1、导入
import ReactEcharts from 'echarts-for-react';
import * as echarts from 'echarts'; //渐变色
2、使用
<ReactEcharts option={option} style={{ width: '100%', height: '50%' }} />
3、option常用定义
const option = {
// 图表周围空白边距(内边距)
grid: {
top: 40,
bottom: 30,
right: 0,
left: 57,
},
// 鼠标移动至图表的提示框
tooltip: {
// 触发方式
trigger: 'axis'
},
// x轴
xAxis: {
type: 'category',
data: params.dataX,
// 轴线
axisLine: {
lineStyle: {
color: 'rgba(63, 163, 191, 0.49)',
}
},
// 文本标签
axisLabel: {
color: 'rgba(194, 221, 248, 1)',
fontSize: 16,
},
// 刻度线
axisTick: {
show: false,
}
},
// y轴
yAxis: {
type: 'value',
// 名称
name: params.name,
nameTextStyle: {
color: 'rgba(194, 221, 248, 1)',
fontSize: 16,
},
// 轴线
axisLine: {
show: false,
},
// 文本
axisLabel: {
color: 'rgba(194, 221, 248, 1)',
fontSize: 16,
},
// 背景分割线
splitLine: {
lineStyle: {
color: 'rgba(63, 163, 191, 0.49)',
type: 'dashed',
}
}
},
series: [{
data: params.dataY,
type: 'line',
// 折线
lineStyle: {
color: params.color,
lineWidth: 4,
},
// 拐点
itemStyle: {
borderColor: params.color,
borderWidth: 2,
},
// 填充面积(渐变色)
areaStyle: {
color: new echarts.graphic.LinearGradient(
0, 0, 0, 1,
[
{ offset: 0, color: params.color },
{ offset: 1, color: 'rgba(255, 255, 255, 0)' }
]
)
}
}]
};
