a dedicated computer control system.

Keywords XY table servo system CNC machine tools

目录

2.1交流伺服电动机的选型

2.1.1电机的选择依据

2.1.2电机的负载力矩和惯量的计算

2.2交流伺服电动机概述

2.2.1选择伺服电动机
