jeesite4.0 树桩图

这一块是树的一个写法 把链接的地方改成自己的就可以

<div class="ui-layout-west">
	<div class="main-content">
		<div class="box box-main">
			<div class="box-header">
				<div class="box-title">
					<i class="fa icon-grid"></i> 组织机构
				</div>
				<div class="box-tools pull-right">

                                        //这里改成自己的office_user:officeUser:edit

					<% if(hasPermi('office_user:officeUser:edit')){ %>

                                                  //链接也改成自己的
						<button type="button" class="btn btn-box-tool addTabPage" data-href="${ctx}/office_user/officeUser/list" title="管理机构"><i class="fa fa-edit"></i></button>
					<% } %>
					<button type="button" class="btn btn-box-tool" id="btnExpand" title="展开" style="display:none;"><i class="fa fa-chevron-up"></i></button>
					<button type="button" class="btn btn-box-tool" id="btnCollapse" title="折叠"><i class="fa fa-chevron-down"></i></button>
					<button type="button" class="btn btn-box-tool" id="btnRefresh" title="刷新机构"><i class="fa fa-refresh"></i></button>
				</div>
			</div>
			<div class="ui-layout-content">
				<div id="tree" class="ztree"></div>
			</div>
		</div>
	</div>
</div>

<!--这一块是grid的一个引用-->
<div class="ui-layout-center">
	<iframe id="mainFrame" name="mainFrame" class="ui-layout-content p0"
		src="${ctx}/sys/empUser/list"></iframe>
</div>

// 初始化布局
$('body').layout({
	west__size: 185
});
// 主页框架 grid这个对象
var win = $("#mainFrame")[0].contentWindow;
console.log(win);
// 树结构初始化加载
var setting = {view:{selectedMulti:false},data:{key:{title:"title"},simpleData:{enable:true}},
	callback:{onClick:function(event, treeId, treeNode){
		tree.expandNode(treeNode);
		win.$('input[type=reset]').click();

//grid查询页面是这么写的

//<#form:treeselect id="company" title="公司"


//code 对象这个 path="employee.company.companyCode"  name 对应这里 labelPath="employee.company.companyName"
								//url="${ctx}/sys/company/treeData" btnClass="btn-sm" allowClear="true" canSelectParent="true"/>

//把值塞进grid页面里 code是隐藏值 name是显示值   下面的就比这写因为具体的我还没有研究

win.$('#companyCode').val(treeNode.id);
		win.$('#companyName').val(treeNode.name);
		win.page();
	}}
}, tree, loadTree = function(){
	js.ajaxSubmit("${ctx}/office_user/officeUser/treeData2", {ctrlPermi:'2'/*1拥有的权限 2管理的权限*/}, function(data){
		tree = $.fn.zTree.init($("#tree"), setting, data);//.expandAll(true);
		// 展开第一级节点
		var nodes = tree.getNodesByParam("level", 0);
		for(var i=0; i<nodes.length; i++) {
			tree.expandNode(nodes[i], true, false, false);
		}
		// 展开第二级节点
// 		nodes = tree.getNodesByParam("level", 1);
// 		for(var i=0; i<nodes.length; i++) {
// 			tree.expandNode(nodes[i], true, false, false);
// 		}
	}, null, null, "正在加载，请稍后...");
};loadTree();
// 工具栏按钮绑定
$('#btnExpand').click(function(){
	tree.expandAll(true);
	$(this).hide();
	$('#btnCollapse').show();
});
$('#btnCollapse').click(function(){
	tree.expandAll(false);
	$(this).hide();
	$('#btnExpand').show();
});
$('#btnRefresh').click(function(){
	loadTree();
});
//调用子页分页函数
function page(){
	win.page();
}

后台这样写

@RequiresPermissions("user")
	@RequestMapping(value = "treeData2")
	@ResponseBody
	public List<Map<String, Object>> treeData2(String excludeCode, String parentCode, Boolean isAll,
			String officeTypes, String companyCode, String isShowCode, String isShowFullName,
			Boolean isLoadUser, String postCode, String roleCode, String ctrlPermi) {
		List<Map<String, Object>> mapList = ListUtils.newArrayList();
		OfficeUser where = new OfficeUser();
		where.setStatus(Office.STATUS_NORMAL);
		List<OfficeUser> list = officeUserService.findList(where);
		for (int i = 0; i < list.size(); i++) {
			OfficeUser e = list.get(i);
			// 过滤非正常的数据
			if (!Office.STATUS_NORMAL.equals(e.getStatus())){
				continue;
			}
			// 过滤被排除的编码（包括所有子级）
			if (StringUtils.isNotBlank(excludeCode)){
				if (e.getId().equals(excludeCode)){
					continue;
				}
				if (e.getParentCodes().contains("," + excludeCode + ",")){
					continue;
				}
			}
			// 根据父节点过滤数据
			if (StringUtils.isNotBlank(parentCode)){
				if (!e.getOfficeCode().equals(parentCode)){
					continue;
				}
				if (!e.getParentCodes().contains("," + parentCode + ",")){
					continue;
				}
			}
			// 根据部门类型过滤数据
			if (StringUtils.isNotBlank(officeTypes)){
				if (!StringUtils.inString(e.getOfficeType(), officeTypes.split(","))){
					continue;
				}
			}
			Map<String, Object> map = MapUtils.newHashMap();
			map.put("id", e.getId());
			map.put("pId", e.getParentCode());
			String name = e.getOfficeName();
			if ("true".equals(isShowFullName) || "1".equals(isShowFullName)){
				name = e.getFullName();
			}
			map.put("name", StringUtils.getTreeNodeName(isShowCode, e.getViewCode(), name));
			map.put("title", e.getFullName());
			mapList.add(map);
		}
		return mapList;
	}
