笔记-谷歌Zxing二维码,用数据流输出到页面显示

笔记,谷歌Zxing二维码,用数据流输出到页面显示

二维码一直都很流行,今日实践了一下,需求是针对不同的参数生成地址链接二维码,并展示在页面上,如果采用生成图片保存本地再返回相对路径,会产生一堆垃圾图片文件,还要后期清除实在是麻烦,想起登录时的校验码可以直接将流输出到页面,故就异曲同工吧,少废话直接上代码。

项目是SpringMVC,maven管理
先导入谷歌的二维码pom文件Zxing的依赖关系

  <!-- 二维码 -->
    <dependency>
      <groupId>com.google.zxing</groupId>
      <artifactId>core</artifactId>
      <version>3.2.0</version>
    </dependency>
    <dependency>
      <groupId>com.google.zxing</groupId>
      <artifactId>javase</artifactId>
      <version>3.2.0</version>
    </dependency>

页面jsp显示二维码处:

<img class="q_code" src="${path}/tv/getQ?id=${id}" />

java controller代码

    @RequestMapping(value = "/getQ", method = { RequestMethod.POST, RequestMethod.GET })
    public void getqcode(HttpServletResponse resp, String id) throws IOException {
        String url = "要生成二维码的地址"+id;
        if (url != null && !"".equals(url)) {
            ServletOutputStream stream = null;
            try {

                int width = 200;//图片的宽度
                int height = 200;//高度
                stream = resp.getOutputStream();
                QRCodeWriter writer = new QRCodeWriter();
                BitMatrix m = writer.encode(url, BarcodeFormat.QR_CODE, height, width);
                MatrixToImageWriter.writeToStream(m, "png", stream);
            } catch (WriterException e) {
                e.printStackTrace();
            } finally {
                if (stream != null) {
                    stream.flush();
                    stream.close();
                }
            }
        }
    }

最后当页面加载的时候会去执行img标签内的src请求返回图片流并展示。
这里写图片描述

ZXing一维码/二维码 使用文档 样例: System.IO.Stream stmYiWei = new System.IO.MemoryStream(); BitMatrix byteMatrix = new MultiFormatWriter().encode(sCode, BarcodeFormat.CODE_39, 230, 40); toBitmap(byteMatrix).Save(stmYiWei, ImageFormat.Bmp); Byte[] byteYiWei = new byte[stmYiWei.Length]; stmYiWei.Position = 0; stmYiWei.Read(byteYiWei, 0, (int)stmYiWei.Length); //将图片文件流保存为二进制文件以便保存到数据库中 System.IO.Stream stmErWei = new System.IO.MemoryStream(); IDictionary hints = new Dictionary(); hints.Add(EncodeHintType.CHARACTER_SET, "UTF-8"); byteMatrix = new MultiFormatWriter().encode(sTmp, BarcodeFormat.QR_CODE, 200, 200, hints); toBitmap(byteMatrix).Save(stmErWei, ImageFormat.Bmp); Byte[] byteErWei = new byte[stmErWei.Length]; stmErWei.Position = 0; stmErWei.Read(byteErWei, 0, (int)stmErWei.Length); //将图片文件流保存为二进制文件以便保存到数据库中 strSQL = "insert into gdzc_biaoqian( bq_gd_no,bq_yiweima,bq_erweima,bq_us_no) values("; strSQL = strSQL + " @bq_gd_no,@bq_yiweima,@bq_erweima,@bq_us_no)"; SqlCommand commandImage = new SqlCommand(strSQL, connectionImage); commandImage.Parameters.Clear(); commandImage.Parameters.Add("@bq_gd_no", SqlDbType.Int).Value = Convert.ToInt32(sGdzcNo); commandImage.Parameters.Add("@bq_yiweima", SqlDbType.Image).Value = byteYiWei; commandImage.Parameters.Add("@bq_erweima", SqlDbType.Image).Value = byteErWei; commandImage.Parameters.Add("@bq_us_no", SqlDbType.Int).Value = Convert.ToInt32(Session["LoginUserID"]); commandImage.ExecuteNonQuery(); commandImage.Dispose();
