AI算法可视化：Matplotlib与Seaborn模型解释全指南

前些天发现了一个巨牛的人工智能学习网站，通俗易懂，风趣幽默，忍不住分享一下给大家。点击跳转到网站https://www.captainbed.cn/north

一、基础可视化工具配置

1.1 环境设置与样式配置

import matplotlib.pyplot as plt
import seaborn as sns
import numpy as np

# 设置全局样式
plt.style.use('seaborn-v0_8-whitegrid')  # 白色网格背景
sns.set_palette("husl")  # 设置调色板
plt.rcParams['font.family'] = 'SimHei'  # 中文显示
plt.rcParams['axes.unicode_minus'] = False  # 解决负号显示问题

# 创建示例数据
np.random.seed(42)
X = np.random.randn(100, 3)
y = X[:, 0] + 2*X[:, 1] - 1.5*X[:, 2] + np.random.randn(100)*0.5

二、数据分布可视化

2.1 特征分布分析

def plot_feature_distributions(X, feature_names):
    """绘制特征分布矩阵图"""
    fig, axes = plt.subplots(1, 3, figsize=(15, 4))

    for i, (ax, name) in enumerate(zip(axes, feature_names)):
        # 直方图与密度曲线
        sns.histplot(X[:, i], kde=True, ax=ax, bins=15)
        ax.set_title(f'特征 {name} 分布')
        ax.set_xlabel('值范围')
        ax.set_ylabel('频数')

    plt.tight_layout()
    plt.show()

# 使用示例
plot_feature_distributions(X, ['特征1', '特征2', '特征3'])

2.2 目标变量分析

def plot_target_analysis(y):
    """目标变量综合分析"""
    fig = plt.figure(figsize=(14, 4))

    # 分布图
    ax1 = fig.add_subplot(131)
    sns.histplot(y, kde=True, ax=ax1)
    ax1.set_title('目标值分布')

    # 箱线图
    ax2 = fig.add_subplot(132)
    sns.boxplot(y=y, ax=ax2)
    ax2.set_title('目标值箱线图')

    # QQ图
    ax3 = fig.add_subplot(133)
    stats.probplot(y, dist="norm", plot=ax3)
    ax3.set_title('正态性检验(Q-Q图)')

    plt.tight_layout()
    plt.show()

plot_target_analysis(y)

三、模型训练过程可视化

3.1 学习曲线绘制

from sklearn.model_selection import learning_curve

def plot_learning_curve(estimator, X, y):
    """绘制学习曲线"""
    train_sizes, train_scores, test_scores = learning_curve(
        estimator, X, y, cv=5, n_jobs=-1,
        train_sizes=np.linspace(0.1, 1.0, 10))

    train_mean = np.mean(train_scores, axis=1)
    train_std = np.std(train_scores, axis=1)
    test_mean = np.mean(test_scores, axis=1)
    test_std = np.std(test_scores, axis=1)

    plt.figure(figsize=(10, 6))
    plt.fill_between(train_sizes, train_mean - train_std,
                     train_mean + train_std, alpha=0.1, color="r")
    plt.fill_between(train_sizes, test_mean - test_std,
                     test_mean + test_std, alpha=0.1, color="g")
    plt.plot(train_sizes, train_mean, 'o-', color="r",
             label="训练分数")
    plt.plot(train_sizes, test_mean, 'o-', color="g",
             label="交叉验证分数")

    plt.title('学习曲线')
    plt.xlabel('训练样本数')
    plt.ylabel('分数(R2)')
    plt.legend(loc="best")
    plt.grid(True)
    plt.show()

# 使用示例
from sklearn.linear_model import LinearRegression
plot_learning_curve(LinearRegression(), X, y)

3.2 损失函数可视化

from keras.models import Sequential
from keras.layers import Dense
from keras.callbacks import History

def plot_loss_history(model, X, y):
    """训练过程损失变化可视化"""
    history = History()
    model = Sequential([
        Dense(10, input_dim=3, activation='relu'),
        Dense(1)
    ])
    model.compile(optimizer='adam', loss='mse')
    model.fit(X, y, epochs=100, verbose=0, callbacks=[history])

    plt.figure(figsize=(10, 5))
    plt.plot(history.history['loss'], label='训练损失')
    plt.title('模型训练损失变化')
    plt.xlabel('Epoch')
    plt.ylabel('MSE')
    plt.legend()
    plt.grid(True)
    plt.show()

plot_loss_history(model, X, y)

四、模型结果解释

4.1 回归模型可视化

def plot_regression_results(y_true, y_pred):
    """回归结果可视化"""
    plt.figure(figsize=(12, 5))

    # 真实值vs预测值
    plt.subplot(121)
    max_val = max(y_true.max(), y_pred.max())
    min_val = min(y_true.min(), y_pred.min())
    plt.scatter(y_true, y_pred, alpha=0.5)
    plt.plot([min_val, max_val], [min_val, max_val], '--r')
    plt.xlabel('真实值')
    plt.ylabel('预测值')
    plt.title('真实值 vs 预测值')

    # 残差图
    plt.subplot(122)
    residuals = y_true - y_pred
    plt.scatter(y_pred, residuals, alpha=0.5)
    plt.axhline(y=0, color='r', linestyle='--')
    plt.xlabel('预测值')
    plt.ylabel('残差')
    plt.title('残差分析')

    plt.tight_layout()
    plt.show()

# 示例使用
from sklearn.linear_model import LinearRegression
model = LinearRegression().fit(X, y)
y_pred = model.predict(X)
plot_regression_results(y, y_pred)

4.2 分类模型可视化

from sklearn.metrics import confusion_matrix, roc_curve, auc

def plot_classification_results(y_true, y_pred, y_score):
    """分类模型结果可视化"""
    plt.figure(figsize=(15, 5))

    # 混淆矩阵
    plt.subplot(131)
    cm = confusion_matrix(y_true, y_pred)
    sns.heatmap(cm, annot=True, fmt='d', cmap='Blues')
    plt.title('混淆矩阵')
    plt.xlabel('预测标签')
    plt.ylabel('真实标签')

    # ROC曲线
    plt.subplot(132)
    fpr, tpr, _ = roc_curve(y_true, y_score)
    roc_auc = auc(fpr, tpr)
    plt.plot(fpr, tpr, color='darkorange', lw=2,
             label='ROC曲线 (AUC = %0.2f)' % roc_auc)
    plt.plot([0, 1], [0, 1], color='navy', lw=2, linestyle='--')
    plt.xlabel('假阳性率')
    plt.ylabel('真阳性率')
    plt.title('ROC曲线')
    plt.legend(loc="lower right")

    # 概率分布
    plt.subplot(133)
    sns.kdeplot(y_score[y_true==0], label='负类', shade=True)
    sns.kdeplot(y_score[y_true==1], label='正类', shade=True)
    plt.title('类别概率分布')
    plt.xlabel('预测概率')
    plt.ylabel('密度')
    plt.legend()

    plt.tight_layout()
    plt.show()

# 示例使用（二分类）
from sklearn.ensemble import RandomForestClassifier
from sklearn.datasets import make_classification

X_clf, y_clf = make_classification(n_samples=1000, n_features=4, random_state=42)
clf = RandomForestClassifier().fit(X_clf, y_clf)
y_pred = clf.predict(X_clf)
y_score = clf.predict_proba(X_clf)[:, 1]
plot_classification_results(y_clf, y_pred, y_score)

五、特征重要性分析

5.1 树模型特征重要性

def plot_feature_importance(model, feature_names):
    """特征重要性可视化"""
    importance = model.feature_importances_
    indices = np.argsort(importance)[::-1]

    plt.figure(figsize=(10, 6))
    plt.title("特征重要性")
    plt.bar(range(len(importance)), importance[indices],
            color="lightblue", align="center")
    plt.xticks(range(len(importance)),
               [feature_names[i] for i in indices], rotation=45)
    plt.xlim([-1, len(importance)])
    plt.tight_layout()
    plt.show()

# 示例使用
from sklearn.ensemble import RandomForestRegressor
model = RandomForestRegressor().fit(X, y)
plot_feature_importance(model, ['特征1', '特征2', '特征3'])

5.2 SHAP值可视化

import shap

def plot_shap_summary(model, X, feature_names):
    """SHAP特征贡献可视化"""
    explainer = shap.Explainer(model)
    shap_values = explainer(X)

    plt.figure(figsize=(10, 6))
    shap.summary_plot(shap_values, X, feature_names=feature_names,
                      plot_type="bar", show=False)
    plt.title("SHAP特征重要性(绝对值平均)")
    plt.tight_layout()
    plt.show()

    plt.figure(figsize=(10, 6))
    shap.summary_plot(shap_values, X, feature_names=feature_names,
                      show=False)
    plt.title("SHAP值分布")
    plt.tight_layout()
    plt.show()

# 示例使用
plot_shap_summary(model, X, ['特征1', '特征2', '特征3'])

六、决策边界可视化

6.1 二维决策边界

from sklearn.datasets import make_classification
from mlxtend.plotting import plot_decision_regions

def plot_2d_decision_boundary(model, X, y):
    """二维特征空间决策边界"""
    plt.figure(figsize=(10, 6))
    plot_decision_regions(X, y, clf=model, legend=2)
    plt.title("决策边界可视化")
    plt.xlabel("特征1")
    plt.ylabel("特征2")
    plt.show()

# 示例使用（二维特征）
X_2d, y_2d = make_classification(n_samples=200, n_features=2,
                                n_redundant=0, random_state=42)
clf_2d = RandomForestClassifier().fit(X_2d, y_2d)
plot_2d_decision_boundary(clf_2d, X_2d, y_2d)

6.2 高维投影决策边界

from sklearn.decomposition import PCA

def plot_pca_decision_boundary(model, X, y):
    """PCA降维后的决策边界"""
    pca = PCA(n_components=2)
    X_pca = pca.fit_transform(X)
    model_pca = RandomForestClassifier().fit(X_pca, y)

    plt.figure(figsize=(12, 5))

    plt.subplot(121)
    plt.scatter(X_pca[:, 0], X_pca[:, 1], c=y, cmap='coolwarm', alpha=0.6)
    plt.title("PCA降维投影")
    plt.xlabel("主成分1")
    plt.ylabel("主成分2")

    plt.subplot(122)
    plot_decision_regions(X_pca, y, clf=model_pca, legend=2)
    plt.title("降维空间决策边界")
    plt.xlabel("主成分1")

    plt.tight_layout()
    plt.show()

# 示例使用
plot_pca_decision_boundary(clf, X_clf, y_clf)

七、聚类结果可视化

7.1 二维聚类可视化

from sklearn.cluster import KMeans
from sklearn.datasets import make_blobs

def plot_cluster_results(X, n_clusters=3):
    """聚类结果可视化"""
    kmeans = KMeans(n_clusters=n_clusters, random_state=42)
    clusters = kmeans.fit_predict(X)
    centers = kmeans.cluster_centers_

    plt.figure(figsize=(12, 5))

    plt.subplot(121)
    plt.scatter(X[:, 0], X[:, 1], c=clusters, cmap='viridis', alpha=0.5)
    plt.scatter(centers[:, 0], centers[:, 1], c='red', s=200, alpha=0.8)
    plt.title("聚类结果")
    plt.xlabel("特征1")
    plt.ylabel("特征2")

    plt.subplot(122)
    silhouette_vals = silhouette_samples(X, clusters)
    y_lower = 10
    for i in range(n_clusters):
        ith_cluster_silhouette_vals = silhouette_vals[clusters == i]
        ith_cluster_silhouette_vals.sort()
        size_cluster_i = ith_cluster_silhouette_vals.shape[0]
        y_upper = y_lower + size_cluster_i
        plt.fill_betweenx(np.arange(y_lower, y_upper),
                          0, ith_cluster_silhouette_vals,
                          alpha=0.7)
        plt.text(-0.05, y_lower + 0.5 * size_cluster_i, str(i))
        y_lower = y_upper + 10
    plt.title("轮廓系数分析")
    plt.xlabel("轮廓系数值")
    plt.ylabel("聚类标签")

    plt.tight_layout()
    plt.show()

# 示例使用
X_blobs, _ = make_blobs(n_samples=300, centers=3, random_state=42)
plot_cluster_results(X_blobs)

八、神经网络可视化

8.1 模型结构可视化

from keras.models import Sequential
from keras.layers import Dense
from keras.utils import plot_model

def visualize_keras_model():
    """Keras模型结构可视化"""
    model = Sequential([
        Dense(64, input_dim=20, activation='relu'),
        Dense(32, activation='relu'),
        Dense(1, activation='sigmoid')
    ])

    plot_model(model, to_file='model.png', show_shapes=True,
               show_layer_names=True, rankdir='LR')

    # 在Notebook中直接显示
    from IPython.display import Image
    return Image(filename='model.png')

visualize_keras_model()

8.2 激活热图可视化

from keras.applications.vgg16 import VGG16, preprocess_input
from keras.preprocessing import image

def visualize_activation_heatmap(img_path):
    """CNN激活热图可视化"""
    model = VGG16(weights='imagenet')

    # 预处理图像
    img = image.load_img(img_path, target_size=(224, 224))
    x = image.img_to_array(img)
    x = np.expand_dims(x, axis=0)
    x = preprocess_input(x)

    # 获取预测类别
    preds = model.predict(x)
    class_idx = np.argmax(preds[0])

    # 获取最后一个卷积层的梯度
    last_conv_layer = model.get_layer('block5_conv3')
    grads = K.gradients(model.output[:, class_idx], last_conv_layer.output)[0]
    pooled_grads = K.mean(grads, axis=(0, 1, 2))
    iterate = K.function([model.input], [pooled_grads, last_conv_layer.output[0]])
    pooled_grads_value, conv_layer_output_value = iterate([x])

    # 计算热图
    for i in range(512):
        conv_layer_output_value[:, :, i] *= pooled_grads_value[i]
    heatmap = np.mean(conv_layer_output_value, axis=-1)
    heatmap = np.maximum(heatmap, 0)
    heatmap /= np.max(heatmap)

    # 可视化
    plt.figure(figsize=(10, 5))

    plt.subplot(121)
    plt.imshow(img)
    plt.title('原始图像')

    plt.subplot(122)
    plt.imshow(heatmap, cmap='jet')
    plt.title('激活热图')

    plt.tight_layout()
    plt.show()

# 示例使用（需要实际图像文件）
# visualize_activation_heatmap('elephant.jpg')

九、时间序列预测可视化

9.1 预测结果对比

def plot_time_series_forecast(y_true, y_pred, title="时间序列预测结果"):
    """时间序列预测可视化"""
    plt.figure(figsize=(12, 6))
    plt.plot(y_true, label='真实值', color='blue', alpha=0.6)
    plt.plot(y_pred, label='预测值', color='red', linestyle='--', alpha=0.8)
    plt.fill_between(range(len(y_true)),
                    y_pred - 0.2*np.std(y_true),
                    y_pred + 0.2*np.std(y_true),
                    color='pink', alpha=0.3)
    plt.title(title)
    plt.xlabel('时间步')
    plt.ylabel('值')
    plt.legend()
    plt.grid(True)
    plt.show()

# 示例使用
np.random.seed(42)
time_series = np.sin(np.linspace(0, 10, 100)) + np.random.randn(100)*0.2
prediction = np.sin(np.linspace(0, 10, 100)+0.1) + np.random.randn(100)*0.1
plot_time_series_forecast(time_series, prediction)

十、交互式可视化进阶

10.1 Plotly交互可视化

import plotly.express as px
import pandas as pd

def interactive_feature_analysis(X, y, feature_names):
    """交互式特征分析"""
    df = pd.DataFrame(X, columns=feature_names)
    df['target'] = y

    fig = px.scatter_matrix(df, dimensions=feature_names,
                           color='target', opacity=0.7,
                           title="交互式特征矩阵图")
    fig.update_traces(diagonal_visible=False)
    fig.show()

    fig2 = px.parallel_coordinates(df, color='target',
                                  labels={col:col for col in df.columns},
                                  title="平行坐标图")
    fig2.show()

# 示例使用
interactive_feature_analysis(X, y, ['特征1', '特征2', '特征3'])

通过以上可视化技术，您可以全面理解AI模型的行为、诊断问题并有效解释模型决策。每种可视化方法都针对特定的模型解释需求，建议根据您的具体场景选择组合使用。

一、基础可视化工具配置

1.1 环境设置与样式配置

import matplotlib.pyplot as plt
import seaborn as sns
import numpy as np

# 设置全局样式
plt.style.use('seaborn-v0_8-whitegrid')  # 白色网格背景
sns.set_palette("husl")  # 设置调色板
plt.rcParams['font.family'] = 'SimHei'  # 中文显示
plt.rcParams['axes.unicode_minus'] = False  # 解决负号显示问题

# 创建示例数据
np.random.seed(42)
X = np.random.randn(100, 3)
y = X[:, 0] + 2*X[:, 1] - 1.5*X[:, 2] + np.random.randn(100)*0.5

二、数据分布可视化

2.1 特征分布分析

def plot_feature_distributions(X, feature_names):
    """绘制特征分布矩阵图"""
    fig, axes = plt.subplots(1, 3, figsize=(15, 4))

    for i, (ax, name) in enumerate(zip(axes, feature_names)):
        # 直方图与密度曲线
        sns.histplot(X[:, i], kde=True, ax=ax, bins=15)
        ax.set_title(f'特征 {name} 分布')
        ax.set_xlabel('值范围')
        ax.set_ylabel('频数')

    plt.tight_layout()
    plt.show()

# 使用示例
plot_feature_distributions(X, ['特征1', '特征2', '特征3'])

2.2 目标变量分析

def plot_target_analysis(y):
    """目标变量综合分析"""
    fig = plt.figure(figsize=(14, 4))

    # 分布图
    ax1 = fig.add_subplot(131)
    sns.histplot(y, kde=True, ax=ax1)
    ax1.set_title('目标值分布')

    # 箱线图
    ax2 = fig.add_subplot(132)
    sns.boxplot(y=y, ax=ax2)
    ax2.set_title('目标值箱线图')

    # QQ图
    ax3 = fig.add_subplot(133)
    stats.probplot(y, dist="norm", plot=ax3)
    ax3.set_title('正态性检验(Q-Q图)')

    plt.tight_layout()
    plt.show()

plot_target_analysis(y)

三、模型训练过程可视化

3.1 学习曲线绘制

from sklearn.model_selection import learning_curve

def plot_learning_curve(estimator, X, y):
    """绘制学习曲线"""
    train_sizes, train_scores, test_scores = learning_curve(
        estimator, X, y, cv=5, n_jobs=-1,
        train_sizes=np.linspace(0.1, 1.0, 10))

    train_mean = np.mean(train_scores, axis=1)
    train_std = np.std(train_scores, axis=1)
    test_mean = np.mean(test_scores, axis=1)
    test_std = np.std(test_scores, axis=1)

    plt.figure(figsize=(10, 6))
    plt.fill_between(train_sizes, train_mean - train_std,
                     train_mean + train_std, alpha=0.1, color="r")
    plt.fill_between(train_sizes, test_mean - test_std,
                     test_mean + test_std, alpha=0.1, color="g")
    plt.plot(train_sizes, train_mean, 'o-', color="r",
             label="训练分数")
    plt.plot(train_sizes, test_mean, 'o-', color="g",
             label="交叉验证分数")

    plt.title('学习曲线')
    plt.xlabel('训练样本数')
    plt.ylabel('分数(R2)')
    plt.legend(loc="best")
    plt.grid(True)
    plt.show()

# 使用示例
from sklearn.linear_model import LinearRegression
plot_learning_curve(LinearRegression(), X, y)

3.2 损失函数可视化

from keras.models import Sequential
from keras.layers import Dense
from keras.callbacks import History

def plot_loss_history(model, X, y):
    """训练过程损失变化可视化"""
    history = History()
    model = Sequential([
        Dense(10, input_dim=3, activation='relu'),
        Dense(1)
    ])
    model.compile(optimizer='adam', loss='mse')
    model.fit(X, y, epochs=100, verbose=0, callbacks=[history])

    plt.figure(figsize=(10, 5))
    plt.plot(history.history['loss'], label='训练损失')
    plt.title('模型训练损失变化')
    plt.xlabel('Epoch')
    plt.ylabel('MSE')
    plt.legend()
    plt.grid(True)
    plt.show()

plot_loss_history(model, X, y)

四、模型结果解释

4.1 回归模型可视化

def plot_regression_results(y_true, y_pred):
    """回归结果可视化"""
    plt.figure(figsize=(12, 5))

    # 真实值vs预测值
    plt.subplot(121)
    max_val = max(y_true.max(), y_pred.max())
    min_val = min(y_true.min(), y_pred.min())
    plt.scatter(y_true, y_pred, alpha=0.5)
    plt.plot([min_val, max_val], [min_val, max_val], '--r')
    plt.xlabel('真实值')
    plt.ylabel('预测值')
    plt.title('真实值 vs 预测值')

    # 残差图
    plt.subplot(122)
    residuals = y_true - y_pred
    plt.scatter(y_pred, residuals, alpha=0.5)
    plt.axhline(y=0, color='r', linestyle='--')
    plt.xlabel('预测值')
    plt.ylabel('残差')
    plt.title('残差分析')

    plt.tight_layout()
    plt.show()

# 示例使用
from sklearn.linear_model import LinearRegression
model = LinearRegression().fit(X, y)
y_pred = model.predict(X)
plot_regression_results(y, y_pred)

4.2 分类模型可视化

from sklearn.metrics import confusion_matrix, roc_curve, auc

def plot_classification_results(y_true, y_pred, y_score):
    """分类模型结果可视化"""
    plt.figure(figsize=(15, 5))

    # 混淆矩阵
    plt.subplot(131)
    cm = confusion_matrix(y_true, y_pred)
    sns.heatmap(cm, annot=True, fmt='d', cmap='Blues')
    plt.title('混淆矩阵')
    plt.xlabel('预测标签')
    plt.ylabel('真实标签')

    # ROC曲线
    plt.subplot(132)
    fpr, tpr, _ = roc_curve(y_true, y_score)
    roc_auc = auc(fpr, tpr)
    plt.plot(fpr, tpr, color='darkorange', lw=2,
             label='ROC曲线 (AUC = %0.2f)' % roc_auc)
    plt.plot([0, 1], [0, 1], color='navy', lw=2, linestyle='--')
    plt.xlabel('假阳性率')
    plt.ylabel('真阳性率')
    plt.title('ROC曲线')
    plt.legend(loc="lower right")

    # 概率分布
    plt.subplot(133)
    sns.kdeplot(y_score[y_true==0], label='负类', shade=True)
    sns.kdeplot(y_score[y_true==1], label='正类', shade=True)
    plt.title('类别概率分布')
    plt.xlabel('预测概率')
    plt.ylabel('密度')
    plt.legend()

    plt.tight_layout()
    plt.show()

# 示例使用（二分类）
from sklearn.ensemble import RandomForestClassifier
from sklearn.datasets import make_classification

X_clf, y_clf = make_classification(n_samples=1000, n_features=4, random_state=42)
clf = RandomForestClassifier().fit(X_clf, y_clf)
y_pred = clf.predict(X_clf)
y_score = clf.predict_proba(X_clf)[:, 1]
plot_classification_results(y_clf, y_pred, y_score)

五、特征重要性分析

5.1 树模型特征重要性

def plot_feature_importance(model, feature_names):
    """特征重要性可视化"""
    importance = model.feature_importances_
    indices = np.argsort(importance)[::-1]

    plt.figure(figsize=(10, 6))
    plt.title("特征重要性")
    plt.bar(range(len(importance)), importance[indices],
            color="lightblue", align="center")
    plt.xticks(range(len(importance)),
               [feature_names[i] for i in indices], rotation=45)
    plt.xlim([-1, len(importance)])
    plt.tight_layout()
    plt.show()

# 示例使用
from sklearn.ensemble import RandomForestRegressor
model = RandomForestRegressor().fit(X, y)
plot_feature_importance(model, ['特征1', '特征2', '特征3'])

5.2 SHAP值可视化

import shap

def plot_shap_summary(model, X, feature_names):
    """SHAP特征贡献可视化"""
    explainer = shap.Explainer(model)
    shap_values = explainer(X)

    plt.figure(figsize=(10, 6))
    shap.summary_plot(shap_values, X, feature_names=feature_names,
                      plot_type="bar", show=False)
    plt.title("SHAP特征重要性(绝对值平均)")
    plt.tight_layout()
    plt.show()

    plt.figure(figsize=(10, 6))
    shap.summary_plot(shap_values, X, feature_names=feature_names,
                      show=False)
    plt.title("SHAP值分布")
    plt.tight_layout()
    plt.show()

# 示例使用
plot_shap_summary(model, X, ['特征1', '特征2', '特征3'])

六、决策边界可视化

6.1 二维决策边界

from sklearn.datasets import make_classification
from mlxtend.plotting import plot_decision_regions

def plot_2d_decision_boundary(model, X, y):
    """二维特征空间决策边界"""
    plt.figure(figsize=(10, 6))
    plot_decision_regions(X, y, clf=model, legend=2)
    plt.title("决策边界可视化")
    plt.xlabel("特征1")
    plt.ylabel("特征2")
    plt.show()

# 示例使用（二维特征）
X_2d, y_2d = make_classification(n_samples=200, n_features=2,
                                n_redundant=0, random_state=42)
clf_2d = RandomForestClassifier().fit(X_2d, y_2d)
plot_2d_decision_boundary(clf_2d, X_2d, y_2d)

6.2 高维投影决策边界

from sklearn.decomposition import PCA

def plot_pca_decision_boundary(model, X, y):
    """PCA降维后的决策边界"""
    pca = PCA(n_components=2)
    X_pca = pca.fit_transform(X)
    model_pca = RandomForestClassifier().fit(X_pca, y)

    plt.figure(figsize=(12, 5))

    plt.subplot(121)
    plt.scatter(X_pca[:, 0], X_pca[:, 1], c=y, cmap='coolwarm', alpha=0.6)
    plt.title("PCA降维投影")
    plt.xlabel("主成分1")
    plt.ylabel("主成分2")

    plt.subplot(122)
    plot_decision_regions(X_pca, y, clf=model_pca, legend=2)
    plt.title("降维空间决策边界")
    plt.xlabel("主成分1")

    plt.tight_layout()
    plt.show()

# 示例使用
plot_pca_decision_boundary(clf, X_clf, y_clf)

七、聚类结果可视化

7.1 二维聚类可视化

from sklearn.cluster import KMeans
from sklearn.datasets import make_blobs

def plot_cluster_results(X, n_clusters=3):
    """聚类结果可视化"""
    kmeans = KMeans(n_clusters=n_clusters, random_state=42)
    clusters = kmeans.fit_predict(X)
    centers = kmeans.cluster_centers_

    plt.figure(figsize=(12, 5))

    plt.subplot(121)
    plt.scatter(X[:, 0], X[:, 1], c=clusters, cmap='viridis', alpha=0.5)
    plt.scatter(centers[:, 0], centers[:, 1], c='red', s=200, alpha=0.8)
    plt.title("聚类结果")
    plt.xlabel("特征1")
    plt.ylabel("特征2")

    plt.subplot(122)
    silhouette_vals = silhouette_samples(X, clusters)
    y_lower = 10
    for i in range(n_clusters):
        ith_cluster_silhouette_vals = silhouette_vals[clusters == i]
        ith_cluster_silhouette_vals.sort()
        size_cluster_i = ith_cluster_silhouette_vals.shape[0]
        y_upper = y_lower + size_cluster_i
        plt.fill_betweenx(np.arange(y_lower, y_upper),
                          0, ith_cluster_silhouette_vals,
                          alpha=0.7)
        plt.text(-0.05, y_lower + 0.5 * size_cluster_i, str(i))
        y_lower = y_upper + 10
    plt.title("轮廓系数分析")
    plt.xlabel("轮廓系数值")
    plt.ylabel("聚类标签")

    plt.tight_layout()
    plt.show()

# 示例使用
X_blobs, _ = make_blobs(n_samples=300, centers=3, random_state=42)
plot_cluster_results(X_blobs)

八、神经网络可视化

8.1 模型结构可视化

from keras.models import Sequential
from keras.layers import Dense
from keras.utils import plot_model

def visualize_keras_model():
    """Keras模型结构可视化"""
    model = Sequential([
        Dense(64, input_dim=20, activation='relu'),
        Dense(32, activation='relu'),
        Dense(1, activation='sigmoid')
    ])

    plot_model(model, to_file='model.png', show_shapes=True,
               show_layer_names=True, rankdir='LR')

    # 在Notebook中直接显示
    from IPython.display import Image
    return Image(filename='model.png')

visualize_keras_model()

8.2 激活热图可视化

from keras.applications.vgg16 import VGG16, preprocess_input
from keras.preprocessing import image

def visualize_activation_heatmap(img_path):
    """CNN激活热图可视化"""
    model = VGG16(weights='imagenet')

    # 预处理图像
    img = image.load_img(img_path, target_size=(224, 224))
    x = image.img_to_array(img)
    x = np.expand_dims(x, axis=0)
    x = preprocess_input(x)

    # 获取预测类别
    preds = model.predict(x)
    class_idx = np.argmax(preds[0])

    # 获取最后一个卷积层的梯度
    last_conv_layer = model.get_layer('block5_conv3')
    grads = K.gradients(model.output[:, class_idx], last_conv_layer.output)[0]
    pooled_grads = K.mean(grads, axis=(0, 1, 2))
    iterate = K.function([model.input], [pooled_grads, last_conv_layer.output[0]])
    pooled_grads_value, conv_layer_output_value = iterate([x])

    # 计算热图
    for i in range(512):
        conv_layer_output_value[:, :, i] *= pooled_grads_value[i]
    heatmap = np.mean(conv_layer_output_value, axis=-1)
    heatmap = np.maximum(heatmap, 0)
    heatmap /= np.max(heatmap)

    # 可视化
    plt.figure(figsize=(10, 5))

    plt.subplot(121)
    plt.imshow(img)
    plt.title('原始图像')

    plt.subplot(122)
    plt.imshow(heatmap, cmap='jet')
    plt.title('激活热图')

    plt.tight_layout()
    plt.show()

# 示例使用（需要实际图像文件）
# visualize_activation_heatmap('elephant.jpg')

九、时间序列预测可视化

9.1 预测结果对比

def plot_time_series_forecast(y_true, y_pred, title="时间序列预测结果"):
    """时间序列预测可视化"""
    plt.figure(figsize=(12, 6))
    plt.plot(y_true, label='真实值', color='blue', alpha=0.6)
    plt.plot(y_pred, label='预测值', color='red', linestyle='--', alpha=0.8)
    plt.fill_between(range(len(y_true)),
                    y_pred - 0.2*np.std(y_true),
                    y_pred + 0.2*np.std(y_true),
                    color='pink', alpha=0.3)
    plt.title(title)
    plt.xlabel('时间步')
    plt.ylabel('值')
    plt.legend()
    plt.grid(True)
    plt.show()

# 示例使用
np.random.seed(42)
time_series = np.sin(np.linspace(0, 10, 100)) + np.random.randn(100)*0.2
prediction = np.sin(np.linspace(0, 10, 100)+0.1) + np.random.randn(100)*0.1
plot_time_series_forecast(time_series, prediction)

十、交互式可视化进阶

10.1 Plotly交互可视化

import plotly.express as px
import pandas as pd

def interactive_feature_analysis(X, y, feature_names):
    """交互式特征分析"""
    df = pd.DataFrame(X, columns=feature_names)
    df['target'] = y

    fig = px.scatter_matrix(df, dimensions=feature_names,
                           color='target', opacity=0.7,
                           title="交互式特征矩阵图")
    fig.update_traces(diagonal_visible=False)
    fig.show()

    fig2 = px.parallel_coordinates(df, color='target',
                                  labels={col:col for col in df.columns},
                                  title="平行坐标图")
    fig2.show()

# 示例使用
interactive_feature_analysis(X, y, ['特征1', '特征2', '特征3'])

通过以上可视化技术，您可以全面理解AI模型的行为、诊断问题并有效解释模型决策。每种可视化方法都针对特定的模型解释需求，建议根据您的具体场景选择组合使用。

一、基础可视化工具配置

1.1 环境设置与样式配置

import matplotlib.pyplot as plt
import seaborn as sns
import numpy as np

# 设置全局样式
plt.style.use('seaborn-v0_8-whitegrid')  # 白色网格背景
sns.set_palette("husl")  # 设置调色板
plt.rcParams['font.family'] = 'SimHei'  # 中文显示
plt.rcParams['axes.unicode_minus'] = False  # 解决负号显示问题

# 创建示例数据
np.random.seed(42)
X = np.random.randn(100, 3)
y = X[:, 0] + 2*X[:, 1] - 1.5*X[:, 2] + np.random.randn(100)*0.5

二、数据分布可视化

2.1 特征分布分析

def plot_feature_distributions(X, feature_names):
    """绘制特征分布矩阵图"""
    fig, axes = plt.subplots(1, 3, figsize=(15, 4))

    for i, (ax, name) in enumerate(zip(axes, feature_names)):
        # 直方图与密度曲线
        sns.histplot(X[:, i], kde=True, ax=ax, bins=15)
        ax.set_title(f'特征 {name} 分布')
        ax.set_xlabel('值范围')
        ax.set_ylabel('频数')

    plt.tight_layout()
    plt.show()

# 使用示例
plot_feature_distributions(X, ['特征1', '特征2', '特征3'])

2.2 目标变量分析

def plot_target_analysis(y):
    """目标变量综合分析"""
    fig = plt.figure(figsize=(14, 4))

    # 分布图
    ax1 = fig.add_subplot(131)
    sns.histplot(y, kde=True, ax=ax1)
    ax1.set_title('目标值分布')

    # 箱线图
    ax2 = fig.add_subplot(132)
    sns.boxplot(y=y, ax=ax2)
    ax2.set_title('目标值箱线图')

    # QQ图
    ax3 = fig.add_subplot(133)
    stats.probplot(y, dist="norm", plot=ax3)
    ax3.set_title('正态性检验(Q-Q图)')

    plt.tight_layout()
    plt.show()

plot_target_analysis(y)

三、模型训练过程可视化

3.1 学习曲线绘制

from sklearn.model_selection import learning_curve

def plot_learning_curve(estimator, X, y):
    """绘制学习曲线"""
    train_sizes, train_scores, test_scores = learning_curve(
        estimator, X, y, cv=5, n_jobs=-1,
        train_sizes=np.linspace(0.1, 1.0, 10))

    train_mean = np.mean(train_scores, axis=1)
    train_std = np.std(train_scores, axis=1)
    test_mean = np.mean(test_scores, axis=1)
    test_std = np.std(test_scores, axis=1)

    plt.figure(figsize=(10, 6))
    plt.fill_between(train_sizes, train_mean - train_std,
                     train_mean + train_std, alpha=0.1, color="r")
    plt.fill_between(train_sizes, test_mean - test_std,
                     test_mean + test_std, alpha=0.1, color="g")
    plt.plot(train_sizes, train_mean, 'o-', color="r",
             label="训练分数")
    plt.plot(train_sizes, test_mean, 'o-', color="g",
             label="交叉验证分数")

    plt.title('学习曲线')
    plt.xlabel('训练样本数')
    plt.ylabel('分数(R2)')
    plt.legend(loc="best")
    plt.grid(True)
    plt.show()

# 使用示例
from sklearn.linear_model import LinearRegression
plot_learning_curve(LinearRegression(), X, y)

3.2 损失函数可视化

from keras.models import Sequential
from keras.layers import Dense
from keras.callbacks import History

def plot_loss_history(model, X, y):
    """训练过程损失变化可视化"""
    history = History()
    model = Sequential([
        Dense(10, input_dim=3, activation='relu'),
        Dense(1)
    ])
    model.compile(optimizer='adam', loss='mse')
    model.fit(X, y, epochs=100, verbose=0, callbacks=[history])

    plt.figure(figsize=(10, 5))
    plt.plot(history.history['loss'], label='训练损失')
    plt.title('模型训练损失变化')
    plt.xlabel('Epoch')
    plt.ylabel('MSE')
    plt.legend()
    plt.grid(True)
    plt.show()

plot_loss_history(model, X, y)

四、模型结果解释

4.1 回归模型可视化

def plot_regression_results(y_true, y_pred):
    """回归结果可视化"""
    plt.figure(figsize=(12, 5))

    # 真实值vs预测值
    plt.subplot(121)
    max_val = max(y_true.max(), y_pred.max())
    min_val = min(y_true.min(), y_pred.min())
    plt.scatter(y_true, y_pred, alpha=0.5)
    plt.plot([min_val, max_val], [min_val, max_val], '--r')
    plt.xlabel('真实值')
    plt.ylabel('预测值')
    plt.title('真实值 vs 预测值')

    # 残差图
    plt.subplot(122)
    residuals = y_true - y_pred
    plt.scatter(y_pred, residuals, alpha=0.5)
    plt.axhline(y=0, color='r', linestyle='--')
    plt.xlabel('预测值')
    plt.ylabel('残差')
    plt.title('残差分析')

    plt.tight_layout()
    plt.show()

# 示例使用
from sklearn.linear_model import LinearRegression
model = LinearRegression().fit(X, y)
y_pred = model.predict(X)
plot_regression_results(y, y_pred)

4.2 分类模型可视化

from sklearn.metrics import confusion_matrix, roc_curve, auc

def plot_classification_results(y_true, y_pred, y_score):
    """分类模型结果可视化"""
    plt.figure(figsize=(15, 5))

    # 混淆矩阵
    plt.subplot(131)
    cm = confusion_matrix(y_true, y_pred)
    sns.heatmap(cm, annot=True, fmt='d', cmap='Blues')
    plt.title('混淆矩阵')
    plt.xlabel('预测标签')
    plt.ylabel('真实标签')

    # ROC曲线
    plt.subplot(132)
    fpr, tpr, _ = roc_curve(y_true, y_score)
    roc_auc = auc(fpr, tpr)
    plt.plot(fpr, tpr, color='darkorange', lw=2,
             label='ROC曲线 (AUC = %0.2f)' % roc_auc)
    plt.plot([0, 1], [0, 1], color='navy', lw=2, linestyle='--')
    plt.xlabel('假阳性率')
    plt.ylabel('真阳性率')
    plt.title('ROC曲线')
    plt.legend(loc="lower right")

    # 概率分布
    plt.subplot(133)
    sns.kdeplot(y_score[y_true==0], label='负类', shade=True)
    sns.kdeplot(y_score[y_true==1], label='正类', shade=True)
    plt.title('类别概率分布')
    plt.xlabel('预测概率')
    plt.ylabel('密度')
    plt.legend()

    plt.tight_layout()
    plt.show()

# 示例使用（二分类）
from sklearn.ensemble import RandomForestClassifier
from sklearn.datasets import make_classification

X_clf, y_clf = make_classification(n_samples=1000, n_features=4, random_state=42)
clf = RandomForestClassifier().fit(X_clf, y_clf)
y_pred = clf.predict(X_clf)
y_score = clf.predict_proba(X_clf)[:, 1]
plot_classification_results(y_clf, y_pred, y_score)

五、特征重要性分析

5.1 树模型特征重要性

def plot_feature_importance(model, feature_names):
    """特征重要性可视化"""
    importance = model.feature_importances_
    indices = np.argsort(importance)[::-1]

    plt.figure(figsize=(10, 6))
    plt.title("特征重要性")
    plt.bar(range(len(importance)), importance[indices],
            color="lightblue", align="center")
    plt.xticks(range(len(importance)),
               [feature_names[i] for i in indices], rotation=45)
    plt.xlim([-1, len(importance)])
    plt.tight_layout()
    plt.show()

# 示例使用
from sklearn.ensemble import RandomForestRegressor
model = RandomForestRegressor().fit(X, y)
plot_feature_importance(model, ['特征1', '特征2', '特征3'])

5.2 SHAP值可视化

import shap

def plot_shap_summary(model, X, feature_names):
    """SHAP特征贡献可视化"""
    explainer = shap.Explainer(model)
    shap_values = explainer(X)

    plt.figure(figsize=(10, 6))
    shap.summary_plot(shap_values, X, feature_names=feature_names,
                      plot_type="bar", show=False)
    plt.title("SHAP特征重要性(绝对值平均)")
    plt.tight_layout()
    plt.show()

    plt.figure(figsize=(10, 6))
    shap.summary_plot(shap_values, X, feature_names=feature_names,
                      show=False)
    plt.title("SHAP值分布")
    plt.tight_layout()
    plt.show()

# 示例使用
plot_shap_summary(model, X, ['特征1', '特征2', '特征3'])

六、决策边界可视化

6.1 二维决策边界

from sklearn.datasets import make_classification
from mlxtend.plotting import plot_decision_regions

def plot_2d_decision_boundary(model, X, y):
    """二维特征空间决策边界"""
    plt.figure(figsize=(10, 6))
    plot_decision_regions(X, y, clf=model, legend=2)
    plt.title("决策边界可视化")
    plt.xlabel("特征1")
    plt.ylabel("特征2")
    plt.show()

# 示例使用（二维特征）
X_2d, y_2d = make_classification(n_samples=200, n_features=2,
                                n_redundant=0, random_state=42)
clf_2d = RandomForestClassifier().fit(X_2d, y_2d)
plot_2d_decision_boundary(clf_2d, X_2d, y_2d)

6.2 高维投影决策边界

from sklearn.decomposition import PCA

def plot_pca_decision_boundary(model, X, y):
    """PCA降维后的决策边界"""
    pca = PCA(n_components=2)
    X_pca = pca.fit_transform(X)
    model_pca = RandomForestClassifier().fit(X_pca, y)

    plt.figure(figsize=(12, 5))

    plt.subplot(121)
    plt.scatter(X_pca[:, 0], X_pca[:, 1], c=y, cmap='coolwarm', alpha=0.6)
    plt.title("PCA降维投影")
    plt.xlabel("主成分1")
    plt.ylabel("主成分2")

    plt.subplot(122)
    plot_decision_regions(X_pca, y, clf=model_pca, legend=2)
    plt.title("降维空间决策边界")
    plt.xlabel("主成分1")

    plt.tight_layout()
    plt.show()

# 示例使用
plot_pca_decision_boundary(clf, X_clf, y_clf)

七、聚类结果可视化

7.1 二维聚类可视化

from sklearn.cluster import KMeans
from sklearn.datasets import make_blobs

def plot_cluster_results(X, n_clusters=3):
    """聚类结果可视化"""
    kmeans = KMeans(n_clusters=n_clusters, random_state=42)
    clusters = kmeans.fit_predict(X)
    centers = kmeans.cluster_centers_

    plt.figure(figsize=(12, 5))

    plt.subplot(121)
    plt.scatter(X[:, 0], X[:, 1], c=clusters, cmap='viridis', alpha=0.5)
    plt.scatter(centers[:, 0], centers[:, 1], c='red', s=200, alpha=0.8)
    plt.title("聚类结果")
    plt.xlabel("特征1")
    plt.ylabel("特征2")

    plt.subplot(122)
    silhouette_vals = silhouette_samples(X, clusters)
    y_lower = 10
    for i in range(n_clusters):
        ith_cluster_silhouette_vals = silhouette_vals[clusters == i]
        ith_cluster_silhouette_vals.sort()
        size_cluster_i = ith_cluster_silhouette_vals.shape[0]
        y_upper = y_lower + size_cluster_i
        plt.fill_betweenx(np.arange(y_lower, y_upper),
                          0, ith_cluster_silhouette_vals,
                          alpha=0.7)
        plt.text(-0.05, y_lower + 0.5 * size_cluster_i, str(i))
        y_lower = y_upper + 10
    plt.title("轮廓系数分析")
    plt.xlabel("轮廓系数值")
    plt.ylabel("聚类标签")

    plt.tight_layout()
    plt.show()

# 示例使用
X_blobs, _ = make_blobs(n_samples=300, centers=3, random_state=42)
plot_cluster_results(X_blobs)

八、神经网络可视化

8.1 模型结构可视化

from keras.models import Sequential
from keras.layers import Dense
from keras.utils import plot_model

def visualize_keras_model():
    """Keras模型结构可视化"""
    model = Sequential([
        Dense(64, input_dim=20, activation='relu'),
        Dense(32, activation='relu'),
        Dense(1, activation='sigmoid')
    ])

    plot_model(model, to_file='model.png', show_shapes=True,
               show_layer_names=True, rankdir='LR')

    # 在Notebook中直接显示
    from IPython.display import Image
    return Image(filename='model.png')

visualize_keras_model()

8.2 激活热图可视化

from keras.applications.vgg16 import VGG16, preprocess_input
from keras.preprocessing import image

def visualize_activation_heatmap(img_path):
    """CNN激活热图可视化"""
    model = VGG16(weights='imagenet')

    # 预处理图像
    img = image.load_img(img_path, target_size=(224, 224))
    x = image.img_to_array(img)
    x = np.expand_dims(x, axis=0)
    x = preprocess_input(x)

    # 获取预测类别
    preds = model.predict(x)
    class_idx = np.argmax(preds[0])

    # 获取最后一个卷积层的梯度
    last_conv_layer = model.get_layer('block5_conv3')
    grads = K.gradients(model.output[:, class_idx], last_conv_layer.output)[0]
    pooled_grads = K.mean(grads, axis=(0, 1, 2))
    iterate = K.function([model.input], [pooled_grads, last_conv_layer.output[0]])
    pooled_grads_value, conv_layer_output_value = iterate([x])

    # 计算热图
    for i in range(512):
        conv_layer_output_value[:, :, i] *= pooled_grads_value[i]
    heatmap = np.mean(conv_layer_output_value, axis=-1)
    heatmap = np.maximum(heatmap, 0)
    heatmap /= np.max(heatmap)

    # 可视化
    plt.figure(figsize=(10, 5))

    plt.subplot(121)
    plt.imshow(img)
    plt.title('原始图像')

    plt.subplot(122)
    plt.imshow(heatmap, cmap='jet')
    plt.title('激活热图')

    plt.tight_layout()
    plt.show()

# 示例使用（需要实际图像文件）
# visualize_activation_heatmap('elephant.jpg')

九、时间序列预测可视化

9.1 预测结果对比

def plot_time_series_forecast(y_true, y_pred, title="时间序列预测结果"):
    """时间序列预测可视化"""
    plt.figure(figsize=(12, 6))
    plt.plot(y_true, label='真实值', color='blue', alpha=0.6)
    plt.plot(y_pred, label='预测值', color='red', linestyle='--', alpha=0.8)
    plt.fill_between(range(len(y_true)),
                    y_pred - 0.2*np.std(y_true),
                    y_pred + 0.2*np.std(y_true),
                    color='pink', alpha=0.3)
    plt.title(title)
    plt.xlabel('时间步')
    plt.ylabel('值')
    plt.legend()
    plt.grid(True)
    plt.show()

# 示例使用
np.random.seed(42)
time_series = np.sin(np.linspace(0, 10, 100)) + np.random.randn(100)*0.2
prediction = np.sin(np.linspace(0, 10, 100)+0.1) + np.random.randn(100)*0.1
plot_time_series_forecast(time_series, prediction)

十、交互式可视化进阶

10.1 Plotly交互可视化

import plotly.express as px
import pandas as pd

def interactive_feature_analysis(X, y, feature_names):
    """交互式特征分析"""
    df = pd.DataFrame(X, columns=feature_names)
    df['target'] = y

    fig = px.scatter_matrix(df, dimensions=feature_names,
                           color='target', opacity=0.7,
                           title="交互式特征矩阵图")
    fig.update_traces(diagonal_visible=False)
    fig.show()

    fig2 = px.parallel_coordinates(df, color='target',
                                  labels={col:col for col in df.columns},
                                  title="平行坐标图")
    fig2.show()

# 示例使用
interactive_feature_analysis(X, y, ['特征1', '特征2', '特征3'])

通过以上可视化技术，您可以全面理解AI模型的行为、诊断问题并有效解释模型决策。每种可视化方法都针对特定的模型解释需求，建议根据您的具体场景选择组合使用。
