java图片转ASCII码_抖音神器---Java实现图片(Image)转字符(ASCII)图片

最近抖音上挺火的一个小把戏，在记事本打开，一整篇的乱码字符，然后进过调整之后，出现一张由各种字符组成的黑白照片。先看一个效果图

微信小程序体验

直接体验请微信扫码

选择图片转字符图片

接下来我们就用Java来实现吧。

需要用到的工具类代码

非闪图图片转字符画到记事本

package com.xs.util.image;

import java.awt.image.BufferedImage;

import java.io.BufferedReader;

import java.io.File;

import java.io.FileInputStream;

import java.io.FileOutputStream;

import java.io.IOException;

import java.io.InputStreamReader;

import java.io.PrintWriter;

import javax.imageio.ImageIO;

import com.xs.util.image.other.ImageHelper;

/**

* Image2ASCII

* @author 小帅丶

* 2018年8月14日

*/

public class Image2ASCII{

static String ascii = "$@B%8&WM#*oahkbdpqwmZO0QLCJUYXzcvunxrjft/\\|()1{}[]?-_+~<>i!lI;:,\\\"^`'.";

static String base = "@#&$%*o!;.";//小帅丶使用这个字符

//main方法调用

public static void main(String[] args) throws Exception {

load("G:/phone.jpg", "F:/gif/woman.txt");//静态图片转字符保存为txt文件

}

/**

* 图片转字符

* @param imagePath 图片路径

* @param txtPath 文本存放路径

* @throws IOException

*/

public static void load(String imagePath, String txtPath)

throws IOException {

BufferedImage image = ImageHelper.resize(ImageIO.read(new File(imagePath)),150,150);

load(image, txtPath);

}

/**

* 图片转字符

* @param bi BufferedImage图片

* @param txtPath 文本存放路径

* @throws IOException

*/

public static void load(BufferedImage bi, String txtPath)

throws IOException {

try {

int width = bi.getWidth();

int height = bi.getHeight();

boolean flag = false;

String result = "";

for (int i = 0; i < height; i += 2) {

for (int j = 0; j < width; j++) {

int pixel = bi.getRGB(j, i); // 下面三行代码将一个数字转换为RGB数字

int red = (pixel & 0xff0000) >> 16;

int green = (pixel & 0xff00) >> 8;

int blue = (pixel & 0xff);

float gray = 0.299f * red + 0.578f * green + 0.114f * blue;

int index = Math.round(gray * (base.length() + 1) / 255);

result += index >= base.length() ? " " : String.valueOf(base.charAt(index));

}

result += "\r\n";

}

flag = writeTxtFile(result,txtPath);//保存字符到文本文件

System.out.println(flag?"图片转字符保存成功":"图片转字符保存失败");

} catch (Exception e) {

System.out.println("图片转字符异常"+e.getMessage());

}

}

/**

* 字符保存到txt文件中

* @param imageStr 字符

* @param txtPath txt文件

* @return boolean

* @throws Exception

*/

private static boolean writeTxtFile(String imageStr, String txtPath) throws Exception{

// 先读取原有文件内容，然后进行写入操作

boolean flag = false;

String filein = imageStr;

String temp = "";

FileInputStream fis = null;

InputStreamReader isr = null;

BufferedReader br = null;

FileOutputStream fos = null;

PrintWriter pw = null;

try {

// 文件路径

File file = new File(txtPath);

if (!file.exists()) {

file.createNewFile();

}

// 将文件读入输入流

fis = new FileInputStream(file);

isr = new InputStreamReader(fis);

br = new BufferedReader(isr);

StringBuffer buf = new StringBuffer();

// 保存该文件原有的内容

for (int j = 1; (temp = br.readLine()) != null; j++) {

buf = buf.append(temp);

}

buf.append(filein);

fos = new FileOutputStream(file);

pw = new PrintWriter(fos);

pw.write(buf.toString().toCharArray());

pw.flush();

flag = true;

} catch (IOException e) {

System.out.println("文件保存失败"+e.getMessage());

} finally {

if (pw != null) {

pw.close();

}

if (fos != null) {

fos.close();

}

if (br != null) {

br.close();

}

if (isr != null) {

isr.close();

}

if (fis != null) {

fis.close();

}

}

return flag;

}

}

非闪图图片转字符画返回BASE64

直接保存为图片也可以。

import java.awt.Color;

import java.awt.Font;

import java.awt.Graphics;

import java.awt.image.BufferedImage;

import java.io.ByteArrayOutputStream;

import java.io.IOException;

import javax.imageio.ImageIO;

import sun.misc.BASE64Encoder;

/**

* Image2ASCII

* @author 小帅丶

* 2018年8月14日

*/

public class Image2ASCII{

static String ascii = "$@B%8&WM#*oahkbdpqwmZO0QLCJUYXzcvunxrjft/\\|()1{}[]?-_+~<>i!lI;:,\\\"^`'.";

static String base = "@#&$%*o!;.";//小帅丶使用这个字符

/** 图片类型 */

private static final int IMAGE_TYPE = BufferedImage.TYPE_INT_RGB;

/**

* 图片转字符再保存为图片 只返回图片的base64

* @param bi 原图

* @param outPutPath

* @return String

*/

public static String txtToImageByBase64(BufferedImage bi) {

System.out.println("进来的时间"+System.currentTimeMillis());

int width = bi.getWidth();

int height = bi.getHeight();

int minx = bi.getMinX();

int miny = bi.getMinY();

int speed = 7;

BufferedImage bufferedImage = new BufferedImage(width,height,IMAGE_TYPE);

// 获取图像上下文

Graphics g = createGraphics(bufferedImage, width, height, speed);

// 图片中文本行高

final int Y_LINEHEIGHT = speed;

int lineNum = 1;

for (int i = miny; i < height; i += speed) {

for (int j = minx; j < width; j += speed) {

int pixel = bi.getRGB(j, i); // 下面三行代码将一个数字转换为RGB数字

int red = (pixel & 0xff0000) >> 16;

int green = (pixel & 0xff00) >> 8;

int blue = (pixel & 0xff);

float gray = 0.299f * red + 0.578f * green + 0.114f * blue;

int index = Math.round(gray * (base.length() + 1) / 255);

String c = index >= base.length() ? " " : String.valueOf(base.charAt(index));

g.drawString(String.valueOf(c), j, i);

}

lineNum++;

}

g.dispose();

ByteArrayOutputStream out = new ByteArrayOutputStream();

try {

ImageIO.write(bufferedImage,"jpg",out);

BASE64Encoder base64Encoder = new BASE64Encoder();

String base64 =base64Encoder.encode(out.toByteArray());

return base64;

} catch (IOException e) {

System.out.println("ImageIO.write异常" + e.getMessage());

}finally{

if(null!=out){

try {

out.close();

} catch (IOException e) {

System.out.println("out.close()异常" + e.getMessage());

}

}

}

return null;

}

/**

* 画板默认一些参数设置

* @param image 图片

* @param width 图片宽

* @param height 图片高

* @param size 字体大小

* @return

*/

private static Graphics createGraphics(BufferedImage image, int width,

int height, int size) {

Graphics g = image.createGraphics();

g.setColor(null); // 设置背景色

g.fillRect(0, 0, width, height);// 绘制背景

g.setColor(Color.BLACK); // 设置前景色

g.setFont(new Font("微软雅黑", Font.PLAIN, size)); // 设置字体

return g;

}

}

效果图

方法返回的为图片的base64数据。格式为jpg。加头信息即可在img标签的src中显示图片哦。


闪图图片转字符画返回图片

package com.xs.util.image;

import java.awt.Color;

import java.awt.Font;

import java.awt.Graphics;

import java.awt.image.BufferedImage;

import java.io.File;

import java.io.FileNotFoundException;

import java.io.FileOutputStream;

import java.io.IOException;

import java.io.OutputStream;

import javax.imageio.spi.ImageReaderSpi;

import javax.imageio.stream.FileImageInputStream;

import com.sun.image.codec.jpeg.ImageFormatException;

import com.sun.image.codec.jpeg.JPEGCodec;

import com.sun.image.codec.jpeg.JPEGImageEncoder;

import com.sun.imageio.plugins.gif.GIFImageReader;

import com.sun.imageio.plugins.gif.GIFImageReaderSpi;

import sun.misc.BASE64Encoder;

/**

* Image2ASCII

* @author 小帅丶

* 2018年8月14日

*/

public class Image2ASCII{

static String ascii = "$@B%8&WM#*oahkbdpqwmZO0QLCJUYXzcvunxrjft/\\|()1{}[]?-_+~<>i!lI;:,\\\"^`'.";

static String base = "@#&$%*o!;.";//小帅丶使用这个字符

/** 图片类型 */

private static final int IMAGE_TYPE = BufferedImage.TYPE_INT_RGB;

/**

* gif图片转gif字符图

* @param imagePath 原图路径

* @param outPath 输出图片的文件夹路径

* @throws IOException

*/

public static void loadGif(String imagePath, String outPath)

throws IOException {

File imageFile = new File(imagePath);

FileImageInputStream in = new FileImageInputStream(imageFile);

ImageReaderSpi readerSpi = new GIFImageReaderSpi();

GIFImageReader gifImageReader = new GIFImageReader(readerSpi);

gifImageReader.setInput(in);

int num = gifImageReader.getNumImages(true);

System.out.println(num);

BufferedImage[] bufferedImages = new BufferedImage[num];

for (int i = 0; i < num; i++) {

BufferedImage bi = gifImageReader.read(i);

bufferedImages[i] = txtToImage(bi, outPath + "out" + i + ".jpeg"); //每一帧都保存为图片

}

jpgToGif(bufferedImages,outPath + imagePath.substring(imagePath.length() - 6)+ "outGif.gif", 200);

}

/**

* 图片转字符再保存为图片

* @param bi 原图

* @param outPutPath

* @return BufferedImage

*/

public static BufferedImage txtToImage(BufferedImage bi, String outPutPath) {

File imageFile = new File(outPutPath);

if (!imageFile.exists()) {

try {

imageFile.createNewFile();

} catch (IOException e) {

e.printStackTrace();

}

}

int width = bi.getWidth();

int height = bi.getHeight();

int minx = bi.getMinX();

int miny = bi.getMinY();

System.out.println(width + " " + height);

int speed = 7;

BufferedImage bufferedImage = new BufferedImage(width,height,BufferedImage.TYPE_INT_RGB);

// 获取图像上下文

Graphics g = createGraphics(bufferedImage, width, height, speed);

// 图片中文本行高

final int Y_LINEHEIGHT = speed;

int lineNum = 1;

for (int i = miny; i < height; i += speed) {

for (int j = minx; j < width; j += speed) {

int pixel = bi.getRGB(j, i); // 下面三行代码将一个数字转换为RGB数字

int red = (pixel & 0xff0000) >> 16;

int green = (pixel & 0xff00) >> 8;

int blue = (pixel & 0xff);

float gray = 0.299f * red + 0.578f * green + 0.114f * blue;

int index = Math.round(gray * (base.length() + 1) / 255);

//char c = ascii.charAt((int) (gray / 255 * ascii.length()));

//char c = toChar((int) gray);

//char c = toChar(index);

String c = index >= base.length() ? " " : String.valueOf(base.charAt(index));

g.drawString(String.valueOf(c), j, i);

}

lineNum++;

}

g.dispose();

// 保存为jpg图片

FileOutputStream fos;

try {

fos = new FileOutputStream(imageFile);

JPEGImageEncoder encoder = JPEGCodec.createJPEGEncoder(fos);

OutputStream out = encoder.getOutputStream();

BASE64Encoder base64Encoder = new BASE64Encoder();

encoder.encode(bufferedImage);

fos.close();

} catch (FileNotFoundException e) {

e.printStackTrace();

} catch (ImageFormatException e) {

e.printStackTrace();

} catch (IOException e) {

e.printStackTrace();

}

return bufferedImage;

}

/**

* 画板默认一些参数设置

* @param image 图片

* @param width 图片宽

* @param height 图片高

* @param size 字体大小

* @return

*/

private static Graphics createGraphics(BufferedImage image, int width,

int height, int size) {

Graphics g = image.createGraphics();

g.setColor(null); // 设置背景色

g.fillRect(0, 0, width, height);// 绘制背景

g.setColor(Color.BLACK); // 设置前景色

g.setFont(new Font("微软雅黑", Font.PLAIN, size)); // 设置字体

return g;

}

/**

* n张jpg转gif方法

* @param bufferedImages

* @param newPic

* @param playTime

*/

private static void jpgToGif(BufferedImage[] bufferedImages, String newPic,

int playTime) {

try {

AnimatedGifEncoder e = new AnimatedGifEncoder();

e.setRepeat(0);

e.start(newPic);

for (int i = 0; i < bufferedImages.length; i++) {

e.setDelay(playTime); // 设置播放的延迟时间

e.addFrame(bufferedImages[i]); // 添加到帧中

}

e.finish();

} catch (Exception e) {

System.out.println("jpgToGif Failed:");

}

}

}

调用代码

public static void main(String[] args) throws Exception {

loadGif("C:/Users/Administrator/Desktop/页面录屏显示.gif", "F:/gif/");//动图转为动态的字符图片

}

返回的图片效果原图为小程序演示闪图
