#为什么会最终会选择树图

在长达三天尝试，根据图的要求，第一次选择了echarts的关系图，但是在做的过程中就出现了问题，首先我选择的是坐标生成位置，由于后端返的数据不是固定的而且两条关系中必然有相同的名称，这个关系图就很符合当时我要做的效果，但是source，target的指向不可以重复，当关系复杂时而且再保证看的不乱的情况下，这种是不符合我的要求的，加上它的坐标生成的位置，对于我的数据来说不太好动态生成。

#为什么是最终选择树图，那你第二次选的什么

当这个不好生成之后，就开始另谋他路，Relation Graph在这个上面我看到了很多不一样的demo，虽然demo多多，但是找到符合的还是很少，其中一个尝试之后，还是跟上一个的选择的问题有些相似之处的，这是它的在线配置工具

#选择echarts的树图之后，具体步骤能说么

这个当然可以,下面的代码相信大家都会放对位置的，就不再过多叙述了

<div class="chartbox" id="chartbox">
   <div :style="{height:chartHeight+ 'px'}" id="ass"> </div>
 </div>


chartHeight:1200,


.chartbox{
  overflow-y: auto;
  overflow-x: hidden;
  height: 900px;
}

 getData(){  // 获取后端的数据并处理
      this.$request  // 这里是在全局中配置了
        .post('地址',{})
        .then((res)=>{
          this.datas = res.data
          this.tree_data = {
            name: "噜啦嘞",
            children: [],
            value:'0',
            //  symbol 是需要在每一个包含children的中去单独配置的，只在series中配置不生效
            //  symbol的图片的生成的方法写最后
          };
         var temp ={}
         for (var key in this.datas) {
          this.datas[key].children = [];
          this.datas[key].children.push({
            name: this.datas[key].dName,
            children: [],
            value:'0',
          });
          this.datas[key].children.forEach((i, ik) => {
            this.datas[key].moList.forEach((direItem) => {
                  this.datas[key].children[ik].children.push({
                    name: direItem.aName,
                    children:[],
                    value:'0',

              })

              direItem.oiList.forEach((oils)=>{
              temp  = { name: oils.otName, children: [],value:'1',
                oils.oList.forEach((oilDep)=>{
                  temp.children.push({
                    name:oilDep.otwoName,
                    children:[],
                    value:'1',


                  })
                  oilDep.reList.forEach((ref)=>{
                    temp.children[ik].children.push({
                      name:ref.reName,
                      symbolSize: 1, // 无children的设置为1，不显示节点
                    })
                  })
                  oilDep.oiList.forEach((gaso)=>{
                    temp.children[ik].children.push({
                      name:gaso.gName,
                      symbolSize: 1,
                      label: {
                          position: "right",
                          verticalAlign: "middle",
                          align: "left",
                          color: "#BDBDBD",
                          fontSize: 24,
                      },
                    })
                  })
                })
                oils.oiOList.forEach((gas)=>{
                  temp.children.push({
                    name:gas.gName,
                    symbolSize: 1,

                    label: {
                       position: "right",
                       verticalAlign: "middle",
                       align: "left",
                       color: "#BDBDBD",
                       fontSize: 24,
                    },
                  })
                })
              })
              this.datas[key].children[0].children.forEach((te)=>{
                te.children.push(temp)
              })
            });
            this.tree_data.children.push(this.datas[key].children[ik]);
          });


        }
        this.tree_data.children.forEach((item)=>{
            item.children.forEach((itc)=>{
              if(itc.children.length>1){
                itc.children = itc.children.splice(0,1)
                console.log(itc);
              }
            })
        })
          var series = [];
          var tooltip = [];
          tooltip.push({
            trigger: "item",
            triggerOn: "mousemove",
          });
          series.push({
            type: "tree",
            id: 0,
            name: "tree1",
            data: [this.tree_data],
            top: "8%",
            left: "5%",
            bottom: "22%",
            right: "20%",
            symbolSize: 20,
            symbol: "emptyCircle", //设置图形的形状
            edgeShape: "polyline",//折线，curve 曲线
            edgeForkPosition: "63%",
            initialTreeDepth: 3,
            height:'1000px',
            with:'100%',
            lineStyle: {
              width: 3,
            },
            itemStyle: {
              borderColor: "#60e4fb", //图形的边框颜色
              color: "#60e4fb", //图形的填充颜色
            },
            label: {
              position: "left",
              verticalAlign: "middle",
              align: "right",
              borderColor: "#F56C6C",
              color: "#fff",
              fontSize: 24,
              fontWeight: "bold",
            },
            leaves: {
              label: {
                position: "right",
                verticalAlign: "middle",
                align: "left",
                color: "#fff",
                fontSize: 24,

              },
            },
            emphasis: {
              focus: "descendant",
            },
            expandAndCollapse: true,
            animationDuration: 550,
            animationDurationUpdate: 750,
          });
          this.sendingChart(tooltip, series);//请求到数据并处理之后调用

        })
    },
   sendingChart(tooltip, series) {
      this.$echarts.init(document.getElementById("ass")).dispose();
      var myChart = this.$echarts.init(document.getElementById("ass"));
      var option = {
        tooltip: tooltip,
        series: series,
      };
        option && myChart.setOption(option);
        myChart.on('click',(param)=>{
          if(param.data.value=="0"){
            param.data.value="1"
            myChart.resize();
          }else{
            param.data.value="0"
            myChart.resize();
          }
        });
        // 这里是滚动条的前提，让子节点数据过多时不挤一块，
        const eleArr = Array.from(new Set(myChart._chartsViews[0]._data._graphicEls))
        const itemHeight = 50
        const currentHeight = itemHeight * (eleArr.length-1) || itemHeight
        const newHeight = Math.max(currentHeight,itemHeight)
        this.chartHeight = newHeight
        myChart.resize({
          height:newHeight
        })
        document.getElementById("chartbox").scrollTop = (newHeight/2)-900
    },

#效果图，滚动条让我遮住了…

滚动条的样式我是处理过的

在这里插入图片描述

#有什么要注意的

首先是symbol的图片生成，在官网找到tree下的symbol，点击试一试，上传本地图片，看下图所示，复制即可；
其次就是点击节点图片变化，前提你得准备两张图myChart.resize();得加这个属性，不然不会生效，还有就是不能在在children中push自定义的值，本人测试过，一直报错，所以用value来代替，写成固定值，点击之后变换值，再替换图片；
最后就是代码中不要直接复制粘贴，找到核心的且有用的，再复制。
在这里插入图片描述

#end…

本期到此结束，这里是能学一点是一点，如有疑问欢迎留言，如有致电，请拨打电话，如没关注，请不用关注…
