harbor安装_在Ubuntu Server 20上安装harbor

Harbor的架构图（图片来自网洛）

1. 在安装ubuntu的时候，可以同时选择安装docker，否则需要单独安装docker。

sudo apt-get remove docker docker-engine docker.io containerd runc
sudo apt-get update
sudo apt-get install -y
    apt-transport-https
    ca-certificates
    curl
    gnupg-agent
    software-properties-common

curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo apt-key add -

sudo add-apt-repository
   "deb [arch=amd64] https://download.docker.com/linux/ubuntu
   $(lsb_release -cs)
   stable"

sudo apt-get install -y docker-ce docker-ce-cli containerd.io

sudo apt install -y python3-pip
sudo pip3 install docker-compose

2. 创建https 证书

sudo openssl genrsa -out ca.key 4096

sudo openssl req -x509 -new -nodes -sha512 -days 3650
 -subj "/C=CN/ST=Beijing/L=Beijing/O=example/OU=Personal/CN=registry.my-example.tech"
 -key ca.key
 -out ca.crt

sudo openssl genrsa -out registry.my-example.tech.key 4096

sudo openssl req -sha512 -new
    -subj "/C=CN/ST=Beijing/L=Beijing/O=example/OU=Personal/CN=registry.my-example.tech"
    -key registry.my-example.tech.key
    -out registry.my-example.tech.csr

sudo vi v3.ext

v3.ext 内容如下

authorityKeyIdentifier=keyid,issuer
basicConstraints=CA:FALSE
keyUsage = digitalSignature, nonRepudiation, keyEncipherment, dataEncipherment
extendedKeyUsage = serverAuth
subjectAltName = @alt_names

[alt_names]
DNS.1=registry.my-example.tech
DNS.2=my-example.tech
DNS.3=registry

创建https证书

sudo openssl x509 -req -sha512 -days 3650
    -extfile v3.ext
    -CA ca.crt -CAkey ca.key -CAcreateserial
    -in registry.my-example.tech.csr
    -out registry.my-example.tech.crt

sudo openssl x509 -inform PEM
    -in registry.my-example.tech.crt
    -out registry.my-example.tech.cert

3. 安装

curl -O https://github.com/goharbor/harbor/releases/download/v2.1.0/harbor-offline-installer-v2.1.0.tgz
tar xvf harbor-offline-installer-v2.1.0.tgz
cd ./harbor
sudo ./install.sh

• 基于harbor.yml.templete文件创建配置文件 harbor.yml,并放在harbor的目录下

log

$ sudo ./install.sh
[sudo] password for coder:

[Step 0]: checking if docker is installed ...

Note: docker version: 19.03.11

[Step 1]: checking docker-compose is installed ...

Note: docker-compose version: 1.25.5

[Step 2]: loading Harbor images ...
70379f503788: Loading layer   34.5MB/34.5MB
...
...
...
...
...
bde4e186d586: Loading layer  53.87MB/53.87MB
b63404705663: Loading layer   2.56kB/2.56kB
Loaded image: goharbor/harbor-core:v2.1.0


[Step 3]: preparing environment ...

[Step 4]: preparing harbor configs ...
prepare base dir is set to /home/coder/harbor
no config file: /home/coder/harbor/harbor.yml

5. 初始化harbor

默认用户/密码是: admin/Harbor12345

创建一个系统用户 coder，创建一个项目 test，并添加项目的成员coder

6. 给客户端的docker添加https证书

以mac为例

• 创建https证书

keytool -printcert -sslserver registry.my-example.tech -rfc > registry.my-example.tech.crt

• 导入证书

sudo security add-trusted-cert -d -r trustRoot -k /Library/Keychains/System.keychain ./registry.my-example.tech.crt.crt

重新启动docker

• 在ubuntu上需要这样

创建或者拷贝ca.crt到 /etc/docker/certs.d/registry.my-example.tech/ 目录下去

sudo mkdir -p /etc/docker/certs.d/registry.my-example.tech/
cd /etc/docker/certs.d/registry.my-example.tech/
sudo openssl s_client -showcerts -connect registry.my-example.tech:443 </dev/null 2>/dev/null|openssl x509 -outform PEM > ca.crt

证书导入到系统

sudo cp /etc/docker/certs.d/registry.my-example.tech/ca.crt /usr/local/share/ca-certificates/registry.my-example.tech.crt
sudo update-ca-certificates

然后做一下测试

$ docker login registry.my-example.tech
Username: coder
Password:
Login Succeeded

$ docker pull busybox
...
...

$ docker tag busybox:latest registry.my-example.tech/test/busybox:latest
...
...

$ docker push registry.my-example.tech/test/busybox:latest
The push refers to repository [registry.my-example.tech/test/busybox]
be8b8b42328a: Pushed
latest: digest: sha256:2ca5e69e244d2da7368f7088ea3ad0653c3ce7aaccd0b8823d11b0d5de956002 size: 527
