高德地图 绘制步行路线规划、骑行路线规划

高德地图 绘制步行路线规划、骑行路线规划

<template>
  <div class="home">
    <div class="top">
      <p class="text">
        全程{{
          navRoute.distance >= 1000
            ? navRoute.distance / 1000 + "km"
            : navRoute.distance + "m"
        }}，预计
        <span>{{ formatSecondsAsHHMM(navRoute.time) }}</span>
      </p>
    </div>
    <div class="map" id="container"></div>
  </div>
</template>

<script>
import { setLocalStore } from "@/utils/plugins";
import { Toast } from "vant";
import { http } from "@/utils/http-request";

export default {
  components: {},
  data() {
    return {
      electricPin: this.$route.query.electricPin,
      userId: this.$route.query.userId,
      ses_id: this.$route.query.ses_id,
      navRoute: {
        time: "",
        type: "",
        distance: "",
      },
      startPosition: {
        lng: "121.286354",
        lat: "28.099415",
      },
      endPosition: {
        lat: "28.226092",
        lng: "121.304734",
      },
      amap: null,
      map: null,
      walking: null,
      driving: null,
      list: [
        {
          lat: "28.226450",
          lng: "121.303763",
        },
        {
          lat: "28.168666",
          lng: "121.360070",
        },
        {
          lat: "28.235824",
          lng: "121.268558",
        },
        {
          lat: "28.226092",
          lng: "121.304734",
        },
      ],
    };
  },
  computed: {},
  async mounted() {
    setLocalStore("user", {
      ses_id: this.ses_id,
      userId: this.userId,
    });
    this.getSDK();
    window._AMapSecurityConfig = {
      securityJsCode: "自己的安全密钥",
    };
    await window.AMapLoader.load({
      key: "自己的key",
      plugins: [
        "AMap.Driving",
        "AMap.Transfer",
        "AMap.Walking",
        "AMap.convertFrom",
      ],
    })
      .then(async (AMap) => {
        this.amap = AMap;
      })
      .catch((e) => {
        console.error(e);
      });
    this.map = new this.amap.Map("container", {
      zoom: 12,
      center: [this.startPosition.lng, this.startPosition.lat],
    });
    this.getMedicalList();
    // 步行路线规划
    // this.walkingRoute(this.startPosition, this.endPosition);
  },
  methods: {
    // 百度转高德经纬度坐标系  初始定位
    async convertFromStart() {
      const _this = this;
      var gps = [this.startPosition.lng, this.startPosition.lat];
      await this.amap.convertFrom(gps, "baidu", function (status, result) {
        if (result.info === "ok") {
          _this.startPosition.lng = result.locations[0].lng; // Array.<LngLat>
          _this.startPosition.lat = result.locations[0].lat; // Array.<LngLat>=
        }
      });
    },
    // 百度转高德经纬度坐标系  结束位置
    async convertFromEnd() {
      const _this = this;
      var end = [this.endPosition.lng, this.endPosition.lat];
      await this.amap.convertFrom(end, "baidu", function (status, result) {
        if (result.info === "ok") {
          _this.endPosition.lng = result.locations[0].lng; // Array.<LngLat>
          _this.endPosition.lat = result.locations[0].lat; // Array.<LngLat>
        }
      });
    },
    // 微信jssdk
    getSDK() {
      http
        .postRequest("Wctrl/W000", {
          signurl: window.location.href.split("#")[0],
        })
        .then((res) => {
          if (res.result === "0") {
            const { appid, timestamp, nonceStr, signature } = res.data;
            window.wx.config({
              debug: false, // 开启调试模式,调用的所有api的返回值会在客户端alert出来，若要查看传入的参数，可以在pc端打开，参数信息会通过log打出，仅在pc端时才会打印。
              appId: appid, // 必填，公众号的唯一标识
              timestamp, // 必填，生成签名的时间戳
              nonceStr, // 必填，生成签名的随机串
              signature, // 必填，签名
              jsApiList: [
                "miniProgram",
                "miniProgram.getEnv",
                "openLocation",
                "miniProgram.navigateTo",
                "miniProgram.navigateBack",
                "miniProgram.redirectTo",
                "miniProgram.navigateToMiniProgram",
                "miniProgram.switchTab",
                "miniProgram.reLaunch",
              ], // 必填，需要使用的JS接口列表
            });
            window.wx.ready(function () {
              console.log("wx.ready 初始化ok");
              window.wx.checkJsApi({
                jsApiList: [
                  "miniProgram",
                  "miniProgram.getEnv",
                  "openLocation",
                  "miniProgram.navigateTo",
                  "miniProgram.navigateBack",
                  "miniProgram.redirectTo",
                  "miniProgram.navigateToMiniProgram",
                  "miniProgram.switchTab",
                  "miniProgram.reLaunch",
                ], // 需要检测的 JS 接口列表，所有 JS 接口列表见附录2,
                success: function (res) {
                  console.log("wxJsApi success:", res);
                },
                fail: (err) => {
                  console.log("wxJsApi fail:", err);
                },
              });
            });
          } else {
            Toast(res.msg);
          }
        });
    },
    getMedicalList() {
      // http
      //   .postRequest("frontEnd/MED03", {
      //     pageNum: this.query.pageNum,
      //     pageSize: 10,
      //     lng: this.startPosition.lng,
      //     lat: this.startPosition.lat,
      //   })
      //   .then((res) => {
      //     if (res.result === "0") {
      // this.list.value =
      //   this.query.pageNum === 1
      //     ? res.data.data
      //     : [...this.list.value, ...res.data.data];
      // this.query.loading = false;
      // this.query.pageNum++;
      // this.query.finished = res.data.data.length < 10 ? true : false;
      this.list.forEach((item) => {
        const medicalLocation = new this.amap.Marker({
          icon: new this.amap.Icon({
            size: new this.amap.Size(26, 31),
            image: require("@/assets/img/medicalHealth/wz2@2x.png"),
            imageSize: new this.amap.Size(26, 31),
          }),
          position: [item.lng, item.lat],
        });
        medicalLocation.on("click", () => {
          console.log(item);
          if (this.walking!=null) {
            console.log("666666", this.walking);
            this.walking.clear();
          }
          this.walkingRoute(this.startPosition, item);
        });
        this.map.add(medicalLocation);
      });
      this.map.setFitView();
      // } else {
      //   this.$toast(res.msg);
      // }
      // });
    },
    // 步行路线规划  骑行路线规划
    walkingRoute(start, end) {
      const _this = this;
      this.walking = new this.amap.Walking({
        map: this.map,
      });
      this.walking.search(
        [start.lng, start.lat],
        [end.lng, end.lat],
        function (status, result) {
          if (status === "complete") {
            const { distance, time } = result.routes[0];
            _this.navRoute.time = time;
            _this.navRoute.distance = distance;
            if (result.routes && result.routes.length) {
              // 步行路线
              _this.drawRoute(result.routes[0]);
              // 骑行路线规划
              // _this.Cycling(result.routes[0]);
              console.log("线路规划成功");
            }
          } else {
            Toast("步行路线数据查询失败" + result);
          }
        }
      );
    },
    // 骑行线路规划绘制
    async Cycling(route) {
      var path = await this.parseRouteToPath(route);

      var startMarker = new this.amap.Marker({
        position: path[0],
        icon: "https://webapi.amap.com/theme/v1.3/markers/n/start.png",
        anchor: "bottom-center",
        // map: this.map,
      });

      var endMarker = new this.amap.Marker({
        position: path[path.length - 1],
        icon: "https://webapi.amap.com/theme/v1.3/markers/n/end.png",
        anchor: "bottom-center",
        // map: this.map,
      });

      var routeLine = new this.amap.Polyline({
        path: path,
        isOutline: true,
        outlineColor: "#ffeeee",
        borderWeight: 2,
        strokeWeight: 5,
        strokeColor: "#0091ff",
        strokeOpacity: 0.9,
        lineJoin: "round",
      });

      this.map.add(routeLine);
      // 调整视野达到最佳显示区域
      this.map.setFitView([startMarker, endMarker, routeLine]);
    },
    // 步行线路规划绘制
    async drawRoute(route) {
      var path = await this.parseRouteToPath(route);
      console.log("3");
      console.log(path[0]);
      var startMarker = new this.amap.Marker({
        position: path[0],
        icon: "https://webapi.amap.com/theme/v1.3/markers/n/start.png",
        // map: this.map,
        anchor: "bottom-center",
      });
      var endMarker = new this.amap.Marker({
        position: path[path.length - 1],
        icon: "https://webapi.amap.com/theme/v1.3/markers/n/end.png",
        // map: this.map,
        anchor: "bottom-center",
      });
      var routeLine = new this.amap.Polyline({
        path: path,
        isOutline: true,
        outlineColor: "#ffeeee",
        borderWeight: 2,
        strokeWeight: 5,
        strokeColor: "#0091ff",
        strokeOpacity: 0.9,
        lineJoin: "round",
      });
      this.map.add(routeLine);
      // 调整视野达到最佳显示区域
      this.map.setFitView([startMarker, endMarker, routeLine]);
    },
    // 解析WalkRoute对象，构造成AMap.Polyline的path参数需要的格式
    // WalkRoute对象的结构文档 https://lbs.amap.com/api/javascript-api/reference/route-search#m_WalkRoute
    parseRouteToPath(route) {
      var path = [];
      for (var i = 0, l = route.steps.length; i < l; i++) {
        var step = route.steps[i];
        for (var j = 0, n = step.path.length; j < n; j++) {
          path.push(step.path[j]);
        }
      }
      return path;
    },
    // 算预计时间
    formatSecondsAsHHMM(seconds) {
      const hours = Math.floor(seconds / 3600);
      const minutes = Math.floor((seconds % 3600) / 60);
      if (seconds / 60 >= 60) {
        return `${hours}小时${minutes}分钟`;
      } else return `${parseInt(seconds / 60)}分钟`;
    },
  },
};
</script>

<style lang="less" scoped>
.home {
  .map {
    width: 100%;
    height: calc(100vh - 274px);
  }
  .top {
    width: 100%;
    height: 75px;
    padding: 10px 12px;
    background: #ffffff;
    .text {
      font-size: 14px;
      text-align: center;
      span {
        padding-left: 5px;
        font-size: 18px;
        font-weight: 500;
      }
    }
  }
}
.flex {
  display: flex;
}
.flex-s {
  display: flex;
  justify-content: space-between;
}
</style>
