RpcEndpointRef

作用

RpcEndpointRef作为是RpcEndpoint的引用，观察类方法可以发现，其模版是用于节点发送消息。
包含请求回调(ask) 、异步请求回调(askSync)、通知(send)等方法。

private[spark] abstract class RpcEndpointRef(conf: SparkConf)
  extends Serializable with Logging {

  private[this] val maxRetries = RpcUtils.numRetries(conf)
  private[this] val retryWaitMs = RpcUtils.retryWaitMs(conf)
  private[this] val defaultAskTimeout = RpcUtils.askRpcTimeout(conf)

  /**
   * return the address for the [[RpcEndpointRef]]
   */
  def address: RpcAddress

  def name: String

  /**
   * Sends a one-way asynchronous message. Fire-and-forget semantics.
   */
  def send(message: Any): Unit

  /**
   * Send a message to the corresponding [[RpcEndpoint.receiveAndReply)]] and return a
   * [[AbortableRpcFuture]] to receive the reply within the specified timeout.
   * The [[AbortableRpcFuture]] instance wraps [[Future]] with additional `abort` method.
   *
   * This method only sends the message once and never retries.
   */
  def askAbortable[T: ClassTag](message: Any, timeout: RpcTimeout): AbortableRpcFuture[T] = {
    throw new UnsupportedOperationException()
  }

  /**
   * Send a message to the corresponding [[RpcEndpoint.receiveAndReply)]] and return a [[Future]] to
   * receive the reply within the specified timeout.
   *
   * This method only sends the message once and never retries.
   */
  def ask[T: ClassTag](message: Any, timeout: RpcTimeout): Future[T]

  /**
   * Send a message to the corresponding [[RpcEndpoint.receiveAndReply)]] and return a [[Future]] to
   * receive the reply within a default timeout.
   *
   * This method only sends the message once and never retries.
   */
  def ask[T: ClassTag](message: Any): Future[T] = ask(message, defaultAskTimeout)

  /**
   * Send a message to the corresponding [[RpcEndpoint.receiveAndReply]] and get its result within a
   * default timeout, throw an exception if this fails.
   *
   * Note: this is a blocking action which may cost a lot of time,  so don't call it in a message
   * loop of [[RpcEndpoint]].

   * @param message the message to send
   * @tparam T type of the reply message
   * @return the reply message from the corresponding [[RpcEndpoint]]
   */
  def askSync[T: ClassTag](message: Any): T = askSync(message, defaultAskTimeout)

  /**
   * Send a message to the corresponding [[RpcEndpoint.receiveAndReply]] and get its result within a
   * specified timeout, throw an exception if this fails.
   *
   * Note: this is a blocking action which may cost a lot of time, so don't call it in a message
   * loop of [[RpcEndpoint]].
   *
   * @param message the message to send
   * @param timeout the timeout duration
   * @tparam T type of the reply message
   * @return the reply message from the corresponding [[RpcEndpoint]]
   */
  def askSync[T: ClassTag](message: Any, timeout: RpcTimeout): T = {
    val future = ask[T](message, timeout)
    timeout.awaitResult(future)
  }

}

NettyRpcEndpointRef

看源码中dispatcher.registerRpcEndpoint()方法是初始化RpcEndpointRef的入口，真正的实现类是NettyRpcEndpointRef，内部有具体的请求逻辑。

 def registerRpcEndpoint(name: String, endpoint: RpcEndpoint): NettyRpcEndpointRef = {
    val addr = RpcEndpointAddress(nettyEnv.address, name)
    val endpointRef = new NettyRpcEndpointRef(nettyEnv.conf, addr, nettyEnv)
    synchronized {
      if (stopped) {
        throw new IllegalStateException("RpcEnv has been stopped")
      }
      if (endpoints.containsKey(name)) {
        throw new IllegalArgumentException(s"There is already an RpcEndpoint called $name")
      }

      endpointRefs.put(endpoint, endpointRef)

      var messageLoop: MessageLoop = null
      try {
        messageLoop = endpoint match {
          case e: IsolatedRpcEndpoint =>
            new DedicatedMessageLoop(name, e, this)
          case _ =>
            sharedLoop.register(name, endpoint)
            sharedLoop
        }
        endpoints.put(name, messageLoop)
      } catch {
        case NonFatal(e) =>
          endpointRefs.remove(endpoint)
          throw e
      }
    }
    endpointRef
  }

RpcEndpoint

作用

RpcEndpoint 可以理解为接收信息的的站点 ,主要通过receive/receiveAndReply两个方法接收消息并处理的。

RpcEndpoint也可以获取自己的RpcEndpointRef引用(rpcEnv.endpointRef(this)) 实现发送消息的功能。

/**
 * An end point for the RPC that defines what functions to trigger given a message.
 *
 * It is guaranteed that `onStart`, `receive` and `onStop` will be called in sequence.
 *
 * The life-cycle of an endpoint is:
 *
 * {@code constructor -> onStart -> receive* -> onStop}
 *
 * Note: `receive` can be called concurrently. If you want `receive` to be thread-safe, please use
 * [[ThreadSafeRpcEndpoint]]
 *
 * If any error is thrown from one of [[RpcEndpoint]] methods except `onError`, `onError` will be
 * invoked with the cause. If `onError` throws an error, [[RpcEnv]] will ignore it.
 */
private[spark] trait RpcEndpoint {

  /**
   * The [[RpcEnv]] that this [[RpcEndpoint]] is registered to.
   */
  val rpcEnv: RpcEnv

  /**
   * The [[RpcEndpointRef]] of this [[RpcEndpoint]]. `self` will become valid when `onStart` is
   * called. And `self` will become `null` when `onStop` is called.
   *
   * Note: Because before `onStart`, [[RpcEndpoint]] has not yet been registered and there is not
   * valid [[RpcEndpointRef]] for it. So don't call `self` before `onStart` is called.
   */
  final def self: RpcEndpointRef = {
    require(rpcEnv != null, "rpcEnv has not been initialized")
    rpcEnv.endpointRef(this)
  }

  /**
   * Process messages from `RpcEndpointRef.send` or `RpcCallContext.reply`. If receiving a
   * unmatched message, `SparkException` will be thrown and sent to `onError`.
   */
  def receive: PartialFunction[Any, Unit] = {
    case _ => throw new SparkException(self + " does not implement 'receive'")
  }

  /**
   * Process messages from `RpcEndpointRef.ask`. If receiving a unmatched message,
   * `SparkException` will be thrown and sent to `onError`.
   */
  def receiveAndReply(context: RpcCallContext): PartialFunction[Any, Unit] = {
    case _ => context.sendFailure(new SparkException(self + " won't reply anything"))
  }

  /**
   * Invoked when any exception is thrown during handling messages.
   */
  def onError(cause: Throwable): Unit = {
    // By default, throw e and let RpcEnv handle it
    throw cause
  }

  /**
   * Invoked when `remoteAddress` is connected to the current node.
   */
  def onConnected(remoteAddress: RpcAddress): Unit = {
    // By default, do nothing.
  }

  /**
   * Invoked when `remoteAddress` is lost.
   */
  def onDisconnected(remoteAddress: RpcAddress): Unit = {
    // By default, do nothing.
  }

  /**
   * Invoked when some network error happens in the connection between the current node and
   * `remoteAddress`.
   */
  def onNetworkError(cause: Throwable, remoteAddress: RpcAddress): Unit = {
    // By default, do nothing.
  }

  /**
   * Invoked before [[RpcEndpoint]] starts to handle any message.
   */
  def onStart(): Unit = {
    // By default, do nothing.
  }

  /**
   * Invoked when [[RpcEndpoint]] is stopping. `self` will be `null` in this method and you cannot
   * use it to send or ask messages.
   */
  def onStop(): Unit = {
    // By default, do nothing.
  }

  /**
   * A convenient method to stop [[RpcEndpoint]].
   */
  final def stop(): Unit = {
    val _self = self
    if (_self != null) {
      rpcEnv.stop(_self)
    }
  }
}
