LRU是Least Recently Used的缩写,即最近最少使用,是一种常用的页面置换算法,选择最近最久未使用的页面予以淘汰。该算法赋予每个页面一个访问字段,用来记录一个页面自上次被访问以来所经历的时间 t,当须淘汰一个页面时,选择现有页面中其 t 值最大的,即最近最少使用的页面予以淘汰。
用HashMap 存储 key,这样可以做到 save 和 get key的时间都是 O(1),而 HashMap 的 Value 指向双向链表实现的 LRU 的 Node 节点,
1.双向链表+HashMap
import java.util.*;
/**
* Created on 2020/11/12 0012.
*
* @author lsz
*/
public class LRUCache<K, V> implements Iterable<K> {
private Node head;
private Node tail;
private HashMap<K, Node> map;
private int maxSize;
private class Node {
Node pre;
Node next;
K k;
V v;
public Node(K k, V v) {
this.k = k;
this.v = v;
}
}
public LRUCache(int maxSize) {
this.maxSize = maxSize;
this.map = new HashMap<>(maxSize * 4 / 3);
head = new Node(null, null);
tail = new Node(null, null);
head.next = tail;
tail.pre = head;
}
public V get(K key) {
if (!map.containsKey(key)) {
return null;
}
Node node = map.get(key);
unlink(node);
appendHead(node);
return node.v;
}
public void put(K key, V value) {
if (map.containsKey(key)) {
Node node = map.get(key);
unlink(node);
}
Node node = new Node(key, value);
map.put(key, node);
appendHead(node);
if (map.size() > maxSize) {
Node toRemove = removeTail();
map.remove(toRemove.k);
}
}
private void unlink(Node node) {
Node pre = node.pre;
Node next = node.next;
pre.next = next;
next.pre = pre;
//
// node.pre = null;
// node.next = null;
}
private void appendHead(Node node) {
Node next = head.next;
node.next = next;
next.pre = node;
node.pre = head;
head.next = node;
}
private Node removeTail() {
Node node = tail.pre;
Node pre = node.pre;
tail.pre = pre;
pre.next = tail;
node.pre = null;
node.next = null;
return node;
}
@Override
public Iterator<K> iterator() {
return new Iterator<K>() {
private Node cur = head.next;
@Override
public boolean hasNext() {
return cur != tail;
}
@Override
public K next() {
Node node = cur;
cur = cur.next;
return node.k;
}
};
}
public static void main(String[] args) {
LRUCache cache = new LRUCache(3);
cache.put(1, 11);
cache.put(2, 22);
cache.put(3, 33);
// cache.put(3, new ArrayList<Integer>(Arrays.asList(1,2,3)));
System.out.println(cache.get(2));
cache.put(4, "lisz");
System.out.println("分割线----");
Iterator iterator = cache.iterator();
while (iterator.hasNext()) {
System.out.println(cache.get(iterator.next()));
}
}
}
2.LinkedHashMap
public class LRUCache1<K, V> extends LinkedHashMap<K, V> {
private static final int MAX_ENTRIES = 3;
protected boolean removeEldestEntry(Map.Entry eldest) {
return size() > MAX_ENTRIES;
}
public LRUCache1() {
super(LoginOptions.MAX, 0.75f, true);
}
public static void main(String[] args) {
LRUCache1<Integer, String> cache = new LRUCache1<>();
cache.put(1, "a");
cache.put(2, "b");
cache.put(3, "c");
cache.get(1);
cache.put(4, "d");
System.out.println(cache.keySet());
}
