【注】：使用的是LayUI作为前端框架，实现网页聊天功能，部分包可能出现版本更迭无法使用

前端页面

<%--
  Created by IntelliJ IDEA.
  User: ZhuDi
  Date: 2021/07/07
  Time: 15:10
  To change this template use File | Settings | File Templates.
--%>
<%@ page contentType="text/html;charset=UTF-8" language="java" %>
<%
    String path = request.getContextPath();
    String basePath = request.getScheme()+"://"+request.getServerName()+":"+request.getServerPort()+path+"/";

%>
<html>
<head>
    <title>博客</title>
    <link rel="stylesheet" href="../../res/layui/css/layui.css">
    <script src="../../res/layui/layui.js"></script>
    <script src="../../res/js/jquery.min.js"></script>

    <meta content="width=device-width, initial-scale=1, maximum-scale=1, user-scalable=no" name="viewport">
    <!-- Bootstrap v3.3.7 -->
    <link rel="stylesheet" href="https://cdn.bootcss.com/bootstrap/3.3.7/css/bootstrap.min.css">
    <!-- Font Awesome v4.7.0 -->
    <link rel="stylesheet" href="https://cdn.bootcss.com/font-awesome/4.7.0/css/font-awesome.min.css">
    <!-- Ionicons v2.0.0 -->
    <link rel="stylesheet" href="https://cdn.bootcss.com/ionicons/2.0.0/css/ionicons.min.css">
    <!-- Theme style v2.4.2 -->
    <link rel="stylesheet" href="https://cdn.bootcss.com/admin-lte/2.4.2/css/AdminLTE.min.css">
    <!-- DataTables v1.10.16 -->
    <link rel="stylesheet" href="https://cdn.bootcss.com/datatables/1.10.16/css/dataTables.bootstrap.min.css">
    <!-- AdminLTE Skins.v2.4.2 -->
    <link rel="stylesheet" href="https://cdn.bootcss.com/admin-lte/2.4.2/css/skins/skin-blue.css">
    <!-- jQuery UI CSS v1.12.1 -->
    <link rel="stylesheet" href="https://cdn.bootcss.com/jqueryui/1.12.1/jquery-ui.min.css">

    <link rel="stylesheet" href="../../res/hk/css/blogdefault.css"/>
    <!-- 百度地图 API -->
    <script type="text/javascript"
            src="http://api.map.baidu.com/getscript?v=2.0&ak=gh4PjU5UsCxml6vxPDmshSDaIWl63Vz8"></script>

    <!-- HTML5 Shim and Respond.js IE8 support of HTML5 elements and media queries -->
    <!-- WARNING: Respond.js doesn't work if you view the page via file:// -->
    <!--[if lt IE 9]>

    <script src="https://oss.maxcdn.com/html5shiv/3.7.3/html5shiv.min.js"></script>
    <script src="https://oss.maxcdn.com/respond/1.4.2/respond.min.js"></script>
    <![endif]-->

    <!-- Google Font -->
    <!--添加中科大CDN-->
    <link rel="stylesheet"
          href="https://fonts.lug.ustc.edu.cn/css?family=Source+Sans+Pro:300,400,600,700,300italic,400italic,600italic">
    <style type="text/css">
        /* Chart.js */
        @-webkit-keyframes chartjs-render-animation {
            from {
                opacity: 0.99
            }
            to {
                opacity: 1
            }
        }
        @keyframes chartjs-render-animation {
            from {
                opacity: 0.99
            }
            to {
                opacity: 1
            }
        }
        .chartjs-render-monitor {
            -webkit-animation: chartjs-render-animation 0.001s;
            animation: chartjs-render-animation 0.001s;
        }
        *{
            margin: 0;
            padding: 0;
            font-family: Arial, Helvetica,"Microsoft Yahei", sans-serif;
        }
        a{
            text-decoration: none;
            color: black;
        }
        input{
            outline: none;
        }
        li{
            list-style-type: none;
        }

        .hidden{
            display: none;
        }

        .noRead{
            color: green;
        }

        .Read{
            color: gray;
        }

        .container{
            border-radius: 4px;
            border: 0.5px solid #e0e0e0;
            background-color: #f5f5f5;
            display: flex;
            flex-flow: column;
            overflow: hidden;
        }
        .content{
            width: calc(100% - 5px);
            padding: 20px;
            overflow-y: scroll;
            flex: 1;
        }
        .content:hover::-webkit-scrollbar-thumb{
            background:rgba(0,0,0,0.1);
        }
        .bubble{
            max-width: 400px;
            padding: 10px;
            border-radius: 5px;
            position: relative;
            color: #000;
            word-wrap:break-word;
            word-break:normal;
        }
        .item-left .bubble{
            margin-left: 15px;
            background-color: #fff;
        }
        .item-left .bubble:before{
            content: "";
            position: absolute;
            width: 0;
            height: 0;
            border-left: 10px solid transparent;
            border-top: 10px solid transparent;
            border-right: 10px solid #fff;
            border-bottom: 10px solid transparent;
            left: -20px;
        }
        .item-right .bubble{
            margin-right: 15px;
            background-color: #9eea6a;
        }
        .item-right .bubble:before{
            content: "";
            position: absolute;
            width: 0;
            height: 0;
            border-left: 10px solid #9eea6a;
            border-top: 10px solid transparent;
            border-right: 10px solid transparent;
            border-bottom: 10px solid transparent;
            right: -20px;
        }
        .item{
            margin-top: 15px;
            display: flex;
        }
        .item.item-right{
            justify-content: flex-end;
        }
        .item.item-center{
            justify-content: center;
        }
        .item.item-center span{
            font-size: 12px;
            padding: 2px 4px;
            color: #fff;
            background-color: #dadada;
            border-radius: 3px;
            -moz-user-select:none; /*火狐*/
            -webkit-user-select:none; /*webkit浏览器*/
            -ms-user-select:none; /*IE10*/
            -khtml-user-select:none; /*早期浏览器*/
            user-select:none;
        }

        .avatar img{
            width: 42px;
            height: 42px;
            border-radius: 50%;
        }
        .input-area{
            border-top:0.5px solid #e0e0e0;
            height: 150px;
            display: flex;
            flex-flow: column;
            background-color: #fff;
        }
        textarea{
            flex: 1;
            padding: 5px;
            font-size: 14px;
            border: none;
            cursor: pointer;
            overflow-y: auto;
            overflow-x: hidden;
            outline:none;
            resize:none;
        }
        .button-area{
            display: flex;
            height: 40px;
            margin-right: 10px;
            line-height: 40px;
            padding: 5px;
            justify-content: flex-end;
        }
        .button-area button{
            width: 80px;
            border: none;
            outline: none;
            border-radius: 4px;
            float: right;
            cursor: pointer;
        }

        /* 设置滚动条的样式 */
        ::-webkit-scrollbar {
            width:10px;
        }
        /* 滚动槽 */
        ::-webkit-scrollbar-track {
            -webkit-box-shadow:inset006pxrgba(0,0,0,0.3);
            border-radius:8px;
        }
        /* 滚动条滑块 */
        ::-webkit-scrollbar-thumb {
            border-radius:10px;
            background:rgba(0,0,0,0);
            -webkit-box-shadow:inset006pxrgba(0,0,0,0.5);
        }

    </style>
</head>
<body onload="load()" style="background-color:whitesmoke;overflow-y: scroll">
    <jsp:include page="../common/nav.jsp"></jsp:include>

    <div style="margin: -25px auto;position:relative;height: 85%;width: 65%;background-color: white;border-radius: 10px;box-shadow: -1px 1px 10px #999999;">
<%--        左侧开始--%>
        <div id="leftpart" style="background-color: #2e2e2e;float: left;width: 30%;height: 100%;border-radius: 10px 0 0 10px">
            <div id="uchat" style="position: absolute;height: 72px;width: 65%;line-height: 72px;">
                <img src="${sessionScope.UserInfo.UImg}" style="height: 48px;width: 48px;border-radius: 48px;margin-left: 15px" alt="">
                <text style="margin-left: 18px;color: white">${sessionScope.UserInfo.UNickName}</text>
            </div>
            <hr style="margin-top: 80px;border-bottom: rgba(255,255,255,0.5)"/>
            <div id="chaters">
                <div id="chat" style="height: 80px;line-height: 80px" onclick="showChat()">
                    <img id="chaterimg" src="" style="height: 40px;width: 40px;border-radius: 40px;margin-left: 20px" alt="">
                    <div style="position:relative;">
                        <text id="chaternickname" style="margin-left: 5px;color: white;position: absolute;top: -70px;left: 80px;">${sessionScope.UserInfo.UName}</text>
                        <%--                存放聊天信息--%>
                        <text id="chatnew" class="Read" style="position: absolute;top: -50px;left: 85px;font-size: 12px">暂无最新消息</text>
                        <text id="lastchattime" style="color: gray;position: absolute;top: -60px;left: 230px;font-size: 12px"></text>
                    </div>
                    <hr style="color: rgba(0,0,0,0.3);"/>
                </div>
            </div>
        </div>
<%--        左侧结束--%>

<%--        右侧开始--%>
        <div id="rightmenu" style="position: relative;background-color: white;float: right;width: 70%;height: 100%;border-radius: 0 10px 10px 0">
            <div id="chatpage" class="container hidden" style="width: 100%;height: 100%;">
                <div class="content">
                    <chatcontent id="chatcontent"></chatcontent>
                </div>
                <div class="input-area">
                    <textarea name="sendContent" id="sendContent"></textarea>
                    <div class="button-area">
                        <button id="send-btn" onclick="sendMsg()">发 送</button>
                    </div>
                </div>
            </div>

        </div>
<%--        右侧结束--%>
    </div>

</body>

WebSocket业务处理

<script>
    layui.use('element', function(){
        var element = layui.element;
    });


//    websocket开始
    var ws;
    window.onload=function(){
        ws = new WebSocket("ws://localhost:8080/WebSocket/"+${sessionScope.UserInfo.UId});
        ws.onopen = function(){
            console.log("===============WebSocket IS OPEN NOW===============");
            var txt = "{'type':'上线了'}"
            sendMsg(txt);//获取未读消息
        };
    }

    document.onkeydown=function(event){
        var e = event || window.event || arguments.callee.caller.arguments[0];
        if (e && e.keyCode == 13) {
            sendMsg();
        }
    };

    function sendMsg(unread){
        var msg = $('#sendContent').val(),
            content;
        console.log(msg)
        /**
         * 发送消息
         */
        if(msg.length>0){
            content = "{'msg':'"+msg+"',"+"'type':'send',"+"'receiverOpenId':'8'}";
            ws.send(content);
            var html = $('#chatcontent').html()+"<div class='item item-right'><div class='bubble bubble-right'>"+msg+"</div><div class='avatar'><img src='${sessionScope.UserInfo.UImg}' /></div></div>";
            $('#chatcontent').html(html);
        }else if(unread.length>0){
            ws.send(unread);
        }else{
            alert("请输入文字");
        }
        /**
         * 接收返回的消息
         */
        ws.onmessage = function (res)
        {
            var ret = JSON.parse(res.data);
            if(ret.code == '20000'){
                $('#chaterimg').attr('src',ret.unReadMsg[0].sender.uImg);
                $('#chaternickname').text(ret.unReadMsg[0].sender.uNickName);
                $('#lastchattime').text(ret.unReadMsg[0].cIUpdatedTime.split(" ")[0]);
                $('#chatnew').text("您有未读消息");
                $('#chatnew').removeClass("Read");
                $('#chatnew').addClass("noRead");
                sessionStorage.setItem("UnRead",JSON.stringify(ret.unReadMsg));
            }
        };
    }
    window.onclose = function (){
        close();
    }
    function close(){
        /**
         * 关闭连接
         */
        ws.onclose = function(){
            console.log("===============WebSocket IS CLOSED===============");
        };
    }

    function showChat(){
        $('#chatpage').removeClass('hidden');
    //  "<div class='item item-center'><span>你已添加了凡繁烦，现在可以开始聊天了。</span></div>"
        var unread = JSON.parse(sessionStorage.getItem("UnRead"));
        console.log(unread)
        var html = "";
        for(var i = 0;i<unread.length;i++){
            html += "<div class='item item-center'><span>"+unread[i].cICreatedTime.split(".")[0]+"</span></div>"
                + "<div class='item item-left'><div class='avatar'><img src='"+unread[i].sender.uImg+"' /></div><div class='bubble bubble-left'>"+unread[i].cIContent+"</div></div>"
        }
        $('#chatcontent').html(html);
        $('#chatnew').text("暂无最新消息");
        $('#chatnew').removeClass("noRead");
        $('#chatnew').addClass("Read");
    }
</script>
