Vue实现图形化积木式编程(十)

路由

下一篇

历史回顾

Babylon.js部分

Blockly部分

前言

前段时间想要做一个web端的图形化积木式编程(类似少儿编程)的案例,网上冲浪了一圈又一圈,终于技术选型好,然后代码一顿敲,终于出来了一个雏形。

TIPS:该案例设计主要参考iRobot Coding,只用做学习用途,侵删。

https://code.irobot.com/#/

最终实现效果

最终实现效果

本文实现效果

  • Blockly自定义块
    Blockly自定义块

完整代码

  • Blockly自定义块
<template>
  <div id="blockly">
    <!-- 工作区 -->
    <div id="blocklyDiv" ref="blocklyDiv" style="height: 500px; width: 800px;"></div>
    <button style="position: fixed;left: 50px;top: 10px;" @click="block2code">生成代码</button>
    <!-- 代码显示区 -->
    <div style="background-color: lightgrey;width: 800px;text-align: left">
      <pre v-html="code?code:'请点击生成代码按钮'"></pre>
    </div>
    <button style="position: fixed;left: 150px;top: 10px;" @click="runCode">执行代码</button>
  </div>
</template>

<script>
import Blockly from 'blockly'
import BlocklyJS from 'blockly/javascript';
import './customBlock'
export default {
  name: "blocklyClass1",
  data() {
    return {
      code:'',
      options: {
        horizontalLayout: true,//工具箱水平
        toolboxPosition: "end",//工具箱在底部
        toolbox: {
          "kind": "flyoutToolbox",

          "contents": [
            {
              "kind": "block",
              "type": "while_program_start",
            },
            {
              "kind": "block",
              "type": "move",
            },
            {
              "kind": "block",
              "type": "turn",
            },
            {
              "kind": "block",
              "type": "arc"
            },
            {
              "kind": "block",
              "type": "draw"
            },
            {
              "kind": "block",
              "type": "pencilcolor"
            },
            {
              "kind": "block",
              "type": "controls_repeat_ext"
            },
            {
              "kind": "block",
              "type": "controls_whileUntil"
            },
            {
              "kind": "block",
              "type": "controls_for"
            },
            {
              "kind": "block",
              "type": "controls_if"
            },

            {
              "kind": "block",
              "type": "logic_compare"
            },
            {
              "kind": "block",
              "type": "logic_operation"
            },
            {
              "kind": "block",
              "type": "logic_negate"
            },
            {
              "kind": "block",
              "type": "logic_boolean"
            },
            {
              "kind": "sep",
              "gap": "32"
            },
            {
              "kind": "block",
              "blockxml": "<block type='math_number'><field name='NUM'>10</field></block>"
            },
            {
              "kind": "block",
              "type": "math_arithmetic"
            },
            {
              "kind": "block",
              "type": "math_single"
            },
            {
              "kind": "block",
              "type": "text"
            },
            {
              "kind": "block",
              "type": "text_length"
            },
            {
              "kind": "block",
              "type": "text_print"
            },
            {
              "kind": "block",
              "type": "variables_get"
            },
            {
              "kind": "block",
              "type": "variables_set"
            },
          ]
        }
      }
    }
  },
  mounted() {
    Blockly.inject(this.$refs.blocklyDiv, this.options);
  },
  methods:{
    /**
     * block代码块转为代码
     */
    block2code(){
      this.code = BlocklyJS.workspaceToCode(this.$refs.blocklyDiv.workspace)
    },

    /**
     * 执行生成代码
     */
    runCode(){
        if(!this.code){alert('请先点击生成代码');return}
        eval(this.code)
    },
  },
}
</script>

<style scoped>
#blockly {
  position: absolute;
  left: 50px;
  top: 50px;
  bottom: 0;
  width: calc(100vw - 50px);
  height: calc(100vh - 50px);
  display: flex;
  flex-direction: column;
}
</style>
  • 封装的自定义块方法 - customBlock.js
import * as Blockly from 'blockly/core'

import * as hans from 'blockly/msg/zh-hans'

Blockly.setLocale(hans);//汉化

/**
 * 自定义组件注册
 */
Blockly.defineBlocksWithJsonArray(
    [
        //事件
        {
            "type": "while_program_start",
            "message0": "当程序运行 %1 %2",
            "args0": [
                {
                    "type": "input_dummy"
                },
                {
                    "type": "input_statement",
                    "name": "while_content"
                }
            ],
            "previousStatement": null,
            "nextStatement": null,
            "colour": "#609FD6",
            "strokeColour": "#4088C8",
            "tooltip": "123",
            "helpUrl": "1"
        },
        //指令
        {
            "type": "move",
            "message0": "移动 %1 CM",
            "args0": [
                {
                    "type": "field_input",
                    "name": "move_distance",
                    "text": "50"
                }
            ],
            "previousStatement": null,
            "nextStatement": null,
            "colour": "#F7D233",
            "strokeColour": "#CCAD2B",
            "tooltip": "",
            "helpUrl": ""
        },
        {
            "type": "turn",
            "message0": "向 %1 %2",
            "args0": [
                {
                    "type": "field_dropdown",
                    "name": "dirction",
                    "options": [
                        [
                            "左转",
                            "0"
                        ],
                        [
                            "右转",
                            "1"
                        ]
                    ]
                },
                {
                    "type": "field_angle",
                    "name": "degree",
                    "angle": 90
                }
            ],
            "previousStatement": null,
            "nextStatement": null,
            "colour": "#F7D233",
            "strokeColour": "#CCAD2B",
            "tooltip": "",
            "helpUrl": ""
        },
        {
            "type": "arc",
            "message0": "弧形 %1 %2 ,半径 %3 CM",
            "args0": [
                {
                    "type": "field_dropdown",
                    "name": "dirction",
                    "options": [
                        [
                            "向左",
                            "0"
                        ],
                        [
                            "向右",
                            "1"
                        ]
                    ]
                },
                {
                    "type": "field_angle",
                    "name": "degree",
                    "angle": 90
                },
                {
                    "type": "field_number",
                    "name": "radius",
                    "value": 50,
                    "min": 1,
                    "max": 100
                }
            ],
            "previousStatement": null,
            "nextStatement": null,
            "colour": "#F7D233",
            "strokeColour": "#CCAD2B",
            "tooltip": "",
            "helpUrl": ""
        },
        {
            "type": "draw",
            "message0": "设置 %1",
            "args0": [
                {
                    "type": "field_dropdown",
                    "name": "pencilState",
                    "options": [
                        [
                            {
                                "width": 50,
                                "height": 50,
                                "alt": "pencil down"
                            },
                            "1"
                        ],
                        [
                            {
                                "width": 50,
                                "height": 50,
                                "alt": "pencil up"
                            },
                            "0"
                        ]
                    ]
                }
            ],
            "previousStatement": null,
            "nextStatement": null,
            "colour": "#81C679",
            "tooltip": "",
            "helpUrl": ""
        },
        {
            "type": "pencilcolor",
            "message0": "设置笔颜色: 红 %1 绿 %2 蓝 %3",
            "args0": [
                {
                    "type": "field_number",
                    "name": "red",
                    "value": 100,
                    "min": 0,
                    "max": 255
                },
                {
                    "type": "field_number",
                    "name": "green",
                    "value": 100,
                    "min": 0,
                    "max": 255
                },
                {
                    "type": "field_number",
                    "name": "blue",
                    "value": 100,
                    "min": 0,
                    "max": 255
                }
            ],
            "previousStatement": null,
            "nextStatement": null,
            "colour": "#81C679",
            "tooltip": "",
            "helpUrl": ""
        }
    ]
);

/**
 * 自定义组件生成代码
 * @param block
 * @returns {string}
 */
Blockly.JavaScript['while_program_start'] = function (block) {
    block
    var while_content = Blockly.JavaScript.statementToCode(block, 'while_content');
    var code =
        'robot.init();\n'
        + while_content +
        'robot.stop();\n';
    return code;
};

Blockly.JavaScript['move'] = function (block) {
    var text_move_distance = block.getFieldValue('move_distance');
    var code = 'robot.move(' + text_move_distance + ');\n';
    return code;
};

Blockly.JavaScript['turn'] = function (block) {
    var dropdown_dirction = block.getFieldValue('dirction');
    var angle_degree = block.getFieldValue('degree');
    var code = 'robot.turn(' + dropdown_dirction + ', ' + angle_degree + ');\n';
    return code;
};

Blockly.JavaScript['arc'] = function (block) {
    var dropdown_dirction = block.getFieldValue('dirction');
    var angle_degree = block.getFieldValue('degree');
    var radius = block.getFieldValue('radius');
    var code = 'robot.arc(' + dropdown_dirction + ', ' + angle_degree + ',' + radius + ');\n';
    return code;
};

Blockly.JavaScript['draw'] = function (block) {
    var dropdown_pencilstate = block.getFieldValue('pencilState');
    var code = 'robot.drawable(' + dropdown_pencilstate + ');\n';
    return code;
};

Blockly.JavaScript['pencilcolor'] = function (block) {
    var number_red = block.getFieldValue('red') / 255.0;
    var number_green = block.getFieldValue('green') / 255.0;
    var number_blue = block.getFieldValue('blue') / 255.0;
    var code = 'await robot.pencilcolor(' + number_red + ',' + number_green + ',' + number_blue + ');\n';
    return code;
};

代码分解

自定义块主要分3部分:
1、定义块行为
2、注册块
3、定义块生成代码
4、引入块

0.代码块前置知识

0.1 汉化

import * as hans from 'blockly/msg/zh-hans'
Blockly.setLocale(hans);//汉化

0.2 预置块

  • Blockly原本已经预置了很多代码块了

  • 逻辑块(logic_compare、logic_operation、logic_negate、logic_boolean)
    在这里插入图片描述

  • 循环控制块(controls_repeat_ext、controls_whileUntil、controls_if)
    在这里插入图片描述

  • 数学模块(math_number、math_arithmetic、math_single)
    在这里插入图片描述

  • 文本模块(text、text_length、text_print)
    在这里插入图片描述

  • 变量块(variables_get、variables_set)
    在这里插入图片描述

0.3 不同样式块含义

0.3.1 连接方式

  • 上下连接
    在这里插入图片描述

以javascript为例,在一个事件循环中,代码块会顺序执行(不包含异步代码块),代码块之间就是上下连接方式

let loop = 10//上连接为空,下连接为print
print('hello world')//上连接为赋值语句,下连接为for循环代码块
for(let i = 0; i < 10; i++){...}//上连接为print,下连接为while循环代码块
while(loop){...}//上连接为for循环代码块,下连接为空
  • 左连接
    在这里插入图片描述

左连接可以理解为其为输出
任何值的输出都使用左连接方式,如(数字模块输出数字、文本模块输出文本、逻辑模块输出真假)

0.3.2 输入方式

输入方式,即函数传入的参数
输入的连接方式不一样,日常使用中感觉不出区别
输入可以现在输入的类型,如if、when模块的外接类型输入限制了类型只能为逻辑模块

  • 内联
    在这里插入图片描述

  • 外接
    在这里插入图片描述

0.3.2 输入类型

输入的模块的类型分为值输入和块输入

  • 值输入(数字、文本、逻辑)

  • 块输入(代码块)

0.4 代码块构建代码块

  • Blockly预置的很多代码块基本符合日常编程的各种使用场景,而其更出色的地方在于其能自定义代码块,而且是通过代码块来生成代码块

官方的自定义代码块链接:自定义代码块构建工具
工具的食用方法可参考大佬文章:blockly构建自定义块及其工具

  • 而在本文中的案例中,控制小车的移动等操作,小车的动作是依次执行的,其实用得最多是上下连接的代码块,该代码块中包含内联的一个或多个值输入:
    在这里插入图片描述

  • 对应的构造如下:
    在这里插入图片描述

  • 还有就是小车启动的函数,用的是上下连接的代码块,该代码块中包含外接的块输入:
    在这里插入图片描述

  • 对应的构造如下,其中空输入只是为了在其中填入文本让其能单独一行显示(好看一点):
    在这里插入图片描述

1. 自定义块

  • 熟悉Block Definition的生成规则当然是最好的了,但是官方提供的代码块构建工具,进行了可视化预览、定义配置、块的生成代码,极大方便了我们的开发。
    在这里插入图片描述
  • 所以自定义块的流程变得很简单啦
    1、通过toolbox提供的各种工具块,拖动到编辑区,根据自己的需求区构建自定义块。
    2、通过预览区实时查看自定义块是否达到预期效果
    3、达到预期效果后,将定义配置区中的JSON配置信息在项目中使用Blockly.defineBlocksWithJsonArray的方法注册自定义块
    4、如果是需要生成JavaScript代码,生成代码区选择JavaScript,然后将代码复制到项目中
    5、最后就是将代码块引入到toolbox工具箱中

1.1 定义块行为

  • 定义块行为就是上面所说的编辑区编辑块规则,或者熟悉Block Definition的同学通过块定义的规则编写JSON格式文本,从而形成块的形状(其形状基本是决定了请行为和功能)

1.2 注册块

  • 将定义配置区中的JSON配置信息在项目中使用Blockly.defineBlocksWithJsonArray的方法注册自定义块
/**
 * 自定义组件注册
 */

Blockly.defineBlocksWithJsonArray(
    [
      //当程序运行代码块
      {
        "type": "while_program_start",
        "message0": "当程序运行 %1 %2",
        "args0": [
          {
            "type": "input_dummy"
          },
          {
            "type": "input_statement",
            "name": "while_content"
          }
        ],
        "previousStatement": null,
        "nextStatement": null,
        "colour": "#609FD6",
        "strokeColour": "#4088C8",
        "tooltip": "123",
        "helpUrl": "1"
      },
      //弧度移动代码块
      {
        "type": "arc",
        "message0": "弧形 %1 %2 ,半径 %3 CM",
        "args0": [
          {
            "type": "field_dropdown",
            "name": "dirction",
            "options": [
              [
                "向左",
                "0"
              ],
              [
                "向右",
                "1"
              ]
            ]
          },
          {
            "type": "field_angle",
            "name": "degree",
            "angle": 90
          },
          {
            "type": "field_number",
            "name": "radius",
            "value": 50,
            "min": 1,
            "max": 100
          }
        ],
        "previousStatement": null,
        "nextStatement": null,
        "colour": "#F7D233",
        "strokeColour": "#CCAD2B",
        "tooltip": "",
        "helpUrl": ""
      }
    ]);

1.2 定义块生成代码

  • 生成代码区选择JavaScript,然后将代码复制到项目中,其中代码已经写好了变量的获取方式,返回值就是生成的代码,我们需要编写的就是返回值的内容。
  • 而对于控制小车对象而言,笔者这里统一使用robot对象,然后调用对象中的各种方法,如下面代码中拼接出来的代码为robot.arc('方向','弧的角度','弧的半径')
/**
 * 弧度运动自定义块
 * @param block
 * @returns {string}
 */
Blockly.JavaScript['arc'] = function(block) {
  var dropdown_dirction = block.getFieldValue('dirction');
  var angle_degree = block.getFieldValue('degree');
  var radius = block.getFieldValue('radius');
  // TODO: Assemble JavaScript into code variable.
  var code = 'robot.arc(' + dropdown_dirction + ', ' + angle_degree + ',' + radius + ');\n';
  return code;
};
  • 如下代码是控制程序生命周期的,拼接出来的代码为
robot.init();
...(控制小车运动的代码块)
robot.stop();
/**
 *程序启动自定义块
 * @param block
 * @returns {string}
 */
Blockly.JavaScript['while_program_start'] = function (block) {
  block
  var while_content = Blockly.JavaScript.statementToCode(block, 'while_content');
  var code = 'robot.init();\n' +
      while_content +
      'robot.stop();\n';

  return code;
};

1.3 引入块

  • 将自定义块引入到toolbox工具箱中
data() {
      options: {
        toolbox: {
          "kind": "flyoutToolbox",

          "contents": [
            {
              "kind": "block",
              "type": "while_program_start",
            },
            {
              "kind": "block",
              "type": "arc"
            },
            ...
          ]
        }
      }
  },
mounted() {
	//注入选项
    Blockly.inject(this.$refs.blocklyDiv, this.options);
  },

后续计划

Blockly

  • blockly第三方组件使用
  • 小车控制方法的封装
  • 接入js-interpreter,步骤运行block块
  • …(想到啥写啥)

开源项目GitHub链接

https://github.com/Wenbile/Child-Programming-Web

资源下载链接
