vue3-tree-org 组织结构图

官方文档: vue3-tree-orghttps://sangtian152.github.io/vue3-tree-org/

 可以进行新增/编辑/拖拽等. 相关事件可以查看官方文档

        命令安装: npm i vue3-tree-org -S  /  yarn add vue3-tree-org

// 在main.js中引入

import { createApp } from 'vue'
import vue3TreeOrg from 'vue3-tree-org'
import 'vue3-tree-org/lib/vue3-tree-org.css'

app.use(vue3TreeOrg)

<template>
    <div style="height: 400px;">
        <vue3-tree-org
            :data="data"
            :horizontal="horizontal"
            :collapsable="collapsable"
            :label-style="style"
            :node-draggable="true"
            :scalable="false"
            :only-one-node="onlyOneNode"
            :default-expand-level="1"
            :clone-node-drag="cloneNodeDrag"
            @on-contextmenu="onMenus"
            @on-node-click="onNodeClick"
        >
            <!-- 自定义节点内容 -->
            <template v-slot="{node}">
                <div class="tree-org-node__text node-label">
                    <div class="custom-content">自定义内容</div>
                    <div>节点名称：{{node.label}}</div>
                </div>
            </template>
            <!-- 自定义展开按钮 -->
            <template v-slot:expand="{node}">
                <div>{{node.children.length}}</div>
            </template>
        </vue3-tree-org>
    </div>
</template>
<script>
export default {
    name: "slotTree",
    data() {
        return {
            data: {
                "id":1,"label":"xxx科技有限公司",
                "children":[
                    {
                        "id":2,"pid":1,"label":"产品研发部",
                        "style":{"color":"#fff","background":"#108ffe"},
                        "children":[
                            {"id":6,"pid":2,"label":"禁止编辑节点","disabled":true},
                            {"id":8,"pid":2,"label":"禁止拖拽节点","noDragging":true},
                            {"id":10,"pid":2,"label":"测试"}
                        ]
                    },
                    {
                        "id":3,"pid":1,"label":"客服部",
                        "children":[
                            {"id":11,"pid":3,"label":"客服一部"},
                            {"id":12,"pid":3,"label":"客服二部"}
                        ]
                    },
                    {"id":4,"pid":1,"label":"业务部"}
                ]
            },
            horizontal: false,
            collapsable: true,
            onlyOneNode: true,
            cloneNodeDrag: true,
            expandAll: true,
            style: {
                background: "#fff",
                color: "#5e6d82",
            },
        };
    },
    methods: {
        onMenus({ node, command }) {
            console.log(node, command);
        },
        onNodeClick(e, data) {
            this.$Message.info(data.label);
        },
        expandChange() {
            this.toggleExpand(this.data, this.expandAll);
        },
    },
};
</script>
<style lang="scss" scoped>
.tree-org-node__text {
    text-align: left;
    font-size: 14px;
    .custom-content {
        padding-bottom: 8px;
        margin-bottom: 8px;
        border-bottom: 1px solid currentColor;
    }
}
</style>
