Android ViewPager Fragment实现选项卡和fragment

原文 http://blog.csdn.net/hongshengpeng/article/details/19674137

fragment再creatview中获取布局中的view，通过imflate对应的layout。根view和activity可以findviewbyid（）。。。getactivity（）可以获取绑定的activity，获取activity上下文，

或者在通过getapp等获取程序上下文。

viewpager是分页容器，frament是页面，指示器是imageview，自己定义滑动动画，根据选项偏移。textview是分页标题。监听，viewpager 。selectcurrentitem（int）。

监听viewpager滚动，两种：相邻滑动和tab选择跨页滑动，设定指示器偏移量和动画，是重点。可以计算标题数量和宽度，提前算出几个位置的偏移量，到时候选择。

可以动态的计算长度和偏移量，设计好的指示器。

public class MainActivity extends FragmentActivity {
    private static final String TAG = "MainActivity";
    private ViewPager mPager;
    private ArrayList<Fragment> fragmentsList;
    private ImageView ivBottomLine;
    private TextView tvTabActivity, tvTabGroups, tvTabFriends, tvTabChat;

    private int currIndex = 0;
    private int bottomLineWidth;
    private int offset = 0;
    private int position_one;
    private int position_two;
    private int position_three;
    private Resources resources;

    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        requestWindowFeature(Window.FEATURE_NO_TITLE);
        setContentView(R.layout.main);
        resources = getResources();
        InitWidth();
        InitTextView();
        InitViewPager();
    }

    private void InitTextView() {
        tvTabActivity = (TextView) findViewById(R.id.tv_tab_activity);
        tvTabGroups = (TextView) findViewById(R.id.tv_tab_groups);
        tvTabFriends = (TextView) findViewById(R.id.tv_tab_friends);
        tvTabChat = (TextView) findViewById(R.id.tv_tab_chat);

        tvTabActivity.setOnClickListener(new MyOnClickListener(0));
        tvTabGroups.setOnClickListener(new MyOnClickListener(1));
        tvTabFriends.setOnClickListener(new MyOnClickListener(2));
        tvTabChat.setOnClickListener(new MyOnClickListener(3));
    }

    private void InitViewPager() {
        mPager = (ViewPager) findViewById(R.id.vPager);
        fragmentsList = new ArrayList<Fragment>();

        Map<String, Object> paramMap = new HashMap<String, Object>();
        paramMap.put("userid","小洪");
        paramMap.put("age",23);


        Map<String, Object> paramMap2 = new HashMap<String, Object>();
        paramMap2.put("userid","vatty");
        paramMap2.put("age",24);

        Map<String, Object> paramMap3 = new HashMap<String, Object>();
        paramMap3.put("userid","小明");
        paramMap3.put("age",25);


        Map<String, Object> paramMap4 = new HashMap<String, Object>();
        paramMap4.put("userid","hongshengpeng.com");
        paramMap4.put("age",26);


        Fragment activityfragment = TestFragment.newInstance("Hello Activity.",paramMap);
        Fragment groupFragment = TestFragment.newInstance("Hello Group.",paramMap2);
        Fragment friendsFragment=TestFragment.newInstance("Hello Friends.",paramMap3);
        Fragment chatFragment=TestFragment.newInstance("Hello Chat.",paramMap4);

        fragmentsList.add(activityfragment);
        fragmentsList.add(groupFragment);
        fragmentsList.add(friendsFragment);
        fragmentsList.add(chatFragment);

        mPager.setAdapter(new MyFragmentPagerAdapter(getSupportFragmentManager(), fragmentsList));
        mPager.setCurrentItem(0);
        mPager.setOnPageChangeListener(new MyOnPageChangeListener());
    }

    private void InitWidth() {
        ivBottomLine = (ImageView) findViewById(R.id.iv_bottom_line);
        bottomLineWidth = ivBottomLine.getLayoutParams().width;
        Log.d(TAG, "cursor imageview width=" + bottomLineWidth);
        DisplayMetrics dm = new DisplayMetrics();
        getWindowManager().getDefaultDisplay().getMetrics(dm);
        int screenW = dm.widthPixels;
        offset = (int) ((screenW / 4.0 - bottomLineWidth) / 2);
        Log.i("MainActivity", "offset=" + offset);

        position_one = (int) (screenW / 4.0);
        position_two = position_one * 2;
        position_three = position_one * 3;
    }

    public class MyOnClickListener implements View.OnClickListener {
        private int index = 0;

        public MyOnClickListener(int i) {
            index = i;
        }

        @Override
        public void onClick(View v) {
            mPager.setCurrentItem(index);
        }
    };

    public class MyOnPageChangeListener implements OnPageChangeListener {

        @Override
        public void onPageSelected(int arg0) {
            Animation animation = null;
            switch (arg0) {
            case 0:
                if (currIndex == 1) {
                    animation = new TranslateAnimation(position_one, 0, 0, 0);
                    tvTabGroups.setTextColor(resources.getColor(R.color.lightwhite));
                } else if (currIndex == 2) {
                    animation = new TranslateAnimation(position_two, 0, 0, 0);
                    tvTabFriends.setTextColor(resources.getColor(R.color.lightwhite));
                } else if (currIndex == 3) {
                    animation = new TranslateAnimation(position_three, 0, 0, 0);
                    tvTabChat.setTextColor(resources.getColor(R.color.lightwhite));
                }
                tvTabActivity.setTextColor(resources.getColor(R.color.white));
                break;
            case 1:
                if (currIndex == 0) {
                    animation = new TranslateAnimation(0, position_one, 0, 0);
                    tvTabActivity.setTextColor(resources.getColor(R.color.lightwhite));
                } else if (currIndex == 2) {
                    animation = new TranslateAnimation(position_two, position_one, 0, 0);
                    tvTabFriends.setTextColor(resources.getColor(R.color.lightwhite));
                } else if (currIndex == 3) {
                    animation = new TranslateAnimation(position_three, position_one, 0, 0);
                    tvTabChat.setTextColor(resources.getColor(R.color.lightwhite));
                }
                tvTabGroups.setTextColor(resources.getColor(R.color.white));
                break;
            case 2:
                if (currIndex == 0) {
                    animation = new TranslateAnimation(0, position_two, 0, 0);
                    tvTabActivity.setTextColor(resources.getColor(R.color.lightwhite));
                } else if (currIndex == 1) {
                    animation = new TranslateAnimation(position_one, position_two, 0, 0);
                    tvTabGroups.setTextColor(resources.getColor(R.color.lightwhite));
                } else if (currIndex == 3) {
                    animation = new TranslateAnimation(position_three, position_two, 0, 0);
                    tvTabChat.setTextColor(resources.getColor(R.color.lightwhite));
                }
                tvTabFriends.setTextColor(resources.getColor(R.color.white));
                break;
            case 3:
                if (currIndex == 0) {
                    animation = new TranslateAnimation(0, position_three, 0, 0);
                    tvTabActivity.setTextColor(resources.getColor(R.color.lightwhite));
                } else if (currIndex == 1) {
                    animation = new TranslateAnimation(position_one, position_three, 0, 0);
                    tvTabGroups.setTextColor(resources.getColor(R.color.lightwhite));
                } else if (currIndex == 2) {
                    animation = new TranslateAnimation(position_two, position_three, 0, 0);
                    tvTabFriends.setTextColor(resources.getColor(R.color.lightwhite));
                }
                tvTabChat.setTextColor(resources.getColor(R.color.white));
                break;
            }
            currIndex = arg0;
            animation.setFillAfter(true);
            animation.setDuration(300);
            ivBottomLine.startAnimation(animation);
        }

        @Override
        public void onPageScrolled(int arg0, float arg1, int arg2) {
        }

        @Override
        public void onPageScrollStateChanged(int arg0) {
        }
    }
}
