1、概述
Flume是一个分布式、可靠、高可用的高效的日志数据收集、聚合以及传输系统,它简单和灵活的架构是基于数据流的。Flume具备强大的容错保证机制,有多种容错和恢复保证。Flume使用简单可扩展的数据模型允许开发在线分析处理应用。
Flume Event
:事件对象被定义数据流中一个单元,Event数据流的有效载荷(body)为采集到的一条记录,Event Head中可以添加一些可选的KV的描述信息。
Flume Agent
:Agent实例是一个JVM进程,它里面包含三个核心组件(Source、Channel、Sink),可以将数据从外部的系统传输到目的地进行有效存储。
Agent Source
:Source组件负责数据的收集接受,并且会将收集到的数据封装为==Event(Head[k=v] + Body[一条记录])==事件对象,发送给Channel。
Agent Channel
:Channel组件,类似于写缓存,本质上Event队列(符合队列先进先出FIFO)。
Agent Sink
:Sink组件,负责Channel中Event最终处理,将采集到的数据保存到指定的外部存储系统中。
2、环境搭建
[root@hadoop ~]# tar -zxf apache-flume-1.7.0-bin.tar.gz -C /usr
[root@hadoop ~]# cd /usr/apache-flume-1.7.0-bin/
启动指令:
bin/flume-ng agent -n $agent_name -c conf -f conf/flume-conf.properties.template
$agent_name:agent的名字。
conf/flume-conf.properties.template:flume文件的path。
3、使用案例
功能:flume读取netcat,数据打印在控制台上
# example.conf: A single-node Flume configuration
# Name the components on this agent
a1.sources = r1
a1.sinks = k1
a1.channels = c1
# Describe/configure the source
a1.sources.r1.type = netcat
a1.sources.r1.bind = localhost
a1.sources.r1.port = 44444
# Describe the sink
a1.sinks.k1.type = logger
# Use a channel which buffers events in memory
a1.channels.c1.type = memory
a1.channels.c1.capacity = 1000
a1.channels.c1.transactionCapacity = 100
# Bind the source and sink to the channel
a1.sources.r1.channels = c1
a1.sinks.k1.channel = c1
启动:
[root@hadoop apache-flume-1.7.0-bin]# bin/flume-ng agent --conf conf --conf-file conf/simple.conf --name a1 -Dflume.root.logger=INFO,console
4、常用的Source、Channel、Sink
4.1 Source
①netcat:Netcat常使用于测试环境,启动服务,通过TCP/IP协议客户端发送请求数据,进行采集。
a1.sources.r1.type = netcat
a1.sources.r1.bind = localhost
a1.sources.r1.port = 44444
②exec:Exec将Linux的操作指令的执行结果作为数据来源。
a1.sources.r1.type = exec
a1.sources.r1.command = tail -f /usr/apache-flume-1.7.0-bin/access.log
③Spooling Directory:将Linux文件系统中某一个目录中文本文件的内容作为数据来源。
注意: 数据目录中数据文件的内容一旦采集完成,数据文件会自动重命名为
.COMPLETED
,如果监控文件夹下新增文件,flume同样可以采集到,并且命名.COMPLETED
a1.sources.r1.type = spooldir
a1.sources.r1.spoolDir = /root/data
④kafka:将Kafka消息队列中的数据,作为Source的数据来源。
# 定义消息源类型
a1.sources.r1.type = org.apache.flume.source.kafka.KafkaSource
# 定义kafka所在zk的地址
a1.sources.r1.zookeeperConnect = 192.168.139.156:2181
# 配置消费的kafka topic
a1.sources.r1.topic = kafkasource
# 配置消费者组的id
a1.sources.r1.groupId = flume
# 消费超时时间,参照如下写法可以配置其他所有kafka的consumer选项。注意格式从kafka.xxx开始是consumer的配置属性
a1.sources.r1.kafka.consumer.timeout.ms = 100
4.2 Channel
①Memory:使用内存存储Event事件,使用Memory存放数据可能会造成数据丢失。
a1.channels.c1.type = memory
②JDBC:将Event存储到一个内嵌的数据库Derby中
a1.channels.c1.type = jdbc
③Spillable Memory Channel:内存溢写的Channel,当内存中存放的Event达到阈值会自动溢写到磁盘进行存储。
4.3 Sink
①Logger:将数据最终输出到控制台窗口 以INFO
级别日志的形式进行展示
a1.sinks.k1.type = logger
②HDFS:将数据保存到HDFS中进行持久化存储
a1.sinks.k1.type = hdfs
a1.sinks.k1.hdfs.path = hdfs://hadoop:9000/flume/events/%y-%m-%d/%H%M/%S
a1.sinks.k1.hdfs.filePrefix = events-
# 每10分钟产生一个数据目录 不够10分钟的数据 存放到相同的数据目录中
a1.sinks.k1.hdfs.round = true
a1.sinks.k1.hdfs.roundValue = 10
a1.sinks.k1.hdfs.roundUnit = minute
a1.sinks.k1.hdfs.fileType = DataStream
出现异常:Caused by: java.lang.NullPointerException: Expected timestamp in the Flume event headers, but it was null
解决方案:给Event事件对象添加TimeStamp时间戳信息,拦截器(interceptor)
a1.sources.r1.type = netcat
a1.sources.r1.bind = 192.168.12.129
a1.sources.r1.port = 44444
a1.sources.r1.interceptors = i1
a1.sources.r1.interceptors.i1.type = timestamp
HDFS Sink 默认采用SequenceFile
的文件格式存放采集到的数据,如果需要保存数据的真实内容,需要将fileType修改为DataStream
