Atmosphere Space Series - CoreSerial Triggering

SerialUSB

struct SerialUSB {
    std::string VID;
    std::string PID;
    std::string Port;
    std::string Path;
    SYSTEMTIME  TimeInput;

    SerialUSB() {
        this->VID  = "";
        this->PID  = "";
        this->Path = "";
        this->Port = "";
    }
    bool valid() {
        if (this->VID  == "") return false;
        if (this->PID  == "") return false;
        if (this->Port == "") return false;
        if (this->Path == "") return false;
        return true;
    }
    void out() {
        printf("VID=%s PID=%s Port=%s Path=%s \n", this->VID.c_str(), this->PID.c_str(), this->Port.c_str(), this->Path.c_str());
    }
};

SerialUSB getSerialUSB(std::wstring token)
{
    SerialUSB usb;

    std::wstring upperToken = token;
    std::transform(upperToken.begin(), upperToken.end(), upperToken.begin(), ::toupper);

    std::wstring path(upperToken);
    size_t vid_pos = path.find(L"VID_");
    size_t pid_pos = path.find(L"PID_");
    if (vid_pos != std::wstring::npos && pid_pos != std::wstring::npos) {
        std::wstring vid = path.substr(vid_pos + 4, 4);
        std::wstring pid = path.substr(pid_pos + 4, 4);

        usb.VID  = std::string( vid.begin(),  vid.end());
        usb.PID  = std::string( pid.begin(),  pid.end());
        usb.Path = std::string(path.begin(), path.end());

        usb.Port = GetComPortByPath(usb.VID, usb.PID);
    }

    return usb;
}

Exit Callback

void ExitEventCallbackProc(const char* portName, int eventType) {
    if (eventType == DBT_DEVICEARRIVAL) {
        printf("Plugin  : 0x%.4X %s \n", eventType, portName);
        // TODO
    }
    if (eventType == DBT_DEVICEREMOVECOMPLETE) {
        printf("Plugout : 0x%.4X %s \n", eventType, portName);
        // TODO
    }
}

std::wstring ⇒ std::string

if (TRUE) {
	WCHAR hardwareID[256] = { 0 };
	DWORD size = sizeof(hardwareID);
	if (!SetupDiGetDeviceRegistryProperty(hDevInfo, &devData, SPDRP_HARDWAREID, NULL, (PBYTE)hardwareID, size, &size)) continue;

	std::wstring wdid = std::wstring(hardwareID);
	std::string did = std::string(wdid.begin(), wdid.end());;
}

Scenario 1

BOOL EnumerateDevice() {
    // Initialize the GUID for the Serial COM ports
    GUID guid = GUID_DEVINTERFACE_COMPORT;

    HDEVINFO deviceInfoSet;
    SP_DEVINFO_DATA deviceInfoData;
    CHAR hardwareId[MAX_PATH], serialNumber[MAX_PATH];

    deviceInfoSet = SetupDiGetClassDevs(&guid, NULL, NULL, DIGCF_PRESENT | DIGCF_DEVICEINTERFACE);
    if (deviceInfoSet == INVALID_HANDLE_VALUE) {
        printf("SetupDiGetClassDevs failed!\n");
        return (FALSE);
    }

    deviceInfoData.cbSize = sizeof(SP_DEVINFO_DATA);
    for (DWORD index = 0; SetupDiEnumDeviceInfo(deviceInfoSet, index, &deviceInfoData); index++) {
        if (SetupDiGetDeviceRegistryPropertyA(deviceInfoSet, &deviceInfoData, SPDRP_HARDWAREID, NULL, (BYTE*)hardwareId, sizeof(hardwareId), NULL)) {
            if (SetupDiGetDeviceRegistryPropertyA(deviceInfoSet, &deviceInfoData, SPDRP_FRIENDLYNAME, NULL, (BYTE*)serialNumber, sizeof(serialNumber), NULL)) {
                std::string path = serialNumber;
                size_t bof_pos = path.find("(");
                size_t eof_pos = path.find(")");
                std::string port_name = path.substr(bof_pos+1, (eof_pos - bof_pos - 1));

                printf("EnumerateDevice > %s, %s, %s\n", hardwareId, port_name.c_str(), serialNumber);
            }
        }
    }
    SetupDiDestroyDeviceInfoList(deviceInfoSet);
    return (TRUE);
}

Scenario 2

std::vector<std::string> EnumerateComPort() {
    std::vector<std::string> content;
    HKEY hKey;
    if (RegOpenKeyEx(HKEY_LOCAL_MACHINE, L"HARDWARE\\DEVICEMAP\\SERIALCOMM", 0, KEY_READ, &hKey) == ERROR_SUCCESS)
    {
        wchar_t valueName[256], portName[256];
        DWORD index = 0, valueNameSize, portNameSize, type;

        for (int i = 0; TRUE; i++) {
            valueNameSize = sizeof(valueName);
            portNameSize = sizeof(portName);
            LONG ret = RegEnumValue(hKey, index++, valueName, &valueNameSize, NULL, &type, (LPBYTE)portName, &portNameSize);

            if (ret != ERROR_SUCCESS) break;

            std::wstring wdat = portName;
            content.push_back(std::string(wdat.begin(), wdat.end()));
        }
        RegCloseKey(hKey);
    }
    return content;
}

Scenario 3

std::vector<std::string> plugQueue(std::vector<std::string> left, std::vector<std::string> right)
{
	std::set<std::string> leftSet(left.begin(), left.end());
	std::set<std::string> rightSet(right.begin(), right.end());

	std::vector<std::string> plug;
	std::set_difference(rightSet.begin(), rightSet.end(), leftSet.begin(), leftSet.end(), std::inserter(plug, plug.begin()));

	return plug;
}
