该文详细阐述了一副用于生产吉康牌塑料饮水瓶盖的注塑模具设计过程，包括塑件工艺分析、模具结构、注塑机选择、浇注系统、导向和推出机构、侧向抽芯机构以及冷却系统设计。设计考虑了塑件的特性，如两端相通的螺纹结构，采用了侧抽芯机构和强制拔模来实现。目标是实现自动化生产和提高产量。

摘要生成于 C知道，由 DeepSeek-R1 满血版支持，前往体验 >

摘要

本课题主要是针对吉康牌塑料饮水瓶盖的模具设计，通过对塑件进行工艺的分析和比较,最终设计出一副注塑模。该课题从产品结构工艺性，具体模具结构出发，对模具的浇注系统、模具成型部分的结构、顶出系统、冷却系统、注塑机的选择及有关参数的校核、都有详细的设计，同时并简单的编制了模具的加工工艺。通过整个设计过程表明该模具能够达到此塑件所要求的加工工艺。根据题目设计的主要任务是吉康牌塑料饮水瓶盖注塑模具的设计。也就是设计一副注塑模具来生产吉康牌塑料饮水瓶盖塑件产品，以实现自动化提高产量。针对吉康牌塑料饮水瓶盖的具体结构，该模具是侧浇口的单分型面注射模具。由于塑件两端相通，又有螺纹，并且考虑到材质较软，内螺纹为半圆形且只有二圈，所以采用侧抽芯机构来实现外螺纹，内螺纹采用强制拔模。

关键词塑料模具；饮水瓶盖；模具

ABSTRACT

This topic mainly aims at the mold design which The Water Injection bottle top of the label of jikang, through to models to carry on the craft the analysis and the comparison, designs a note mold finally. This topic from the product mix technology capability, the concrete mold structure embarks, to mold's gating system, the mold formation part's structure, goes against the system, the cooling system, injection molding machine's choice and the related parameter examination, has the detailed design, simultaneously and simple establishment mold's processing craft. Through the entire design process indicated that this mold can achieve this to model the processing craft which an institute requests. It is The Water Injection bottle top of the label of jikang according to the topic design's primary mission injection mold's design. It also designs an injection mold to produce The Water Injection bottle top of the label of jikang to attach models a product, realizes the automation to raise the output. Concrete structure which attaches in view of The Water Injection bottle top of the label of jikang, this mold is runner Shan Fen the profile injection mold. Because models both sides to be interlinked, also has the thread, must therefore use revolving to pull out the core organization and the side pulls out the core organization to realize. Considered the structure the particularity, its merit lies in two step movement to be possible also to carry on, and the movement is keen. Because the plastic parts connect at both ends, have thread, take into account that the material is soft, and the mould of internal thread is semi-circular and only two laps, it take the way of the core mechanism to achieve external thread, and internal thread use the way of force pull mode.

Keywords ：Plastic Mold；Bottle Top；Mold
