SpringBoot+Mybatis-Plus整合Sharding-JDBC实现分库分表

搭建项目

首先创建一个springboot单体工程

准备工作

先建一个数据库,创建三张表 把表名改成对应的

CREATE TABLE `user` (
  `cid` bigint NOT NULL AUTO_INCREMENT,
  `name` varchar(255) CHARACTER SET utf8mb3 COLLATE utf8mb3_general_ci DEFAULT NULL,
  `gender` varchar(255) CHARACTER SET utf8mb3 COLLATE utf8mb3_general_ci DEFAULT NULL,
  `data` varchar(255) CHARACTER SET utf8mb3 COLLATE utf8mb3_general_ci DEFAULT NULL,
  PRIMARY KEY (`cid`) USING BTREE
) ENGINE=InnoDB DEFAULT CHARSET=utf8mb3 ROW_FORMAT=DYNAMIC;

pom依赖

 <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.5.5</version>
        <relativePath/>
    </parent>

    <properties>
        <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
    </properties>
    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
            <version>2.2.5.RELEASE</version>
        </dependency>
        <dependency>
            <groupId>org.apache.shardingsphere</groupId>
            <artifactId>shardingsphere-jdbc-core-spring-boot-starter</artifactId>
            <version>5.1.1</version>
        </dependency>
        <!--  lombok  -->
        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <version>1.18.26</version>
        </dependency>
        <!-- jdbc -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-jdbc</artifactId>
            <version>2.2.5.RELEASE</version>
        </dependency>
        <!--  mysql  -->
        <dependency>
            <groupId>mysql</groupId>
            <artifactId>mysql-connector-java</artifactId>
            <version>8.0.32</version>
        </dependency>
        <!--  mybatis-plus  -->
        <dependency>
            <groupId>com.baomidou</groupId>
            <artifactId>mybatis-plus-boot-starter</artifactId>
            <version>3.5.1</version>
        </dependency>
    </dependencies>

yml依赖

server:
  port: 8089
spring:
  shardingsphere:
    mode:
      type: memory
    # 是否开启
    datasource:
      # 数据源（逻辑名字）
      names: m1
      # 配置数据源
      m1:
        type: com.zaxxer.hikari.HikariDataSource
        driver-class-name: com.mysql.cj.jdbc.Driver
        url: jdbc:mysql://localhost:3306/day0416?useSSL=false&autoReconnect=true&characterEncoding=UTF-8&serverTimezone=UTC&nullCatalogMeansCurrent=true #连接地址
        username: root
        password: 1234
    # 分片的配置
    rules:
      sharding:
        # 表的分片策略
        tables:
          # 逻辑表的名称
          user:
            # 数据节点配置，采用Groovy表达式
            actual-data-nodes: m1.user_$->{0..1}
            # 配置策略
            table-strategy:
              # 用于单分片键的标准分片场景
              standard:
                sharding-column: cid
                # 分片算法名字
                sharding-algorithm-name: user_inline
            key-generate-strategy: # 主键生成策略
              column: cid  # 主键列
              key-generator-name: snowflake  # 策略算法名称(推荐使用雪花算法)
        key-generators:
          snowflake:
            type: SNOWFLAKE
        sharding-algorithms:
          user_inline:
            type: inline
            props:
              algorithm-expression: user_$->{cid % 2}
    props:
      # 日志显示具体的SQL
      sql-show: true


logging:
  level:
    com.wang.test.demo: DEBUG

mybatis-plus:
  mapper-locations: classpath:mapper/*.xml
  type-aliases-package: com.jyq.domain
  configuration:
    #在映射实体或者属性时，将数据库中表名和字段名中的下划线去掉，按照驼峰命名法映射 address_book ---> addressBook
    map-underscore-to-camel-case: true

mybatis反向生成实体类以及service

实体类判断非空

@NotBlank(message = "姓名不能为空")
    private String name;

    /**
     *
     */
    @NotBlank(message = "性别不能为空")
    private String gender;

启动类

package com.jyq;

import org.mybatis.spring.annotation.MapperScan;
import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;

@MapperScan("com.jyq.mapper")
@SpringBootApplication
public class AppRun {
    public static void main(String[] args) {
        SpringApplication.run(AppRun.class,args);
    }

}

controller层

package com.jyq.controller;

import com.jyq.domain.User;
import com.jyq.service.UserService;
import lombok.RequiredArgsConstructor;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.validation.BindingResult;
import org.springframework.validation.annotation.Validated;
import org.springframework.web.bind.annotation.*;

import javax.validation.Valid;
import java.util.List;

@RestController
@RequestMapping("test")
@RequiredArgsConstructor
public class UserController {

    private final UserService userService;

    @PostMapping("/saveUser")
    public String saveUser(@RequestBody @Valid User user, BindingResult result) {
        if (result.hasErrors()) {
            return result.getAllErrors().get(0).getDefaultMessage();
        }
        userService.save(user);
        return "ok";
    }

    @GetMapping("selectUsers")
    public List<User> selectUsers() {
        return userService.list();
    }
}

效果演示

执行之后会把数据随机存入到一张表中
